Information Sheet

KEF Audio (UK), Eccleston Road,Tovil, Maidstone, Kent, ME15 6QP U.K. Telephone: + 44 (0) 1622 672261. Fax: + 44 (0) 1622 750653 www.kef.com

KEF America, 10 Timber Lane, Marlboro, New Jersey, 07746 USA. Telephone: + 1 732 683 2356. Fax: + 1 732 683 2358 www.kefamerica.com

GP Acoustics GmbH, Heinrichstraße 51, D-44536 Lünen, Deutschland. Telephone: +49 (0) 231 9860-320. Fax: +49 (0) 231 9860-330. www.kefaudio.de

Intended to be as unobtrusive as possible,

the Ci Series Ci130.2QS and Ci130.2QR

arehigh-fidelity flush-mount loudspeakers

utilising KEF’s Uni-Q®driver array

technology. This gives the round and

squarebezel speakers the inherent

smooth dispersion characteristics to fill

any normal room with an expansive,

generous and rich sound stage.

Equally at home - the square speaker in the

wall or round speaker in the ceiling - the

driver arrayis mounted into a moulded

ABS baffle and can be easily and quickly

installed with the moisture-resistant

bracket and fixings allowing placement in

the harshest environments, such as

bathrooms or even outside (under eaves).

Features and Benefits:

The Ci130.2QS and Ci130.2QR combine

50W power handling and 86dB sensitivity.

A130mm (51⁄4”) bass/mid driver giving

good bass extension along with a 19mm

(3⁄4”) aluminium dome tweeter provide

excellent power handling and smooth

response.

The bezel and grille can be painted or

covered by fabric to match the interior décor.

Installation

1

3

2

4

56

500Hz 1kHz

2kHz 4kHz

8kHz 16kHz

Polar graphs

Directivity Index / Beamwidth

Frequency / Power response, Input impedance

Specifications

Architectural specifications:

The Ci Series Ci130.2QS and Ci130.2QR

comprise a Uni-Q®coincident mounted

19mm aluminium dome tweeter with a

130mm white polypropylene bass/mid unit.

Performance should meet or exceed the

following criteria: frequency response 1

metreon-axis with swept sinewaveshall

be 50Hz to 40kHz QS, 100Hz to 40kHz

QR, sensitivity shall be at least 86dB for

2.83V@1m. The impedance and maximum

power shall be 50W at 8 ohms. The Ci

Series Ci130.2QS and Ci130.2QR is best

suited where high quality music and speech

reinforcement applications require hi-fi

performance such as:

·Multi Room systems.

·Home Theatre systems.

·Lounges, Bars, Boutiques.

·Boardrooms & Offices.

·Airports, Convention Centres, Hotels.

Frequency range ± 3dB QS: 50Hz - 40kHz, QR: 100Hz - 40kHz

Sensitivity (2.83v @ 1m) 86dB

Rec. amplifier power 10 - 50W

Nominal Impedance 8Ω(min. 3.2Ω)

Crossover Frequency 2.8kHz

Enclosure material Steel with QR

T

erminals spring terminals up to Ø2.5mm (0.1”)*

Dimensions (H x W x D) 180 x 180 x 105 mm, 7.1 x 7.1 x 4.1 in QS

Ø180 x 105 mm, 7.1 x 4.1 in QR**

Net weight 1.3kg (2.9lbs) QS, 1.7kg (3.7lbs) QR

*Block terminals up to Ø2.5mm with Ci130.2QR enclosure.

** Depth 154mm (6in) with Ci130.2QR enclosure.
