Kaysun KC-03 SPS Instructions d'installation
INSTALLATION AND OWNER’S MANUAL
WIRED REMOTE CONTROLLER
MODEL: KC-03 SPS
IMPORTANT NOTE:
Read this manual carefully before installing or operating your wired remote controller. Make sure
to save this manual for future reference.
• This manual gives detailed description of precautions that should be brought to your
attention during operation.
• In order to ensure correct service of the wired controller please read this manual
carefully before using the unit.
• For convenience of future reference, keep this manual after reading it.
CONTENTS
1. SAFETY PRECAUTION............................................................................. 1
2. INSTALLATION ACCESSORY.................................................................... 2
3. INSTALLATION METHOD........................................................................... 4
4. SPECIFICATION......................................................................................... 9
5. FEATURE AND FUNCTION OF THE WIRED CONTROLLER.................. 10
6. NAME ON THE LCD OF THE WIRE CONTROLLER................................ 11
7. NAME OF BUTTON ON THE WIRE CONTROLLER................................ 12
8. PREPARATORY OPERATION.................................................................. 13
9. OPERATION.............................................................................................. 14
10. TIMER FUNCTIONS................................................................................ 20
11. WEEKLY TIMER...................................................................................... 23
12. FAULT ALARM HANDING....................................................................... 29
13.TECHNICAL INDICATION AND REQUIREMENT ................................... 29
1
1. SAFETY PRECAUTION
• Read the safety precautions carefully before installing the unit.
• Stated below are important safety issues that must be obeyed.
WARNING
Means improper handling may lead to personal death or severe
injury.
CAUTION Means improper handling may lead to personal injury or property
loss.
WARNING
Please entrust the distributor or professionals to install the unit.
Installation by other persons may lead to imperfect installation, electric shock or re.
Adhere to this installation manual.
Imporper installation may lead to electric shock or re.
Reinstallation must be performed by professionals.
Do not uninstall the unit randomly.
Random uninstalling may lead to abnormal operation, heating or re of the air condition.
NOTE
1. Do not install the unit in a place vulnerable to leakage of ammable gases.Once am-
mable gases are leaked and left around the wire controller, re may occur.
2. Do not operate with wet hands or let water enter the wire controller. Otherwise, electric
shock may occur.
3. The wiring should adapt to the wire controller current. Otherwise, electric leakage heating
may occur and result in re.
4. The specied cables shall be applied in the wiring. No external force may be applied to
the terminal. Otherwise, wire cut and heating may occur and result in re.
2
2. INSTALLATION ACCESSORY
Select the installation location
Don’t install at the place where cover with heavy oil, vapor or sulfureted gas,
otherwise, this product would be deformed that would lead to system malfunction.
Preparation before installation
1. Please conrm that all the following parts you have been supplied.
No. Name Qty. Remarks
1 Wire controller 1 -----
2 Installation and owner’s manual 1 -----
3 Screws 3 M4X20 (For mounting on the Wall)
4 Wall plugs 3 For Mounting on the Wall
5 Screws 2 M4X25 (For mounting on switch box)
6 Plastic screw bars 2 For xing on switch box
7 Battery 1
8 The connective wires group 1 Optional
2. Prepare the following assemblies on the site.
No. Name Qty. (embeded
into wall)
Specication
(only for refe-
rence)
Remarks
1Switch box 1 ----- -----
2Wiring Tube (Insulating
Sleeve and Tightening
Screw)
1 ----- -----
3
2. INSTALLATION ACCESSORY
Precaution of install the wire controller
1. This manual provides the installation method of wire controller. Please refer to the wiring
diagram of this installation manual to wire the wire controller with indoor unit
2. The wire controller working in low voltage loop circuit. Forbid to directly contact the
cable of 220Vcommercial electricity or of 380V high voltage, and don’t wire this kind of
wire in the said loop; wiring clearance between congured tubes should at the range of
300~500mm or above.
3. The Shielded wire of the wire controller must be grounded reliable.
4. Upon nish the wire controller connection, do not employed tramegger to detect the insu-
lation.
4
3. INSTALLATION METHOD
1. Wired remote controller structure size gure
Fig 3-1
2. Remove the upper part of wire controller
• Insert a slot screwdriver into the slots in the lower part of the wire controller (2 places),
and remove the upper part of the wire controller. (Fig. 3-2)
NOTICE
The PCB is mounted in the upper part of the wire controller. Be careful not to
damage the board with the slot screwdriver.
Slots
Fig 3-2
5
3. INSTALLATION METHOD
3. Fasten the black plate of the wire controller
• For exposed mounting, fasten the back plate on the wall with the 3 screws (M4x20) and
plugs. (Fig. 3-3)
Back plate
Screws (M4x20
Fig 3-3
• For ush-mounting, fasten the back plate on the switch box with 2 screws (M4x25) and
fasten it on the wall with 1 screw (M4x20). (Fig. 3-4)
Back plate Switch box
Screw (M4x20)
Screws (M4x25)
Fig 3-4
NOTICE
Put on a at surface. Be careful not to distort the back plate of the wire contro
ller by overtightening the mounting screws.
6
3. INSTALLATION METHOD
4. Battery installation
Fig 3-5
• Put the battery into the installation site and make sure the positive side of the battery is
in accordance with the positive side of installation site. (See Fig. 3-5)
• Please set the time corrected on the rst time operation. Batteries in the wire controller
can timing under power failure which ensure the time keep right. When the power res-
tores, if the time displayed is not correct, it means the battery is dead and replace the
battery.
