The Kamco ‘SCALEBREAKER' range of pumps and chemicals have been specifically designed for the removal of scale
and rust deposits which naturally form in heating and cooling circuits.
This manual contains detailed guidelines for the safe use of the Scalebreaker range of equipment. How to connect the
pump onto the equipment to be descaled, creating a circuit, and which chemical is best suited for each application.
Please take time to carefully read through these guidelines before using your Kamco pump.
Kamco Ltd
Unit 9 Curo Park, Frogmore,
St. Albans, Hertfordshire, AL2 2DD
Tel: 01727 875020
email: info@kamco.co.uk
Additional information may be obtained from our website:
www.kamco.co.uk
Kamco Descaling Pump Manual
C20 | C40 | C90 | C210
______________________________________________________________________________
Kamco Descaling Pump Manual
April 2022 edition 3 | P a g e
MAIN CONTENTS
Section A –Introduction Page
Introduction ......................................................................................................................................................4
Section B –Scalebreaker Pump Specification Page
Introduction ......................................................................................................................................................5
Scalebreaker C20 - Technical Data .....................................................................................................................6
Scalebreaker C40 (standard model) - Technical Data..........................................................................................7
Scalebreaker C40 (with flush facility) - Technical Data ........................................................................................8
Scalebreaker C90 (standard model) - Technical Data..........................................................................................9
Scalebreaker C90 (with flush facility) - Technical Data ......................................................................................10
Scalebreaker C210 (with flush facility) - Technical Data ....................................................................................11
Section C –Descaling Chemicals & Test Equipment Page
Introduction ....................................................................................................................................................12
Scalebreaker CG & Scalebreaker SR .................................................................................................................13
Scalebreaker FX & SCalebreaker HD.................................................................................................................14
Neutralising Crystals & Foambreaker ...............................................................................................................15
Summary of Descaling Chemicals.....................................................................................................................16
pH Paper .........................................................................................................................................................17
Electronic pH Meter ........................................................................................................................................18
Section D –Use of the Descaling Equipment Page
Scalebreaker Controls......................................................................................................................................19
Hose Connections to the Scalebreaker Pump ...................................................................................................19
Descaling Procedure........................................................................................................................................20
Checking the Progress of the Descale...............................................................................................................20
Completing the Descale, Disposal of the Solution and Testing ..........................................................................21
Section E –Frequently Asked Questions and Their Answers Page
FAQs 22
Section F –Trouble Shooting, Service & Repair Page
Trouble Shooting and Problem Solving.....................................................................................................23 & 24
Exploded View and Spares Diagram for Scalebreaker C20 ................................................................................25
Exploded View and Spares Diagram for Scalebreaker C40 and C90 (standard models) ......................................26
Exploded View and Spares Diagram for Scalebreaker C40 and C90 (with flush facility)......................................27
Exploded View and Spares Diagram for Scalebreaker C210 (standard model)...................................................28
Exploded View and Spares Diagram for Scalebreaker C210 (with flush facility) .................................................29
Exploded View of Hose Connections ................................................................................................................30
Pump Spares Lists...........................................................................................................................31, 32, 33, 34
Hose Components and Hose Assemblies Lists ..................................................................................................35
Kamco Descaling Pump Manual
C20 | C40 | C90 | C210
______________________________________________________________________________
Kamco Descaling Pump Manual
April 2022 edition 4 | P a g e
SECTION A –INTRODUCTION
The Kamco ‘SCALEBREAKER' range of pumps and chemicals have been specifically designed for the removal
of scale and rust deposits which naturally form in heating and cooling circuits.
Heating and cooling systems using steel pipework and components frequently suffer fouling, and a build-up
of debris as a result of the natural corrosion process by which iron tries to revert to its oxides.
In hard water areas, when water is heated, the natural minerals within the water break down into insoluble
crystals, which deposit out as scale.
These deposits not only restrict water flow, but also act as a very effective insulant, severely reducing heat
transfer and hence efficiency of the equipment, necessitating regular cleaning and descaling.
Applications include:
Heat exchangers and calorifiers.
Boilers and steam generators.
Condensers and chillers.
Injection moulding and extrusion machines.
Catering equipment.
Cooling towers and evaporators.
Precautions should be taken to ensure a safe working environment:
Take care when lifting large or heavy items.
Regularly check power leads for wear or damage, use with a residual circuit breaker.
When handling chemicals wear suitable protective clothing, gloves and goggles.
Use in a well-ventilated area.
PAT test (Portable Appliance Test) the electrics annually.
Read and observe manufacturers’instructions.
Kamco Descaling Pump Manual
C20 | C40 | C90 | C210
______________________________________________________________________________
Kamco Descaling Pump Manual
April 2022 edition 5 | P a g e
SECTION B –SCALEBREAKER PUMP SPECIFICATION
INTRODUCTION
All Kamco pumps are of the self-priming, vertical axis centrifugal type.
Units are built for ease of handling, with hand holds and grips for manoeuvrability and emptying.
Low weight and a wide base aid stability. Models from the C40 upwards are fitted with wheels.
'Standard' model or 'Fresh Water Flush Facility' (FWF) model
The larger Scalebreaker pumps are available in two different formats:
'Standard' format with a two-part hose set: flow and return.
'Fresh Water Flush Facility' format with four-part hose set: flow, return, water inlet and dump.
The 'Fresh Water Flush Facility' format gives the operator the option of introducing fresh water directly into the tank,
and the ability to dump the waste into a nearby drain or disposal vessel without the need to disconnect the flow and
return hoses from the equipment being descaled.
Motors.
Electric motors are totally enclosed fan-cooled type, to IP54 and IP55 protection rating, continuously rated.
Pumps are available with 230v, 50Hz, 110v, 50Hz, or 120v, 60Hz motors, with illuminated, membrane covered
switches. 240v, 60Hz motors are available on larger models.
Flow reversal device.
All units have an instantaneous flow reverser valve to change the direction of flow between clockwise and
anticlockwise directions. The valve can be operated without the need to switch the motor off.
Alternating the flow of the descaling chemical enables deposits to be attacked from different directions and can
drastically reduce the time taken. It is also very effective in flushing out loosened debris.
Operational and temperature capabilities.
All units can operate up to 60°C.
Descaling can be undertaken cold, above 0°C, but chemical performance is enhanced with temperature.
Chemical handling capabilities
Scalebreaker pumps are acid-proof, and may be used with all acids in common descaling use,
i.e. hydrochloric, phosphoric, sulphamic, citric, formic, acetic, etc. as well as alkalis.
Pumps may be used with chlorine solutions for sterilising purposes.
For compatibility with other chemicals, please check with Kamco.
Hoses and connections.
Reinforced PVC hoses with polypropylene chemical resistant BSP threaded female couplings.
Kamco Descaling Pump Manual
C20 | C40 | C90 | C210
______________________________________________________________________________
Kamco Descaling Pump Manual
April 2022 edition 6 | P a g e
SCALEBREAKER C20 - TECHNICAL DATA
Scalebreaker C20
Pump Type: Positive drive centrifugal
Motor: 0.45 kW, 230v
Degree of protection: IP54
Motor rating: Continuous
Temperature range: 0°C to 50°C
Dimensions: W 260mm, D 460mm, H 540mm.
Weight empty (without hoses): 8kg.
Tank capacity (to filler cap): 20l.
Product code for 230v model: CDP020
A 5amp fuse should be fitted in the plug top. A residual current circuit breaker adapter should be used.
Contents of the Scalebreaker C20 kit
C20 descaling pump.
Set of 2 x 3m x 16mm dia. flow and return hoses.
3/4" BSP connections to pump unit
1/2" BSP connections on free ends of flow and return hoses.
Hoses supplied loose.
10 part BSP adapter set.
Kamco Descaling Pump Manual
C20 | C40 | C90 | C210
______________________________________________________________________________
Kamco Descaling Pump Manual
April 2022 edition 7 | P a g e
SCALEBREAKER C40 (STANDARD MODEL) - TECHNICAL DATA
Scalebreaker C40 Standard
Pump Type: Positive drive centrifugal
Motor: 0.80 kW, 230v
Degree of protection: IP55
Motor rating: Continuous
Temperature range: 0°C to 50°C
Dimensions: W 390mm, D 440mm, H 690mm.
Weight empty (without hoses): 17kg.
Tank capacity (to filler cap): 39l.
Wheels: 75mm diameter wheels inset in rear face.
Product code for 230v model: CDP040S
A 5amp fuse should be fitted in the plug top. A residual current circuit breaker adapter should be used.
Contents of the Scalebreaker C40 kit
C40 descaling pump.
Set of 2 x 3m x 16mm dia. flow and return hoses.
3/4" BSP connections.
Hoses supplied loose.
10 part BSP adapter set.
Kamco Descaling Pump Manual
C20 | C40 | C90 | C210
______________________________________________________________________________
Kamco Descaling Pump Manual
April 2022 edition 8 | P a g e
SCALEBREAKER C40 (WITH FLUSH FACILITY) - TECHNICAL DATA
Scalebreaker C40 FWF
Pump Type: Positive drive centrifugal
Motor: 0.80 kW, 230v
Degree of protection: IP55
Motor rating: Continuous
Temperature range: 0°C to 50°C
Dimensions: W 390mm, D 440mm, H 690mm.
Weight empty (without hoses): 17kg.
Tank capacity (to filler cap): 39l.
Features: Fresh water inlet, and dirty water dumping facility.
Wheels: 75mm diameter wheels inset in rear face.
Product code for 230v model: CDP040
A 5amp fuse should be fitted in the plug top. A residual current circuit breaker adapter should be used.
Contents of the Scalebreaker C40 kit
C40 descaling pump.
Set of 2 x 3m x 16mm dia. flow and return hoses.
Water inlet tap with 3m x 13mm dia. hose.
1 x 3m x 16mm dia. dump hose.
3/4" BSP connections.
Hoses supplied loose.
10 part BSP adapter set.
Kamco Descaling Pump Manual
C20 | C40 | C90 | C210
______________________________________________________________________________
Kamco Descaling Pump Manual
April 2022 edition 9 | P a g e
SCALEBREAKER C90 (STANDARD MODEL) - TECHNICAL DATA
Scalebreaker C90 Standard
Pump Type: Positive drive centrifugal
Motor: 1.1 kW, 230v
Degree of protection: IP55
Motor rating: Continuous
Temperature range: 0°C to 50°C
Dimensions: W 390mm, D 590mm, H 890mm.
Weight empty (without hoses): 23kg.
Tank capacity (to filler cap): 57l.
Wheels: 200mm diameter wheels.
Product code for 230v model: CDP090S
A 5amp fuse should be fitted in the plug top. A residual current circuit breaker adapter should be used.
Contents of the Scalebreaker C90 kit
C90 descaling pump.
Set of 2 x 3m x 19mm dia. flow and return hoses.
3/4" BSP connections.
Hoses supplied loose.
10 part BSP adapter set.
Kamco Descaling Pump Manual
C20 | C40 | C90 | C210
______________________________________________________________________________
Kamco Descaling Pump Manual
April 2022 edition 10 | P a g e
SCALEBREAKER C90 (WITH FLUSH FACILITY) - TECHNICAL DATA
Scalebreaker C90 FWF
Pump Type: Positive drive centrifugal
Motor: 1.1 kW, 230v
Degree of protection: IP55
Motor rating: Continuous
Temperature range: 0°C to 50°C
Dimensions: W 390mm, D 590mm, H 890mm.
Weight empty (without hoses): 23kg.
Tank capacity (to filler cap): 57l.
Features: Fresh water inlet, and dirty water dumping facility.
Wheels: 200mm diameter wheels.
Product code for 230v model: CDP090
A 5amp fuse should be fitted in the plug top. A residual current circuit breaker adapter should be used.
Contents of the Scalebreaker C90 kit
C90 descaling pump.
Set of 2 x 3m x 19mm dia. flow and return hoses.
Water inlet tap with 3m x 13mm dia. hose.
1 x 3m x 19mm dia. dump hose.
3/4" BSP connections onto pump.
Hoses supplied loose.
10 part BSP adapter set.
Ce manuel convient aux modèles suivants
3
Table des matières
Autres manuels Kamco Pompe à eau
Manuels Pompe à eau populaires d'autres marques
Sykes AmeriPumps
Sykes AmeriPumps GP100M Guide de dépannage
DUROMAX
DUROMAX XP WX Series Manuel utilisateur
BRINKMANN PUMPS
BRINKMANN PUMPS SBF550 Manuel utilisateur
Franklin Electric
Franklin Electric IPS Manuel utilisateur
Xylem
Xylem e-1532 Series Manuel utilisateur
Milton Roy
Milton Roy PRIMEROYAL Manuel utilisateur
