Kärcher B 60 Manuel utilisateur

QUICKSTART

5.964-272.0 10/12

Warning

These are only brief instructions! Please read and comply with these instructions prior to using or servicing your

appliance.

The non-compliance of the operating and safety instructions may lead to damages of the appliance and to dangers

for the operator and other persons.

Start up

1A B A Unplug the charger from the mains.

B Wind the mains cable around the cable hold-

ers.

2A B A Open the lock of the fresh water reservoir.

Fill fresh water (maximum 60 °C) until the

lower edge of the filling nozzle.

Close the lock of the fresh water reservoir.

B Connect the hose to the automatic filling

system and open the water supply

(max. 60 °C, max. 5 bars).

3A B Model with dosing equipment "Dose"

A Place the detergent bottle into the holder.

Close the bottle lid.

Insert the suction hose of the dosaging

equipment into the bottle.

Model without dosing equipment "Dose"

B Add the detergent to the fresh water

reservoir.

Operation

1A B Starting the machine

A Turn the program selection switch to "OFF".

B Plug in the Intelligent Key.

B 60

QUICKSTART

5.964-272.0 10/12

CDriving

A Turn the programme selector switch to

position 1 "Transport mode".

B First select the driving speed at the rotary

knob.

Drive forward

C Press the driving lever to the front.

Stop the machine: Release driving lever.

Reverse drive

D Press the driving lever to the rear.

Stop the machine: Release driving lever.

Stop

E Release driving lever.

3AAdjusting the brush contact pressure

A Arrest the lever in the desired position.

Upper position: higher contact pressure

Lower position: reduced contact pressure

4Cleaning Programs

AEco!efficiency mode

Wet clean the floor and vacuum up dirt water.

BNormal mode

Wet clean the floor and vacuum up dirt water.

CIntense mode

Wet clean the floor and allow the detergent to

react.

DVacuum mode

Vacuum the wastewater.

EPolishing mode

Polishing the floor without the application of

liquid.

5ASetting the water quantity

A Adjust the water quantity using the regulating

button according to the dirt on the floor cover-

ing.

6AInfo button

Use the Info button to select the menu items and

do the settings.

A Turning the button to the right/left scrolls

through the menus forward/ backward.

The selected setting gets accepted by

pressing the button.

Operation

QUICKSTART

5.964-272.0 10/12

Finish operation

Turn off the appliance

A Close the regulatory button for setting the

water quantity.

B Release driving lever.

C Settheprogramselectionswitchtosuctionor

vacuuming.

D Briefly drive forward and suck of the remain-

ing water.

E Turn the program selection switch to "OFF".

F Remove the Intelligent Key.

2A B Emptying the Dirt Water Reservoir

몇Warning

Pleaseobservethelocalprovisionsregardingthe

wastewater treatment.

A Take the water discharge hose from the

support and lower above a suited collection

device.

B Rinse the wastewater reservoir with clea

water or with the rinsing system for the

wastewater reservoir (option).

Take the water discharge hose from the

support and lower above a suited collection

device.

Leave the cover open to let it dry.

3AEmptying the Fresh Water Tank

몇Warning

Pleaseobservethelocalprovisionsregardingthe

wastewater treatment.

A Loosen the lid for emptying the fresh

water - do not remove it fully. Drain water.

Torinse thefreshwaterreservoir,removethe

cover with the seal completely and remove

the fresh water filter.

4AEmpty waste container (only with R

cleaning head)

A Remove bulk waste container and empty it.

5ACharging battery

A Charge battery, if required.

Insert the plug of the connecting cable into

the socket.

QUICKSTART

5.964-272.0 10/12

Maintenance and care

daily

monthly

Kärcher Customer Service

1A B A Remove the coarse dirt sieve from

thewastewaterreservoir and clean

it.

B Check the fluff filter, clean if re-

quired.

2A B 몇Warning

Please observe the local provisions

regarding the wastewater treatment.

A Loosen the lid for emptying the

fresh

water - do not remove it fully. Drain

water.

B To rinse the fresh water reservoir,

remove the cover with the seal

completely and remove the fresh

water filter.

Check fresh water filter; clean if

required.

3AA Remove the water distribution strip

from the cleaning head and clean

water canal (only R cleaning head).

4A B A Clean the vacuum lips on the

vacuum bar, turn or replace if

required.

B Clean the suction channel.

5AA Clean the seals between dirt water

reservoir and cover and check for

tightness, replace if required.

QUICKSTART

5.964-272.0 10/12

Troubleshooting

1ABAppliance cannot be started

A Stand-by. Plug in the Intelligent Key.

Turn the program selection switch to

the desired programme.

B Battery depleted.

Charge battery.

CInsufficient vacuum performance

A Clean the seals between dirt water reservoir

and cover and check for tightness, replace if

required.

B Clean the vacuum lips on the

vacuum bar, turn or replace if

required.

C Check suction hose for blockages; clean if

required.

Check connection between suction hose and

suctionbar and suction hoseand wastewater

tank.

D Remove the coarse dirt sieve from the waste-

water reservoir and clean it.

E Check the fluff filter, clean if required.

F Check the setting of the vacuum bar.

G Check if the cover on the dirt water discharge

hose is closed

H Empty wastewater tank (See "End opera-

tion", item 2).

3A B Insufficient cleaning result

A Check brush for wear and tear and clean it.

Check the brushes for wear (bristle length at

least 10 mm), replace if required.

4A B

CInsufficient water quantity

A Check fresh water level, refill tank if neces-

sary.

B Increase the water volume on the regulating

knob for water volume.

C Unscrew the lock ofthe fresh water reservoir.

Remove and clean the fresh water filter. In-

sert the filter and screw in the lock.

D Remove the water distribution strip from the

cleaning head and clean water canal (only R

cleaning head).

QUICKSTART

5.964-272.0 10/12

5ABrushes do not turn

A If over-current switch in the electronics sys-

tem has been triggered, turn programme se-

lection switch to "OFF". Afterwards, set it

back to the desired programme.

B Check the brushes for blockage due to for-

eign particles, remove them if found.

6A B Do not add detergents

A Increase the water volume to activate the

dosing pump.

B Check level of detergent solution in the fresh

water tank; refill, if required.

Troubleshooting
