Kärcher K1900PS Manuel utilisateur

your product

www.kaercher.com/welcome

K1900PS

1.106-210.0

K1900PSB

1.106-213.0

Operator Manual

Electric Pressure Washer ............... 4

Manuel D’utilisation

Laveuse à pression électrique ...... 21

Manual De Usuario

Hidrolavadora de alta presion ....... 38

9.808-308.0-A 02/22

1. Water Inlet

2. High Pressure Outlet

3. Hose Connector

4. ON/Off Pedal

5. Power Cord Cleat

6. Nozzles

7. Turbo Nozzle

8. High Pressure Hose

9. Spray Wand

10. Spray Gun

11. Handle

12. Plug Storage

13. Wheel

14. Detergent Tank

15. Power Cord

Machine Parts List

376

4 English

Customer Service . . . . . . . . . . . . . . . 4

Safety Instructions . . . . . . . . . . . . . . . 5

Hazard Levels . . . . . . . . . . . . . . . . . . 5

Assembly Instructions . . . . . . . . . . . . 8

Intended Use . . . . . . . . . . . . . . . . . . . 8

Initial Start-Up . . . . . . . . . . . . . . . . . . 9

Using the Accessories . . . . . . . . . . . . 11

Working with Detergents . . . . . . . . . . 12

Taking a Break. . . . . . . . . . . . . . . . . . 13

Shutting Down &

Cleaning Up. . . . . . . . . . . . . . . . . . . . 14

Winterizing & Long Term Storage . . . 15

Maintenance Instructions. . . . . . . . . . 15

Cleaning Tips. . . . . . . . . . . . . . . . . . . 16

Optional Accessories. . . . . . . . . . . . . 17

Troubleshooting. . . . . . . . . . . . . . . . . 18

READ AND COMPLY WITH ALL

INSTRUCTIONS BEFORE USING

THIS MACHINE.

SAVE THESE INSTRUCTIONS

Your device must be registered in

order to help with any questions or

issues that you have. You can register

your device at www.karcher-

www.karcher.com/ca if located in

Canada, or www.karcher.com/mx if

located in Mexico.

In the case of a warranty claim, you

can contact customer support. Please

see the contact information listed

below for either the USA, Canada, or

Mexico. You MUST provide your proof

of purchase in order to file a warranty

claim either via email, phone, or fax.

You can contact our Customer Service

department by phone at 1-800-537-

4129 or via the website at

www.karcher.com/us.

You can contact our Customer Service

department by phone at 1-800-465-

4980 or via the website at

www.karcher.com/ca.

K1900PS Pressure Washer

Contents

Specifications

K1900PS Series

Operating Pressure 1900psi

Max Water Volume 1.2GPM

Amp Draw 13 Amps

Voltage 120V

Phase 1

Frequency 60 Hz

Model Number 1.106-210.0

1.106-213.0

Serial Number

Customer Service

Registration

Warranty

USA Customer Service

Canada Customer

Service

English 5

Indicates “an imminently hazardous

situation which, if not avoided, will

result in death or serious injury.”

Indicates “a potentially hazardous

situation which, if not avoided, could

result in death or injury.”

Indicates “a potentially hazardous

situation which, if not avoided, may

result in minor or moderate injury or in

property damage incidents.”

When using this product basic

precautions should always be

followed, including the following:

●Read all the instructions before using

the product.

●To reduce the risk of injury, close

supervision is necessary when a

product is used near children.

●Know how to stop the product and

bleed pressures quickly. Be

thoroughly familiar with the controls.

●Stay alert - watch what you are doing.

●Do not operate the product when

fatigued or under the influence of

alcohol or drugs.

●Keep operating area clear of all

persons.

●Do not overreach or stand on

unstable support. Keep good footing

and balance at all times.

●Follow the maintenance instructions

specified in the manual.

●This product is provided with a

Ground Fault Circuit Interrupter built

into the power cord plug. If

replacement of the plug or cord is

needed, use only identical

replacement parts.

Risk of Injection or Injury – Do Not

Direct Discharge Stream At

Persons.

●High-pressure jets can be dangerous

if misused. The jet must not be

directed at persons, animals,

electrical devices, or the unit itself.

●Wear safety goggles and ear

protection.

Risk Of Fire/Explosion – Do not

spray flammable liquids.

●Do not use acids, alkaline, solvents,

or any flammable material in this

product. These products can cause

physical injuries to the operator and

irreversible damage to the machine.

Risk of Electrocution.

●Inspect cord before using - Do not

use if cord is damaged.

●Keep all connections dry and off the

ground.

●Do not touch plug with wet hands.

Safety Instructions

Hazard Levels

Important Safety

Instructions

6 English

●Do not use extension cord with this

product.

●Connect to individual branch circuit

only.

Risk of Eye Injury

●Spray can splash back or propel

objects. Always wear properly rated

eye protection such as goggles or

face shield while spraying. (Safety

glasses do not provide full protection)

This unit has been designed for use

with cleaning detergents

recommended by the manufacturer.

The use of other cleaning

detergents may affect the operation

of the machine and void the

warranty.

Gun kicks back – Hold with both

hands.

●The trigger gun safety lock prevents

the trigger from accidentally being

engaged. This safety feature must

be engaged when replacing nozzles

or not in use.

●This safety feature DOES NOT lock

spray in the ON position.

●Do not spray electrical connections,

electrical outlets or fixtures.

●Do not use with flammable liquids

and toxic chemicals.

●High-pressure. Keep clear of nozzle.

●Injection hazard: Equipment can

cause serious injury if the spray

penetrates the skin. Do not point the

gun at anyone or any part of the

body. In case of penetration seek

medical aid immediately.

●This system is capable of producing

1900 psi. To avoid rupture and injury,

do not operate this pump with

components rated less than 1900 psi

working pressure (including but not

limited to spray guns, hose and hose

connections).

●Before servicing, cleaning or

removing any parts, shut off power

and relieve pressure.

●If connection is made to a potable

water system, the system shall be

protected against back flow.

English 7

When connecting the water inlet to

the water supply mains, local

regulations of your water company

must be observed. In some areas

the unit must not be connected

directly to the public drinking water

supply. This is to ensure that there

is no feedback of chemicals into

the water supply. Direct connection

via a receiver tank or backflow

preventer, for example,

is permitted.

Use a water filter to avoid potential

damage from dirt in the water

supply such as Karcher part

number 4.730-059.0 from

www.kaercher.com.

●Garden hose must be at least

5/8 inch (16 mm) in diameter.

●Flow rate of water supply must not

fall below 2 GPM/gallons per minute

(7.6 L/min).

●Flow rate can be determined by

running the water for one minute into

an empty 5-gallon (18.9 liter)

container.

●The water supply temperature must

not exceed 104°F/40°C.

●Never use the pressure washer to

draw in water contaminated with

solvents,

e.g. paint thinners, gasoline, oil, etc.

●Always prevent debris from being

drawn into the unit by using a clean

water source.

This electric pressure washer is

equipped with a Ground Fault Circuit

Interrupter (GFCI) built into the plug of

the power cord for your protection.

The Consumer Product Safety

Commission recommends that you

test all GFCI's once a month. Since

the frequency of pressure washer use

varies, we recommend that you test

the GFCI as part of your startup

procedure each time you use your

pressure washer. It might need to be

reset before working with the pressure

washer. To learn how to perform the

GFCI test and how to reset it, visit

http://www.karcher-help.com and

search for GFCI for further

instructions. DO NOT USE IF GFCI

FAILS TEST.

NOTE: The actual appearance of the

GFCI may be different from this illustra-

tion.

Water Supply

(Cold Water Only) Ground Fault Circuit

Interrupter Protection

8 English

This high pressure washer

(hereinafter referred to as “device”) is

designed for domestic use only.

●For cleaning machines, vehicles,

buildings, tools, facades, terraces,

gardening tools, etc. By means of a

high-pressure water jet (if necessary,

with additional cleaning agents).

●With accessories, replacement parts

and cleaning agents approved by

KÄRCHER. Please observe the

information accompanying the

cleaning agents.

The owner and/or user must have an

understanding of the manufacturer’s

operating instructions and warnings

before using this device.

Warning information should be

emphasized and understood.

If the operator is not fluent in English,

the manufacturer’s instructions and

warnings shall be read to and

discussed with the operator in the

operator’s native language by the

purchaser/owner, making sure that the

operator comprehends its

contents.Owner and/or user must

study and maintain for future

reference the manufacturer’s

instructions.

1. Insert wheels into the body of the

machine. Secure with axle pin.

2. Push the handle into place.

3. Install the hose connector to the

water inlet.

Intended Use

Owner/User

Responsibility

Assembly Instructions

English 9

4. Attach nozzles to handle.

5. Thread one end of the high pressure

hose tightly onto the high pressure

outlet on the unit.

6. Thread the other end of the high

pressure hose onto the spray gun

inlet.

1. Thread the garden hose onto the

water inlet connector and hand

tighten.

2. Connect the garden hose to the cold

water source and turn the water

completely on.

3. Attach the spray wand to the spray

gun by pressing the gun into the

Initial Start-Up

10 English

wand and hand tightening the

threading of the gun onto the wand.

4. Pull the lever on the trigger gun to

make sure that water is flowing freely

and that all air has been purged from

the device.

NOTE: We recommend that you test

the GFCI as part of your startup

procedure each time you use the

device, see chapter GFCI

INSTRUCTIONS.

Do not use if GFCI fails test.

1. Plug the Ground Fault Circuit

Interrupter (GFCI) into a working

outlet.

2. Press “TEST”, then press “RESET” to

assure proper connection.

NOTE: The actual appearance of the

GFCI may be different from this illustra-

tion.

ATTENTION

Pump running dry will cause

damage to the device.

If pressure does not build up in the

device after 2 minutes then switch the

device off and proceed according to

the instruction in chapter,

troubleshooting guide.

NOTE: Maintain a spraying distance

of at least 12 inches (30 cm) when

cleaning painted surface. Do not get

closer than 24 inches (60 cm) (0r 2

feet) when washing a vehicle.

1. Install the nozzle with the quick

connect on the end of the wand by

pulling the collar back, inserting the

soap nozzle, then pushing the collar

GFCI Instructions

Operation Instructions

High Pressure Operation

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Kärcher Nettoyeur haute pression

Kärcher

Kärcher K 3.91 MD Manuel utilisateur

Kärcher

Kärcher HD 10/21-4 Cage Manuel utilisateur

Kärcher

Kärcher K 4000 M Manuel utilisateur

Kärcher

Kärcher HD 830 BS Manuel utilisateur

Kärcher

Kärcher K 4.80 Manuel utilisateur

Kärcher

Kärcher K 2.35 Manuel utilisateur

Kärcher

Kärcher HD 11/35 Ec-B Cage Manuel utilisateur

Kärcher

Kärcher K 3.450 Manuel utilisateur

Kärcher

Kärcher K 3.95 M Manuel utilisateur

Kärcher

Kärcher G 2500 DC Manuel utilisateur

Kärcher

Kärcher K 7 Power Manuel utilisateur

Kärcher

Kärcher HDS 5 U Series Manuel utilisateur

Kärcher

Kärcher K 5.55 Jubilee Manuel utilisateur

Kärcher

Kärcher K 5 Premium Manuel utilisateur

Kärcher

Kärcher K 2.70 Manuel utilisateur

Kärcher

Kärcher K 7 Manuel utilisateur

Kärcher

Kärcher B602 plus Manuel utilisateur

Kärcher

Kärcher 330 Manuel utilisateur

Kärcher

Kärcher K 5 Full Control Plus Manuel utilisateur

Kärcher

Kärcher K 2.13 Manuel utilisateur

Kärcher

Kärcher K 3.95 M Manuel utilisateur

Kärcher

Kärcher HD 4/8 Classic Manuel utilisateur

Kärcher

Kärcher K 5 Compact Manuel utilisateur

Kärcher

Kärcher HD 5/13 P Manuel utilisateur

Manuels Nettoyeur haute pression populaires d'autres marques

Shark

Shark RG-232637 Manuel utilisateur

Shakti Technology

Shakti Technology S3 Manuel utilisateur

Porter-Cable

Porter-Cable D25806-025-2 Manuel utilisateur

REM POWER

REM POWER HDEm 662 Manuel utilisateur

Landa

Landa HS-3000 Manuel utilisateur

Craftsman

Craftsman 580.752270 Manuel utilisateur

HIKOKI

HIKOKI AW 100 Manuel utilisateur

Delco

Delco DC 1302 Manuel utilisateur

BIEMMEDUE

BIEMMEDUE 120/10 - 170/13 Manuel utilisateur

ARKSEN

ARKSEN 014-HG-14141-HR Manuel utilisateur

Black & Decker

Black & Decker PW1700SPX Manuel utilisateur

Kärcher

Kärcher 595 - SPARE Mode d’emploi

Kranzle

Kranzle B 10 200 Manuel utilisateur

Stihl

Stihl RE 90 Manuel utilisateur

Husky

Husky HU80911 Manuel utilisateur

PowR-Quip

PowR-Quip PQ-2600 Manuel utilisateur

Hotsy

Hotsy 5645 Manuel utilisateur

Kranzle

Kranzle B170T Manuel utilisateur
