PXI-63980
PXI Embedded Controller
User’s Manual
Manual Rev.: 1.00
Revision Date: JUL.16, 2016

I
Getting Service
Contact us should you require any service or assistance.
SHANGHAI JYTEK Co., Ltd.
Web site: hp://www.jytek.com
Address: (201203) 300 Fang Chun Rd., Zhangjiang Hi-Tech Park, Pudong New Area,
Shanghai, 201203 China
Tel: +86-21-5047-5899
Fax: +86-21-5047-5899
Email: [email protected]
Addional informaon, aids, and ps that help users perform tasks
Informaon to prevent minor physical injury, component damage, data loss,
and/or program corrupon when trying to complete a task.
Informaon to prevent serious physical injury, component damage, data loss,and/
or program corrupon when trying to complete a specic task.

II
Table of Contents
Geng Service �������������������������������������������������������������������������������������������������� I
1 Introducon������������������������������������������������������������������������������������������������ 1
1�1 Features ��������������������������������������������������������������������������������������������� 2
1.2 Specicaons ������������������������������������������������������������������������������������� 3
2 Geng Started�������������������������������������������������������������������������������������������� 6
2�1 Package Contents ������������������������������������������������������������������������������� 6
2.2 Operang System Installaon������������������������������������������������������������� 6
2.3 Hardware Instrucons ������������������������������������������������������������������������ 7
2�3�1 Faceplate Connectors & Indicators ������������������������������������������ 7
2�3�2 PXI Trigger Connector�������������������������������������������������������������� 9
2�3�3 DVI-I Connector����������������������������������������������������������������������� 9
2�3�4 GPIB Connector����������������������������������������������������������������������10
2.3.5 Reset Buon ��������������������������������������������������������������������������11
2�3�6 LED Indicators ������������������������������������������������������������������������11
2�3�7 USB 2�0 Ports �������������������������������������������������������������������������12
2�3�8 Gigabit Ethernet Ports ������������������������������������������������������������13
2�3�9 USB 3�0 Ports �������������������������������������������������������������������������13
2.3.10 Onboard Connecons and Sengs���������������������������������������13
2.3.11 Installaon Environment ������������������������������������������������������14
2�3�12 Installing the PXI-63980��������������������������������������������������������15
2�3�13 Replacing the Hard Drive or Solid State Drive �����������������������15
2.3.14 Replacing the Baery Backup �����������������������������������������������16
2�3�15 Clearing CMOS ���������������������������������������������������������������������16
2.3.16 Iniang Backup BIOS Flash �������������������������������������������������17
3 Driver Installaon ��������������������������������������������������������������������������������������18
3�1 Installing Windows Drivers ����������������������������������������������������������������18
3�2 Installing the Chipset Driver���������������������������������������������������������������18
3�3 Installing the Graphics Driver�������������������������������������������������������������19
3�4 Installing the Ethernet Driver�������������������������������������������������������������19
3�5 Installing the GPIB Driver�������������������������������������������������������������������19
3.6 Installing the Management Engine Driver ������������������������������������������20
3�7 Installing the PXI Trigger Driver����������������������������������������������������������20
3�8 Installing the WDT Driver�������������������������������������������������������������������20
3�9 Installing the USB 3�0 Driver ��������������������������������������������������������������21
4 BIOS Setup �������������������������������������������������������������������������������������������������22
4.1 Starng the BIOS�������������������������������������������������������������������������������22
4�2 Main Setup����������������������������������������������������������������������������������������23
4�3 Advanced Setup ��������������������������������������������������������������������������������24
4.4 Chipset Conguraon ������������������������������������������������������������������������25
4�5 Boot Setup ����������������������������������������������������������������������������������������25

III
4.6 Security Setup �����������������������������������������������������������������������������������25
4�7 Save & Exit Setup ������������������������������������������������������������������������������26
Appendix A - PXI Trigger I/O Funcon Reference����������������������������������������������27
A.1 Data Types ����������������������������������������������������������������������������������������27
A.2 Funcon Library��������������������������������������������������������������������������������28
A�2�1 TRIG_Init �������������������������������������������������������������������������������28
A�2�2 TRIG_Close ����������������������������������������������������������������������������28
A.2.3 TRIG_SetSoTrg���������������������������������������������������������������������29
A�2�4 TRIG_Trigger_Route ���������������������������������������������������������������29
A�2�5 TRIG_Trigger_Clear ����������������������������������������������������������������31
A.2.6 TRIG_GetSoTrg ��������������������������������������������������������������������31
A.2.7 TRIG_Trigger_Route_Query����������������������������������������������������32
A�2�8 TRIG_GetDriverRevision���������������������������������������������������������33
Appendix B - Watchdog Timer �������������������������������������������������������������������������35
B.1 WDT Funcon Library������������������������������������������������������������������������35
B�1�1 InitWDT ���������������������������������������������������������������������������������35
B�1�2 SetWDT����������������������������������������������������������������������������������35
B�1�3 StartWDT ������������������������������������������������������������������������������36
B�1�4 ResetWDT ������������������������������������������������������������������������������36
B�1�5 StopWDT��������������������������������������������������������������������������������37
Important Safety Instrucons ��������������������������������������������������������������������������38

IV
List of Tables
Table 2-1: DVI-I Pin Assignment ����������������������������������������������������������������������10
Table 2-2: GPIB Pin Descripon �����������������������������������������������������������������������11
Table 2-3: LED Indicator Legend ����������������������������������������������������������������������11
Table 2-4: USB 2.0 Port Pin Assignment�����������������������������������������������������������12
Table 2-5: PXI-63980 Ethernet Port Pin Assignments ���������������������������������������13
Table 4-1: BIOS Hot Key Funcons�������������������������������������������������������������������23
Table 4-2: BIOS Main Setup Menu�������������������������������������������������������������������24
Table 4-3: BIOS Advanced Setup Menu �����������������������������������������������������������24
Table 4-4: BIOS Chipset Conguraon Menu ���������������������������������������������������25
Table 4-5: BIOS Boot Setup Menu �������������������������������������������������������������������25
Table 4-6: BIOS Security Setup Menu ��������������������������������������������������������������25

V
List of Figures
Figure 1-1: PXI-63980 Funconal Block Diagram ����������������������������������������������� 3
Figure 2-1: PXI-63980 Faceplate������������������������������������������������������������������������ 7
Figure 2-2: PXI Trigger SMB Jack������������������������������������������������������������������������ 9
Figure 2-3: PXI-63980 LED Indicators����������������������������������������������������������������11
Figure 2-4: PXI-63980 Onboard Conguraon ��������������������������������������������������14
Figure 4-1: BIOS Setup Navigaon��������������������������������������������������������������������23

1
1 Introduction
The JYTEK PXI-63980 PXI™ embedded controller, based on the Intel® Core™ i7 processor,
is specically designed for PXIbased tesng systems, providing a rugged and stable
operang environment for a wide variety of tesng and measurement applicaons.
Combining state-of-the-art Intel® Core™ i7-2715QE 2.1 GHz processors, and up to 16 GB
of 1333 MHz DDR3 memory, the PXI-63980 ulizes four separate compung engines
on a single processor, enabling execuon of four independent tasks simultaneously in a
multasking environment.
PXI-based tesng systems typically make up a PXI plaorm and diversied standalone
instruments for complex tesng tasks. The PXI-63980 provides ample interface
choices, including GPIB, USB2.0, and USB3.0, for connecng and controlling instruments.
The PXI-63980 also provides dual Gigabit Ethernet ports, one for LAN connecon and the
other for controlling LXI instruments. With exible instrument control interfaces and
mechanical and electronic reliability, the JYTEK PXI-63980 is more than equal to the
challenges of the most demanding PXI-based tesng systems
Memory addressing over 4GB is OS-dependent, such that a 32-bit operang system
may be unable to address memory space over 4GB. To fully ulize memory, 64-bit
operang systems are required.

2
1�1 Features
• PXI™-1 PXI Hardware Specicaon Rev.2.2 complaint
• Intel® Core™ i7-2715QE 2.1 GHz processor for maximum compung power, 3.0GHz
maximum in single-core, Turbo Boost mode.
• Dual Channel DDR3 SODIMM
• Up to 16 GB 1333 MHz
• Maximum system throughput 132 MB/s
• Pre-installed 500 GB SATA hard drive
• Supports 2.5" HDD or SSD
• SATA 3.0 Gb/s
• Supports AHCI
• Integrated I/O
◦ Dual Gigabit Ethernet ports
◦ Four USB 2.0 Ports
◦ Built-in GPIB (IEEE488) controller
◦ DVI-I video connector
◦ Two USB 3.0 Ports
◦ Trigger I/O for advanced PXI™ trigger funcons
• Programmable watchdog mer

3
1�2 Specifications
Channel B
204 pin SODIMM
Channel A
204 pin SODIMM
Front Panel
Connectors
Intel® QM67
Express Chipset
Intel® Core™
i7-2715QE 2.1GHz
Processor
PCIe x1
GbE
connectorGbE I/F
USB
connector x4
GPIB controllerUSB2.0
GPIB
connectorGPIB
SMB
Connector
PXI Connector
Trigger Bus
Controller
USB3.0
connector x2
PCIe-to-PCI
bridge
2.5" SATA HDD
SATA
GbE
connectorGbE I/F
Digital
Display I/F
DVI
DVI-I
connector
PCIe x1
DVI level shifter
Trigger Signal
SMBUS
Intel FDI DMI
GbE PHY
82579LM
GbE controller
I210
Trigger Bus
PCI
DDR3
1333MHz
DDR3
1333MHz
USB 2.0
PCIe x1USB3.0 PCIe-to-USB3.0
PCIe x1
Figure 1-1: PXI-63980 Functional Block Diagram
Processor
• Intel® Core™ i7-2715QE 2.1GHz processor, 3.0GHz maximum in single-core, Turbo
Boost mode
• DMI (Direct Media Interface) with 5 GT/s of bandwidth in each direcon
Chipset
Mobile Intel® QM67 Express
Memory
• Two standard 204-pin DDR3 SODIMM sockets
• Support for +1.5 V DDR3, 1066/1333 MHz RAM up to 16 GB total
• Support for non-ECC unbuered memory
The externally accessible SODIMM socket can accept replacement DDR3 DRAM
DIMM modules.
PXI-63980 specicaons and stability guarantees are only supported when JYTEK-
provided DDR3 DRAM DIMM modules are used.

4
Video
• DVI output supporng up to 1920x 1200 @ 60 Hz resoluon
• VGA output for analog CRT route to DVI-I connector on the faceplate, supporng up
to 2048 x 1536 bpp at 75Hz
• DVI-I connector for dual digital and analog video signal output via the included JYTEK
Y-cable
Hard Drive
Built-in 2.5” 500 GB 7200 RPM SATA hard drive or 120GB SATA solid state driver
I/O Connecvity
Dual Gigabit Ethernet controllers through two RJ-45 connectors with speed/link/acve LED
on the faceplate, with upper connector supporng Wake on LAN.
USB
Four USB 2.0 and two USB 3.0 ports on the faceplate.
GPIB
Onboard IEEE488 GPIB controller through Micro-D 25-pin connector on the faceplate.
Trigger I/O
One SMB connector on the faceplate to route an external trigger signal to/from PXI trigger
bus
Dimensions (3-slot 3U PXI module)
3U/3-slot PXI standard
60.5 W x 128.7 H x 213.2 D mm (2.38 x 5.07 x 8.39 in.)
Slot Requirements
System slot (5V VIO PCI bus) and 2 controller expansion slots on chassis/backplane.
32-bit and 5V VIO PCI bus of system slot.
Do not remove the blue key from the PXI-63980 system connector, only the 5V
VIO PCI bus is compable.
3.3V VIO PCI bus is not.
SEVERE system damage may result.
Weight
0.9 kg (exclusive of packaging)
Environmental
Operang temperature with SSD 0 to 55°C
Operang temperature with HDD 0 to 50°C
Storage temperature -20 to 70°C
Relave humidity , non-condensing 5 to 95%
