TV/VIDEO

MENU/OK

CHANNEL

VOLUME

COLOUR TELEVISION

INSTRUCTIONS

The illustrations of LT-32EX17 is used in this instruction manual for explanation

purpose. Your TV may not look exactly the same as illustrated.

This illustration shows LT-32EX17.

LT-32EX17

LT-32EX177

LT-37EX17

LT-42EX17

PREPARATION FUNCTIONS REFERENCE

Contents

Safety precautions ......................... 2

Set up and connections ................. 3

Initial settings ................................. 5

Remote control buttons

and functions ................................. 6

TV buttons and functions ............... 7

Operating the menus ..................... 8

Picture setting ................................ 9

Original features for picture ......... 12

Sound setting .............................. 13

Customized setting ...................... 14

Operate JVC recorders and

other devices ............................... 16

TV channel presetting ................. 18

Troubleshooting ........................... 19

CH/CC List ................................... 21

Speciﬁcation ................................ 22

GGT0191-001A-H

Follow this manual regarding

setup!

• Connect only to a 110-240 V,

50/60 Hz AC outlet.

(Except China, Russia : connect

to a 220-240 V, 50/60 Hz AC

outlet)

Thank you for buying this JVC colour television.

To make sure you understand how to use your new TV, please read this manual thoroughly before you begin.

Do not allow the TV to fall!

• Do not rest your elbows on, or

allow children to hang from the

TV.

There is a risk that the TV will fall

and cause injuries.

Make enough room for inserting

and removing the power plug!

Place the TV as close to the

outlet as possible!

• The main power supply for this

TV is controlled by inserting or

removing the power plug.

Never cut or damage the power

cord!

• If the AC plug is not the

right shape, or the power

cord is not long enough,

use an appropriate plug

adapter or extension

cable. (Consult your retailer.)

Never place anything on the TV!

• Placing liquid,

naked ﬂames,

cloths, paper,

etc. on the TV

may cause a ﬁre.

Never expose to rain or

moisture!

• To prevent ﬁre

or electric shock,

never allow liquids

to enter the unit.

Never insert objects into the

cabinet openings!

• It may cause a

fatal electric shock.

Take care when

children are near.

Never listen to headphones at

high volume!

• It may damage your hearing.

• For more details on installation, usage and safety \ Consult your retailer.

Never try to repair the TV

yourself!

\� If the problem cannot be

solved in “Troubleshooting”

(P.17), unplug the power cord

and contact your retailer.

If the TV is damaged or

behaving strangely, stop

using it at once!

\� Unplug the power cord and

contact your retailer.

Unplug the power cord when

going out!

• The power buttons on the

remote control and the TV unit

cannot completely

turn off the TV.

(Make appropriate

arrangements for

bedridden people.)

Hold the TV so as not to scratch

the screen!

• Do not touch the screen when

carrying the TV.

Do not carry the TV on

your own!

• In order to prevent

accidents, ensure that

the TV is carried by

two or more people.

Never dismantle the rear panel!

• It may cause an electric shock.

Never obstruct the ventilation

holes!

• It may cause overheating or a

ﬁre.

Handle LCD panel with care!

• Use a soft, dry cloth when

cleaning.

When attaching the TV to the

wall, use the optional JVC wall

mounting unit!

• Consult a qualiﬁed technician.

• See the included manual on

mounting procedures.

• JVC assumes no responsibility

for damage due to improper

mounting.

150mm 50mm 150mm

200mm

50mm

RV S

L/ MONO

VIDEO-3

INPUT

PREPARATION

Set up and connections

Check accessories

Care when setting

■ Power requirements

• Connect the power cord only to a 110-240 V, 50/60 Hz AC outlet.

(Except China, Russia : connect to a 220-240 V, 50/60 Hz AC outlet.)

■ When attaching the TV to the wall, use the optional JVC wall

mounting unit.

• Consult a qualiﬁed technician.

• JVC assumes no responsibility for damage due to improper mounting.

• 200 mm x 200 mm mount which conforms to VESA standards.

■ Installation requirements

• To avoid overheating, ensure the unit has ample room.

• After all the connections have been made, insert the plug into an AC

outlet.

• If both composite and S-VIDEO cables are connected, S-VIDEO will

be enable.

Please read the user manuals of each device carefully before setup.

It is necessary to connect an aerial to watch TV.

■ Connect with other devices ➡ “Connecting external devices” (P.4)

Connect an aerial and VCR / DVD Player

■ Insert the batteries

Use two “AAA/R03” dry cell batteries.

Insert the batteries from the · end,

making sure the ª and · polarities

are correct.

Remote control

(RM-C1857)

“AAA/R03” Batteries

For conﬁrming

the TV works

VCR (DVD Player)

AERIAL

OUTPUT

INPUT

Pr/Cr Pb/Cb Y

R SL/MONO V

VIDEO-1

INPUT

VIDEO-2

INPUT

AUDIO

(ANALOG)

VIDEO/AUDIO

(DIGITAL)

VIDEO-3

INPUT

Set up and connections (continued)

You can connect many different devices to the rear panel of the TV.

Please read the user manuals of each device before setting up.

(Connecting cables are not supplied with this TV.)

Connecting external

] signal direction VIDEO-1 Watching DVDs

Output Input

• Composite signal/

Component signal

• Sound L / R

Use component signal:

“Video-1 Setting” (Page 15)

VIDEO-2 Watching videos

Output Input

• Composite signal

• Sound L / R

VIDEO-3 Watching videos

Output Input

• Composite signal/

S-VIDEO

• Sound L / R

Use S-VIDEO:

If both composite and S-VIDEO

cables are connected, S-VIDEO will

enable.

HDMI Connecting

HDMI devices

Output Input

• HDMI signal

• “HDMI Setting” (Page 15)

OUT

Video and sound signal of a TV

channel you are viewing outputs from

this terminal.

Output

• Composite signal

• Sound L / R

DVD player

(HDMI compatible)

VCR / DVD Player

Game consoles

Video camera

VCR / DVD Player

Ampliﬁer

(L) (R)

Headphone

IN HDMI

HDMI

OUT

VIDEO-1

VIDEO-2

IN HDMI

VIDEO-3

]

LANGUAGE

ENGLISH

FRANÇAIS

PУCCKИЙ

‰∑¬

Tieáng Vieät

УKPAЇHCЬKA

CASTELLANO

TELETEXT LANGUAGE

GROUP – 1

GROUP – 2

GROUP – 3

GROUP – 4

GROUP – 5

AUTO PROGRAM

CH 28

14%

EDIT

PR ID CH / CC

AV CH 04

01 CH 09

02 CH 02

03 CC 76

04 CC 78

05 CH 05

06 CH 07

PREPARATION

Initial settings

Turn on the TV.

• Show only when powering on for the ﬁrst time.

• The power on the unit can also be used.

Select a language

Select the teletext language group

• For the teletext language group

\ “Teletext Language” (P. 12)

• If the characters are unreadable

\ “Teletext Language” (P. 12)

Automatically register channels

Check what was registered

■ Edit Channels

\ “TV channel presetting” (P. 18)

Conﬁrm

Select

Set

Select

Remote control buttons and functions

Select Channel

Select the desired channel number.

For Hyper Scan:

Press and hold

PR changes without changing the

picture. Once you stop pressing

or button, picture will

change to the desired PR.

Turn the volume Off / On

RETURN PLUS function

Return to the frequently viewed channel.

RETURN PLUS

PROGRAMMED!

Press and hold

RETURN PLUS

CANCELED!

To cancel

Choose the channel you want to programme

RETURN function

If you have not set or have canceled the RETURN

PLUS channel, this will return to the previously

viewed channel.

Press and hold

Select TV or Video input

Operate the menu

Channel information

Turn the TV on from standby

Display menu on screen menu (P. 8)

Switch between “TV / VCR / DVD / AUDIO” (P. 16)

Change channel / page

Adjust the volume, Turn off Muting

View the Teletext�(P. 12)

To teletext (P. 12)

View the Teletext�(P. 12)

FAVOURITE CHANNEL (P. 12) To previous screen

Not available

Turn on “CINEMA SURROUND”

Change the aspect ratio

TV/VIDEO

MENU/OK

CHANNEL

VOLUME

FUNCTIONS

TV buttons and functions

Switch between TV / VIDEO devices

Display on-screen menu / set

Change channel / page

Hyper Scan Function

Volume

Power On / Off

To headphones (P. 4)

Power lamp

ON: Lit (Green)

OFF: Unlit

● Power lamp lights while

the TV is on.

Remote control sensor


PICTURE MODE

BACK LIGHT

CONTRAST

BRIGHT

SHARP

COLOUR

TINT

FEATURES

BRIGHT

PICTURE MODE STANDARD


SOUND

FEATURES

SET UP

Operating the menus.

1 Display the menu bar

2 Select a menu

3 Select an item

4 Adjust / Conﬁgure

■ When adjusting with

the sliding-bar

■ When adjusting from

presets

The item will change.

● Some items have a

sub-menu.

Menu Item Adjustments / Conﬁgurations


PICTURE MODE Picture mode (BRIGHT / SOFT / STANDARD)

BACK LIGHT Backlight brightness (Darker j Brighter)

CONTRAST Contrast (Lower j Higher)

BRIGHT Brightness (Darker j Brighter)

SHARP Sharpness (Softer j Sharper)

COLOUR Colour (Lighter j Deeper)

TINT Tint (Reddish j Greenish) Only NTSC

FEATURES Finer picture adjustments. (WHITE BALANCE /

DIGITAL VNR / DigiPure / PULL DOWN /

COLOUR MANAGEMENT / PICTURE MANAGEMENT /

COLOUR SYSTEM / 4:3 AUTO ASPECT)

SOUND

STEREO / I■II Mode / Languages ( : MONO / : STEREO /

I : SUB1 / II : SUB2 / MONO)

BASS Low tones (Weaker j Stronger)

TREBLE High tones (Weaker j Stronger)

BALANCE Speaker balance (Left Stronger j Right Stronger)

CINEMA SURROUND

Ambience level (HIGH / LOW / MONO / OFF)

FEATURES

TIMER Set timer for turning off or turning on the TV.

(ON TIMER / SLEEP TIMER)

CHANNEL GUARD Stops children from watching speciﬁc channels

BLUE BACK Displays a blue screen and mute the sound when the signal

is weak or absent. (ON / OFF)

CHILD LOCK Disables the front control buttons of the TV. (ON / OFF)

AUTO SHUTOFF Set the power to turn off if no signal is received and no

operation is performed for about 15 minutes. (ON / OFF)

FAVOURITE SETTING

Clear favourite channel settings.

APPEARANCE Format for displaying the channel number and menu screen

(TYPE A / TYPE B).

ECO MODE Adjust picture contrast according to room bright.

(OFF / ECO-1 / ECO-2)

SET UP

AUTO PROGRAM Automatically registers channels.

EDIT / MANUAL Change registered channels or add new ones.

LANGUAGE Select a language for on-screen menus.

VIDEO-1 SETTING For use with video players and other devices.

(VIDEO / COMPONENT)

AI VOLUME Prevent sudden increase or decrease of sound when

changing channels. (ON / OFF)

TELETEXT LANGUAGE

Select a language for Teletext programmes.

HDMI SETTING HDMI: Size (1 / 2 / Auto)

Audio (DIGITAL / ANALOGUE / AUTO)

Select

Set

Select

Set

Select

Adjust / Select

Set

( STANDARD )

Move

Items

FUNCTIONS

PICTURE menu

Picture setting

COLOUR SYSTEM

You can select the appropriate colour system when the picture is not clear

or no colour appears.

For the colour system in each country or region, see the table below:

Area Country or Region System

Asia,

Middle East

Bahrain, Kuwait, Oman, Qatar, United Arab Emirates,

Yemen, Indonesia, Malaysia, Singapore, Thailand,

India, China, Vietnam, Hong Kong, etc.

PAL

Islamic Republic of Iran, Lebanon, Saudi Arabia, etc. SECAM

Philippines, Taiwan, Myanmar, etc. NTSC

Europe

Russia, etc. SECAM

Czech Republic, Poland, Germany, Holland, Belgium,

UK, etc. PAL

Oceania Australia, New Zealand, etc. PAL

Africa Republic of South Africa, Nigeria, etc. PAL

Egypt, Morocco, etc. SECAM

PICTURE MODE

You can choose the desired picture setting.

BRIGHT Heightens contrast and sharpness.

SOFT Softens contrast and sharpness.

STANDARD Standard picture setting.

FEATURES

MENU COLOUR SYSTEM

AUTO PAL SECAM NTSC3.58 NTSC4.43

MENU PICTURE MODE

PICTURE menu

WHITE BALANCE

You can change the white balance of the picture to better match the type

of video being viewed.

WARM Reddish white

COOL Bluish white

MID Normal white balance

MENU FEATURES

PICTURE menu

BACK LIGHT

You can change the backlight brightness.

Choose 1 : Darker 2 : Brighter

MENU BACK LIGHT

PICTURE menu

CONTRAST

You can change the contrast of the picture.

Choose 1 : Lower 2 : Higher

MENU CONTRAST

PICTURE menu

BRIGHT

You can change the brightness of the picture.

Choose 1 : Darker 2 : Brighter

MENU BRIGHT

PICTURE menu WHITE BALANCE

Picture setting (continued)

PICTURE menu

SHARP

You can change the sharpness of the picture.

Choose 1 : Softer 2 : Sharper

MENU SHARP

PICTURE menu

COLOUR

You can change the sharpness of the picture.

Choose 1 : Lighter 2 : Deeper

MENU COLOUR

PICTURE menu

TINT

You can adjust Tint only in NTSC.

Choose 1 : Reddish 2 : Greenish

MENU TINT

PICTURE menu

DIGITAL VNR

You can cut down the amount of noise in the original picture.

ON Reduce the picture noise.

OFF Function is turned off.

MENU FEATURES

PICTURE menu

DigiPure

You can set the picture for a natural-looking outlines.

ON Set to a natural-looking picture.

OFF Function is turned off.

PICTURE menu

PULL DOWN

You can set the picture for smooth cinema ﬁlm.

ON Function is always on.

AUTO Automatically adjusts.

OFF Function is turned off.

ECO MODE

You can adjust TV screen contrast according to the brightness of your

room.

OFF Function is turned off.

ECO-1 Mild contrast (recommended)

ECO-2 Even contrast.

DIGITAL VNR

DigiPure

PULL DOWNFEATURES

FEATURES

FEATURES menu

MENU ECO MODE

Note: For component progressive and HDMI signal, the DIGITAL VNR

function cannot operate.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels JVC TV

JVC

JVC AV-28BD5EKI Manuel utilisateur

JVC

JVC I'Art Palette PD-50X795 Manuel utilisateur

JVC

JVC AV-28ED5BN, AV-28ED5SN Manuel utilisateur

JVC

JVC AV-N2172 Manuel utilisateur

JVC

JVC AV 24F702 Manuel utilisateur

JVC

JVC AV-17V214/V Manuel utilisateur

JVC

JVC AV-29DL6SGE Guide de démarrage rapide

JVC

JVC I'Art AV-27MF36 Guide d'installation

JVC

JVC AV-32X5SU Manuel utilisateur

JVC

JVC AV-28H5BL Guide de démarrage rapide

JVC

JVC AV-21F25 Manuel utilisateur

JVC

JVC AV-2100QE Manuel utilisateur

JVC

JVC LT-58VU3005 Manuel utilisateur

JVC

JVC AV-21RT4BU Manuel utilisateur

JVC

JVC AV-2168TEE Manuel utilisateur

JVC

JVC AV28CT1EKS Manuel utilisateur

JVC

JVC AV-1406FE Manuel utilisateur

JVC

JVC Emerald EM32T Manuel utilisateur

JVC

JVC AV-29RS(C-AU) Manuel utilisateur

JVC

JVC AV-20N33 Manuel utilisateur

JVC

JVC COLOUR TELEVISON AV-29LS24 Manuel utilisateur

JVC

JVC AV-28GH1BUF Manuel utilisateur

JVC

JVC LT-49C888 Manuel utilisateur

JVC

JVC AV-32X37SUE Manuel utilisateur

Manuels TV populaires d'autres marques

Philips

Philips Colour Television Manuel utilisateur

Toshiba

Toshiba 27A10 Manuel utilisateur

Philips

Philips 42PF9630A/37 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Philips

Philips Matchline 21CE7551 Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Philips

Philips 25PT4523-16 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Philips

Philips PR0930X3 Manuel utilisateur

Philips

Philips Brilliance 231P4QPY Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Philips

Philips 32HF9385D Guide de dépannage

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Philips

Philips 32PFH5300 Manuel utilisateur
