JVC DR-MV150B - DVDr/ VCR Combo Manuel utilisateur

Included Accessories

Remote control

Audio cable

Video cable

"AAA" battery x 2

(For remote control)

RF cable

Connections

Basic-1 : Antenna or

Wall Jack (Cable TV)

Basic-2 : Cable or

Satellite Box

DR-MV150B

DVD VIDEO RECORDER

Basic Operation

Need Help? Please call the JVC Customer Service

TOLL FREE CUSTOMER CARE HOTLINE: 1(800)252-5722

http://www.jvc.com

QUICK

START

GUIDE

INSTRUCTIONS

pg. 10

DR-MV150B

Antenna or cable

Connect the Antenna, Cable TV, Cable Box

DR-MV150B

AV OUTPUT

(Video/Audio)

Cable or Satellite Box

AV OUTPUT

Video (R) - Audio - (L)

Antenna or cable

In case there are no AV

output, use this connection

ANTENNA IN

(VHF/UHF IN)

ANTENNA OUT

(VHF/UHF OUT)

INPUT1

(Video/Audio)

Cable or Satellite Box without AVOUT

LVT2017-001B

0209SKMLGEEGL

- 1 -

Basic-3 : Connecting To TV

INSTRUCTIONS

pg. 11

AC Outlet

Connect with your TV

After connections,

Power On.

Basic-4 : If your TV has Antenna In Jack only.

DR-MV150B

To TV

(AV INPUT)

ANTENNA

OUT

ANTENNA

OUTPUT

(Video/Audio) AV INPUT

Rear of TV

ANTENNA

OUT

ANTENNA

IN AV INPUT

RF Modulator

(Not Supplied)

ANTENNA

OUT

ANTENNA

OUTPUT

(Video/Audio)

AV INPUT

(Video/Audio)

The TV must be set to the same channel as the output of the RF Modulator.

The TV must be set to EXT-Video, Aux, Video 1, or etc to watch DVD, VCR or Tuner.

You must make this connection.

Necessary if you want to

record and watch different

programs at the same time.

- 2 -

Initial Setup Wizard INSTRUCTIONS

pg. 15

STANDBY/ON

Select Language

Move next step

Press "ENTER"

Finish

Select "Tuning Band"

Moves the cursor to the previous or

next column.

Changes the setting at the current

cursor position.

Set the "Date,Year

and Time"

Press

"STANDBY/ON"

The Remote code must be set correctly. Refer to page 8 of the Instruction.

- 3 -

Select "DVD"

Select "VCR"

BASIC PLAYBACK

DVD VHS

Stop Playback

Playable Discs: DVD-Video, DVD-R, DVD+R, DVD-RW, DVD+RW, DVD-RAM, CD-R, CD-RW,

Video CD, Audio CD, DVD+R DL

(One-Touch Recording)

Start Recording

5Stop Recording

Start Playback

Select Mode

INSTRUCTIONS

pg. 25

BASIC RECORDING INSTRUCTIONS pg. 34

Select "DVD or VCR"

DVD: XP, SP, LP or EP

VCR: SP or SLP

Note:

To playback the recorded disc

with other DVD players, it is

necessary to finalize the disc.

(INSTRUCTIONS pg. 22)

Recordable Discs: DVD-R, DVD+R, DVD-RW, DVD+RW, DVD-RAM

Select Input

(AV1, AV2, DV IN or Ch)

2or Channel

- 4 -

TIMER RECORDING

(Munual Timer Programming) INSTRUCTIONS

pg. 35

Select "Timer

Record"

Select "HOME"

Press "ENTER"

to check on the

Timer Record List

Press "RETURN"

Finish

Select "NEW" and

Press "ENTER"

STANDBY/ON

Enter the necessary information for you timer

recording(s).

Changes the setting at the current cursor position.

Note:

To playback the recorded disc

with other DVD players, it is

necessary to finalize the disc.

(INSTRUCTIONS pg. 22)

- 5 -

Dubbing from VCR to DVD

DVD

VHS

Insert Blank Disc

and Cassette

Find the place

on the VHS tape

from which you

want to start

dubbing.

Access the

Dubbing

menu screen.

Stop Dubbing.

Preparation : Set the resolution to 480i using the OUTPUT STATUS button before dubbing.

Press VCR button to set the VCR mode.

6Start Dubbing.

4Select the desired

Record Mode.

You can copy the contents of a VHS tape to a DVD using the DUBBING

button. This allows you to archive your old VHS tapes to DVD.

INSTRUCTIONS

pg. 37

5Select [Dubbing].

Note:

To playback the recorded disc with other DVD players, it is necessary to finalize the disc.

(INSTRUCTIONS pg. 22)

Select XP, SP, LP or EP

- 6 -
