For canceling the display demonstration, see page 7.
For installation and connections, refer to the separate manual.
INSTRUCTIONS
GET0450-001A
[UI]
KD-DV7304
DVD/CD RECEIVER
Cover_KD-DV7304[UI]f.indd 1Cover_KD-DV7304[UI]f.indd 1 2/13/07 4:04:32 PM2/13/07 4:04:32 PM
2
Caution for DualDisc playback
The Non-DVD side of a “DualDisc” does not comply with
the “Compact Disc Digital Audio” standard. Therefore,
the use of Non-DVD side of a DualDisc on this product
may not e recommended.
Caution on volume setting
Discs and the connected USB devices produce very little
noise compared with other sources. Lower the volume
efore playing to avoid damaging the speakers y the
sudden increase of the output level.
Thank you for purchasing a JVC product.
Please read all instructions carefully efore operation, to ensure your complete understanding and to o tain the est
possi le performance from the unit.
IMPORTANT FOR ASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user servicea le parts inside the unit; leave all servicing to
qualified service personnel.
3. CAUTION: Visi le and/or invisi le class 1M laser radiation when open. Do not view directly with optical
instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
This product incorporates copyright protection
technology that is protected y U.S. patents and
other intellectual property rights. Use of this
copyright protection technology must e authorized
y Macrovision, and is intended for home and
other limited viewing uses only unless otherwise
authorized y Macrovision. Reverse engineering or
disassem ly is prohi ited.
[European Union only]
EN02-07_DV7304[UI]f.indd 2EN02-07_DV7304[UI]f.indd 2 2/13/07 4:04:09 PM2/13/07 4:04:09 PM
3
WARNINGS:
To prevent accidents and damage
• DO NOT install any nit in locations where;
– it may obstr ct the steering wheel and
gearshift lever operations.
– it may obstr ct the operation of safety
devices s ch as air bags.
– it may obstr ct visibility.
• DO NOT operate the nit while driving.
• If yo need to operate the nit while
driving, be s re to look ahead caref lly.
• The driver m st not watch the monitor
while driving.
If the parking brake is not engaged,
“DRIVER MUST NOT WATCH THE MONITOR
WHILE DRIVING.” appears on the monitor,
and no playback pict re will be shown.
– This warning appears only when the
parking brake wire is connected to the
parking brake system b ilt in the car
(refer to the Installation/Connection
Man al).
How to reset your unit
• Your preset adjustments will also be erased (except
the registered Bluetooth device, see page 29).
How to forcibly eject a disc
“PLEASE” and “EJECT” appear alternately on the
display.
• Be care ul not to drop the disc when it ejects.
• I this does not work, reset your unit.
How to use functions mode
If you press M MODE, the unit goes into functions
mode, then the num er uttons (except “1”) and
5/∞ uttons work as different function uttons.
[Within 5 seconds...]
EN02-07_DV7304[UI]f.indd 3EN02-07_DV7304[UI]f.indd 3 2/13/07 4:04:11 PM2/13/07 4:04:11 PM
4
Detaching the control panel Attaching the control panel
For safety...
• Do not raise the volume level too much, as this will
lock outside sounds, making driving dangerous.
• Stop the car efore performing any complicated
operations.
Temperature inside the car...
If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car ecomes
normal efore operating the unit.
CAUTION:
The lever comes out if you pressed the 0 utton while the
panel is detached. If this happens, push the lever ack into lock
position efore attaching the panel.
Lever
Indication lang age:
In this manual, English indications are used for purposes of explanation. You can select the indication language
on the monitor on the “LANGUAGE” setting (see page 42).
EN02-07_DV7304[UI]f.indd 4EN02-07_DV7304[UI]f.indd 4 2/13/07 4:04:12 PM2/13/07 4:04:12 PM
5
CONTENTS
INTRODUCTIONS
Playable disc type ............................................................................................... 6
Preparation ....................................................................................................... 7
OPERATIONS
Basic operations ................................................................................................. 8
• Using the control panel ................................................................................. 8
• Using the remote controller (RM-RK241) ........................................................ 9
istening to the radio .......................................................................................... 12
Disc operations ................................................................................................... 13
istening to the USB device .................................................................................. 26
Dual Zone operations .......................................................................................... 28
EXTERNAL DEVICES
Using the Bluetooth ® devices .............................................................................. 29
• Using the Bluetooth cellular phone ................................................................ 31
• Using the Bluetooth audio player ................................................................... 33
istening to the CD changer ................................................................................. 34
istening to the iPod / D. player ........................................................................... 35
istening to the other external components .......................................................... 36
SETTINGS
Selecting a preset sound mode ............................................................................. 38
General settings — PSM ...................................................................................... 39
Setup menu ........................................................................................................ 42
Bluetooth settings .............................................................................................. 44
Assigning titles ................................................................................................... 45
REFERENCES
Maintenance ...................................................................................................... 46
More about this unit ........................................................................................... 47
Troubleshooting ................................................................................................. 53
Specifications ..................................................................................................... 57
EN02-07_DV7304[UI]f.indd 5EN02-07_DV7304[UI]f.indd 5 2/13/07 4:04:12 PM2/13/07 4:04:12 PM
6
Playable disc type
Disc type Recording format, file type, etc Playable
DVD DVD-Video (Region Code num ers include “5”) *1
DVD-Audio
DVD-ROM
DVD Recordable/Rewritable
(DVD-R *2/-RW, +R/+RW *3)
• DVD Video: UDF ridge
• DVD-VR: UDF 201
• DivX/MPEG-1/MPEG-2/MP3/
WMA/WAV: Compliant to ISO
9660 level 1, level 2, Romeo,
Joliet
DVD-Video
DVD-VR (non-CPRM only)
DivX/MPEG-1/MPEG-2 Video
MP3/WMA/WAV
DVD+VR
JPEG/MPEG4
DVD-RAM All
D al Disc DVD side
Non-DVD side
CD/VCD Audio CD/CD Text (CD-DA)/DTS-CD *4
VCD (Video CD)
CD-ROM
CD-I (CD-I Ready)
CD Recordable/Rewritable
(CD-R/-RW)
• Compliant to ISO 9660 level 1,
level 2, Romeo, Joliet
CD-DA
DivX/MPEG-1/MPEG-2 Video
MP3/WMA/WAV
JPEG/MPEG4
*1 I you insert a DVD Video disc o an incorrect Region Code, “REGION CODE ERROR!” appears on the monitor.
*2 DVD-R recorded in multi-border ormat is also playable (except or dual layer discs).
*3 It is possible to play back inalized +R/+RW (Video ormat only) discs. However, the use o +R double layer disc on
this unit is not recommended.
*4 To reproduce DTS sound, use the DIGITAL OUT terminal (see also pages 43, 50, and 51).
EN02-07_DV7304[UI]f.indd 6EN02-07_DV7304[UI]f.indd 6 2/13/07 4:04:12 PM2/13/07 4:04:12 PM
7INTRODUCTIONS
Preparation
Cancel the display demonstration and set the clock
• See also page 40.
~ T rn on the power.
Ÿ Enter the PSM settings.
! ] ⁄ Cancel the display demonstrations
Select “DEMO,” then “DEMO OFF.”
Set the clock
Select “CLOCK H” (hour), then adjust the hour.
Select “CLOCK M” (minute), then adjust the minute.
@ Finish the proced re.
When the power is turned off: Check the current clock time
When the power is turned on: Change the display information
EN02-07_DV7304[UI]f.indd 7EN02-07_DV7304[UI]f.indd 7 2/13/07 4:04:13 PM2/13/07 4:04:13 PM
8
Basic operations
Using the control panel
1 Select the source.
FM/AM = DISC * = USB = CD-CH */IPOD */
D.PLAYER * (or EXT IN) = BT-PHONE (Bluetooth
Phone) * = BT-AUDIO (Bluetooth Audio) * =
LINE IN = (back to the beginning)
* You cannot select these sources if they are not
ready or not connected.
2 • FM/AM: Select the bands.
• DISC/USB: Start playback.
3 • Turn on the power.
• Turn off the power Hold].
• Attenuate the sound (if the power is on).
• Volume control Turn].
4 • Adjust the sound mode.
• Enter the PSM settings Hold].
5 Display window
6 Select the sound mode.
7 Eject disc.
8 USB (Universal Serial Bus) input terminal
9 Detach the panel.
p Change the display information.
q Enter functions mode.
Press M MODE, then one of the following buttons
(within 5 seconds)...
MO : Turn on/off monaural reception.
SSM : Automatic station presetting Hold].
DUAL : Activate/deactivate Dual Zone.
RPT : Select repeat play.
RND : Select random play.
5 / ∞ : Skip 10 chapters/tracks.
w • FM/AM: Select preset station.
• DISC/USB: Select chapter/title/program/folder/
track/disc (for CD changer).
• BT-PHONE: Select preset phone number.
e • FM/AM: Search for station.
• DISC/USB: Select chapter/track.
• IPOD/D.PLAYER: Select track.
• BT-PHONE/BT-AUDIO: Select setting item/
Select a registered device.
r • FM/AM: Select preset station.
• DISC/USB: Select title/program/playlist/folder.
• IPOD/D.PLAYER: Enter the main menu/Pause or
stop playback/Confirm selection.
• BT-PHONE/BT-AUDIO: Pause or start playback/
Enter setting menu/Confirm selection.
EN08-15_DV7304[UI]f.indd 8EN08-15_DV7304[UI]f.indd 8 2/13/07 4:03:56 PM2/13/07 4:03:56 PM
9OPERATIONS
Before usin the remote controller:
• Aim the remote controller directly at the remote
sensor on the unit.
• DO NOT expose the remote sensor to bright light
(direct sunlight or artificial lighting).
Display window
Using the remote controller (RM-RK241)
Installin the lithium coin battery (CR2025)
Continued on the next page
Remote sensor
1 Playback source indicators
2 Loudness indicator
3 Track information indicators
4 Sound mode indicators
• lights up for the selected item.
5 Tuner reception indicators
6 Playback mode/item indicators
(Random/Repeat)
7 Equalizer indicator
8 Bluetooth indicator
9 Dual Zone indicator
p Main display
(Time, menu, playback information)
q Track indicator
w Source display/Preset No./Track No./Folder No./
Disc No./Chapter No.
e Status of Bluetooth device
(Device number, 1 – 5]; signal strength, 0 – 3]*;
battery reminder, 0 – 3]*)
* As the number increases, the signal/battery
strength becomes stronger.
EN08-15_DV7304[UI]f.indd 9EN08-15_DV7304[UI]f.indd 9 2/13/07 4:03:58 PM2/13/07 4:03:58 PM
10
Warnin :
To prevent accidents and dama e
• Do not install any battery other than CR2025 or its
equivalent.
• Do not leave the remote controller in a place
(such as dashboards) exposed to direct sunlight
for a long time.
• Store the battery in a place where children cannot
reach.
• Do not recharge, short, disassemble, heat the
battery, or dispose of it in a fire.
• Do not leave the battery with other metallic
materials.
• Do not poke the battery with tweezers or similar
tools.
• Wrap the battery with tape and insulate when
throwing away or saving it.
IMPORTANT:
If Dual Zone is activated (see page 28), the remote
controller only functions for operating the DVD/CD
player.
EXTRA MONITOR
1 Monitor control buttons
• Used for a JVC monitor—KV-MR9010,
KV-MH6510, KV-M706, or KV-M705.
DVD/RECEIVER
2 • Turns the power on if pressed briefly or
attenuates the sound when the power is on.
• Turns the power off if pressed and held.
3 Selects the source.
4 Selects the FM/AM bands.
5 Not applicable for this unit.
6 Activates or deactivates Dual Zone.
7 Adjusts the volume level.
• Also functions as 2nd VOL button when
pressed with SHIFT button (see page 28).
8 *1 • DVD-Video/DivX: Shows disc menu.
• DVD-VR: Shows the ORIGINAL PROGRAM
screen.
• VCD: Starts PBC playback.
9 *1 Enters disc setup menu.
p SHIFT button
q For disc/USB operations:
• 7 : Stops playback.
•
3 : Starts playback.
• 8 : Pauses.
For Bluetooth operations:
•
7 : Ends the call for phone operations.
• 3 : Answers the incoming call for phone
operations.
•
3 also function as ZOOM button when
pressed with SHIFT button (see page 21).
• Not applicable for CD changer/iPod/D. player
operations.
EN08-15_DV7304[UI]f.indd 10EN08-15_DV7304[UI]f.indd 10 2/13/07 4:03:59 PM2/13/07 4:03:59 PM
Table des matières
Autres manuels JVC Récepteur de voiture
JVC
JVC KS-FX8RE Manuel utilisateur
JVC
JVC KW-AVX720 - DVD Player With LCD Manuel utilisateur
JVC
JVC KD-R811 Mode d’emploi
JVC
JVC KS-LH4R Manuel utilisateur
JVC
JVC KD-G333 Manuel utilisateur
JVC
JVC KD-ADV5490 Manuel utilisateur
JVC
JVC KD-R506 Manuel utilisateur
JVC
JVC KS-FX12 Manuel utilisateur
JVC
JVC KS-FX202 Manuel utilisateur
JVC
JVC KD-SX1500R Manuel utilisateur
JVC
JVC KW-XG701E Manuel utilisateur
JVC
JVC KD-PDR45 Manuel utilisateur
JVC
JVC KS-FX12J Mode d’emploi
JVC
JVC Navigation/CD Receiver KD-NX1R Manuel utilisateur
JVC
JVC KDSX770 - In-Dash CD Player Mode d’emploi
JVC
JVC GET0067-001A Manuel utilisateur
JVC
JVC CD Receiver KD-G387 Mode d’emploi
JVC
JVC KW-XC828 Manuel utilisateur
JVC
JVC KD-S100 - CD Receiver Mode d’emploi
JVC
JVC Exad KD-AVX33 Manuel utilisateur
