SERVICE MANUAL

2005/4

COMPACT VHS CAMCORDER

YF07420054

GR-AXM287UM, GR-SXM289UA,

GR-SXM289UB, GR-SXM289UM

For disassembling and assembling of MECHANISM ASSEMBLY, refer to the SERVICE MANUAL No.86700 (MECHANISM ASSEMBLY).

Regarding service information other than these sections, refer to the service manual No. YF073 (GR-SXM37US).

Also, be sure to note important safety precautions provided in the service manual.

TABLE OF CONTENTS

1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

GR-AXM287UMM[M5A622]

GR-SXM289UAM, GR-SXM289UBM,

GR-SXM289UMM[M5C623]

1-2 (No.YF074)

SPECIFICATION

AC Adapter

Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject to change without notice.

General Format VHS (GR-AXM287 only) / S-VHS NTSC standard

Power source DC 11 V (Using AC Adapter)

DC 6 V (Using battery pack)

Power consumption Viewfinder on 3.5 W

LCD monitor on 4.3 W

Video light* 0.4 W

* Applicable models only.

Signal system NTSC-type

Video recording system Luminance FM recording

Colour Converted sub-carrier direct recording Conforms to VHS standard

Cassette / cassette

Tape speed SP 33.35 mm/sec.(1-5/16 ips)

EP 11.12 mm/sec.(7/16 ips)

Recording time (max.) SP 40 minutes

EP 120 minutes (with TC-40 cassette)

Operating temperature 0°C to 40°C(32°F to 104°F)

Operating humidity 35% to 80%

Storage temperature -20°C to 50°C(-4°F to 122°F)

Weight Approx. 770 g

Dimensions (W ×H ×D) 81 mm ×125 mm ×216 mm(3-1/4” ×4-15/16” ×8-9/16”)

(with the LCD monitor closed and with the viewfinder fully tilted downward)

Pickup 1/6" format CCD

Lens F1.8 f = 2.2 mm to 44 mm, 20:1 power zoom lens with auto iris and macro con-

trol filter diameter 30.5 mm(GR-AXM287 only) /

F1.8 f = 2.2 mm to 55 mm, 25:1 power zoom lens with auto iris and macro con-

trol filter diameter 30.5 mm

Viewfinder Electronic viewfinder with black/white LCD

White balance adjustment Auto/Manual adjustment

Connectors Video 1 V (p-p), 75 Ωunbalanced, analogue output (via Video output connector)

Audio 300 mV (rms), 1 kΩ, analogue output (via Audio output connector)

S-Video* Y : 1 V (p-p), 75 Ω, analog output

C : 0.29 V (p-p), 75 Ω, analog output

* Applicable models only.

Power requirement U.S.A and Canada AC 120 V to 60 V~

Other countries AC 110 V to 240 V~, 50 Hz/60 Hz

Output DC 11 V, 1 A

(No.YF074)1-3

SECTION 1

PRECAUTION

Please refer to "GR-SXM37US No.YF073" about this section.

SECTION 2

SPECIFIC SERVICE INSTRUCTIONS

2.1 DIFFERENCE LIST

The following table indicate main different points between models GR-SXM37US, GR-AXM287UM, GR-SXM289UA, GR-

SXM289UB and GR-SXM289UM.

SECTION 3

DISASSEMBLY

Please refer to "GR-SXM37US No.YF073" about this section.

SECTION 4

ADJUSTMENT

Please refer to "GR-SXM37US No.YF073" about this section.

SECTION 5

TROUBLESHOOTING

Please refer to "GR-SXM37US No.YF073" about this section.

MODEL GR-SXM37US GR-AXM287UM GR-SXM289UA GR-SXM289UB GR-SXM289UM

TAPE FORMAT S-VHS-C VHS-C S-VHS-C S-VHS-C S-VHS-C

VIDEO LIGHT YES NO YES YES YES

S OUTPUT YES NO YES YES YES

AC ADAPTER AP-V16U AP-V16U AP-V14UA AP-V14E AP-V16U

AC CORD NO NO YES(IRAM PLUG) YES(SASO PLUG) NO

A / V CABLE OPTIONAL PROVIDED OPTIONAL PROVIDED OPTIONAL

CASSETTE ADAPTER OPTIONAL OPTIONAL PROVIDED(C-P8U) OPTIONAL PROVIDED(C-P8U)

(No.YF074)

AV & MULTIMEDIA COMPANY CAMCORDER CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan

Victor Company of Japan, Limited

VPT

Printed in Japan
