JVC GR-AX841U Manuel utilisateur

February 1999

GR-AX841U

Regarding service information other than these sections, refer to the GR-AX940U service manual (No. 86446).

Also, be sure to note important safety precautions provided in the service manual.

COMPACT VHS CAMCORDER

SPECIFICATIONS

4. CHARTS AND DIAGRAMS

4.12 MAIN CIRCUIT BOARD...................................................................................................................................4-23

5. PARTS LIST

5.2 FINALASSEMBLY <M2> ...................................................................................................................................5-3

5.3 MECHANISM ASSEMBLY <M3> ....................................................................................................................... 5-6

5.4 ELECTRONIC VIEWFINDER ASSEMBLY <M4> ..............................................................................................5-8

TABLE OF CONTENTS

The following table indicate main different points between models GR-AX940U and GR-AX841U.

ZOOM 100X 50X

GR-AX940U GR-AX841U

MODEL

ITEM

The following table indicate different parts number between models GR-AX940U and GR-AX841U.

PACKING ASSEMBLY <M1>

Note: Mark – is not used.

2 PACKING CASE LY30905-018A LY30905-062A

5 INST. BOOK (EN) LYT0259-001A LYT0356-001A

MODEL

ITEM

REF. NO.

FINAL ASSEMBLY <M2>

101 LOWER CASE ASSY LY10122-009B LY10122-024A

101P SHEET. A – LY41444-001A

106 FRONT COVER ASSY LY10124-010C LY10124-030B

110 TOP COVER LY10129-016B LY10129-060A

MODEL

ITEM

REF. NO.

MECHANISM ASSEMBLY <M3>

480 SPECIAL SCREW – LY40320-002A

MODEL

ITEM

REF. NO.

GR-AX940U GR-AX841U

Note: Mark – is not used.

ELECTRONIC VIEWFINDER ASSEMBLY <M4>

361 SPACER-A – LY30016-0M7A

MODEL

ITEM

REF. NO.

MAIN BOARD ASSEMBLY <01>

PW MAIN BOARD ASSY YB10243UC-01 YB10243UG-02

IC4006 IC TMS4C2973-28-X –

Q2061 TRANSISTOR 2SC4617/QR/-X –

Q2062 TRANSISTOR 2SC4617/QR/-X –

R2061 MG RESISTOR NRSA63J-103X –

R2062 MG RESISTOR NRSA63J-104X –

R2063 MG RESISTOR NRSA63J-104X –

R2064 MG RESISTOR NRSA63J-104X –

R2065 MG RESISTOR NRSA63J-183X NRSA63J-0R0X

C2061 CAPACITOR NCB21EK-104X –

C2062 CAPACITOR NCF21CZ-105X –

C4037 CAPACITOR NCF31EZ-104X –

C4038 CAPACITOR NCF31EZ-104X _

MODEL

ITEM

REF. NO.

GR-AX940U GR-AX841U

SECTION 4

CHARTS AND DIAGRAMS

4.12 MAIN CIRCUIT BOARD

4-23

4-24

FOIL SIDE (B)

CAUTION:

FOR CONTINUED PROTECTION AGAINST

FIRE HAZARD, REPLACE ONLY WITH SAME

TYPE AND RATED FUSE.

ATTENTION:

POUR UNE PROTECTION PERMANENTE

CONTRE LES RISQUE D’INCENDE,

REMPLACER LE FUSIBLE PAR UN AUTRE

DE MEME TYPE ET DE MEME TENSION.

4-25

COMPONENT PARTS LOCATION GUIDE (MAIN)

REF.No. LOCATION REF.No. LOCATION REF.No. LOCATION REF.No. LOCATION REF.No. LOCATION REF.No. LOCATION REF.No. LOCATION

C101 A C 4B

C102 B C 4C

C103 A C 2A

C104 A C 3B

C105 A C 4B

C106 A C 4B

C107 B C 3A

C108 B C 1B

C109 A C 3B

C110 A C 3B

C111 B C 1B

C112 A C 2B

C113 A C 2B

C114 A C 4B

C115 A C 4C

C116 B C 3A

C117 B C 3A

C118 B C 3A

C119 A C 4C

C120 B C 4C

C121 A C 3A

C122 A C 3A

C123 A C 2A

C124 B C 1A

C125 B C 1A

C126 B C 1A

C127 B C 1A

C128 B C 1A

C129 B C 2A

C130 B C 2B

C131 B C 3A

C132 A C 2B

C133 A C 3B

C134 A C 3B

C135 A C 3A

C136 A C 3A

C137 A C 3A

C138 A C 2A

C139 A C 2A

C140 A C 2B

C141 B C 3B

C142 B C 5C

C143 A C 2B

C144 B C 3A

C145 B C 3A

C146 A C 3A

C147 A C 4A

C1201 A C 4C

C1202 A C 4D

C1204 B C 4D

C1205 B C 4D

C1206 B C 4D

C1601 A C 4D

C1602 A C 5E

C1603 A C 5D

C1604 A C 5E

C1605 A C 5E

C1606 B C 5E

C1607 B C 5E

C1608 B C 5E

C1609 B C 5E

C1610 A C 5D

C1611 B C 4E

C1612 B C 4E

C1613 B C 4E

C1614 B C 4E

C1615 A C 4E

C1616 A C 4E

C1617 A C 4D

C1618 B C 5D

C1619 B C 5D

C1620 B C 5D

C1621 A C 5D

C1622 B C 5D

C1623 B C 5D

C1624 B C 5E

C1625 B C 5E

C1626 B C 5E

C1627 B C 5E

C1628 B C 5E

C1629 A C 5E

C1630 B C 5E

C1631 B C 5D

C1632 A C 5E

C1633 A C 5D

C1634 B C 4E

C1635 B C 4E

C1636 B C 4E

C1801 A C 2D

C1802 B C 2D

C1803 A C 2E

C1804 B C 1E

C1805 A C 2D

C1806 A C 2E

C1807 B C 1D

C1808 A C 2D

C1809 B C 2D

C2001 B C 4D

C2002 A C 4D

C2003 A C 4D

C2004 A C 4D

C2005 A C 4D

C2006 B C 4D

C2008 A C 6B

C2009 A C 6B

C2010 A C 6A

C2021 B C 6A

C2022 B C 6A

C2024 B C 6A

C2025 A C 6A

C2026 A C 6A

C2027 A C 6A

C2028 A C 6A

C2029 A C 6A

C2030 A C 6A

C2031 A C 6A

C2032 A C 6A

C2051 B C 1C

C2052 B C 1C

C2061 A C 6A

C2062 A C 6A

C2063 A C 6A

C2071 A C 5B

C2072 A C 5B

C2073 A C 5B

C2074 A C 5B

C2075 A C 5B

C2076 A C 5B

C2077 A C 5B

C2078 A C 6B

C2079 A C 6B

C2080 A C 6B

C2081 A C 5B

C2401 B C 6E

C2402 B C 6E

C2403 B C 6E

C2404 B C 6E

C2405 B C 6D

C2406 B C 6D

C2407 B C 6D

C2408 B C 7D

C2409 B C 7E

C2410 B C 7D

C2411 B C 7E

C2412 A C 6E

C2413 B C 7E

C2414 B C 7E

C2415 A C 6E

C2416 B C 6D

C2417 B C 6D

C2419 B C 6E

C2420 B C 6E

C2421 A C 6E

C2422 B C 6E

C2423 B C 6D

C3001 B C 6A

C3002 B C 6A

C3003 B C 6A

C3004 B C 6A

C3005 B C 6A

C3006 A C 6A

C3007 A C 7A

C3008 B C 7A

C3009 B C 7A

C3010 B C 7A

C3011 B C 7A

C3012 B C 7A

C3013 B C 7A

C3014 B C 7A

C3015 B C 7A

C3016 B C 7A

C3017 B C 7A

C3018 A C 7A

C3019 B C 7A

C3021 B C 7B

C3022 B C 7B

C3023 B C 7B

C3024 B C 7B

C3025 B C 7B

C3026 B C 6B

C3027 A C 6B

C3029 B C 6B

C3030 A C 6B

C3031 A C 6B

C3032 A C 6B

C3033 A C 6B

C3034 A C 6B

C3035 A C 6B

C3036 B C 5B

C3037 B C 6B

C3038 B C 6B

C3039 B C 6B

C3040 B C 6A

C3041 B C 6A

C3042 A C 6B

C3043 B C 6B

C3044 B C 6A

C3045 B C 5B

C3046 B C 5B

C3047 B C 5B

C3048 A C 7A

C3049 B C 5B

C3101 A C 7B

C3102 A C 7A

C3103 A C 7B

C3104 A C 7B

C3105 A C 7B

C3106 A C 7B

C3107 A C 7B

C3108 A C 7B

C3109 A C 7B

C3110 A C 7B

C3111 B C 2C

C3112 A C 7A

C3113 A C 1A

C3114 A C 7A

C3201 B C 8A

C3202 A C 7B

C3206 B C 8B

C3207 B C 7B

C3208 B C 8B

C3209 B C 7B

C3210 B C 8B

C3211 B C 7B

C3212 B C 8B

C3213 B C 7B

C3214 B C 7B

C3215 B C 8B

C3216 B C 8B

C3217 B C 8B

C3218 B C 8B

C3219 B C 8B

C3220 B C 8C

C3221 B C 8A

C3222 A C 7B

C3223 A C 8B

C3224 A C 8B

C3250 A C 7B

C3252 A C 7B

C3253 B C 2B

C3254 B C 1B

C3301 A C 7D

C3302 A C 8C

C3303 B C 8C

C3304 B C 8C

C3305 A C 8C

C3306 B C 8C

C3307 B C 8C

C3308 B C 8C

C3309 B C 8C

C3310 B C 8C

C3311 B C 8C

C3312 A C 8C

C3501 A C 5A

C3502 A C 5A

C3503 B C 5A

C3504 A C 5A

C3505 A C 5A

C3506 B C 5A

C3507 B C 5A

C3508 A C 5A

C3509 A C 5A

C3510 B C 5A

C3511 B C 5A

C3512 B C 5A

C3513 B C 5A

C3514 A C 5A

C3515 B C 5A

C3516 B C 5A

C3517 A C 5A

C3518 B C 5A

C3519 B C 5A

C3520 B C 5A

C3521 B C 5A

C3522 A C 5A

C3523 B C 5A

C3524 B C 5A

C3525 B C 5A

C3526 A C 5A

C3527 A C 5A

C3901 A C 4A

C3902 A C 4A

C3903 A C 4A

C3904 B C 4A

C3905 B C 4A

C3906 A C 4A

C3907 A C 4A

C3908 B C 4A

C4001 A C 3C

C4002 A C 3C

C4003 A C 3B

C4004 A C 3B

C4005 A C 3B

C4006 A C 3B

C4007 A C 3B

C4008 B C 3C

C4009 A C 2B

C4010 A C 1B

C4011 A C 2B

C4012 A C 2C

C4013 A C 1B

C4014 A C 2B

C4015 A C 2B

C4016 A C 2C

C4017 A C 2C

C4018 A C 3C

C4021 B C 3C

C4022 A C 3C

C4023 A C 3C

C4024 B C 3B

C4025 B C 3C

C4026 B C 3C

C4027 A C 3C

C4032 B C 3D

C4033 B C 3C

C4034 B C 3C

C4037 B C 2B

C4038 B C 2C

C4040 A C 1C

C4041 A C 2B

C4042 B C 2C

C4043 B C 3B

C4044 B C 3C

C4201 A C 1D

C4202 A C 1D

C4203 B C 1C

C4204 B C 1C

C4205 A C 1C

C4206 A C 1C

C4207 A C 1C

C4208 B C 2D

C4209 B C 1C

C4210 B C 2D

C4211 A C 1D

C4212 B C 1D

C4213 A C 1C

C4214 B C 2D

C4215 B C 2D

C4301 B C 2C

C4501 B C 2D

C4502 B C 3E

C4503 A C 2D

C4504 B C 2D

C4505 B C 3E

C4506 B C 3E

C4507 B C 3E

C4508 B C 3E

C4509 B C 3E

C4510 B C 3D

C4511 B C 3E

C4512 B C 2D

C5201 B C 2D

C5202 B C 2C

C5203 B C 3C

C5204 B C 3C

C5205 B C 3C

C5206 B C 3D

C5207 A C 3D

C5210 A C 3D

C5211 A C 3D

C5212 B C 3D

C5214 A C 3D

C5215 B C 3D

C5216 B C 3D

C5217 A C 3D

C5218 B C 2C

C5219 B C 3C

C5220 B C 2C

C5221 A C 2D

C5222 A C 2D

C5223 B C 2D

C5224 A C 2D

C5225 A C 2D

C5226 A C 2D

C5227 B C 2C

C5228 A C 2D

C5229 A C 2D

C5230 A C 2D

C5231 A C 2D

C5234 A C 2D

C5235 B C 2D

C5237 B C 3C

C5239 B C 2D

C5240 B C 2D

C5241 A C 2D

C5242 B C 2C

C6001 A C 7C

C6002 A C 7C

C6003 B C 6C

C6004 B C 6C

C6005 B C 6C

C6006 B C 7C

C6007 B C 7C

C6008 B C 7C

C6009 B C 7C

C6010 B C 7C

C6011 A C 6D

C6012 B C 7C

C6013 B C 7C

C6014 B C 7C

C6015 B C 7C

C6016 B C 7C

C6017 B C 7C

C6018 B C 7C

C6019 B C 6C

C6020 B C 6C

C6021 B C 6C

C6022 B C 6C

C6023 B C 6C

C6024 B C 6C

C6025 B C 6C

C6026 B C 6B

C6027 B C 6B

C6028 B C 6C

C6029 B C 7B

C6030 A C 6D

C6032 B C 6C

C6033 B C 6C

C6034 B C 6C

C6035 B C 6C

C6036 B C 6C

C6037 B C 6C

C6038 B C 7C

C6039 B C 6D

C6040 B C 6D

C6041 A C 7C

C6042 A C 7C

C6043 A C 7C

C6044 A C 7C

C6045 A C 7C

C6046 A C 7D

C6047 B C 6D

C6048 B C 5D

C6049 A C 7C

C6050 A C 7D

C6051 B C 7C

C6052 A C 6D

C6053 B C 7D

C6054 B C 6E

C6201 A C 6D

C7101 A C 7E

C7102 A C 7D

C7103 A C 7D

C7104 A C 7D

C7105 A C 7E

C7106 B C 7D

C7107 B C 7D

C7108 A C 7D

C7109 B C 7D

C7112 B C 7D

CN1 A C 4A

CN2 A C 8A

CN3 A C 4D

CN4 A C 2A

CN5 A C 5A

CN7 A C 3D

CN8 A C 5B

CN11 A C 7D

CN12 B C 7D

CN13 A C 8C

CN14 A C 6D

CN15 A C 2E

CN16 A C 7E

CN18 A C 4E

CN19 B C 2A

CN22 A C 3D

CN25 A C 4C

CN26 A C 5B

CN27 B C 7E

D101 B C 3B

D102 B C 3B

D103 B C 4A

D104 B C 4A

D501 A C 8B

D502 A C 8B

D503 A C 8B

D504 A C 7B

D505 A C 8B

D506 A C 8B

D1801 A C 2E

D3101 A C 2A

D3102 A C 2A

D3103 A C 2A

D3104 B C 1C

D3201 B C 8A

D3202 A C 8A

D3251 B C 1B

D3252 B C 1B

D3301 B C 8C

D5201 A C 3D

D6001 B C 6D

D6002 A C 7C

D6003 A C 7C

D6004 A C 7C

D6005 A C 7C

D7101 A C 7E

DA101 B C 2B

DA105 B C 4A

DA107 A C 4A

IC101 A C 3A

IC102 B C 4C

IC103 A C 2A

IC104 B C 2B

IC105 B C 2B

IC107 B C 4C

IC108 B C 3A

IC109 B C 1A

IC110 A C 2B

IC111 B C 2B

IC112 B C 2B

IC1201 B C 4C

IC1601 B C 5E

IC1801 A D 2D

IC1802 B C 2E

IC2071 A C 5B

IC2401 B C 6E

IC3001 B C 6A

IC3101 A C 7B

IC3102 A C 7B

IC3103 A C 7B

IC3201 B C 7B

IC3202 A C 8B

IC3251 A C 1A

IC3301 B C 8C

IC3302 B C 8C

IC3501 B C 5A

IC4001 A C 2C

IC4002 A C 2B

IC4003 B C 3C

IC4005 B C 3C

IC4006 B C 2C

IC4201 B C 2D

IC4202 B C 1C

IC4203 A C 1C

IC4301 B C 2C

IC4501 B C 2E

IC5201 B C 3D

IC5202 A C 2D

IC5203 B C 2C

IC6001 B C 7C

IC6002 B C 7C

IC7101 A C 7E

IC7102 A C 7D

IC7103 B C 7D

L101 B C 4C

L102 B C 1A

L501 A C 8B

L2001 B C 4D

L2002 B C 5B

L2051 B C 1C

L2052 B C 1C

L2071 A C 5B

L2072 A C 5B

L2401 A C 6E

L3001 B C 6A

L3003 A C 7A

L3004 A C 6B

L3005 A C 6B

L3006 B C 5B

L3007 B C 5B

L3101 A C 7A

L3102 A C 1A

L3201 A C 8B

L3202 B C 8A

L3301 A C 7B

L3501 A C 5A

L3502 A C 5A

L3901 A C 4A

L3902 A C 4A

L3903 A C 4A

L3904 B C 4A

L4001 A C 1B

L4002 B C 3D

L4201 B C 2D

L4501 B C 2C

L4502 B C 2D

L4503 B C 2D

L5201 B C 3C

L5203 B C 2D

L5204 B C 2D

L6001 A C 6C

L6002 A C 6C

L6003 A C 6C

L6004 A C 6C

L6005 A C 6C

L6006 A C 6C

L6007 B C 7C

L6008 B C 6E

L7101 B C 7D

L7103 B C 7D

Q101 B C 3B

Q102 B C 3B

Q105 B C 4C

Q106 B C 4C

Q107 B C 4C

Q108 B C 4C

Q109 A C 7A

Q110 A C 7A

Q111 A C 7A

Q112 A C 7A

Q113 A C 8C

Q1801 A D 2D

Q1802 B C 2E

Q2001 B C 4D

Q2002 B C 4D

Q2003 B C 5D

Q2004 A C 4D

Q2005 B C 4D

Q2006 B C 4D

Q2007 A C 4C

Q2008 A C 4C

Q2009 A C 4D

Q2011 A C 6A

Q2012 A C 6A

Q2013 A C 6A

Q2014 A C 6A

Q2015 A C 6A

Q2061 A C 6A

Q2062 A C 6A

Q2401 B C 6D

Q2402 A C 7E

Q2403 A C 6E

Q2404 A C 6E

Q2408 B C 6E

Q3002 B C 7A

Q3003 B C 7A

Q3004 B C 7A

Q3005 B C 7A

Q3006 A C 7B

Q3007 B C 6B

Q3008 B C 6B

Q3009 B C 5B

Q3011 B C 6A

Q3012 A C 7A

Q3101 A C 7A

Q3102 A C 7A

Q3103 A C 7A

Q3104 A C 1A

Q3105 A C 1A

Q3106 A C 7B

Q3107 B C 5B

Q3201 B C 8A

Q3202 B C 8A

Q3203 B C 8A

Q3204 B C 8A

Q3205 B C 8A

Q3206 B C 8A

Q3207 A C 8A

Q3208 A C 8A

Q3209 B C 8B

Q3210 A C 8A

Q3211 A C 8B

Q3212 B C 7B

Q3213 B C 8A

Q3301 A C 8C

Q3302 A C 8C

Q3303 B C 8C

Q3304 B C 8C

Q3305 B C 8C

Q3306 B C 8C

Q3501 A C 5A

Q3502 A C 5A

Q3503 A C 5A

Q3506 A C 5A

Q3507 A C 5A

Q3508 A C 5A

Q3509 B C 5A

Q3901 B C 4A

Q3903 B C 4A

Q3904 A C 4A

Q3905 B C 4A

Q3906 B C 4A

Q4001 B C 3B

Q4002 B C 3C

Q4005 B C 3C

CAPACITOR

CONNECTOR

DIODE

COIL

TRANSISTOR

4-26

REF.No. LOCATION REF.No. LOCATION REF.No. LOCATION REF.No. LOCATION REF.No. LOCATION REF.No. LOCATION REF.No. LOCATION

Q4006 A C 4C

Q4007 A C 4C

Q4201 B C 2C

Q4202 B C 2D

Q4203 B C 3D

Q4501 A C 3E

Q4502 A C 2E

Q6001 B C 6B

Q6002 B C 6C

Q6003 B C 6C

Q6004 B C 6D

Q6005 B C 6D

Q6006 B C 6D

Q6007 A C 7C

Q6008 A C 7C

Q6009 A C 7C

Q6201 B C 6D

Q6202 B C 6E

Q6203 A C 6E

QA1601

BC 4E

QA1602

BC 4E

R101 A C 2A

R102 B C 3B

R103 B C 3B

R104 B C 3B

R105 B C 3B

R106 B C 3B

R107 B C 4B

R108 B C 2B

R109 A C 2A

R110 A C 3B

R111 A C 3B

R112 B C 2B

R113 A C 4B

R114 A C 3B

R115 A C 4B

R116 A C 2B

R117 A C 2B

R118 A C 3A

R119 B C 3A

R120 A C 2B

R121 B C 4C

R122 A C 3B

R123 B C 1A

R124 A C 3B

R125 B C 3A

R126 B C 3A

R127 A C 3A

R128 B C 4C

R129 B C 4C

R130 B C 4C

R131 A C 3A

R132 A C 7A

R133 A C 7A

R134 A C 7A

R135 B C 3A

R136 A C 2B

R137 B C 3A

R138 A C 2A

R139 A C 3A

R140 A C 2A

R141 B C 1A

R142 B C 2B

R143 B C 2A

R144 B C 2A

R145 B C 2A

R146 B C 2B

R147 B C 3A

R148 B C 3A

R149 B C 3A

R150 B C 3A

R151 B C 3A

R152 B C 3A

R153 B C 3A

R154 B C 3A

R155 B C 3A

R156 A C 2A

R157 B C 4A

R158 B C 4A

R159 B C 4A

R160 B C 3B

R161 B C 3B

R162 B C 3B

R163 A C 3B

R165 B C 3A

R166 A C 3A

R167 A C 3A

R168 B C 3A

R169 B C 4B

R170 B C 4B

R171 B C 2B

R172 B C 2B

R173 B C 4B

R174 A C 2A

R178 A C 3A

R179 A C 4A

R180 A C 3A

R181 A C 3A

R182 A C 2B

R183 A C 2B

R184 A C 7A

R185 A C 2A

R186 A C 2B

R187 A C 2A

R188 A C 3A

R189 A C 3A

R190 B C 4B

R191 B C 5C

R192 A C 3A

R193 B C 3B

R194 A C 3B

R195 A C 8C

R501 A C 8C

R502 A C 8C

R503 B C 1B

R504 A C 8B

R505 A C 8B

R1201 B C 4C

R1202 B C 4C

R1203 B C 4D

R1204 B C 4D

R1601 A C 5E

R1602 A C 5E

R1603 B C 5E

R1604 B C 5E

R1605 B C 5E

R1606 B C 4E

R1607 B C 4E

R1608 B C 4E

R1609 A C 5D

R1610 A C 4E

R1611 A C 4E

R1612 A C 5D

R1613 A C 5D

R1614 B C 5D

R1615 A C 5D

R1616 A C 5D

R1617 B C 5E

R1618 B C 5E

R1619 B C 5E

R1620 A C 5E

R1621 A C 5E

R1622 A C 5E

R1623 B C 6E

R1624 B C 6E

R1625 A C 5D

R1626 A C 4E

R1627 A C 4E

R1628 A C 4E

R1629 A C 5E

R1630 B C 5D

R1631 B C 5D

R1801 B C 1D

R1802 B C 2E

R1803 B C 2E

R1804 B C 2D

R1805 A C 2E

R1806 A C 2E

R1807 A C 2E

R1808 A C 2E

R1809 A C 2E

R1810 A C 2D

R1811 B C 2D

R1812 B C 2D

R1813 B C 1D

R1814 A C 1D

R1815 A C 2D

R1816 B C 2E

R2001 B C 4D

R2002 B C 4D

R2003 B C 4D

R2004 B C 4D

R2005 B C 4D

R2006 B C 4D

R2007 A C 4D

R2008 A C 4D

R2009 A C 4D

R2010 B C 4D

R2011 A C 4C

R2012 A C 4C

R2013 B C 5B

R2014 B C 5B

R2015 B C 5B

R2016 A C 4C

R2017 A C 6A

R2018 B C 5B

R2019 B C 5B

R2020 A C 3C

R2021 B C 6A

R2022 B C 6A

R2023 B C 6A

R2024 A C 6A

R2026 A C 6A

R2027 B C 1C

R2028 A C 6A

R2029 A C 6A

R2030 A C 6A

R2033 A C 6A

R2034 A C 6A

R2035 A C 6A

R2036 A C 6A

R2051 B C 1C

R2052 B C 1C

R2053 B C 1C

R2061 A C 7A

R2062 A C 6A

R2063 A C 6A

R2064 A C 6A

R2065 A C 6A

R2066 A C 6A

R2071 A C 5B

R2072 A C 5B

R2073 A C 5B

R2074 A C 5B

R2075 A C 5B

R2076 A C 5B

R2077 A C 5B

R2078 A C 6B

R2079 A C 5B

R2080 A C 5B

R2081 A C 5B

R2401 B C 6E

R2402 B C 6E

R2403 B C 6E

R2404 B C 6E

R2405 B C 6E

R2406 B C 6E

R2407 B C 6D

R2408 B C 6D

R2409 B C 6D

R2410 B C 6D

R2411 B C 6D

R2412 A C 6E

R2413 A C 6E

R2414 A C 6E

R2415 A C 6E

R2416 A C 6E

R2422 B C 6E

R2423 B C 6E

R3001 B C 6A

R3002 B C 6A

R3003 B C 7A

R3004 B C 7A

R3005 B C 6A

R3006 B C 6A

R3007 A C 6A

R3008 A C 6A

R3009 B C 7A

R3011 B C 7B

R3012 A C 7B

R3013 A C 7B

R3014 B C 7B

R3015 B C 7B

R3016 B C 2B

R3017 B C 2B

R3019 B C 6B

R3020 B C 6B

R3021 B C 6B

R3022 B C 6B

R3023 B C 6B

R3024 B C 6B

R3025 A C 6B

R3026 A C 6B

R3027 B C 6B

R3028 B C 5B

R3029 B C 6B

R3030 B C 6B

R3031 B C 5B

R3033 B C 6A

R3034 B C 5B

R3035 B C 5B

R3036 A C 7B

R3037 B C 6A

R3038 A C 7A

R3039 A C 6A

R3101 A C 7A

R3102 A C 7B

R3103 A C 7B

R3104 A C 7B

R3109 A C 7B

R3110 A C 7A

R3111 A C 7A

R3112 A C 7A

R3113 A C 7A

R3114 A C 7A

R3115 A C 7B

R3116 A C 7A

R3117 A C 7A

R3118 A C 7A

R3119 A C 1A

R3120 A C 1A

R3121 A C 7A

R3122 A C 1A

R3123 A C 7A

R3125 A C 7B

R3126 A C 7B

R3127 A C 7B

R3128 A C 7B

R3129 A C 1A

R3130 A C 1A

R3132 A C 7B

R3133 B C 5B

R3134 A C 7B

R3136 B C 7B

R3137 A C 1A

R3138 A C 2A

R3139 B C 5B

R3140 B C 6B

R3141 A C 7A

R3201 B C 8A

R3202 B C 8A

R3203 B C 7A

R3204 B C 7A

R3205 B C 7B

R3206 B C 8A

R3207 B C 7A

R3208 B C 8A

R3209 B C 8A

R3210 B C 8A

R3211 B C 7A

R3212 B C 8A

R3213 A C 8A

R3214 A C 8A

R3215 A C 8A

R3221 B C 7B

R3222 B C 7B

R3223 B C 7B

R3224 B C 7B

R3225 B C 7B

R3226 B C 7B

R3227 B C 7B

R3228 B C 7B

R3229 B C 7B

R3230 B C 7B

R3231 B C 7B

R3232 B C 7B

R3233 B C 8B

R3234 B C 8B

R3235 B C 8B

R3236 B C 8B

R3237 B C 8B

R3238 B C 8B

R3239 A C 8A

R3240 A C 8A

R3241 A C 8B

R3242 B C 7C

R3243 B C 8A

R3244 B C 8A

R3245 A C 8B

R3246 A C 8B

R3251 B C 1B

R3252 B C 1B

R3301 A C 8C

R3302 A C 7C

R3303 A C 8C

R3304 A C 7C

R3305 A C 7C

R3306 A C 8C

R3307 B C 8C

R3308 B C 8C

R3309 B C 8C

R3310 B C 8C

R3311 B C 8C

R3312 B C 8C

R3313 B C 8C

R3314 B C 8C

R3315 B C 8C

R3316 B C 8C

R3317 B C 8C

R3318 B C 8C

R3319 B C 8C

R3320 A C 4C

R3501 A C 5A

R3503 B C 5A

R3504 A C 5A

R3506 A C 5A

R3508 B C 5A

R3509 A C 5A

R3515 A C 5A

R3519 B C 5A

R3520 B C 5A

R3525 A C 5A

R3526 A C 5A

R3527 A C 5A

R3528 A C 5A

R3529 A C 5A

R3530 B C 5A

R3531 B C 5A

R3532 A C 5A

R3533 A C 5A

R3534 B C 5A

R3535 B C 5A

R3536 A C 5A

R3901 A C 4A

R3902 A C 4A

R3903 B C 4A

R3904 B C 4A

R3905 B C 4A

R3906 B C 4A

R4001 A C 3C

R4002 A C 3C

R4003 A C 3C

R4004 A C 3C

R4005 B C 3C

R4006 B C 3B

R4007 B C 3C

R4008 B C 3B

R4009 B C 3B

R4010 B C 3B

R4011 A C 2B

R4012 A C 2B

R4013 A C 2B

R4014 A C 2C

R4015 A C 2C

R4016 A C 2C

R4017 A C 1C

R4018 A C 1C

R4019 A C 1C

R4020 A C 1C

R4021 A C 1C

R4022 A C 1C

R4023 A C 1C

R4024 A C 1C

R4025 A C 1C

R4026 A C 1C

R4027 B C 3B

R4028 B C 3C

R4038 B C 3C

R4039 A C 4C

R4040 A C 4C

R4041 B C 4C

R4042 A C 3C

R4043 A C 4C

R4051 B C 3B

R4052 B C 3B

R4053 B C 3C

R4054 A C 3C

R4055 A C 4C

R4056 A C 3C

R4057 B C 4C

R4062 B C 3B

R4201 B C 1C

R4202 B C 1C

R4203 B C 1C

R4205 A C 1C

R4206 B C 1C

R4207 B C 1C

R4208 B C 1C

R4209 A C 1C

R4210 A C 1C

R4211 B C 1C

R4214 B C 1D

R4215 B C 1D

R4216 A C 1C

R4217 A C 1C

R4218 B C 1D

R4219 B C 1D

R4223 B C 3D

R4224 B C 2D

R4225 B C 1D

R4226 B C 2D

R4227 B C 2D

R4228 B C 2D

R4229 B C 3D

R4230 B C 2D

R4231 B C 2D

R4232 B C 2D

R4233 B C 2D

R4234 A C 1C

R4501 B C 2E

R4502 B C 3E

R4503 B C 2E

R4504 B C 2E

R4505 B C 2E

R4506 B C 2E

R4507 B C 2E

R4508 B C 2E

R4509 B C 2D

R4510 B C 3D

R4511 B C 3D

R4512 A C 3E

R4513 A C 2E

R4515 B C 3D

R4516 B C 3D

R5201 B C 3C

R5202 B C 3C

R5203 B C 3C

R5204 B C 2D

R5205 B C 3C

R5207 B C 3C

R5208 B C 3C

R5209 B C 3C

R5210 B C 3D

R5211 B C 3D

R5212 B C 3D

R5213 A C 3D

R5217 A C 2D

R5228 B C 2D

R5229 A C 2D

R6001 B C 6C

R6002 B C 6C

R6003 B C 7C

R6004 B C 7C

R6005 B C 7C

R6006 B C 7C

R6007 B C 7C

R6008 B C 7C

R6009 B C 7C

R6010 B C 7C

R6011 B C 7C

R6012 B C 7C

R6013 B C 7C

R6014 B C 7C

R6015 A C 7C

R6016 B C 7C

R6017 B C 7C

R6018 A C 7C

R6019 B C 6C

R6020 B C 6C

R6021 B C 6C

R6022 B C 6C

R6023 B C 6C

R6024 B C 6C

R6025 B C 6C

R6026 B C 6C

R6027 B C 6C

R6028 B C 6C

R6029 B C 6D

R6030 B C 6D

R6031 B C 6D

R6032 A C 7D

R6033 A C 7D

R6034 B C 6C

R6035 B C 6C

R6036 B C 6C

R6037 B C 6C

R6038 B C 6C

R6039 B C 6C

R6040 B C 6C

R6041 B C 6C

R6042 B C 6D

R6043 A C 7C

R6044 A C 7C

R6045 A C 7C

R6046 A C 7D

R6047 B C 5C

R6048 B C 6D

R6049 B C 5D

R6050 A C 7C

R6052 B C 7C

R6053 B C 6C

R6054 A C 7D

R6055 B C 7C

R6056 B C 7C

R6201 B C 6E

R6202 A C 6E

R6203 A C 6E

R6204 A C 6E

R6205 B C 6D

R6206 B C 6D

R7101 A C 7D

R7102 A C 7D

R7103 A C 7D

R7104 B C 7D

R7106 A C 7D

R7107 A C 7D

R7108 A C 7E

R7109 A C 7E

R7111 A C 7E

R7112 A C 7E

R7113 A C 7D

R7115 A C 7D

R7116 B C 7D

R7117 B C 7D

R7118 B C 7D

RA101 B C 2A

RA102 B C 3B

RA103 B C 2A

RA105 A C 3A

RA107 B C 4A

RA108 B C 3B

VR3301 A C 8C

VR3302 A C 8C

F6001 B C 5D

F6002 B C 5C

F6003 B C 7D

F6004 B C 7D

F6005 B C 6E

F7101 B C 7D

FL3201 B C 7A

J501 B D 8B

J502 A D 5C

J503 B D 8A

J504 A D 1C

J505 A D 1B

SW503 A C 8D

T2001 A C 4D

T6001 A C 6D

X101 A C 2B

X102 B C 1B

X3001 A D 6B

X5201 B C 3C

RESISTOR

OTHER

4-27

COMPONENT SIDE (A)

4-28

5-3

SECTION 5

PARTS LIST

SAFETY PRECAUTION

Parts identified by the symbol are critical for safety. Replace only with specified part numbers.

5.2 FINAL ASSEMBLY <M2>

116

106A

106B 106M

106D 106G

106E

106

106C

147 n

251C

251D

251B

251C251C

251A

255

251

254 256 252253

CCD

<02>

253

OPTICAL BLOCK

SECTION

141

118

ZOOM

<21>

122

129

104

129

126

123

101N

101A

101G

101B

101M

101L

148

101E

101K101E

103

101D

101H

101F

101D

101C

128

133

102

101J

123 122 125

125

101

105

124

121

137A 137E

137F

137G

g137C

137C

143

146

145 m

nee

MAIN

<01>

145

140

101P

Table des matières

Autres manuels JVC caméscope

JVC

JVC GR-FXM333 Manuel utilisateur

JVC

JVC Everio GZ-HD520AS Manuel d'utilisation et d'entretien

JVC

JVC GZ-MG67U Manuel utilisateur

JVC

JVC GR-DV500 Manuel utilisateur

JVC

JVC GY-HM200 Manuel utilisateur

JVC

JVC GZMG40US - Everio Camcorder - 1.33 MP Manuel utilisateur

JVC

JVC GR-SXM547 Manuel utilisateur

JVC

JVC GY-HM660E Manuel utilisateur

JVC

JVC Connected Cam GY-HC550U Manuel utilisateur

JVC

JVC GR-DVL820A Manuel utilisateur

JVC

JVC GZMC500US - Everio Camcorder - 1.33 MP Instructions de montage

JVC

JVC GR-D90 Manuel utilisateur

JVC

JVC GR-SX20EG Manuel utilisateur

JVC

JVC GR-DX100 Manuel utilisateur

JVC

JVC GC-PX100BE Manuel d'utilisation et d'entretien

JVC

JVC GR-D650AG Manuel utilisateur

JVC

JVC GR-AXM30 Manuel utilisateur

JVC

JVC GZ-RX615BE Manuel d'utilisation et d'entretien

JVC

JVC GR-DVL320A Manuel utilisateur

JVC

JVC Everio GZ-HM30 Instructions d'utilisation

JVC

JVC GY-HC550 Manuel utilisateur

JVC

JVC GR-D74U Manuel utilisateur

JVC

JVC GR-AXM38EG Manuel utilisateur

JVC

JVC GR-AXM510 Manuel utilisateur

Manuels caméscope populaires d'autres marques

Toshiba

Toshiba CAMILEO Z100 Manuel utilisateur

Panasonic

Panasonic NV-VS40B Manuel utilisateur

Canon

Canon RC 260 Manuel utilisateur

Sony

Sony Handycam DCR-DVD7E Manuel utilisateur

Brinno

Brinno TimeLapse TLC200 Manuel utilisateur

Panasonic

Panasonic AG-HMC152EN Manuel utilisateur

Insignia

Insignia NS-DCC5HB09 - Camcorder - 720p Manuel utilisateur

MYDLINK

MYDLINK DCS-6100LH Manuel utilisateur

Sony

Sony video Hi8 Handycam CCD-TR555 Manuel utilisateur

SECURECOM

SECURECOM V-5014B Manuel utilisateur

Panasonic

Panasonic HDC-SD100 Manuel utilisateur

Sharper Image

Sharper Image U-VIDEO Manuel utilisateur

Canon

Canon LEGRIA HV40 Manuel utilisateur

Sony

Sony Handycam DCR-VX2000 Manuel utilisateur

RCA

RCA CC616 Manuel utilisateur

Panasonic

Panasonic NVM40 Manuel utilisateur

ATIK Cameras

ATIK Cameras Horizon Manuel utilisateur

Sony

Sony Handycam HDR-CX580V Manuel utilisateur
