Operating Manual

English

Calibration Baths

FK30-SL

FK31-SL

1.951.2829-V5 11/17

www. .com information@itm.com1.800.561.8187

Congratulations!

You have made an excellent choice.

JULABO thanks you for the trust you have placed in us.

This operating manual has been designed to help you gain an understanding of the operation and

possible applications of our circulators. For optimal utilization of all functions, we recommend that you

thoroughly study this manual prior to beginning operation.

The JULABO Quality Management System

Temperature control devices for research and industry are developed,

produced, and distributed according to the requirements of ISO 9001 and

ISO 14001. Certificate Registration No. 01 100044846

Unpacking and inspecting

Unpack the circulator and accessories and inspect them for possible transport damage. Damage should

be reported to the responsible carrier, railway, or postal authority, and a damage report should be

requested. These instructions must be followed fully for us to guarantee our full support of your claim

for protecting against loss from concealed damage. The form required for filing such a claim will be

provided by the carrier.

Printed in Germany Changes without prior notification reserved

Important: keep operation manual for future use

www. .com information@itm.com1.800.561.8187

TABLE OF CONTENTS

Operating manual................................................................................................................ 5

1. Intended use.................................................................................................................5

1.1. Description...............................................................................................................5

2. Operator responsibility – Safety recommendations....................................................... 6

2.1. Disposal...................................................................................................................8

2.2. Warranty conditions ................................................................................................. 8

2.3. EC Conformity.......................................................................................................... 9

2.4. Technical specifications ......................................................................................... 12

Operating instructions .......................................................................................................15

3. Safety notes for the user............................................................................................. 15

3.1. Explanation of safety notes.................................................................................... 15

3.2. Explanation of other notes...................................................................................... 15

3.3. Safety recommendations........................................................................................ 16

4. Operating controls and functional elements................................................................ 18

5. Preparations............................................................................................................... 22

5.1. Installation.............................................................................................................. 22

5.2. Bath fluids.............................................................................................................. 23

5.3. Filling / draining...................................................................................................... 24

6. Operating procedures................................................................................................. 25

6.1. Power connection................................................................................................... 25

6.2. Switching on / Selecting the language.................................................................... 25

6.2.1.Switching on the cooling machine...................................................................... 26

6.3. Start - Stop............................................................................................................. 26

6.4. Adjusting the temperature chamber........................................................................ 26

7. Setting of temperatures................................................................................. 27

8. Safety installations, warning functions........................................................... 27

8.0.1.Early warning system, low level protection......................................................... 31

9. Menu functions.............................................................................................. 32

9.1. Start of a program.................................................................................................. 34

9.1.1.Status at the end of a program .......................................................................... 36

9.1.2.Indication after successful start.......................................................................... 36

9.1.3.Editing after Start............................................................................................... 37

9.1.4.Interrupting a program....................................................................................... 37

9.1.5.Interruption after a power failure........................................................................ 38

9.1.6.Termination of a program................................................................................... 38

9.2. Program administration, creation............................................................................ 39

9.3. Setting the pump pressure..................................................................................... 43

9.4. Configuration.......................................................................................................... 44

9.4.1.Remote control via the serial interface............................................................... 47

9.4.2.Keypad control or setpoint setting via the analog input...................................... 47

9.4.3.Autostart............................................................................................................ 48

9.4.4.Off-Mode ........................................................................................................... 48

www. .com information@itm.com1.800.561.8187

9.4.5.ActVar - actuating variable..................................................................................49

9.4.6.Setting of clock and date ....................................................................................50

9.4.7.Language...........................................................................................................50

9.4.8.Unit.....................................................................................................................50

9.4.9.Program type......................................................................................................50

9.4.10. Reset.............................................................................................................50

9.4.11. C-Sensor - Precision reference sensor..........................................................51

9.5. Control....................................................................................................................52

9.5.1. Control internal / external...................................................................................54

9.5.2.Selftuning...........................................................................................................55

9.5.3.Dynamik intern ...................................................................................................55

9.5.4.CoSpeed - extern...............................................................................................56

9.5.5.Control parameters – internal/external................................................................56

9.6. Serial Interface........................................................................................................58

9.7. ATC Absolute Temperature Calibration, 3-point calibration.....................................59

9.7.1.ATC Fühler - intern / extern................................................................................62

9.7.2.ATC Status - yes / no .........................................................................................62

9.7.3.Type 1 -/ 2 -/ 3 point..........................................................................................62

9.7.4.Example: 3-point calibration for internal control.................................................63

9.8. Limits......................................................................................................................65

9.8.1.Limits for internal control and external control.....................................................66

9.8.2.Limits for external control....................................................................................67

9.9. Analog inputs/outputs .............................................................................................68

9.9.1.Outputs of the connector - REG+E-PROG..........................................................72

9.9.2.Input of the connector - REG+E-PROG..............................................................73

9.9.3.External Stand-by input ......................................................................................75

9.9.4.Alarm-output.......................................................................................................76

10. Troubleshooting guide / Error messages.....................................................................77

11. Electrical connections..................................................................................................80

12. Remote control............................................................................................................83

12.1. Setup for remote control..........................................................................................83

12.2. Communication with a PC or a superordinated data system ...................................83

12.3. List of commands....................................................................................................84

12.4. Status messages ....................................................................................................88

12.5. Error messages.......................................................................................................88

13. Installation of electronic module with analog connectors .............................................89

14. JULABO Service – Online remote diagnosis ...............................................................90

15. Cleaning / repairing the unit.........................................................................................91

www. .com information@itm.com1.800.561.8187

Operating manual

1. Intended use

JULABO circulators have been designed to control the temperature of specific fluids in a bath tank.

JULABO circulators are not suitable for direct temperature control of foods, semi-

luxury foods and tobacco, or pharmaceutical and medical products.

Direct temperature control means unprotected contact of the object with the bath

medium (bath fluid).

1.1. Description

ICC

TCF

ATC3

RS232

RS485

Pt100

PUMP

SMART

;The circulators are operated via the splash-proof keypad. The implemented

microprocessor technology allows to set and to store different values that can be

indicated on the VFD COMFORT-DISPLAY and LCD DIALOG-DISPLAY. Three

menu keys facilitate adjusting setpoints, warning and safety functions and menu

functions.

;The integrated programmer allows storing and running temperature and time-

dependent processes.

;The control electronics including “ICC - Intelligent Cascade Control“ automatically

adapts the heat supplied to the thermal requirements of the bath.

;The TCF - Temperature Control Features allow the user to have access to all

important temperature control parameters. This means: Full control on the control

mode and the chance to manually adjust or adapt control to the specific application.

;Absolute Temperature Calibration (ATC3) provides high temperature stability in the

bath. With the 3-point calibration an offset is adjusted at three temperatures to

ensure an accurate temperature pattern at the selected spot in the bath over the full

temperature range.

;Electrical connections:

The serial interface, switchable from RS232 to RS485, allows modern process

technology without additional interface.

Connection for Pt100 external sensor for external temperature measurement and

control.

Alarm output for external alarm message or control of JULABO refrigerating baths

or solenoid valve (cooling water).

The electronic module (option) provides 3 further analog connections (alarm input,

standby input, recorder output, programmer input).

;The excess temperature protection conforming to IEC 61010-2-010 is a safety

installation independent from the control circuit. This protection can be indicated

and set on the LCD DIALOG-DISPLAY.

;The early warning system for low level signals that bath fluid needs to be refilled

before the low level protection conforming to IEC 61010-2-010 causes a complete

shut-down of the main functional elements.

;Intelligent pump system: The pump capacity (electronically adjustable via the motor

speed) enables to adapt to varying conditions for internal and external temperature

applications.

www. .com information@itm.com1.800.561.8187

Operator responsibility – Safety recommendations

2. Operator responsibility – Safety recommendations

The products of JULABO ensure safe operation when installed, operated, and maintained according to

common safety regulations. This section explains the potential dangers that may arise when operating

the circulator and also specifies the most important safety precautions to preclude these dangers as far

as possible.

¾The operator is responsible for the qualification of the personnel operating the units.

¾The personnel operating the units should be regularly instructed about the dangers involved with

their job activities as well as measures to avert these dangers.

¾Make sure all persons tasked with operating, installing, and maintaining the unit have read and

understand the safety information and operating instructions.

¾When using hazardous materials or materials that could become hazardous, the circulator may be

operated only by persons who are absolutely familiar with these materials and the circulator. These

persons must be fully aware of possible risks.

If you have any questions concerning the operation of your unit or the information in this manual, please

Contact

Safety instructions for the operator:

¾You have received a product designed for industrial use. Nevertheless, avoid strikes to the

housing, vibrations, damage to the operating-element panel (keypad, display), and contamination.

¾Make sure the product is checked for proper condition regularly (depending on the conditions of

use). Regularly check (at least every 2 years) the proper condition of the mandatory, warning,

prohibition and safety labels.

¾Make sure that the mains power supply has low impedance to avoid any negative effects on

instruments being operated on the same mains.

¾This unit is designed for operation in a controlled electromagnetic environment. This means that

transmitting devices (e.g., cellular phones) should not be used in the immediate vicinity.

Magnetic radiation may affect other devices with components sensitive to magnetic fields

(e.g., monitors). We recommend maintaining a minimum distance of 1 m.

¾Permissible ambient temperature: max. 40 °C, min. 5 °C.

¾Permissible relative humidity: 50% (40 °C).

¾Do not store the unit in an aggressive atmosphere.

¾Protect the unit from contamination.

¾Do not expose the unit to sunlight.

Appropriate operation

Only qualified personnel is authorized to perform configuration, installation, maintenance and repairs of

the circulator.

Routine operation can also be carried out by untrained personnel who should however be instructed by

trained personnel.

www. .com information@itm.com1.800.561.8187

Use:

The bath can be filled with flammable materials. Fire hazard!

There might be chemical dangers depending on the bath medium used.

Observe all warnings for the used materials (bath fluids) and the respective instructions (safety data

sheets).

Insufficient ventilation may result in the formation of explosive mixtures. Only use the unit in well

ventilated areas.

Only use recommended materials (bath fluids). Only use non-acid and non corroding materials.

When using hazardous materials or materials that could become hazardous, the operator must affix

the enclosed safety labels to the front of the unit so they are highly visible:

When using hazardous materials or materials that could become hazardous, the operator must affix

the enclosed safety labels (1 + 2) to the front of the unit so they are highly visible:

Warning label W00: Colors: yellow, black

Danger area. Attention! Observe instructions.

(operating manual, safety data sheet)

Mandatory label M018: Colors: blue, white

Carefully read the user information prior to beginning operation.

Scope: EU

Semi S1-0701 Table A1-2 #9

Carefully read the user information prior to beginning operation.

Scope: USA, NAFTA

Particular care and attention is necessary because of the wide operating range.

There are thermal dangers: Burn, scald, hot steam, hot parts and surfaces that can be touched.

Warning label W26: Colors: yellow, black

Hot surface warning.

(The label is put on by JULABO)

Observe the instructions in the manuals for instruments of a different make that you connect to the

circulator, particularly the respective safety recommendations. Also observe the pin assignment of

plugs and technical specifications of the products.

www. .com information@itm.com1.800.561.8187

Operator responsibility – Safety recommendations

2.1. Disposal

The circulator contains a back-up battery that supplies voltage to memory chips when the unit is

switched off. Do not dispose of the battery with household waste!

Depending on battery regulations in your country, you might be obliged to give back used or defect

batteries to gathering places.

The product may be used with oil as bath fluid. These oils fully or partially consist of mineral oil or

synthetic oil. For disposal, observe the instructions in the safety data sheets.

This unit contains refrigerants, which at this time are not considered harmful to the ozone layer.

However, over the long operating period of the unit, disposal rules may change. Therefore, only

qualified personnel should handle the disposal.

Valid in EU countries

See the current official journal of the European Union – WEEE directive.

Directive of the European Parliament and of the Council on waste electrical and

electronic equipment (WEEE).

This directive requires electrical and electronic equipment marked with a crossed-

out trash can to be disposed of separately in an environmentally friendly manner.

Contact an authorized waste management company in your country.

Disposal with household waste (unsorted waste) or similar collections of municipal

waste is not permitted!

2.2. Warranty conditions

JULABO GmbH warrants its products against defects in material or in workmanship, when used under

appropriate conditions and in accordance with appropriate operating instructions

for a period of ONE YEAR.

Extension of the warranty period – free of charge

With the ‘1PLUS warranty’ the user receives a free of charge extension to the warranty of up to 24

months, limited to a maximum of 10 000 working hours.

To apply for this extended warranty the user must register the unit on the JULABO web site

, indicating the serial no. The extended warranty will apply from the date of JULABO GmbH’s original

invoice.

JULABO GmbH reserves the right to decide the validity of any warranty claim. In case of faults arising

either due to faulty materials or workmanship, parts will be repaired or replaced free of charge, or a new

replacement unit will be supplied.

Any other compensation claims are excluded from this guarantee.

www. .com information@itm.com1.800.561.8187

2.3. EC Conformity

www. .com information@itm.com1.800.561.8187

Operator responsibility – Safety recommendations

www. .com information@itm.com1.800.561.8187

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Julabo Équipement de test

Julabo

Julabo SL-8K Manuel utilisateur

Manuels Équipement de test populaires d'autres marques

SMART

SMART KANAAD SBT XTREME 3G Series Manuel utilisateur

Agilent Technologies

Agilent Technologies BERT Serial Manuel utilisateur

Agilent Technologies

Agilent Technologies N3280A Manuel utilisateur

Vernier

Vernier Go Direct Voltage Manuel utilisateur

Lifeloc

Lifeloc R.A.D.A.R. Manuel utilisateur

Fluke

Fluke T5-600 Instructions d'utilisation et d'installation

Mercury

Mercury TSL01 Manuel utilisateur

MAHA

MAHA MBT Series Manuel utilisateur

Fuji Electric

Fuji Electric P-61 Manuel utilisateur

ETC

ETC SealerAtor Manuel utilisateur

Skyfine

Skyfine ETHYWAY V2 Manuel utilisateur

Appion

Appion G5 Twin Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 8159-0112A Manuel utilisateur

BW Technologies

BW Technologies MicroDock II Manuel utilisateur

Sun Nuclear

Sun Nuclear 1027 Manuel utilisateur

Biomark

Biomark HPR LITE READER Manuel utilisateur

Hioki

Hioki 3169-20 Manuel utilisateur

Ashcroft

Ashcroft ATE-100 Manuel utilisateur
