Joyoung DJ13E-D79 Manuel technique
01-17-1309-0032-A
CCC certification of product
Our company has passed
ISO9001 Quality management
system certification
Joyoung Company Limited
No.999 Meili Road, Huaiyin District, Jinan City
Post code: 250118 Fax: 400 6186 996
www.joyoung.com
Sunshine Service Hotline
400-6186-999
Jiuyang
Operation Instruction
Full-automatic Domestic Soy Milk Machine
DJ13E-D79
Please read this manual carefully before using the product and keep it properly.
Thank you for purchasing Jiuyang products. Please read this manual carefully before
using to ensure that you use this product correctly and safely.
Pictures are for reference only. Please refer to the actual product.
Contents
Chapter I Precautions for Safe Use … … … 1
Chapter II Parts and Accessories........ 4
Chapter III Application method......... 6
Pre-use Instructions … … … 6
Operating Steps and Instructions … … … … 6
Booking Instructions...... 7
Altitude Adaptive Operation … … … … 8
Chapter IV Maintenance
Chapter V Failure Analysis and Removal... 9
Chapter VI Model Specification Parameters … … … 10
Chapter VII Functions and Recipes
Food Contact Material Information...... 14
Hazardous Substances Restriction Use Identification List … … … 15
After-sales Service...... 16
- 1 -
Chapter I Precautions for Safe Use
Warning
Be vigilant against the risks that may lead to personnel danger, serious injury
and major property losses.
Attention
Attention should be paid to the risk of injury to persons or damage to goods.
Represents “Prohibited”, unavailable content.
Represents “Force”, what must be executed
● In order to prevent electric shock, fire, scald and other accidents, please observe the
following contents.
Warning
Please clean the cup body, blade, anti-spill electrode and temperature sensor in
time. The blade edge is sharp. Take out, wipe and clean carefully. Wear protective
gloves.
When the product is boiling, the temperature inside the cup, the lower cover, the
blade and other parts are high before cooling after the work is finished. Please do
not touch them to avoid scald.
Attention
Do not plug or unplug the power cord with wet hands to prevent electric shock.
In the pulping process, do not lift the machine head or move the product quickly to
avoid being scalded by steam, or overflow of food materials, resulting in scalding,
electric shock and other accidents.
Do not lift the whole machine with the nose to avoid slipping of the cup.
Do not use damaged power cords or plugs to prevent accidents or fires caused by
- 2 -
electric shock or short circuit. If the power cord is damaged, you must go to
Jiuyang After-sales Service Department to purchase the special power cord for
replacement.
Do not fill hot water above 70℃to make pulp, so as not to affect the taste or cause
pulverized bad slurry overflow and other anomalies.
Please do not drink until the pulping is finished. Drinking undercooked soy milk
can be harmful to the human body.
Do not overflow the head or cup into the liquid. Do not spray the head, vent holes,
strong electrical couplers, power sockets, and do not water the bottom of the cup.
If water enters, pause and use again to avoid short circuit or electric shock
Care should be taken of children to ensure that they are not likely to play with or
approach the product in order to avoid personal injury from scald or misoperation.
Use this product only with experienced guardians or coaches who have abnormal
or no independent capacity.
Please make sure that the local power supply is in accordance with the marked
power supply of the product before use, otherwise the product will be damaged or
fire will occur.
Operate on a stable horizontal table and stay away from the green side of the table
to prevent falls. Do not use this product under or near the curtains and other
combustible materials (e.g. under the wall), otherwise it may cause the fire engine
head to buckle vertically onto the cup body and the power cord to be inserted into
the power outlet. Make sure that it is installed in place to prevent loosening, power
failure or overheating.
When the product is working, keep a certain distance from the charged object such
as the socket, so that the plug is in the accessible range and away from the easily
explosive object. At the same time, the grounding wire of the power socket must
be kept in good grounding.
After the product starts to work, if any other abnormality occurs in case of power
failure, please pay attention to the replacement of food ingredients and
remanufacture, otherwise it will cause overflow of paste bottom slurry, alarm and
other faults.
After the production, please cut off the power first, remove the machine head and
pour the slurry again. Slide off the machine head or splash out the drink, causing
- 3 -
damage to the products or scald.
The temperature of the newly-made beverages is higher, please use heat-resistant
utensils and pay attention to safety to prevent the beverages from spattering and
scald.
If filtering is necessary, please pay attention to the residues attached to the filter
screen with high temperature. When cleaning the filter screen, do not face people
and pay attention to safety to prevent the residues from spattering and scald.
- 4 -
Tips
This product is only suitable for domestic use, not for commercial use.
When used for the first time (including the first time after adaptation), the pulping time
may be prolonged.
Some food ingredients contain natural pigments, which may cause dyeing of the lower
cover and anti-spill electrode. It is normal and will not affect the beverage. Please feel
free to drink without damage to your health.
In order to fully pulverize and release nutrients, it is normal for intermittent rapid and
slow sounds to occur during machine beating.
Do not continue pulping for a long time, otherwise the motor may start the automatic
protection function, and the electric opportunity will not work temporarily, and the motor
cannot be used normally until it is completely cooled down.
After pulping is completed, the next pulping should be carried out at intervals of more
than 8 minutes, otherwise, the service life of the product will be affected.
Infants, people with renal failure and gastrointestinal dysfunction should choose low
concentrations of beans or reduce consumption as appropriate.
Heat preservation, motor agitation is normal phenomenon, can be ready to drink after
power failure.
- 5 -
Chapter II Parts and Accessories
Control Panel Diagram
Pre-set, Display Area, Start/Cancel
Shortcut function, Function selection, Shortcut function
Function selection: Functions for selecting the display area.
Shortcut features: With the function selection key displayed, it will start automatically for 3
seconds after touching and pressing.
Reservation settings: It is used to set the booking time (3-114 hours) and select the booking
temperature (hot drink or warm drink).
Start/Cancel: Used to start or cancel a function.
Complete machine diagram
1Vent hole (at handle)
2Operating Keys
3Operating status indication
4Nose gasket
5Nose
6Anti-spill electrode
7Lower cover
8Temperature sensor
9High suction finis grinder
10 Blade
11 Strong electric coupler
12 Cup body
13 Water level scale (engraved in the cup)
14 Power outlet
- 6 -
Accessories (1
each)
Power cord Measuring cup Grouting cup Grouting cup
handle
Warm Tips
1Press Figure 1 to remove all objects from the cup.
2Please assemble the cup and its handle correctly in the direction of arrow in
Figure 2 to prevent the cup from slipping off when serving hot drinks and causing scald.
- 7 -
Chapter III Application Method
Pre-use Instructions
1 This product is only used in areas below 2000 meters above sea level on the Chinese
mainland. If the altitude difference is more than 1500 meters after the change of the place of
use, the operation shall be self-adaptive according to the altitude.
2 Clean the machine before use.
3 It is suggested that the beans should be used for the first time.
Operating Steps and Instructions
1 Fill ingredients and water
Fill the cleaned ingredients according to the recipe and fill water between the upper and lower
water levels (see figure on the right).
2Switch on the power supply
①Place the machine head vertically into the cup body. ②Plug in the power cord, ③
Switch on the power, and when the power is turned on, prompt "tick" and the light is on.
Warm Tips
Close the nose and press tight; Please level out when there are more ingredients; Make
sure the nose and strong electrical couplers are in place.
3Select and start the function
Press the “Select” to select the function, and then press the “Start/Cancel” to start the
function.
Select Features
"Tick" a corresponding function lamp flashing
Start-up function
"Tick" two corresponding function lights on (no longer flashing)
