COM-MOTOR05
Servomotor FS90R with caster
1. GENERAL INFORMATION
Dear customer,
thank you for choosing our product. In the following, we will show you what
is important to observe during the commissioning and the usage.
Should you encounter any unexpected problems during use, please do not
hesitate to contact us.
2. COMMISSIONING
3. APPLICATION WITH AN ARDUINO
Initially, connect the motor with your Arduino like shown in the following
connection diagram.
Since the motor is connected, you can transmit the following code
examples to your Arduino and test their functions.
In general applies:
The motor is controlled by the command servo.write();. The value between
the brackets, can be among 0 and 180. If the value is beneath a value of 90,
the motor rotates in one direction. If the value is above a value of 90, the
motor rotates in the other direction. The further away (or rather higher and
lower) the value is from 90, depends on the speed in which the servomotor
is rotating.
If the value is set on 90, the motor stops. You can modify and edit the code
examples according to your wishes as a matter of course.
First of all, you have to wind the rubber tires on the rims. Aer that, you can
put the wheel on the white attachment of the motor with gentle
pressure.
Please note that for direct connection to an Arduino or Raspberry Pi, additional
connection cables are required.
3. APPLICATION WITH AN ARDUINO
// Include Libraries
#include "Arduino.h"
#include "Servo.h"
Servo servo;
void setup()
{
Serial.begin(9600);
servo.attach(2);
}
void loop()
{
servo.write(180);
delay(2000);
servo.write(0);
delay(2000);
servo.write(90);
delay(2000);
servo.detach();
}
4. APPLICATION WITH A RASPBERRY PI
Initially, connect the motor with your Raspberry Pi like shown in the
following connection diagram.
Since the motor is connected, you can transmit the following code
examples to your Raspberry Pi and test their functions.
In general applies:
The motor is controlled by the command pwm.ChangeDutyCycle().The
value between the brackets, can be among 2.5 and 12.5. If the value is
beneath a value of 7.5, the motor rotates in one direction. If the value is
above a value of 7.5, the motor rotates in the other direction. The further
away (or rather higher and lower) the value is from 7.5, depends on the
speed in which the servomotor is rotating.
If the value is set on 7.5, the motor stops.
You can modify and edit the code examples according to your wishes as a
matter of course.
Create now a data le with the following command:
sudo nano servo.py
Now enter the following code example into the editor. Aer that you can
save the le with the key combination of STRG+O and you conrm it with
Enter. You can leave the editor with the key combination STRG+X.
import RPi.GPIO as GPIO
GPIO.setmode(GPIO.BOARD)
GPIO.setup(7,GPIO.OUT)
pwm =GPIO.PWM(7,50)
pwm.start(7.5)
while True:
pwm.ChangeDutyCycle(7.5)
time.sleep(1)
pwm.ChangeDutyCycle(12.5)
time.sleep(1)
pwm.ChangeDutyCycle(2.5)
time.sleep(1)
except KeyboardInterrupt:
GPIO.cleanup()
Subsequently, you can start the code example with following command:
sudo python servo.py
You can quit the code example with the key combination Strg+C.
5. FURTHER INFORMATION
Our informaon and redempon obligaon according to the
electro-law (ElektroG)
Symbol on electrial and electronic products:
This crossed-out bin means that electrical and electronic products do not
belong into the household waste. You must hand over your old appliance
to a registration oice. Before you can hand over the old appliance, you
must remove used batteries and accumulators which are not enclosed by
the device.
Return opons:
As the end user, you can hand over with the purchase of a new device your
old appliance (which has essenally the same funcons as the new one) free
of charge for disposal.
Smaller devices which do not have outer dimensions greater than 25 cm can
be submied independently of the purchase of a new product in normal
household quanes.
Possibility of restuon at our company locaon during our opening hours:
Simac GmbH, Pascalstr. 8, D-47506 Neukirchen-Vluyn
Possibility of restuon nearby:
We send you a parcel stamp with which you can send us your old appliance
free of charge. For this possibility, you must contact us via e-mail at
[email protected]t or via telephone.
Informaon about packaging:
Please package your old appliance safe during transport. Should you not
have a suitable packaging material or you do not want to use your own
material, you can contact us and we will send you an appropriate package.
www.joy-it.net
Simac Electronics Handel GmbH
Pascalstr. 8 47506 Neukirchen-Vluyn
Published:19.08.2019
6. SUPPORT
If any questions remained open or problems may arise aer your purchase,
we are available by e-mail, telephone and ticket support system to answer
these.
E-Mail: servic[email protected]
Ticket-system: http://support.joy-it.net
Telephone: +49 (0)2845 98469 – 66 (10 - 17 o'clock)
For further information visit our website:
www.joy-it.net
