RT655 Operator’s Guide
Foreword Page Issue A
Foreword
The Johnston RT655 Air Regen Sweeper represents the highest grade of craftsmanship and
reliability that makes Johnston probably the world leader in sweeping technology.
This machine is designed for the removal of spoil on traffic or pedestrian areas, and litter collection
using the Wanderhose [EN 13019 refers], and should only be driven by trained operatives.
This machine should not be used for sweeping hot or burning substances. In the unlikely event of
a fire, normal powder or foam fire fighting equipment can be used on this product.
An operator should receive training in the follow elements:
1 Safety Observations/Notices
2 Transit driving
3 Correct use of body prop
4 In cab controls
5 External controls
6 Sweeping techniques
7 Load discharge
8 Channel brush (gutter broom) setting changing
9 Nozzle (pick-up head) setting
10 Daily and weekly maintenance items
11 Driving/operation assessment
12 End of day cleaning of body and machine
Johnston Sweepers Limited can provide operator training upon request.
We would point out that it is the employers responsibility to carry out his own Risk Assessment on
the equipment in his particular working environment and work application.
This handbook should be carefully studied. In it you will find instructions for the operation and
maintenance of your JOHNSTON SWEEPER.
It is vitally important that the operator and maintenance staff have a copy of this book. The life of
the machine will depend upon following these instructions in respect of regular maintenance and
correct operating methods.
It is important that only GENUINE JOHNSTON SPARE PARTS are used when servicing and
maintaining the sweeper. This is especially important for consumables, filters etc, as the use of
non-genuine parts may cause premature failure and invalidation of warranty.
When carrying out maintenance or part replacement, additional explanatory illustrations can be
found in the Parts Manual, which shows and lists hardware, and availability of spares with the
orientation and positions of the various components.
RT655 Operator’s Guide Johnston Sweepers Limited
Foreword
Page Issue A
Every endeavour has been made to ensure that the information contained in this Operator’s Guide
is correct, but due to continuous product development, the Company reserve the right to alter its
contents without notice. This document should not be interpreted as being part of a formal contract.
The universal safety symbol is used throughout this manual to indicate information which
is essential for health and safety for all operating personnel.
Safety Notice
Johnston®JOHNSTON ®JOBRO ® BROOMVAK ® are registered trade marks of Johnston Sweepers Limited.
All copyrights and rights reserved. The reproduction, distribution and utilisation of this document
as well as the communication of its contents to others without express authorisation is prohibited.
Offenders will be held liable for the payment of damages. All rights reserved in the event of the grant
of a patent, utility model or design.
For further information and enquiries please contact:
Johnston Sweepers Limited
Curtis Road, Dorking, Surrey RH4 1XF, UK
Tel: +44 (0)1306 884722
Fax: +44 (0)1306 884151
E-mail: [email protected]
Web: www.johnstonsweepers.com
Ear defenders are recommended when working around the machine
Eye protection is recommended when working around the machine
RT655 Operator’s Guide
Foreword Page Issue A
Page Issue Levels
Page Issue Changed Page Issue Changed
Front Page A Foreword 1 A
Foreword 2 A Foreword 3 A
Foreword 4 A Foreword 5 A
OG1:1 A OG1:2 A
OG1:3 A OG1:4 A
OG2:1 A OG2:2 A
OG2:3 A OG2:4 A
OG2:5 A OG2:6 A
OG2:7 A OG2:8 A
OG3:1 A OG3:2 A
OG3:3 A OG3:4 A
OG3:5 A OG3:6 A
OG3:7 A OG3:8 A
OG3:9 A OG3:10 A
OG3:11 A OG3:12 A
OG4:1 A OG4:2 A
OG4:3 A OG4:4 A
OG4:5 A OG4:6 A
OG6:1 A OG6:2 A
OG6:3 A OG6:4 A
OG6:5 A OG6:6 A
OG6:7 A OG6:8 A
OG6:9 A OG6:10 A
OG6:11 A OG6:12 A
OG6:13 A OG6:14 A
OG6:15 A OG6:16 A
OG6:17 A OG6:18 A
OG7:1 A OG7:2 A
OG7:3 A OG7:4 A
RT655 Operator’s Guide Johnston Sweepers Limited
Foreword
Page Issue A
1. Water tank filler ports 1a = Hose Pipe
1b = Hydrant
2. Hydraulic oil tank filler
3. Fuel tank (diesel) filler
4. Engine air cleaner instructions, i.e. use only genuine Johnston replacement
air cleaner elements and refer to Chapter 6 of this guide for servicing
instructions
RTOG.049
RTOG.049
4
1a
2
3
1b
4
INTERNATIONAL SYMBOLS
Conforming to ISO 3767
Graphical symbols are used to indicate the water, fuel and hydraulic oil tank filler ports and air
cleaner servicing instructions.
Their location and descriptions are shown below.
RT655 Operator’s Guide
Foreword Page Issue A
Safety Symbol Descriptions
Safety alert symbol
Read Operator’s Guide
Ensure body prop is engaged in rack before working under raised body
Body prop NOT engaged in rack
Body prop correctly engaged in rack
Keep clear of brushes
Do not open suction fan safety flap while fan is running
Never reach in or drop tools into the fan case
Release radiator cap carefully when hot to avoid scalding
Stay at least 1 metre distance from the machine
Wear ear defenders when working in this area
Sharp objects warning - there can be a risk of injury from sharp objects such
as discarded hypodermic needles becoming lodged in the sweeping system.
The use of ‘needle stick gloves’ is recommended when changing brushes,
using the wanderhose/Littasnatch and when cleaning out the machine
OG1:1
RT655 Operator’s Guide
CHAPTER 1
Johnston Sweepers Limited
General Arrangements
Chapter - General Arrangement
Page Issue A
Table of Contents
Subject Page
General Arrangement
General Arrangement Drawing OG1 : 2
RT655 Operator’s Guide
OG1:2 Chapter - General Arrangement Page Issue A
29
16
17
32
35
30
30
31 30
13 10
7
4
20
18
19 15
29
1
8
26
13
25 27
1
5
6
34
Cold Weather Drains
RTOG.051
2
8
11 9
21
2
12
14
37 3 22
34
23
26
36 33
28
24
30
GENERAL ARRANGEMENT
Figure 1
RH Sweep machine shown
OG1:3
RT655 Operator’s Guide Johnston Sweepers Limited
Chapter - General Arrangement
Page Issue A
Item Component See Chapter
1 Hopper/load compartment -
2 Auxiliary engine cowl -
3 Body (hopper and cowl) prop 3
4 Auxiliary engine 6
5 Fuel tank -
6 Fuel tank filler access flap -
7 Hydraulic oil reservoir 6
8 Suction fan case 6
9 Variable exhaust gate (VEG) -
10 Pick-up head (hood) 6
11 Blaster duct -
12 Suction duct -
13 Channel brush / gutter broom 6
14 Wear plate -
15 Filter screen 6
16 Filter screen curtain 6
17 Filter screen water sprays 6
18 ‘SepaVac’ separator box 3
19 ‘SepaVac’ access panel -
20 ‘SepaVac’ discharge door 3
21 ‘SepaVac’ water flush 3
22 ‘SepaVac’ water flush hydrant connection 3
23 * R.H. Water tank and contents gauge 6
24 * L.H. Water tank, contents gauge and hose filler 6
25 Water tank(s) hydrant filler 6
26 Water tank drain tap - under both tanks 6
27 Water pump suction filter 6
28 Rear door drainage hoses 3
29 Rear door access door 3
30 Low pressure water spray jets -
31 High pressure Water spray jets -
32 Washdown hose -
33 Master control panel 2
34 Air cleaner 6
35 Air cleaner filter state indicator 6
36 Hydrant hose stowage - optional -
37 Supawash hose reel & handlance 4
* Total water capacity 950 litres
RT655 Operator’s Guide
OG1:4 Chapter - General Arrangement Page Issue A
