TECHNICAL GUIDE

LX SERIES

SPLIT SYSTEM

HEAT PUMPS

16 SEER – R-410A – 1 PHASE

1.5 THRU 5 NOMINAL TONS

MODELS: TH6B18 THRU 60

Due to continuous product improvement, specifications

are subject to change without notice.

Visit us on the web at

www.simplygettingthejobdone.com

Additional rating information can be found at

www.ahridirectory.org

WARRANTY SUMMARY*

Extended 10-Years limited parts warranty.

Standard 10-year limited compressor warranty.

Extended 10-Years limited parts warranty requires

online registration within 90 days of purchase for replacement

or closing for new home construction.

*Does not apply to R-22 models, 3-Phase models, or internet sales.

See Limited Warranty certificate in User's Information Manual for details.

FOR INSTALLATION IN ALL US REGIONS AND CANADA

Installation Allowed

TECHNICAL

GUIDE

TECHNICAL

GUIDE

DESCRIPTION

The TH6B models are part of our successful LX Series split sys-

tem heat pump lineup. These outdoor units are optimized for

the new 16 SEER / 9.0 HSPF Minimum Efficiency in all US

Regions, and are specifically designed to be matched with resi-

dential indoor coils, furnaces, and air handlers to provide a

complete system solution.

FEATURES

•Easier Installation - Independent panels provide quick

access for unit setup. Installation time is reduced by easy

power and control wiring access. All models utilize TXV's.

The factory installed stainless steel filter-drier and factory

charge for a 15-Ft lineset means less time spent brazing and

charging the system. The small base dimension and reduced

unit clearances make for easier retrofits.

•Accessible Information - QR code on unit provides quick

access to technical documents and warranty information.

• Durable Finish - The coated steel wire fan guard, coated

external fasteners, and pre-treated G90-equivalent galva-

nized steel chassis components resist corrosion and rust

creep. Titanium colored powdercoat paint further protects

external panels.

•Rugged Coil Protection - Coils are protected from mechan-

ical damage by a proven extruded louver steel coil guard

design.

•Quality Coils - Enhanced aluminum fins are mechanically

bonded to copper tubing.

•Protected Compressor - Compressors are protected inter-

nally by a high pressure relief valve and a temperature sen-

sor, and externally by the system high and low pressure

switches. The liquid line filter-drier is factory installed to pro-

tect the compressor against moisture and debris.

•Reliable Operation - Ball bearing fan motors provide supe-

rior performance in extreme temperatures. Factory installed

accumulator ensures proper functioning across a wide range

of conditions.

•Environmentally Friendly - CFC-free R-410A refrigerant

delivers environmentally friendly performance with zero

ozone depletion.

•Top Discharge - Warm air is blown up, away from the struc-

ture and any landscaping and allows compact location on

multi-unit applications.

•Low Operating Sound Levels - Developed using CFD and

FEA tools, the sturdy cabinet and top design provides sound

performance of 72 dBA or lower. Compatible accessories for

further sound reduction are also available.

•Better Service Access - Diagonal base valves with open

access for low-loss fittings, single panel access to the electri-

cal controls, full corner access, and removable fan guard

allow easy access for unit maintenance.

•Agency Listed - Safety certified by CSA to UL 1995 / CSA

22.2. Performance certified to ANSI/AHRI Standard 210/240

in accordance with the Unitary Small Equipment certification

program.

5599020-BTG-F-0520

2 Johnson Controls Ducted Systems

LIST OF SECTIONS

DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

NOMENCLATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

PHYSICAL AND ELECTRICAL DATA . . . . . . . . . . . . . . . . . . . . . . . 3

DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS . . . . . . . 4

SYSTEM CAPACITY - Single Piece and Modular Air Handlers . . 5

SYSTEM CAPACITY - Upflow, Downflow &

Horizontal Furnaces and Coils (Coil Only Ratings) . . . . . . . . . . . 9

SYSTEM CAPACITY - With High Efficiency Motor Furnaces . . . . 9

APPLICATION & ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . 36

SOUND POWER RATINGS - COOLING . . . . . . . . . . . . . . . . . . . . . 36

SOUND POWER RATINGS - HEATING . . . . . . . . . . . . . . . . . . . . . 37

MECHANICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . 37

TYPICAL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

TYPICAL FIELD WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

ALTERNATIVE INSTALLATION CLEARANCES . . . . . . . . . . . . . . 39

PERFORMANCE DATA - 1.5 TON . . . . . . . . . . . . . . . . . . . . . . . . . 40

PERFORMANCE DATA - 2 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 45

PERFORMANCE DATA - 2.5 TON . . . . . . . . . . . . . . . . . . . . . . . . . 50

PERFORMANCE DATA - 3 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 55

PERFORMANCE DATA - 3.5 TON . . . . . . . . . . . . . . . . . . . . . . . . . 62

PERFORMANCE DATA - 4 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 68

PERFORMANCE DATA - 5 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 74

NOMENCLATURE

BRAND TT = Factory Branded

PRODUCT TYPE HH = Heat Pump

NOMINAL

SERIES EFFICIENCY

AND STAGING

66 = 16 SEER / 1-Stage

REFRIGERANT BB = R-410A

NOMINAL

UNIT CAPACITY

(MBH)

18 = 1.5 Ton 36 = 3 Ton

24 = 2 Ton 42 = 3.5 Ton

30 = 2.5 Ton 48 = 4 Ton

35 = 3 Ton 60 = 5 Ton

VOLTAGE

(Voltage-Phase-Hertz) 22 = 208/230-1-60

GENERATION

(MAJOR REVISION) 1

1 = 1st Gen

2 = 2nd Gen

etc

FACTORY OPTION SS = Standard (No Options)

STYLE LETTER

(Minor Revision)

Not Used for Ordering

A = Style A

B = Style B

5599020-BTG-F-0520

Johnson Controls Ducted Systems 3

‡ Adapter fitting must be field installed for the required 1-1/8” line set.

All dimensions are in inches and are subject to change without notice.

Overall height is from bottom of base pan to top of fan guard.

Overall length and width include screw heads.

PHYSICAL AND ELECTRICAL DATA

MODEL TH6B1821S TH6B2421S TH6B3021S TH6B3621S TH6B4221SS TH6B4821S TH6B6021S

Unit Supply Voltage 208-230V, 1 60Hz

Normal Voltage Range 1

1. Rated in accordance with AHRI Standard 110-2012, utilization range “A”.

187 to 252

Minimum Circuit Ampacity 14 15.5 19.6 22 28.7 25.9 32.4

Max. Overcurrent Device Amps 2

2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.

20 25 30 35 45 40 50

Min. Overcurrent Device Amps 3

3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.

15 20 20 25 30 30 35

Compressor Type Scroll Scroll Scroll Scroll Scroll Scroll Scroll

Compressor

Amps

Rated Load 9.0 11.8 13.4 15.4 20.7 18.5 23.68

Locked Rotor 47.5 62.9 72.5 83.9 123.9 124 152.5

Crankcase Heater Yes Yes Yes Yes Yes Yes Yes

Factory External Discharge Muffler Yes Yes Yes Yes Yes Yes Yes

HS Kit Required with TXV No No No No No No No

HS Kit Part Number (S1-2SA067*****)4

4. Use S1-2SA067***** series kit. See Hard Start Kit Accessory Installation Manual.

21806 10106 10106 10106 10106 10106 10106

Fan Diameter Inches 22 24 24 24 26 26 26

Fan Motor

Type ECM PSC ECM ECM ECM ECM ECM

Rated HP 1/3 1/8 1/3 1/3 1/3 1/3 1/3

Rated Load Amps 2.8 0.80 2.8 2.8 2.8 2.8 2.8

Nominal RPM 682 1075 682 682 682 834 834

Nominal CFM 2850 2995 2995 3715 3715 4100 4100

Coil

Face Area Sq. Ft. 17.9 23.8 23.8 23.8 26.4 31.2 31.2

Rows Deep 1 112222

Fins / Inch 22 22 22 18 18 18 18

Liquid Line Set OD (Field Installed) 3/8 3/8 3/8 3/8 3/8 3/8 3/8

Vapor Line Set OD (Field Installed)5

5. For applications with non-standard vapor line sizes, see the “Applications & Accessories” section of this Technical Guide.

3/4 3/4 3/4 3/4 7/8 7/8 1-1/8‡

Unit Charge (Lbs. - Oz.) 6

6. The Unit Charge is correct for the outdoor unit, smallest matched indoor unit, and 15 feet of refrigerant tubing. For tubing lengths other than 15 feet, add or subtract

the amount of refrigerant, using the difference in actual lineset length (not the equivalent length) multiplied by the per foot value.

6 - 2 9 - 7 8 - 9 11 - 6 13 - 14 14 - 10 16 - 13

Charge Per Foot, Oz. 0.62 0.62 0.62 0.62 0.67 0.67 0.75

Operating Weight Lbs. 165 175 175 230 235 300 300

$

DIMENSIONS

Unit

Model

Dimensions

(Inches)

Refrigerant Connection

Service Valve Size

A B C Liquid Vapor

TH6B1821S 36-1/4 35-1/4 31-3/4

3/8

3/4

TH6B2421S 39-1/2 35-1/4 31-3/4

TH6B3021S 39-1/2 35-1/4 31-3/4

TH6B3621S 39-1/2 35-1/4 31-3/4

TH6B4221S 39-1/2 38 34-1/4 7/8

TH6B4821S 46 38 34-1/4

TH6B6021S 46 38 34-1/4 7/8‡

5599020-BTG-F-0520

4 Johnson Controls Ducted Systems

CHARGING PROCEDURES:

1. Check the Factory Unit Charge listed on the unit nameplate to verify the refrigerant charge for the outdoor unit, the smallest matched indoor unit, and the 15 feet

of interconnecting lineset.

2. Verify the indoor metering device and additional charge required for the specific matched indoor unit in the system using the above table.

3. Add additional charge for the amount of interconnecting lineset tubing greater than 15 feet at the rate specified in Physical and Electrical Data Table.

4. For installations requiring additional charge, weigh in refrigerant for the specific matching indoor unit and actual lineset length.

5. Once the charge adders for matched indoor unit and for lineset have been weighed in, verify the system operation against the temperatures and pressures in the

Charging Chart for the outdoor unit. Locate Charging Charts on the outdoor unit and also in the Service Data Application Guide on

www.simplygettingthejobdone.com. Follow the Subcool or Superheat charging procedure in the Installation Manual according to the type of indoor metering device

in the system, and allow ten minutes after each charge adjustment for the system operation to stabilize. Record the charge adjustment made to match the Charging

Chart.

6. For Downflow and Horizontal-Right Installations, some indoor units require additional charging adjustments to ensure proper equipment operation. Refer to the

outdoor unit installation manual.

7. Permanently stamp the unit nameplate with the TOTAL SYSTEM CHARGE defined as follows: TOTAL SYSTEM CHARGE = Base Charge (as shipped) + charge

adder for matched indoor unit + charge adder for actual lineset length + charge adjustments to match the Charging Chart.

SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS

Outdoor Unit TH6B1821S TH6B2421S TH6B3021S TH6B3621S TH6B4221S TH6B4821S TH6B6021S

Required TXV 1,2

1. For applications requiring a TXV, use S1-1TVM*** series kit.

2. A TXV kit must be used with these indoor units to obtain system performance.

BA1 BA1 BA1 BA1 or BB1 BC1 BC1 BC1 or BD1

Defrost Jumper Pin Setting 2222211

Indoor Unit 3,4,5

3. Systems matched with furnaces or air handlers not equipped with blower-off delays may require 60 second time delay.

4. CF coils cannot be used in horizontal applications.

5. Charge adders shown above do not indicate that coils are rated for every application. Refer to Performance Data Tables for actual performance for specified

system matches. Obtain certified system ratings from www.ahridirectory.org.

Additional Charge, oz

AP18B –––––––

AP24B 0––––––

AP30B –38––––

AP36B –––––––

AP36C –––––––

AP37C –––––––

AP42C –––––––

AP48(C,D) ––––0––

AP60(C,D) –––––––

AE18B –––––––

AE24B 0––––––

AE30B 28 0 0 – – – –

AE36(B,C) –380–––

AE42C – – – 25 0 – –

AE43C ––––17––

AE48(C,D) – – – 25 0 – –

AE60C ––––200–

AE60D –––––520

AVC18B –––––––

AVC24B 0––––––

AVC30B 28 0 0 – – – –

AVC36(B,C) –380–––

AVC42C – – – 25 0 – –

AVC48(C,D) – – – 25 0 – –

AVC49C – – – 17 –

AVC60C ––––200–

AVC60D –––––520

CF/CM/CU18(A,B) –––––––

CF/CM/CU24(A,B) 0––––––

CF/CM/CU30(A,B,C) 28 0 0 – – – –

CF/CM/CU36(A,B,C) –380–––

CF/CM/CU42(B,C,D) –––––––

CF/CM/CU48(C,D) – – – 25 0 – –

CF/CM50C –––––47–

CF/CM/CU60(C,D) ––––200–

CF/CM61D –––––47–

CF/CM64D –––––520

Some of the combinations shown in the above System Charge table require Advanced Main Air Circulating Fan indoor product. For approved coil

only matches, please see the “COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils” table.

FOOTNOTES:

5599020-BTG-F-0520

Johnson Controls Ducted Systems 5

SYSTEM CAPACITY - Single Piece and Modular Air Handlers

UNIT

MODEL

AIR HANDLER COIL

MODEL3

RATED

CFM

COOLING 1HEATING 2

MODEL WIDTH NET MBH SEER EER NET MBH HSPF

Region IV

HSPF

Region V

COP

TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD

TH6B1821S AE24BX21 17.5 – 625 18.0 12.6 17.00 13.00 18.0 11.9 10.00 8.15 4.80 3.24

TH6B1821S AE30BX21 17.5 – 600 18.0 12.8 17.00 13.00 18.0 11.4 10.00 8.15 4.58 3.08

TH6B1821S AP24BX21 17.5 – 675 18.0 13.3 16.00 13.00 18.0 12.4 9.50 7.95 4.34 2.96

TH6B1821S AVC24BX21 17.5 – 600 18.0 12.2 17.00 13.00 18.0 11.7 10.00 8.30 4.62 3.14

TH6B1821S AVC30BX21 17.5 – 675 18.0 13.8 17.00 13.00 17.2 10.2 9.50 8.40 4.22 2.74

TH6B1821S ME08BN21 17.5 CF/CM24B 575 18.0 12.1 17.00 13.00 18.0 11.7 10.00 8.30 4.54 3.10

TH6B1821S ME08BN21 17.5 CF/CM30B 600 18.0 12.8 17.00 13.00 18.0 11.4 10.00 8.25 4.52 3.06

TH6B1821S ME12BN21 17.5 CF/CM24B 675 18.0 12.9 17.00 13.00 18.0 11.9 10.00 8.15 4.80 3.24

TH6B1821S ME12BN21 17.5 CF/CM30B 675 18.0 13.4 17.00 13.00 18.0 11.6 10.00 8.15 4.68 3.14

TH6B1821S ME12CN21 21.0 CF/CM24C 600 18.0 12.2 17.00 13.00 18.0 11.7 10.00 8.25 4.62 3.14

TH6B1821S ME12CN21 21.0 CF/CM30C 600 18.0 12.8 17.00 13.00 18.0 11.4 10.00 8.25 4.52 3.06

TH6B1821S MVC08BN21 17.5 CF/CM24B 625 18.0 12.5 17.00 13.00 18.0 11.8 10.00 8.20 4.68 3.18

TH6B1821S MVC08BN21 17.5 CF/CM30B 650 18.0 13.2 17.00 13.00 18.0 11.5 10.00 8.15 4.64 3.10

TH6B1821S MVC12CN21 21.0 CF/CM24C 650 18.0 12.7 17.00 13.00 18.0 11.8 10.00 8.20 4.78 3.22

TH6B1821S MVC12CN21 21.0 CF/CM30C 650 18.0 13.2 17.00 13.00 18.0 11.5 10.00 8.15 4.66 3.14

TH6B2421S AE30BX21 17.5 – 900 24.0 18.7 16.00 13.00 23.0 13.5 8.50 6.85 3.86 2.36

TH6B2421S AE36BX21 17.5 – 850 23.8 18.4 16.00 13.00 23.2 14.2 9.00 7.25 4.04 2.58

TH6B2421S AE36CX21 21.0 – 800 23.4 17.6 16.00 13.00 23.0 14.1 9.00 7.25 4.10 2.60

TH6B2421S AP30BX21 17.5 – 850 23.2 18.3 15.00 12.25 23.6 14.7 9.00 7.45 3.82 2.46

TH6B2421S AVC30BX21 17.5 – 900 24.0 18.8 16.00 13.00 23.0 13.5 8.50 6.90 3.76 2.30

TH6B2421S AVC36BX21 17.5 – 825 23.6 18.1 16.00 13.00 23.2 14.3 9.00 7.70 3.84 2.50

TH6B2421S AVC36CX21 21.0 – 950 24.0 19.2 17.00 13.00 23.2 14.3 10.00 8.10 4.32 2.70

TH6B2421S ME08BN21 17.5 CF/CM30B 900 24.0 18.7 16.00 13.00 23.0 13.5 8.50 6.90 3.78 2.30

TH6B2421S ME08BN21 17.5 CF/CM36B 900 24.0 18.9 16.00 13.00 23.2 14.3 9.00 7.30 4.08 2.60

TH6B2421S ME12BN21 17.5 CF/CM30B 875 24.0 18.5 16.00 13.00 22.8 13.4 8.20 6.60 3.74 2.30

TH6B2421S ME12BN21 17.5 CF/CM36B 875 24.0 18.6 17.00 13.00 23.2 14.2 9.00 7.30 4.04 2.58

TH6B2421S ME12CN21 21.0 CF/CM30C 850 24.0 18.4 16.00 13.00 22.8 13.3 8.20 6.65 3.68 2.26

TH6B2421S ME12CN21 21.0 CF/CM36C 850 23.8 18.4 17.00 13.00 23.0 14.2 9.00 7.30 3.98 2.56

TH6B2421S ME16CN21 21.0 CF/CM30C 925 24.0 18.9 16.00 13.00 23.0 13.4 8.50 6.80 3.90 2.36

TH6B2421S ME16CN21 21.0 CF/CM36C 925 24.0 19.0 17.00 13.00 23.2 14.3 9.00 7.20 4.22 2.66

TH6B2421S MVC08BN21 17.5 CF/CM30B 800 23.8 17.9 15.00 13.00 22.8 13.3 8.20 6.75 3.52 2.20

TH6B2421S MVC08BN21 17.5 CF/CM36B 800 23.4 17.8 16.00 13.00 23.0 14.2 9.00 7.45 3.82 2.46

TH6B2421S MVC12BN21 17.5 CF/CM30B 950 24.0 19.1 16.00 13.00 23.0 13.5 9.00 7.30 3.96 2.38

TH6B2421S MVC12BN21 17.5 CF/CM36B 950 24.0 19.2 17.00 13.00 23.4 14.4 10.00 8.15 4.28 2.68

TH6B2421S MVC12CN21 21.0 CF/CM30C 875 24.0 18.5 16.00 13.00 22.8 13.3 8.50 6.90 3.78 2.32

TH6B2421S MVC12CN21 21.0 CF/CM36C 875 24.0 18.7 17.00 13.00 23.0 14.2 9.50 7.80 4.10 2.60

TH6B2421S MVC16CN21 21.0 CF/CM30C 925 24.0 18.8 16.00 13.00 22.8 13.4 9.00 7.30 3.92 2.38

TH6B2421S MVC16CN21 21.0 CF/CM36C 925 24.0 18.9 17.00 13.00 23.2 14.2 9.50 7.65 4.24 2.68

5599020-BTG-F-0520

6 Johnson Controls Ducted Systems

TH6B3021S AE30BX21 17.5 – 1125 30.0 22.4 17.00 13.00 28.4 17.2 9.50 7.90 4.12 2.74

TH6B3021S AE36BX21 17.5 – 1100 30.0 22.0 16.00 13.00 28.6 17.9 9.00 7.55 3.96 2.68

TH6B3021S AE36CX21 21.0 – 1175 30.0 22.2 16.00 13.00 28.6 17.9 9.00 7.50 4.12 2.76

TH6B3021S AP30BX21 17.5 – 1075 30.0 22.0 15.00 12.25 29.0 18.3 9.00 7.65 3.76 2.56

TH6B3021S AVC30BX21 17.5 – 1100 30.0 22.2 16.00 13.00 28.2 17.2 9.00 7.50 4.04 2.72

TH6B3021S AVC36BX21 17.5 – 1025 30.0 22.0 16.00 13.00 28.2 17.6 9.00 7.80 3.82 2.62

TH6B3021S AVC36CX21 21.0 – 1100 30.0 21.8 16.00 13.00 28.4 17.6 9.00 7.55 4.00 2.70

TH6B3021S ME12BN21 17.5 CF/CM30B 1050 30.0 21.8 17.00 13.00 27.8 16.9 9.00 7.45 4.06 2.74

TH6B3021S ME12BN21 17.5 CF/CM36B 1050 30.0 21.6 16.00 13.00 28.2 17.6 9.00 7.60 3.90 2.66

TH6B3021S ME12CN21 21.0 CF/CM30C 1000 30.0 21.6 17.00 13.00 27.6 16.7 9.00 7.45 4.06 2.76

TH6B3021S ME12CN21 21.0 CF/CM36C 1000 30.0 21.2 16.00 13.00 28.0 17.4 9.00 7.60 3.90 2.66

TH6B3021S ME16CN21 21.0 CF/CM30C 1100 30.0 22.2 17.00 13.00 28.0 16.9 9.00 7.40 4.16 2.80

TH6B3021S ME16CN21 21.0 CF/CM36C 1100 30.0 21.8 16.00 13.00 28.4 17.6 9.00 7.55 4.00 2.70

TH6B3021S MVC12BN21 17.5 CF/CM30B 1125 30.0 22.2 17.00 13.00 28.2 17.1 9.00 7.40 4.14 2.76

TH6B3021S MVC12BN21 17.5 CF/CM36B 1075 30.0 21.8 16.00 13.00 28.4 17.7 9.00 7.55 3.94 2.66

TH6B3021S MVC12CN21 21.0 CF/CM30C 1175 30.0 22.4 17.00 13.00 28.2 17.0 9.50 7.85 4.28 2.84

TH6B3021S MVC12CN21 21.0 CF/CM36C 1125 30.0 22.0 16.00 13.00 28.4 17.6 9.00 7.50 4.06 2.74

TH6B3021S MVC16CN21 21.0 CF/CM30C 1125 30.0 22.2 17.00 13.00 28.0 16.9 9.50 7.90 4.24 2.82

TH6B3021S MVC16CN21 21.0 CF/CM36C 1125 30.0 22.0 16.00 13.00 28.4 17.6 9.00 7.50 4.06 2.74

TH6B3621S AE36BX21 17.5 – 975 35.0 22.8 15.00 13.00 35.0 22.8 9.00 7.85 3.68 2.62

TH6B3621S AE36CX21 21.0 – 975 35.2 23.0 16.00 13.00 35.0 22.6 9.00 7.80 3.74 2.66

TH6B3621S AE42CX21 21.0 – 950 36.0 23.0 16.00 13.00 36.0 22.8 9.00 7.70 3.76 2.62

TH6B3621S AE48CX21 21.0 – 1075 36.0 25.0 17.00 13.00 35.6 22.8 9.00 8.15 3.74 2.62

TH6B3621S AE48DX21 24.5 – 1050 36.0 23.6 16.50 13.00 36.0 22.8 9.00 7.60 3.90 2.66

TH6B3621S AVC36BX21 17.5 – 925 34.8 22.4 15.00 13.00 34.8 22.6 9.00 7.90 3.60 2.58

TH6B3621S AVC36CX21 21.0 – 900 35.0 22.2 16.00 13.00 34.6 22.4 9.00 7.85 3.62 2.60

TH6B3621S AVC42CX21 21.0 – 925 36.0 22.8 16.00 13.00 36.0 22.8 9.00 7.75 3.68 2.58

TH6B3621S AVC48CX21 21.0 – 925 36.0 22.8 16.00 13.00 36.0 22.8 9.00 7.75 3.70 2.58

TH6B3621S AVC48DX21 24.5 – 975 36.0 23.2 16.00 13.00 36.0 22.8 9.00 7.75 3.76 2.62

TH6B3621S ME12BN21 17.5 CF/CM36B 1050 35.4 23.8 15.25 13.00 35.2 22.8 9.00 7.80 3.72 2.64

TH6B3621S ME12CN21 21.0 CF/CM36C 1000 35.2 23.2 16.00 13.00 35.0 22.6 9.00 7.80 3.70 2.64

TH6B3621S ME12CN21 21.0 CF/CM48C 1000 36.0 23.4 16.00 13.00 36.0 22.8 9.00 7.70 3.76 2.60

TH6B3621S ME14DN21 24.5 CF/CM36D 1025 35.4 23.6 16.00 13.00 35.0 22.6 9.00 7.75 3.74 2.66

TH6B3621S ME14DN21 24.5 CF/CM48D 1025 36.0 23.4 16.00 13.00 36.0 22.8 9.00 7.70 3.78 2.62

TH6B3621S ME16CN21 21.0 CF/CM36C 1100 35.6 24.2 15.25 13.00 35.4 22.8 9.00 7.75 3.78 2.66

TH6B3621S ME16CN21 21.0 CF/CM48C 1100 36.0 24.0 16.00 13.00 36.0 23.0 9.00 7.65 3.82 2.62

TH6B3621S ME20DN21 24.5 CF/CM36D 1275 36.0 26.0 16.00 13.00 35.8 23.0 9.00 7.60 4.02 2.76

TH6B3621S ME20DN21 24.5 CF/CM48D 1275 36.0 25.0 16.00 13.00 36.0 22.8 9.00 7.50 4.02 2.70

SYSTEM CAPACITY - Single Piece and Modular Air Handlers

UNIT

MODEL

AIR HANDLER COIL

MODEL3

RATED

CFM

COOLING 1HEATING 2

MODEL WIDTH NET MBH SEER EER NET MBH HSPF

Region IV

HSPF

Region V

COP

TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD

5599020-BTG-F-0520

Johnson Controls Ducted Systems 7

TH6B3621S MVC12BN21 17.5 CF/CM36B 950 35.0 22.6 15.25 13.00 34.8 22.6 9.00 7.85 3.64 2.60

TH6B3621S MVC12CN21 21.0 CF/CM36C 1000 35.4 23.4 16.00 13.00 34.8 22.6 9.00 7.80 3.72 2.66

TH6B3621S MVC12CN21 21.0 CF/CM48C 975 36.0 23.2 16.00 13.00 36.0 22.8 9.00 7.75 3.74 2.62

TH6B3621S MVC14DN21 24.5 CF/CM36D 1100 35.8 24.4 16.00 13.00 35.2 22.6 9.00 7.70 3.84 2.70

TH6B3621S MVC14DN21 24.5 CF/CM48D 1000 36.0 23.2 16.50 13.00 36.0 22.8 9.00 7.70 3.78 2.62

TH6B3621S MVC16CN21 21.0 CF/CM36C 1025 35.4 23.6 16.00 13.00 35.0 22.6 9.00 7.75 3.74 2.66

TH6B3621S MVC16CN21 21.0 CF/CM48C 1025 36.0 23.4 16.00 13.00 36.0 22.8 9.00 7.70 3.78 2.62

TH6B3621S MVC20DN21 24.5 CF/CM36D 1175 36.0 25.2 16.00 13.00 35.4 22.8 9.00 7.70 3.92 2.74

TH6B3621S MVC20DN21 24.5 CF/CM48D 1175 36.0 24.4 16.50 13.00 36.0 22.8 9.00 7.60 3.94 2.68

TH6B4221S AE42CX21 21.0 – 1150 41.0 27.2 16.00 13.00 42.0 25.4 9.00 7.25 3.76 2.64

TH6B4221S AE43CX21 21.0 – 1200 41.5 28.4 16.00 13.00 40.5 25.6 9.50 7.90 3.84 2.76

TH6B4221S AE48CX21 21.0 – 1200 41.0 27.4 16.00 13.00 42.0 25.6 9.00 7.00 3.84 2.70

TH6B4221S AE48DX21 24.5 – 1250 41.5 28.2 16.50 13.00 42.0 25.6 9.50 7.80 3.90 2.74

TH6B4221S AE60CX21 21.0 – 1200 41.5 28.4 16.00 13.00 41.5 27.2 9.50 7.80 3.84 2.84

TH6B4221S AE60CX22 21.0 – 1200 41.5 28.4 16.00 13.00 41.5 27.2 9.50 7.80 3.84 2.84

TH6B4221S AP48CX21 21.0 – 1300 40.5 28.2 15.00 12.25 42.0 26.8 9.00 7.35 3.68 2.60

TH6B4221S AVC42CX21 21.0 – 1250 41.0 28.0 16.00 13.00 42.0 25.8 9.00 7.10 3.78 2.66

TH6B4221S AVC48CX21 21.0 – 1200 41.0 27.6 16.00 13.00 42.0 25.6 9.00 7.15 3.78 2.66

TH6B4221S AVC48DX21 24.5 – 1225 41.0 27.6 16.50 13.00 42.0 25.4 9.00 7.05 3.82 2.70

TH6B4221S AVC49CX21 21.0 – 1200 41.5 29.0 16.00 13.00 41.5 26.4 9.50 8.55 3.76 2.78

TH6B4221S ME14DN21 24.5 CF/CM48D 1200 41.0 27.4 16.00 13.00 42.0 25.4 9.00 7.10 3.80 2.66

TH6B4221S ME14DN21 24.5 CF/CM60D 1200 41.5 28.4 16.50 13.00 41.0 27.0 9.50 7.80 3.82 2.86

TH6B4221S ME16CN21 21.0 CF/CM48C 1325 41.0 28.4 16.00 13.00 42.0 26.2 9.00 7.05 3.82 2.70

TH6B4221S ME16CN21 21.0 CF/CM60C 1325 41.5 29.6 16.00 13.00 42.0 27.4 9.00 6.80 3.86 2.82

TH6B4221S ME20DN21 24.5 CF/CM48D 1275 41.5 28.4 16.50 13.00 42.0 25.6 9.00 6.95 3.86 2.72

TH6B4221S ME20DN21 24.5 CF/CM60D 1275 42.0 29.4 16.50 13.00 41.5 27.0 9.50 7.70 3.90 2.86

TH6B4221S MVC14DN21 24.5 CF/CM48D 1250 41.5 28.2 16.50 13.00 42.0 25.6 9.00 6.90 3.86 2.72

TH6B4221S MVC14DN21 24.5 CF/CM60D 1250 42.0 29.2 16.50 13.00 41.0 27.0 9.50 7.70 3.90 2.88

TH6B4221S MVC16CN21 21.0 CF/CM48C 1275 41.5 28.4 16.00 13.00 42.0 25.8 9.00 6.90 3.84 2.70

TH6B4221S MVC16CN21 21.0 CF/CM60C 1275 42.0 29.4 16.50 13.00 41.5 27.2 9.50 7.75 3.88 2.86

TH6B4221S MVC20DN21 24.5 CF/CM48D 1275 41.5 28.2 16.50 13.00 42.0 25.6 9.00 6.85 3.88 2.72

TH6B4221S MVC20DN21 24.5 CF/CM60D 1275 42.0 29.4 16.50 13.00 41.5 27.0 9.50 8.10 3.92 2.88

TH6B4821S AE60CX22 21.0 – 1400 45.5 31.8 15.50 13.00 46.0 29.6 9.00 7.75 3.86 2.84

TH6B4821S AE60DX21 24.5 – 1350 47.5 32.2 16.00 13.00 46.5 27.0 9.00 7.40 4.06 2.74

TH6B4821S AVC60DX21 24.5 – 1425 47.5 32.8 16.00 13.00 47.0 27.6 9.00 7.40 4.06 2.74

TH6B4821S ME16CN21 21.0 CF/CM50C 1475 48.0 36.4 16.00 13.00 45.5 27.8 8.50 7.30 3.54 2.54

TH6B4821S ME16CN21 21.0 CF/CM60C 1500 45.5 32.4 15.00 13.00 46.5 30.0 9.00 7.75 3.88 2.84

TH6B4821S ME20DN21 24.5 CF/CM60D 1500 46.0 32.4 16.00 13.00 46.0 29.6 9.00 7.70 3.98 2.90

SYSTEM CAPACITY - Single Piece and Modular Air Handlers

UNIT

MODEL

AIR HANDLER COIL

MODEL3

RATED

CFM

COOLING 1HEATING 2

MODEL WIDTH NET MBH SEER EER NET MBH HSPF

Region IV

HSPF

Region V

COP

TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD

5599020-BTG-F-0520

8 Johnson Controls Ducted Systems

3. CM coils available with a factory installed horizontal drain pan. See price pages for specific model number.

— = Not applicable.

* Notates “Hot Heat Pump” performance. These ratings are not AHRI listed.

MP Modular Air Handlers use Coil Only Ratings.

TH6B4821S ME20DN21 24.5 CF/CM61D 1450 48.0 35.8 16.00 13.00 45.0 27.4 8.50 7.25 3.62 2.60

TH6B4821S ME20DN21 24.5 CF/CM64D 1475 47.5 33.0 16.50 13.00 47.0 27.6 9.00 7.40 4.14 2.82

TH6B4821S MV20DN21 24.5 CF/CM61D 1400 46.0 33.2 16.00 13.00 46.5 29.6 9.00 8.15 3.76 2.76

TH6B4821S MVC16CN21 21.0 CF/CM50C 1425 48.0 35.8 16.00 13.00 45.0 27.6 8.50 7.30 3.58 2.58

TH6B4821S MVC16CN21 21.0 CF/CM60C 1,400 45.5 31.8 16.00 13.00 46.0 29.4 9.00 7.75 3.86 2.84

TH6B4821S MVC20DN21 24.5 CF/CM60D 1,375 46.0 31.8 16.00 13.00 45.5 29.2 9.00 7.75 3.90 2.88

TH6B4821S MVC20DN21 24.5 CF/CM64D 1,550 48.0 34.0 16.00 13.00 47.5 28.2 9.00 7.40 4.20 2.86

TH6B6021S AE60DX21 24.5 – 1,550 57.5 38.5 15.00 12.50 58.0 36.0 9.00 7.40 3.78 2.60

TH6B6021S AVC60DX21 24.5 – 1,600 57.5 39.5 15.00 12.50 58.0 36.8 9.50 7.95 3.76 2.60

TH6B6021S ME20DN21 24.5 CF/CM64D 1,675 57.5 39.5 15.00 12.50 58.0 37.0 9.50 – 3.88 2.68

TH6B6021S MVC20DN21 24.5 CF/CM61D 1,625 53.0 37.2 14.00 12.00 55.5 35.0 8.20 7.40 3.46 2.30

TH6B6021S MVC20DN21 24.5 CF/CM64D 1,575 57.5 39.0 15.50 13.00 58.0 36.0 9.50 – 3.84 2.64

Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.

1. Cooling MBH based on 80°F entering air temperature, 50% RH (Relative Humidity), and rated air flow.

EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.

SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total electric power input in watt-hours during the same period.

2. Heating MBH based on AHRI standards of 70°F DB (Dry Bulb) entering indoor air, 72% RH (Relative Humidity) outdoor air with 25 feet of interconnecting piping and no supplemental electric heat operation.

HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the total electric power input during the same period.

COP (Coefficient of Performance) equals Heating MBH output divided by (total KW input x 3.412).

SYSTEM CAPACITY - Single Piece and Modular Air Handlers

UNIT

MODEL

AIR HANDLER COIL

MODEL3

RATED

CFM

COOLING 1HEATING 2

MODEL WIDTH NET MBH SEER EER NET MBH HSPF

Region IV

HSPF

Region V

COP

TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD

5599020-BTG-F-0520

Johnson Controls Ducted Systems 9

— = Not Applicable.

MP Modular Air Handlers use Coil Only Ratings.

PSC furnaces, such as the TG8S, TGLS, and TG9S, use Coil Only Ratings.

SYSTEM CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Coil Only Ratings)

UNIT MODEL

COIL CFM RANGE

(MIN.-MAX.)

COOLING HEATING

MODEL WIDTH RATED

CFM

NET MBH SEER 1EER NET MBH HSPF

Region IV

HSPF

Region V

COP

TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD

TH6B1821S CF/CM/CU24A 14.5 450 - 750 600 18.0 12.7 16.00 13.00 18.0 12.3 9.50 8.05 4.18 2.86

TH6B1821S CF/CM/CU24B 17.5 450 - 750 600 18.0 12.7 16.00 13.00 18.0 12.3 9.50 8.05 4.18 2.86

TH6B1821S CF/CM24C 21.0 450 - 750 600 18.0 12.7 16.00 13.00 18.0 12.3 9.50 8.05 4.18 2.86

TH6B3021S CF/CM/CU30A 14.5 800 - 1200 825 28.8 20.2 15.00 13.00 27.6 17.0 8.20 6.95 3.62 2.50

TH6B3021S CF/CM/CU30B 17.5 800 - 1200 1000 29.4 21.6 15.00 13.00 28.4 17.4 8.50 7.15 3.76 2.56

TH6B3021S CF/CM30C 21.0 800 - 1200 1000 29.4 21.6 15.00 13.00 28.4 17.4 8.50 7.15 3.76 2.56

TH6B4221S CF/CM/CU48C 21.0 1200-1600 1400 42.0 30.2 14.00 12.00 42.0 25.6 8.20 7.15 3.54 2.46

TH6B4221S CF/CM/CU48D 24.0 1200-1600 1400 42.0 30.2 14.00 12.00 42.0 25.6 8.20 7.15 3.54 2.46

TH6B4221S CF/CM/CU60C 21.0 1200-1600 1400 42.0 31.1 15.00 13.00 41.0 26.8 9.00 7.50 3.58 2.54

TH6B6021S CF/CM64D 24.5 1520 - 1920 1850 57.5 41.5 14.00 12.00 58.0 39.5 9.00 7.50 3.86 2.70

For rated condition information, see the footnotes below the System Capacity - Single Piece and Modular Air Handlers table.

1. Systems matched with furnaces or air handlers not equipped with blower-off delays may require 60 second time delay.

SYSTEM CAPACITY - With High Efficiency Motor Furnaces1

UNIT

MODEL

FURNACE COIL

MODEL2

COOLING HEATING

MODEL WIDTH RATED

CFM

NET MBH SEER EER NET MBH HSPF

Region IV

HSPF

Region V

COP

TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD

TH6B1821S TM8V060A12MP12C 14.5 CF/CM/CU24A 575 18.0 12.1 17.00 13.00 18.0 11.7 10.00 8.30 4.50 3.06

TH6B1821S TM8V060A12MP12C 14.5 CF/CM/CU24B 575 18.0 12.1 17.00 13.00 18.0 11.7 10.00 8.35 4.52 3.08

TH6B1821S TM8V060A12MP12C 14.5 CF/CM/CU30A 575 18.0 12.6 17.00 13.00 18.0 11.4 10.00 8.25 4.38 2.98

TH6B1821S TM8V060A12MP12C 14.5 CF/CM/CU30B 625 18.0 13.1 17.00 13.00 18.0 11.5 10.00 8.20 4.52 3.04

TH6B1821S TM8V080B12MP12C 17.5 CF/CM/CU24B 625 18.0 12.5 17.00 13.00 18.0 11.9 10.00 8.30 4.58 3.10

TH6B1821S TM8V080B12MP12C 17.5 CF/CM/CU30B 550 18.0 12.4 17.00 13.00 18.0 11.4 10.00 8.35 4.32 2.94

TH6B1821S TM8V080B12MP12C 17.5 CF/CM24C 625 18.0 12.5 17.00 13.00 18.0 11.9 10.00 8.30 4.58 3.12

TH6B1821S TM8V080B12MP12C 17.5 CF/CM30C 625 18.0 13.1 17.00 13.00 18.0 11.5 10.00 8.25 4.48 3.02

TH6B1821S TM8X060A12MP11 14.5 CF/CM/CU24A 625 18.0 12.5 17.00 13.00 18.0 11.9 10.00 8.30 4.58 3.10

TH6B1821S TM8X060A12MP11 14.5 CF/CM/CU24B 650 18.0 12.8 17.00 13.00 18.0 11.9 10.00 8.30 4.66 3.14

TH6B1821S TM8X060A12MP11 14.5 CF/CM/CU30A 625 18.0 13.1 17.00 13.00 18.0 11.6 10.00 8.25 4.48 3.02

TH6B1821S TM8X060A12MP11 14.5 CF/CM/CU30B 650 18.0 13.3 17.00 13.00 18.0 11.6 10.00 8.20 4.56 3.06

TH6B1821S TM8X080B12MP11 17.5 CF/CM/CU24B 675 18.0 13.0 17.00 13.00 18.0 12.0 10.00 8.25 4.72 3.18

TH6B1821S TM8X080B12MP11 17.5 CF/CM/CU30B 675 18.0 13.5 17.00 13.00 18.0 11.6 10.00 8.15 4.62 3.10

TH6B1821S TM8X080B12MP11 17.5 CF/CM24C 675 18.0 13.0 17.00 13.00 18.0 12.0 10.00 8.20 4.74 3.20

TH6B1821S TM8X080B12MP11 17.5 CF/CM30C 675 18.0 13.5 17.00 13.00 18.0 11.6 10.00 8.15 4.64 3.10

TH6B1821S TM8X080C16MP11 21.0 CF/CM24C 700 18.0 13.1 17.00 13.00 18.0 12.0 10.00 8.20 4.84 3.24

TH6B1821S TM8X080C16MP11 21.0 CF/CM30C 700 18.0 13.7 17.00 13.00 18.0 11.6 10.00 8.10 4.72 3.16

5599020-BTG-F-0520

10 Johnson Controls Ducted Systems

TH6B1821S TM8X100C16MP11 21.0 CF/CM24C 700 18.0 13.1 17.00 13.00 18.0 12.0 10.00 8.20 4.84 3.24

TH6B1821S TM8X100C16MP11 21.0 CF/CM30C 700 18.0 13.7 17.00 13.00 18.0 11.6 10.00 8.10 4.72 3.16

TH6B1821S TM8Y060A12MP11 14.5 CF/CM/CU24A 625 18.0 12.5 17.00 13.00 18.0 11.9 10.00 8.30 4.58 3.10

TH6B1821S TM8Y060A12MP11 14.5 CF/CM/CU24B 650 18.0 12.8 17.00 13.00 18.0 11.9 10.00 8.30 4.66 3.14

TH6B1821S TM8Y060A12MP11 14.5 CF/CM/CU30A 625 18.0 13.1 17.00 13.00 18.0 11.6 10.00 8.25 4.48 3.02

TH6B1821S TM8Y060A12MP11 14.5 CF/CM/CU30B 650 18.0 13.3 17.00 13.00 18.0 11.6 10.00 8.20 4.56 3.06

TH6B1821S TM8Y080B12MP11 17.5 CF/CM/CU24B 675 18.0 13.0 17.00 13.00 18.0 12.0 10.00 8.25 4.72 3.18

TH6B1821S TM8Y080B12MP11 17.5 CF/CM/CU30B 675 18.0 13.5 17.00 13.00 18.0 11.6 10.00 8.15 4.62 3.10

TH6B1821S TM8Y080B12MP11 17.5 CF/CM24C 675 18.0 13.0 17.00 13.00 18.0 12.0 10.00 8.20 4.74 3.20

TH6B1821S TM8Y080B12MP11 17.5 CF/CM30C 675 18.0 13.5 17.00 13.00 18.0 11.6 10.00 8.15 4.64 3.10

TH6B1821S TM8Y080C16MP11 21.0 CF/CM24C 700 18.0 13.1 17.00 13.00 18.0 12.0 10.00 8.20 4.84 3.24

TH6B1821S TM8Y080C16MP11 21.0 CF/CM30C 700 18.0 13.7 17.00 13.00 18.0 11.6 10.00 8.10 4.72 3.16

TH6B1821S TM8Y100C16MP11 21.0 CF/CM24C 700 18.0 13.1 17.00 13.00 18.0 12.0 10.00 8.20 4.84 3.24

TH6B1821S TM8Y100C16MP11 21.0 CF/CM30C 700 18.0 13.7 17.00 13.00 18.0 11.6 10.00 8.10 4.72 3.16

TH6B1821S TM9E040A10MP11 14.5 CF/CM/CU24A 675 18.0 13.2 17.00 13.00 18.0 12.3 10.00 8.35 4.46 3.04

TH6B1821S TM9E040A10MP11 14.5 CF/CM/CU24B 700 18.0 13.4 17.00 13.00 18.0 12.3 10.00 8.30 4.54 3.08

TH6B1821S TM9E040A10MP11 14.5 CF/CM/CU30A 675 18.0 13.7 16.00 13.00 18.0 11.9 9.50 7.80 4.38 2.94

TH6B1821S TM9E040A10MP11 14.5 CF/CM/CU30B 700 18.0 13.9 16.00 13.00 18.0 11.9 9.50 7.80 4.46 2.98

TH6B1821S TM9E060B12MP11 17.5 CF/CM/CU24B 675 18.0 13.0 17.00 13.00 18.0 12.0 10.00 8.25 4.66 3.16

TH6B1821S TM9E060B12MP11 17.5 CF/CM/CU30B 675 18.0 13.5 17.00 13.00 18.0 11.7 10.00 8.20 4.56 3.06

TH6B1821S TM9E060B12MP11 17.5 CF/CM24C 675 18.0 13.0 17.00 13.00 18.0 12.0 10.00 8.25 4.66 3.16

TH6B1821S TM9E060B12MP11 17.5 CF/CM30C 675 18.0 13.5 17.00 13.00 18.0 11.7 10.00 8.20 4.58 3.06

TH6B1821S TM9E080B12MP11 17.5 CF/CM/CU24B 700 18.0 13.2 17.00 13.00 18.0 12.0 10.00 8.20 4.76 3.20

TH6B1821S TM9E080B12MP11 17.5 CF/CM/CU30B 700 18.0 13.8 17.00 13.00 18.0 11.7 10.00 8.15 4.66 3.12

TH6B1821S TM9E080B12MP11 17.5 CF/CM24C 700 18.0 13.2 17.00 13.00 18.0 12.0 10.00 8.20 4.78 3.20

TH6B1821S TM9E080B12MP11 17.5 CF/CM30C 700 18.0 13.8 17.00 13.00 18.0 11.7 10.00 8.15 4.66 3.12

TH6B1821S TM9E080C16MP11 21.0 CF/CM24C 600 18.0 12.3 17.00 13.00 18.0 11.8 10.00 8.30 4.58 3.12

TH6B1821S TM9E080C16MP11 21.0 CF/CM30C 600 18.0 12.8 17.00 13.00 18.0 11.4 10.00 8.25 4.48 3.04

TH6B1821S TM9E100C16MP11 21.0 CF/CM24C 625 18.0 12.6 17.00 13.00 18.0 11.8 10.00 8.25 4.62 3.14

TH6B1821S TM9E100C16MP11 21.0 CF/CM30C 625 18.0 13.0 17.00 13.00 18.0 11.5 10.00 8.20 4.52 3.06

TH6B1821S TM9V040A10MP12C 14.5 CF/CM/CU24A 575 18.0 12.1 17.00 13.00 18.0 11.9 10.00 8.40 4.40 3.00

TH6B1821S TM9V040A10MP12C 14.5 CF/CM/CU24B 575 18.0 12.2 17.00 13.00 18.0 11.8 10.00 8.40 4.42 3.02

TH6B1821S TM9V040A10MP12C 14.5 CF/CM/CU30A 575 18.0 12.7 16.00 13.00 18.0 11.5 9.50 7.85 4.30 2.92

TH6B1821S TM9V040A10MP12C 14.5 CF/CM/CU30B 575 18.0 12.7 16.50 13.25 18.0 11.5 9.00 7.35 4.32 2.94

TH6B1821S TM9V060B12MP12C 17.5 CF/CM/CU24B 600 18.0 12.3 17.00 13.00 18.0 11.8 10.00 8.30 4.54 3.10

TH6B1821S TM9V060B12MP12C 17.5 CF/CM/CU30B 550 18.0 12.4 17.00 13.00 18.0 11.3 10.00 8.30 4.34 2.96

TH6B1821S TM9V060B12MP12C 17.5 CF/CM24C 650 18.0 12.8 17.00 13.00 18.0 11.9 10.00 8.25 4.64 3.14

SYSTEM CAPACITY - With High Efficiency Motor Furnaces1

UNIT

MODEL

FURNACE COIL

MODEL2

COOLING HEATING

MODEL WIDTH RATED

CFM

NET MBH SEER EER NET MBH HSPF

Region IV

HSPF

Region V

COP

TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD

Autres manuels pour LX Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Johnson Controls Pompe à chaleur

Johnson Controls

Johnson Controls RL Series Manuel du propriétaire

Johnson Controls

Johnson Controls HMH7 Series Manuel utilisateur

Johnson Controls

Johnson Controls RHP14J 184S21 Guide de démarrage rapide

Johnson Controls

Johnson Controls JE-Series Manuel utilisateur

Johnson Controls

Johnson Controls 13 SEER - THGD Manuel utilisateur

Johnson Controls

Johnson Controls DHPM09NWM42Q1 Manuel utilisateur

Johnson Controls

Johnson Controls YD360 Manuel utilisateur

Johnson Controls

Johnson Controls RHP143 Series Manuel utilisateur

Johnson Controls

Johnson Controls YHG Series Manuel utilisateur

Johnson Controls

Johnson Controls DOAS Series Manuel utilisateur

Johnson Controls

Johnson Controls RBS009 Manuel utilisateur

Johnson Controls

Johnson Controls Duct R-410A Guide de démarrage rapide

Johnson Controls

Johnson Controls RHP150 Series Manuel utilisateur

Johnson Controls

Johnson Controls SABROE HicaHP Manuel utilisateur

Johnson Controls

Johnson Controls VB09 Instructions d'installation et d'utilisation

Johnson Controls

Johnson Controls JRC Series Manuel du propriétaire

Johnson Controls

Johnson Controls YORK EUKC-09 AA Manuel utilisateur

Johnson Controls

Johnson Controls XAF Series Manuel utilisateur

Johnson Controls

Johnson Controls BUQ024 Manuel utilisateur

Johnson Controls

Johnson Controls VBR09 Series Manuel utilisateur

Johnson Controls

Johnson Controls AEROTERMIA AURUM R290 Series Manuel utilisateur

Johnson Controls

Johnson Controls PCG4A30 Manuel utilisateur

Johnson Controls

Johnson Controls THGD Manuel utilisateur

Johnson Controls

Johnson Controls VITALITY Series Manuel utilisateur

Manuels Pompe à chaleur populaires d'autres marques

MICROWELL

MICROWELL HP 1000 GREEN Manuel utilisateur

Sanyo

Sanyo SAP120FCH Manuel utilisateur

Daikin

Daikin EHYHBH05AA Manuel utilisateur

Panasonic

Panasonic WH-SDF03E3E5 Mode d’emploi

Bryant

Bryant 544B Manuel utilisateur

Airxcel

Airxcel 45000 Series Manuel

Mitsubishi Electric

Mitsubishi Electric PUZ-SWM60VAA Manuel utilisateur

Dimplex

Dimplex LI 16I-TUR Guide de l'utilisateur

Carrier

Carrier WSHP Open v3 Guide de configuration rapide

TGM

TGM CTV14CN018A Manuel utilisateur

Carrier

Carrier 38MGQ Series Manuel utilisateur

Kokido

Kokido K2O K880BX/EU Guide de dépannage

Viessmann

Viessmann VITOCAL 300-G PRO Type BW 2150 Guide rapide

Carrier

Carrier 48EZN Manuel utilisateur

Viessmann

Viessmann KWT Vitocal 350-G Pro Series Mode d'emploi

Ariston

Ariston NIMBUS Manuel utilisateur

Weishaupt

Weishaupt WWP L 7 Guide de l'utilisateur

GE Zoneline AZ85H09EAC Manuel utilisateur
