SPLIT-SYSTEM

AIR CONDITIONERS

13 SEER – R-410A – 1 PHASE

MODELS:

TCGD18 THRU 60

(1.5 THRU 5 NOMINAL TONS)

Due to continuous product improvement, specifications are

subject to change without notice.

Visit us on the web at www.york.com

Additional rating information can be found at

www.ahridirectory.org

WARRANTY

Standard 5-year limited parts warranty.

Standard 5-year limited compressor warranty.

Extended 10-year limited parts warranty when product is

registered online within 90 days of purchase for replace-

ment or closing for new home construction.

LISTED

TECHNICAL

GUIDE

TECHNICAL

GUIDE

359319-BTG-G-0509

FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE

DESCRIPTION

The 13 SEER Series unit is the outdoor part of a versatile cli-

mate system. It is designed with a matching indoor coil compo-

nent from Johnson Controls Unitary Products. Available for

typical applications this climate system is supported with acces-

sories and documents to serve specific functions.

FEATURES

•Quality Condenser Coils - The coil is constructed of alumi-

num microchannel tubing and enhanced aluminum fins for

increased efficiency and corrosion protection.

•Protected Compressor - The compressor is internally pro-

tected against high pressure, temperature, and externally by

a factory installed high pressure switch. This is accomplished

by the simultaneous operation of high pressure relief valve

and a temperature sensor which protects the compressor if

undesirable operating conditions occur. A liquid line filter-

drier further protects the compressor.

•Durable Finish - The cabinet is made of pre-painted steel.

The pre-treated galvanized steel provides a better paint to

steel bond, which resists corrosion and rust creep. Special

primer formulas and matted-textured finish insure less fading

when exposed to sunlight.

•Lower Installed Cost - Installation time and costs are

reduced by easy power and control wiring connections.

Available in sweat connect models only. The unit contains

enough refrigerant for matching indoor coils and 15 feet of

interconnecting piping. The small base dimension means

less space is required on the ground or roof.

•Top Discharge - The warm air from the top mounted fan is

blown up away from the structure and any landscaping. This

allows compact location on multi-unit applications.

•Low Operating Sound Level - The upward air flow carries

the normal operating noise away from the living area. The

rigid top panel effectively isolates any motor sound. Isolator

mounted compressor and the rippled fins of the condenser

coil muffle the normal fan motor and compressor operating

sounds.

•Low Maintenance - Long life permanently lubricated motor-

bearings need no annual servicing.

•Easy Service Access - Fully exposed refrigerant connec-

tions, and a single panel covering the electrical controls

make for easy servicing of the unit.

•Secured Service Valves - Secured re-usable service valves

are provided on both the liquid and vapor sweat connections

for ease of evacuating and charging.

•U.L. and C.U.L. listed - approved for outdoor application.

•Agency Listed -U.L. and C.U.L. listed - approved for out-

door application. The unit is certified in accordance with the

Unitary Small Equipment certification program, which is

based on ARI Standard 210/240.

359319-BTG-G-0509

2Johnson Controls Unitary Products

All dimensions are in inches. They are subject to change with-

out notice. Certified dimensions will be provided upon request.

Physical and Electrical Data

MODEL TCGD18

S41S1(H) TCGD24

S41S1 TCGD30

S41S1(H) TCGD36

S41S1(H) TCGD42

S41S1(H) TCGD48

S41S1(H) TCGD60

S41S1

Unit Supply Voltage 208-230V, 1 60Hz

Normal Voltage Range 1187 to 252

Minimum Circuit Ampacity 9.8 12.4 14.7 17.9 21.5 21.1 34.3

Max. Overcurrent Device Amps 215 20 25 30 35 35 60

Min. Overcurrent Device Amps 315 15 15 20 25 25 35

Compressor Type Rotary Recip Recip Recip Recip Recip Scroll

Compressor Amps Rated Load 7.4 9.3 10.6 13.1 16.0 15.7 26.2

Locked Rotor 40.0 43.0 54.0 74 84 84 150

Crankcase Heater No No No No No No No

Fan Motor Amps Rated Load 0.5 0.8 1.4 1.5 1.5 1.5 1.5

Fan Diameter Inches 17.5 17.5 17.5 22 22 22 24

Fan Motor Rated HP 1/12 1/8 1/4 1/4 1/4 1/4 1/4

Nominal RPM 1100 1075 1100 850 850 850 850

Nominal CFM 1400 1950 2050 3200 2950 2950 3600

Coil Face Area Sq. Ft. 9.60 9.60 9.60 13.07 14.16 14.16 18.68

Rows Deep 1 1 1 1 1 1 1

Fin / Inches 23 23 23 23 23 23 23

Liquid Line Set OD (Field Installed) 3/8 3/8 3/8 3/8 3/8 3/8 3/8

Vapor Line Set OD (Field Installed) 5/8 3/4 3/4 3/4 7/8 7/8 7/8

Unit Charge (Lbs. - Oz.) 43 - 3 3 - 13 3 - 14 4 - 9 4 - 5 4 - 9 5 - 6

Charge Per Foot, Oz. 0.58 0.62 0.62 0.62 0.67 0.67 0.67

Operating Weight Lbs. 97 129 131 145 173 173 195

Models with “H” on the end of the model number have a factory installed start kits.

1. Rated in accordance with ARI Standard 110, utilization range “A”.

2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.

3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.

4. The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than 15 feet, add or sub-

tract the amount of refrigerant, using the difference in length multiplied by the per foot value.

Unit

Model

Dimensions

(Inches) Refrigerant Connection

Service Valve Size

1. Including Fan Guard.

B C Liquid Vapor

18 28 23-1/2 23-1/2

3/8”

3/4”

24 28 23-1/2 23-1/2

30 28 23-1/2 23-1/2

36 28 29 29

42 30 29 29 7/8”48 30 29 29

60 32 33-5/8 33-5/8

359319-BTG-G-0509

Johnson Controls Unitary Products 3

PROCEDURES:

1. Unit factory charge listed on the unit nameplate includes refrigerant for the condenser, the smallest evaporator and 15 feet of interconnecting

line tubing.

2. Verify the TXV and additional charge required for specific evaporator coil in the system using the above table.

3. Additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in Physical and Electrical Data Table.

4. For orifice or TXV matches requiring additional charge, the refrigerant needs to be weighed in for specific coil match and lineset length.

5. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + adder for evaporator +

adder for line set.

System Charge for Various Matched Systems

Outdoor Unit TCGD18

S41S1(H) TCGD24

S41S1 TCGD30

S41S1(H) TCGD36

S41S1(H) TCGD42

S41S1(H) TCGD48

S41S1(H) TCGD60

S41S1

Required Orifice or TXV 1,2 0.048/4F1 0.055/4F1 0.061/4F1 0.065/4G1 0.075/4G1 0.073/4H1 0.087/4J1

Factory Charge, lbs-oz 3 - 3 3 - 13 3 - 14 4 - 9 4 - 5 4 - 9 5 - 6

Indoor Coil3,4 Additional Charge, oz

AHP18 0––––––

AHP30 –40––––

AHP36 ––20–––

AHP42 –––00––

AHP/SHP60 –––––00

AHX18 0––––––

AHX30 –40––––

AHX36 –420–––

AHX42 –––82––

AHX48 –––––0–

AHX60 ––––––4

AV*24 TXV+0––––––

AV*36 –420–––

AV/SV*48 ––––TXV+20–

AV/SV*60 ––––TXV+2–0

F4FP024 0––––––

F4FP036 –0–––––

F4FP040 ––0––––

F4FV060 –––––00

F5FP048 –––824–

F5FP060 –––––00

F6FP018 0––––––

F6FP030 –40––––

F6FP036 –40––––

F6FP042 –––82––

F6FP048 ––––TXV+20–

F6FP060 ––––––4

FC/MC/PC/18 0––––––

FC/MC/PC32 –40––––

FC/MC/PC35 –40––––

FC/MC/PC/36 –0–––––

FC/MC/PC37 –420–––

FC/MC/PC43 –4200––

FC/MC/PC48 –––824–

FC/MC/PC60 –––––00

FC/MC62 ––––––4

HC18 0––––––

HC30 –0–––––

HC36 –40––––

HC42 –4200––

HC60 ––––––0

UC18 0––––––

UC36 –0–––––

UC48 –––824–

UC60 –––––00

FOOTNOTES:

1.For applications requiring a TXV use 1TVM series kit.

2.Approved orifice shipped with outdoor unit.

3.Systems matched with furnace or air handlers not equipped with blower-off delays may require blower Time Delay Kit 2FD06700224.

4.PC coils cannot be used in downflow or horizontal applications. FC coils cannot be used in horizontal applications.

Models 12-48 require start kits for TXV matches.

359319-BTG-G-0509

4Johnson Controls Unitary Products

COOLING CAPACITY - With Air Handler Coils

UNIT

MODEL

AIR HANDLER COIL

MODEL1

COOLING

MODEL W RATED

CFM NET MBH SEER EER

TOTAL SENS.

13 SEER AC WITH MA

TCGD18S41S1(H) MA08B 17 FC/MC18B 600 17.5 12.9 13.00 11.00

TCGD24S41S1(H) MA08B 17 FC/MC36B 800 24.0 16.7 13.00 11.00

MA08B 17 FC/MC35B 800 24.0 16.7 13.00 11.00

MA08B 17 FC/MC43B 800 24.0 16.7 13.00 11.00

TCGD30S41S1(H) MA12B 17 FC/MC35B 1000 29.0 21.0 13.00 11.00

MA12B 17 FC/MC43B 1000 29.0 21.0 13.00 11.00

TCGD36S41S1(H) MA12B 17 FC/MC43B 1200 35.0 24.8 13.00 11.00

MA14D 24 FC/MC48D 1200 35.0 24.8 13.00 11.00

TCGD42S41S1(H) MA16C 21 FC/MC43C 1400 42.0 29.2 13.00 11.00

MA14D 24 FC/MC48D 1400 42.0 29.2 13.00 11.00

MA16C 21 FC/MC48C 1400 42.0 29.2 13.00 11.00

TCGD48S41S1(H)

MA16C 21 FC/MC48C 1600 48.0 34.4 13.00 11.00

MA20D 24 FC/MC48D 1600 48.0 34.4 13.00 11.00

MA16C 21 FC60C 1600 48.0 34.4 13.00 11.00

MA20D 24 FC/MC60D 1600 48.0 34.4 13.00 11.00

TCGD60S41S1 MA20D 24 FC/MC60D 1800 57.0 38.5 13.00 11.00

MA20D 24 FC/MC62D 1800 57.0 38.5 13.00 11.00

13 SEER AC WITH MV - VARIABLE SPEED

TCGD18S41S1(H) MV12B 17 FC/MC18B 600 17.5 13.3 14.00 12.50

TCGD24S41S1(H) MV12B 17 FC/MC36B 800 24.0 17.4 14.00 12.00

MV12B 17 FC/MC35B 800 24.0 17.4 14.00 12.00

MV12B 17 FC/MC43B 800 24.0 17.3 14.00 12.00

TCGD30S41S1(H)

MV12B 17 FC/MC35B 1000 29.0 21.6 14.00 12.00

MV16C 21 FC/MC35C 1000 30.0 21.6 14.00 12.00

MV12B 17 FC/MC43B 1000 29.0 21.6 14.00 12.00

MV16C 21 FC/MC43C 1000 30.0 21.6 14.00 12.00

TCGD36S41S1(H)

MV16C 21 FC/MC43C 1200 36.0 25.4 14.00 12.00

MV16C 21 FC/MC48C 1200 36.0 25.4 14.00 12.00

MV20D 24 FC/MC48D 1200 36.0 25.6 14.00 12.00

MV12D 24 FC/MC48D 1135 35.0 25.4 14.00 12.00

TCGD42S41S1(H) MV16C 21 FC/MC43C 1400 42.0 30.0 13.50 12.00

MV16C 21 FC/MC48C 1400 42.0 30.0 13.50 12.00

MV20D 24 FC/MC48D 1400 42.0 30.0 14.00 12.00

TCGD48S41S1(H) MV16C 21 FC/MC48C 1600 48.0 35.0 13.50 12.00

MV20D 24 FC/MC48D 1600 48.0 35.0 13.50 12.00

MV20D 24 FC/MC60D 1600 48.0 35.0 13.50 12.00

TCGD60S41S1 MV20D 24 FC/MC60D 1800 57.0 38.5 13.00 11.00

MV20D 24 FC/MC62D 1800 57.0 38.5 13.00 11.00

13 SEER AC WITH AV / SV / F*FV - VARIABLE SPEED

TCGD18S41S1(H) AV*24 17 – 610 18.0 13.5 14.50 12.00

TCGD24S41S1(H) AV*36 21 – 725 24.0 17.4 14.50 12.00

TCGD30S41S1(H) AV*36 21 – 960 30.0 21.8 14.50 12.00

TCGD36S41S1(H) AV*36 21 – 1190 35.0 25.2 13.50 11.50

TCGD42S41S1(H) AV/SV*48 24 – 1385 42.0 29.8 14.00 12.00

AV/SV*60 24 – 1360 42.0 29.8 14.00 12.00

TCGD48S41S1(H) AV/SV*48 24 – 1625 48.0 35.0 13.50 11.50

AV/SV*60 24 – 1560 48.0 35.0 13.50 11.50

F4FV060 24 – 1600 47.0 34.6 13.40 11.30

TCGD60S41S1 AV/SV*60 24 – 1730 57.0 39.0 13.50 11.50

F4FV060 24 – 1780 56.5 38.5 13.00 11.00

For Notes See Page 5.

359319-BTG-G-0509

Johnson Controls Unitary Products 5

— = Not applicable.

13 SEER AC WITH AHP / SHP / AHX / F*FP

TCGD18S41S1(H)

AHP18 17 – 650 17.5 12.9 13.00 11.00

AHX18 17 - 630 18.0 13.8 14.50 12.00

F4FP024 18 – 600 17.5 12.9 13.00 11.00

F6FP018 17 - 600 17.8 13.3 14.50 12.00

TCGD24S41S1(H)

AHP30 17 – 795 24.0 16.8 13.00 11.00

AHX30 17 – 820 24.0 16.9 14.50 12.00

AHX36 21 – 815 24.0 16.9 14.50 12.00

F4FP036 21.5 – 800 24.0 16.7 13.00 11.00

F6FP030 17 – 850 24.0 16.8 14.00 11.80

F6FP036 21 – 855 24.0 17.0 14.00 12.00

TCGD30S41S1(H)

AHP30 17 – 1015 29.0 21.0 13.00 11.00

AHP36 21 – 1040 29.0 21.0 13.00 11.00

AHX30 17 – 1025 29.4 22.2 14.00 11.75

AHX36 21 – 1005 30.0 22.3 14.50 12.00

F4FP040 18 – 1050 29.0 21.0 13.00 11.00

F6FP030 17 – 1035 29.2 21.6 13.50 11.40

F6FP036 21 – 980 29.4 21.4 14.00 12.00

TCGD36S41S1(H)

AHP36 21 – 1235 35.0 24.8 13.00 11.00

AHP42 21 – 1255 35.0 24.8 13.00 11.00

AHX36 21 – 1225 35.2 25.0 13.50 11.50

AHX42 21 – 1190 35.4 25.2 14.00 11.80

F5FP048 24 – 1235 35.0 24.8 13.00 11.00

F6FP042 21 – 1290 35.8 25.8 13.50 11.50

TCGD42S41S1(H)

AHP42 21 – 1485 41.0 29.2 13.00 11.00

AHX42 21 – 1395 42.0 29.9 14.50 12.00

F5FP048 24 – 1455 41.0 29.2 13.00 11.00

F6FP042 21 – 1455 42.0 30.1 14.00 11.75

F6FP048 24 – 1380 41.5 29.4 13.50 11.70

TCGD48S41S1(H)

AHP/SHP48 24 – 1675 48.0 34.4 13.00 11.00

AHP/SHP60 24 – 1600 48.0 35.0 13.50 11.00

AHX48 24 – 1660 48.0 35.4 13.50 11.50

F5FP048 24 – 1600 48.0 34.4 13.00 11.00

F5FP060 24 – 1600 48.0 34.4 13.00 11.00

F6FP048 24 – 1625 47.0 34.8 13.00 11.30

TCGD60S41S1

AHP/SHP60 24 – 1850 57.0 38.5 13.00 11.00

AHX60 24 – 1905 58.5 40.0 13.50 11.50

F5FP060 24 – 1900 57.0 38.5 13.00 11.00

F6FP060 24 – 1710 57.5 39.0 13.50 11.50

Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.

Cooling MBH based on 8°F entering air temperature, 50% RH, and rated air flow.

EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.

SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power

input in watt-hours during the same period.

1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.

COOLING CAPACITY - With Air Handler Coils (Continued)

UNIT

MODEL

AIR HANDLER COIL

MODEL1

COOLING

MODEL W RATED

CFM NET MBH SEER EER

TOTAL SENS.

359319-BTG-G-0509

6Johnson Controls Unitary Products

COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils

UNIT MODEL FURNACE** COIL

MODEL

COOLING

CFM RANGE

(Min.-max.) WRATED

CFM NET MBH SEER1EER

TOTAL SENS.

TCGD18S41S1(H) 450 - 750 14,17 FC/MC/PC18 600 17.5 12.9 13.00 11.00

450 - 750 14 HC18 600 17.5 12.9 13.00 11.00

450 - 750 14,17 UC18 600 17.5 12.9 13.00 11.00

TCGD24S41S1(H)

600 - 1000 14 FC/MC/PC32 800 24.0 16.7 13.00 11.00

600 - 1000 17,21 FC/MC/PC35 800 24.0 16.7 13.00 11.00

600 - 1000 14,17,21 FC/MC/PC36 800 24.0 16.7 13.00 11.00

600 - 1000 14 FC/MC/PC37 800 24.0 16.7 13.00 11.00

600 - 1000 17,21 FC/MC/PC43 800 24.0 16.7 13.00 11.00

600 - 1000 14 HC30 800 24.0 16.7 13.00 11.00

600 - 1000 17 HC36 800 24.0 16.7 13.00 11.00

600 - 1000 21 HC42 800 24.0 16.7 13.00 11.00

600 - 1000 14,17,21 UC36 800 24.0 16.7 13.00 11.00

TCGD30S41S1(H)

800 - 1200 14 FC/MC/PC32 1000 29.0 21.0 13.00 11.00

800 - 1200 17,21 FC/MC/PC35 1000 29.0 21.0 13.00 11.00

800 - 1200 14 FC/MC/PC37 1000 29.0 21.0 13.00 11.00

800 - 1200 17,21 FC/MC/PC43 1000 29.0 21.0 13.00 11.00

800 - 1200 17 HC36 1000 29.0 21.0 13.00 11.00

800 - 1200 21 HC42 1000 29.0 21.0 13.00 11.00

TCGD36S41S1(H)

1000 - 1400 14 FC/MC/PC37 1200 35.0 24.8 13.00 11.00

1000 - 1400 17,21 FC/MC/PC43 1200 35.0 24.8 13.00 11.00

1000 - 1400 21,24 FC/MC/PC48 1200 35.0 24.8 13.00 11.00

1000 - 1400 21 HC42 1200 35.0 24.8 13.00 11.00

1000 - 1400 21,24 UC48 1200 35.0 24.8 13.00 11.00

TCGD42S41S1(H)

1200 - 1600 17,21 FC/MC/PC43 1400 42.0 29.2 13.00 11.00

1200 - 1600 21,24 FC/MC/PC48 1400 42.0 29.2 13.00 11.00

1200 - 1600 21 HC42 1400 42.0 29.2 13.00 11.00

1200 - 1600 21,24 UC48 1400 42.0 29.2 13.00 11.00

TCGD48S41S1(H)

1400 - 1800 21,24 FC/MC/PC48 1600 48.0 34.4 13.00 11.00

1400 - 1800 21,24 FC/MC/PC60 1600 48.0 34.4 13.00 11.00

1400 - 1800 24 HC60 1600 48.0 34.4 13.00 11.00

1400 - 1800 21,24 UC48 1600 48.0 34.4 13.00 11.00

1400 - 1800 21,24 UC60 1600 48.0 34.4 13.00 11.00

TCGD60S41S1

1600 - 2000 21,24 FC/MC/PC60 1800 57.0 38.5 13.00 11.00

1600 - 2000 24 FC/MC62 1800 57.0 38.5 13.00 11.00

1600 - 2000 24 HC60 1800 57.0 38.5 13.00 11.00

1600 - 2000 21,24 UC60 1800 57.0 38.5 13.00 11.00

1. Requires a 2FD06700224 Blower Time Delay unless a standard furnace is equipped with one.

** Refer to Quick Selection Chart for specific furnace match-up.

359319-BTG-G-0509

Johnson Controls Unitary Products 7

COOLING CAPACITY - With High Efficiency Motor Furnaces

MODELS FURNACE

MODEL COIL

MODEL1WCOOLING

RATED

CFM Net MBH SEER EER

TOTAL SENS.

13 SEER HP WITH VARIABLE SPEED FURNACES2

TCGD18S41S1(H)

T*(8,L)X*A12 FC/MC/PC18A 14 540 17.7 12.9 14.50 12.50

T*(8,L)X*B12 FC/MC/PC18B 17 580 18.0 13.4 14.50 12.50

T*9X*B12 FC/MC/PC18B 17 590 18.0 13.4 14.50 12.50

T*(8,L)X*A12 UC18A 14 590 18.0 13.4 14.50 12.00

T*(8,L)X*B12 UC18B 17 595 18.0 13.4 14.50 12.00

T*9X*B12 UC18B 17 590 18.0 13.4 14.50 12.00

T*(8,L)C*A12 FC/MC/PC18A 14 620 17.5 12.7 14.50 12.50

T*(8,L)C*B12 FC/MC/PC18B 17 580 17.5 12.6 14.50 12.00

(T*9C/T*9V)*B12 FC/MC/PC18B 17 610 17.5 12.8 14.50 12.50

T*(8,L)C*A12 HC18 14 620 17.5 12.8 14.50 12.00

T*(8,L)C*A12 UC18A 14 620 17.5 12.7 14.50 12.00

T*(8,L)C*B12 UC18B 17 580 17.5 12.5 14.50 12.00

(T*9C/T*9V)*B12 UC18B 17 610 17.5 12.6 14.50 12.50

TCGD24S41S1(H)

T*(8,L)X*A12 FC/MC/PC32A 14 800 24.0 16.9 14.00 11.50

T*(8,L)X*B12 FC/MC/PC35B 17 850 24.0 17.0 14.00 12.00

T*9X*C16 FC/MC/PC35C 21 715 23.8 16.3 14.00 12.00

T*9X*C20 FC/MC/PC35C 21 825 24.0 17.0 14.00 12.00

T*(8,L)X*A12 FC/MC/PC36A 14 815 24.0 16.8 14.00 12.00

T*(8,L)X*B12 FC/MC/PC36B 17 835 24.0 16.8 14.00 12.00

T*9X*B12 FC/MC/PC36B 17 775 24.0 16.8 14.00 12.00

T*9X*C16 FC/MC/PC36C 21 770 24.0 16.8 14.00 12.00

T*9X*C20 FC/MC/PC36C 21 810 24.0 16.8 14.00 12.00

T*(8,L)X*A12 FC/MC/PC37A 14 840 24.0 17.0 14.00 12.00

T*(8,L)X*B12 FC/MC/PC43B 17 865 24.0 17.0 14.00 12.00

T*(8,L)C*A12 FC/MC/PC32A 14 775 24.0 17.0 14.00 11.50

T*(8,L)C*B12 FC/MC/PC35B 17 760 24.0 16.8 14.00 12.00

(T*9C/T*9V)*B12 FC/MC/PC35B 17 815 24.0 17.1 14.00 12.00

T*(8,L)C*A12 FC/MC/PC36A 14 805 24.0 16.9 14.00 12.00

T*(8,L)C*B12 FC/MC/PC36B 17 765 24.0 17.0 14.00 12.00

(T*9C/T*9V)*B12 FC/MC/PC36B 17 815 24.0 16.9 14.00 12.00

T*(8,L)C*A12 FC/MC/PC37A 14 805 24.0 17.0 14.00 12.00

T*(8,L)C*B12 FC/MC/PC43B 17 760 24.0 16.9 14.00 12.00

(T*9C/T*9V)*B12 FC/MC/PC43B 17 800 24.0 17.0 14.00 12.00

T*(8,L)C*A12 HC30 14 775 23.8 16.8 13.80 11.50

T*(8,L)C*B12 HC36 17 760 24.0 16.8 14.00 12.00

(T*9C/T*9V)*B12 HC36 17 815 24.0 17.2 14.00 12.00

T*(8,L)C*A12 UC36A 14 805 23.6 16.6 13.80 11.50

T*(8,L)C*B12 UC36B 17 765 23.6 16.7 14.00 11.50

(T*9C/T*9V)*B12 UC36B 17 815 23.6 16.7 13.80 11.50

TCGD30S41S1(H)

T*(8,L)X*A12 FC/MC/PC32A 14 970 29.2 21.4 13.20 11.00

T*(8,L)X*B12 FC/MC/PC35B 17 1120 30.0 22.8 14.00 11.50

T*(8,L)X*C16 FC/MC/PC35C 21 1105 30.0 22.8 14.00 12.00

T*(8,L)X*C20 FC/MC/PC35C 21 850 28.8 20.6 14.00 12.00

T*9X*B12 FC/MC/PC35B 17 1085 29.8 22.8 14.00 12.00

T*9X*C16 FC/MC/PC35C 21 1075 29.8 22.4 14.00 12.00

T*(8,L)X*A12 FC/MC/PC37A 14 1105 30.0 22.9 13.80 11.50

T*(8,L)X*B12 FC/MC/PC43B 17 1125 30.0 22.9 14.00 12.00

T*(8,L)X*C16 FC/MC/PC43C 21 710 28.2 19.3 14.00 12.00

T*(8,L)X*C20 FC/MC/PC43C 21 870 29.6 21.2 14.00 12.00

T*9X*B12 FC/MC/PC43B 17 1095 30.0 22.9 13.80 11.50

T*9X*C16 FC/MC/PC43C 21 1055 30.0 22.9 14.00 12.00

For Notes See Page 10.

359319-BTG-G-0509

8Johnson Controls Unitary Products

TCGD30S41S1(H)

T*9X*C20 FC/MC/PC43C 21 720 28.2 19.3 14.00 12.00

T*(8,L)C*A12 FC/MC/PC32A 14 1045 29.2 21.8 13.20 11.00

T*(8,L)C*B12 FC/MC/PC35B 17 995 29.6 21.4 14.00 11.50

(T*9C/T*9V)*B12 FC/MC/PC35B 17 1045 29.4 22.0 13.50 11.50

T*(8,L)C*C16 FC/MC/PC35C 21 1025 29.6 22.0 14.00 12.00

T*(8,L)C*C20 FC/MC/PC35C 21 1080 30.0 22.4 14.00 12.00

(T*9C/T*9V)*C16 FC/MC/PC35C 21 1005 29.6 22.0 14.00 12.00

(T*9C/T*9V)*C20 FC/MC/PC35C 21 985 29.6 22.0 14.00 12.00

T*(8,L)C*A12 FC/MC/PC37A 14 980 29.8 21.8 13.80 11.50

T*(8,L)C*B12 FC/MC/PC43B 17 990 30.0 22.0 14.00 12.00

(T*9C/T*9V)*B12 FC/MC/PC43B 17 1035 30.0 22.0 13.80 11.50

T*(8,L)C*C16 FC/MC/PC43C 21 990 30.0 22.1 14.00 12.00

T*(8,L)C*C20 FC/MC/PC43C 21 1000 30.0 22.1 14.00 12.00

(T*9C/T*9V)*C16 FC/MC/PC43C 21 1030 30.0 22.0 14.00 12.00

(T*9C/T*9V)*C20 FC/MC/PC43C 21 995 30.0 22.1 14.00 12.00

T*(8,L)C*B12 HC36 17 995 29.6 21.4 14.00 11.50

(T*9C/T*9V)*B12 HC36 17 1045 29.4 22.0 13.70 11.50

T*(8,L)C*C16 HC42 21 990 30.0 22.1 14.00 12.00

T*(8,L)C*C20 HC42 21 1000 30.0 22.1 14.00 12.00

(T*9C/T*9V)*C16 HC42 21 1030 30.0 22.0 14.00 12.00

(T*9C/T*9V)*C20 HC42 21 995 30.0 22.1 14.00 12.00

TCGD36S41S1(H)

T*(8,L)X*A12 FC/MC/PC37A 14 1290 35.2 25.4 13.30 11.25

T*(8,L)X*B12 FC/MC/PC43B 17 1300 35.2 25.4 13.30 11.25

T*(8,L)X*C16 FC/MC/PC43C 21 1175 35.2 24.8 14.00 11.50

T*(8,L)X*C20 FC/MC/PC43C 21 1250 35.6 25.6 13.80 11.70

T*9X*B12 FC/MC/PC43B 17 1270 35.2 25.4 13.25 11.25

T*9X*C16 FC/MC/PC43C 21 1260 35.4 25.4 13.45 11.40

T*9X*C20 FC/MC/PC43C 21 1185 35.0 24.6 13.55 11.40

T*(8,L)X*C16 FC/MC/PC48C 21 1185 35.6 25.2 14.00 11.50

T*(8,L)X*C20 FC/MC/PC48C 21 1270 35.8 25.8 14.00 11.50

T*9X*C16 FC/MC/PC48C 21 1280 35.8 25.8 13.70 11.50

T*9X*C20 FC/MC/PC48C 21 1205 35.4 25.0 13.70 11.50

T*9X*D20 FC/MC/PC48D 24 1240 35.4 25.0 13.70 11.50

T*(8,L)X*C16 UC48C 21 1185 34.2 24.8 13.50 11.50

T*(8,L)X*C20 UC48C 21 1300 34.8 25.4 13.50 11.50

T*9X*C16 UC48C 21 1280 34.6 24.8 13.15 11.20

T*9X*C20 UC48C 21 1205 34.0 24.6 13.25 11.20

T*9X*D20 UC48D 24 1240 34.0 24.6 13.30 11.25

T*(8,L)C*A12 FC/MC/PC37A 14 980 33.8 23.0 13.50 11.00

T*(8,L)C*B12 FC/MC/PC43B 17 1210 35.2 25.2 13.50 11.00

(T*9C/T*9V)*B12 FC/MC/PC43B 17 1200 35.2 25.2 13.50 11.00

T*(8,L)C*C16 FC/MC/PC43C 21 1205 35.6 25.4 14.00 11.50

T*(8,L)C*C20 FC/MC/PC43C 21 1190 35.6 25.4 14.00 12.00

(T*9C/T*9V)*C16 FC/MC/PC43C 21 1240 35.4 25.2 13.50 11.50

(T*9C/T*9V)*C20 FC/MC/PC43C 21 1200 35.6 25.4 14.00 11.50

T*(8,L)C*C16 FC/MC/PC48C 21 1210 36.0 26.0 14.00 12.00

T*(8,L)C*C20 FC/MC/PC48C 21 1155 36.0 26.1 14.00 12.00

(T*9C/T*9V)*C16 FC/MC/PC48C 21 1195 36.0 26.0 14.00 11.50

(T*9C/T*9V)*C20 FC/MC/PC48C 21 1330 36.0 26.5 14.00 11.50

(T*9C/T*9V)*D20 FC/MC/PC48D 24 1240 36.0 26.2 14.00 12.00

T*(8,L)C*C16 HC42 21 1205 35.6 25.4 14.00 11.50

For Notes See Page 10.

COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)

MODELS FURNACE

MODEL COIL

MODEL1WCOOLING

RATED

CFM Net MBH SEER EER

TOTAL SENS.

13 SEER HP WITH VARIABLE SPEED FURNACES2

359319-BTG-G-0509

Johnson Controls Unitary Products 9

TCGD36S41S1(H)

T*(8,L)C*C20 HC42 21 1190 35.6 25.6 14.00 12.00

(T*9C/T*9V)*C16 HC42 21 1240 35.4 25.2 13.50 11.50

(T*9C/T*9V)*C20 HC42 21 1200 35.6 25.4 14.00 11.50

T*(8,L)C*C16 UC48C 21 1210 34.6 24.8 13.50 11.50

T*(8,L)C*C20 UC48C 21 1155 34.8 24.8 14.00 11.50

(T*9C/T*9V)*C16 UC48C 21 1195 34.6 24.8 13.50 11.50

(T*9C/T*9V)*C20 UC48C 21 1305 35.0 25.6 13.30 11.00

(T*9C/T*9V)*D20 UC48D 24 1240 34.8 25.0 13.80 11.50

TCGD42S41S1(H)

T*(8,L)X*B12 FC/MC/PC43B 17 1300 42.0 29.0 13.50 11.50

T*(8,L)X*C16 FC/MC/PC43C 21 1475 42.0 29.9 13.50 11.50

T*(8,L)X*C20 FC/MC/PC43C 21 1415 42.0 29.5 13.50 11.50

T*9X*B12 FC/MC/PC43B 17 1270 42.0 29.0 13.50 11.50

T*9X*C16 FC/MC/PC43C 21 1410 42.0 29.6 13.30 11.00

T*9X*C20 FC/MC/PC43C 21 1400 42.0 29.6 13.50 11.00

T*(8,L)X*C16 FC/MC/PC48C 21 1360 42.0 29.5 13.80 11.50

T*(8,L)X*C20 FC/MC/PC48C 21 1475 42.0 30.1 14.00 11.50

T*9X*C16 FC/MC/PC48C 21 1425 42.0 29.3 13.50 11.50

T*9X*C20 FC/MC/PC48C 21 1420 42.0 29.3 13.50 11.50

T*9X*D20 FC/MC/PC48D 24 1435 42.0 29.7 13.50 11.50

T*(8,L)X*C16 UC48C 21 1400 42.0 29.4 13.50 11.00

T*(8,L)X*C20 UC48C 21 1515 42.0 30.0 13.50 11.00

T*9X*C16 UC48C 21 1425 41.5 29.2 13.30 11.00

T*9X*C20 UC48C 21 1420 42.0 29.4 13.20 11.00

T*9X*D20 UC48D 24 1435 42.0 29.4 13.40 11.00

T*(8,L)C*C16 FC/MC/PC43C 21 1425 42.0 30.0 13.50 11.50

T*(8,L)C*C20 FC/MC/PC43C 21 1450 42.0 30.4 13.50 11.50

(T*9C/T*9V)*C16 FC/MC/PC43C 21 1360 42.0 29.6 13.30 11.00

(T*9C/T*9V)*C20 FC/MC/PC43C 21 1395 42.0 29.6 13.50 11.00

T*(8,L)C*C16 FC/MC/PC48C 21 1435 42.0 30.1 13.80 11.50

T*(8,L)C*C20 FC/MC/PC48C 21 1410 42.0 30.1 14.00 11.50

(T*9C/T*9V)*C16 FC/MC/PC48C 21 1395 42.0 30.3 13.50 11.50

(T*9C/T*9V)*C20 FC/MC/PC48C 21 1430 42.0 30.3 13.50 11.50

(T*9C/T*9V)*D20 FC/MC/PC48D 24 1450 42.0 29.9 13.80 11.50

T*(8,L)C*C16 HC42 21 1425 42.0 30.0 13.50 11.50

T*(8,L)C*C20 HC42 21 1450 42.0 30.0 13.50 11.50

(T*9C/T*9V)*C16 HC42 21 1360 42.0 30.0 13.40 11.00

(T*9C/T*9V)*C20 HC42 21 1395 42.0 30.0 13.50 11.00

T*(8,L)C*C16 UC48C 21 1435 41.5 30.2 13.50 11.00

T*(8,L)C*C20 UC48C 21 1410 41.5 30.2 13.50 11.50

(T*9C/T*9V)*C16 UC48C 21 1395 41.5 30.2 13.30 11.00

(T*9C/T*9V)*C20 UC48C 21 1430 41.5 30.0 13.20 11.00

(T*9C/T*9V)*D20 UC48D 24 1450 41.5 30.2 13.40 11.00

For Notes See Page 10.

COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)

MODELS FURNACE

MODEL COIL

MODEL1WCOOLING

RATED

CFM Net MBH SEER EER

TOTAL SENS.

13 SEER HP WITH VARIABLE SPEED FURNACES2

359319-BTG-G-0509

10 Johnson Controls Unitary Products

TCGD48S41S1(H)

T*(8,L)X*C16 FC/MC/PC48C 21 1600 48.0 34.4 13.30 11.00

T*(8,L)X*C20 FC/MC/PC48C 21 1660 48.0 34.4 13.20 11.00

T*9X*C16 FC/MC/PC48C 21 1565 48.0 34.8 13.10 11.00

T*9X*C20 FC/MC/PC48C 21 1615 48.0 34.4 13.20 11.00

T*9X*D20 FC/MC/PC48D 24 1635 48.0 34.8 13.20 11.00

T*(8,L)X*C16 FC/PC60C 21 1605 48.0 34.6 13.30 11.00

T*(8,L)X*C20 FC/MC/PC60D 21 1595 48.0 34.8 13.30 11.00

T*9X*C16 FC/PC60C 21 1575 48.0 34.6 13.30 11.00

T*9X*C20 FC/PC60C 21 1625 47.0 34.6 13.40 11.00

T*9X*D20 FC/MC/PC60D 24 1490 47.5 33.8 13.20 11.00

T*9X*C16 FC/PC60C 21 1575 47.0 33.8 13.10 11.00

T*9X*C20 FC/PC60C 21 1625 47.0 33.8 13.10 11.00

T*(8,L)C*C16 FC/MC/PC48C 21 1615 48.0 34.4 13.30 11.00

T*(8,L)C*C20 FC/MC/PC48C 21 1640 48.0 34.8 13.20 11.00

(T*9C/T*9V)*C16 FC/MC/PC48C 21 1590 48.0 34.6 13.10 11.00

(T*9C/T*9V)*C20 FC/MC/PC48C 21 1655 48.0 34.8 13.20 11.00

(T*9C/T*9V)*D20 FC/MC/PC48D 24 1645 48.0 35.2 13.20 11.00

(T*9C/T*9V)*D20 FC/MC/PC60D 24 1615 48.0 35.0 13.20 11.00

T*(8,L)C*C16 FC/PC60C 21 1625 48.0 35.2 13.30 11.00

T*(8,L)C*C20 FC/PC60C 21 1605 48.0 35.0 13.50 11.50

(T*9C/T*9V)*C16 FC/PC60C 21 1590 48.0 35.2 13.10 11.00

(T*9C/T*9V)*C20 FC/PC60C 21 1655 48.0 35.2 13.10 11.00

TCGD60S41S1

T*(8,L)X*C16 FC/PC60C 21 1605 56.5 37.8 13.50 11.00

T*(8,L)X*C20 FC/MC/PC60D 21 1690 57.0 37.8 13.50 11.00

T*9X*C16 FC/PC60C 21 1575 56.0 37.8 13.30 11.00

T*9X*C20 FC/PC60C 21 1560 56.0 37.8 13.30 11.00

T*9X*D20 FC/MC/PC60D 24 1630 56.5 37.8 13.30 11.00

T*9X*C20 FC/MC/PC60D 21 1645 56.5 37.8 13.30 11.00

T*(8,L)X*C20 FC/MC62D 21 1665 57.0 37.8 13.50 11.00

T*(8,L)X*C16 UC60C 21 1640 56.0 37.2 13.00 11.00

T*(8,L)X*C20 UC60D 21 1735 56.5 38.5 13.00 11.00

T*9X*C16 FC/PC60C 21 1575 56.0 37.2 13.00 11.00

T*9X*C20 FC/PC60C 21 1560 56.0 37.2 13.00 11.00

T*9X*D20 UC60D 24 1630 56.0 37.2 13.00 11.00

T*(8,L)X*C20 UC60D 21 1735 56.5 38.5 13.00 11.00

T*9X*C20 UC60D 21 1645 56.0 37.2 13.00 11.00

(T*9C/T*9V)*D20 FC/MC/PC60D 24 1615 55.5 36.8 13.30 11.00

T*(8,L)C*C20 FC/MC62D 21 1615 56.5 37.4 13.50 11.00

(T*9C/T*9V)*C20 FC/MC62D 21 1655 56.0 37.2 13.20 11.00

(T*9C/T*9V)*D20 FC/MC62D 24 1630 56.0 37.4 13.30 11.00

T*(8,L)C*C20 FC/PC60C 21 1605 55.5 37.0 13.50 11.00

(T*9C/T*9V)*C20 FC/PC60C 21 1655 55.0 36.8 13.30 11.00

(T*9C/T*9V)*D20 HC60 24 1615 53.5 35.8 13.00 10.90

T*(8,L)C*C20 UC60C 21 1605 54.0 35.2 13.00 11.00

(T*9C/T*9V)*C20 UC60C 21 1655 53.5 35.0 13.00 10.80

(T*9C/T*9V)*D20 UC60D 24 1615 53.5 35.0 13.00 10.90

1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.

2. Variable speed furnaces have B.O.D (Blower on Delay) standard.

COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)

MODELS FURNACE

MODEL COIL

MODEL1WCOOLING

RATED

CFM Net MBH SEER EER

TOTAL SENS.

13 SEER HP WITH VARIABLE SPEED FURNACES2

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Johnson Controls Climatiseur

Johnson Controls

Johnson Controls York ZN-06 Manuel utilisateur

Johnson Controls

Johnson Controls (H,Y)VAHP072B31S Manuel

Johnson Controls

Johnson Controls ZY Series Manuel utilisateur

Johnson Controls

Johnson Controls 13 SEER - GCGD Manuel utilisateur

Johnson Controls

Johnson Controls 14.5 SEER SERIES Mode d’emploi

Johnson Controls

Johnson Controls YORK EOKC-09 FS Manuel utilisateur

Johnson Controls

Johnson Controls SA PC090 THRU 240 Manuel utilisateur

Johnson Controls

Johnson Controls DSH024C Series Manuel utilisateur

Johnson Controls

Johnson Controls Quantech Millennium QCC3080CZE Manuel du propriétaire

Johnson Controls

Johnson Controls 13 SEER - GCGD Manuel utilisateur

Johnson Controls

Johnson Controls DSH Series Manuel du propriétaire

Johnson Controls

Johnson Controls PCE4 Series Manuel utilisateur

Johnson Controls

Johnson Controls DHP09NWB21S Manuel utilisateur

Johnson Controls

Johnson Controls HVWHP072B32S Manuel utilisateur

Johnson Controls

Johnson Controls Split Wall-Mounted Type Manuel utilisateur

Johnson Controls

Johnson Controls DU-15 Manuel utilisateur

Johnson Controls

Johnson Controls YC2E Manuel utilisateur

Johnson Controls

Johnson Controls York YDVC028 Manuel utilisateur

Johnson Controls

Johnson Controls AFFINITY 340968-XIM-A-0108 Manuel utilisateur

Johnson Controls

Johnson Controls HICS015B21S Manuel d'installation et d'exploitation

Johnson Controls

Johnson Controls LX Series Guide de démarrage rapide

Johnson Controls

Johnson Controls Y Seroes Manuel

Johnson Controls

Johnson Controls YXV SERIES Manuel utilisateur

Johnson Controls

Johnson Controls DHMW12NKB21S Manuel utilisateur

Manuels Climatiseur populaires d'autres marques

Spheros

Spheros CC 355 Manuel utilisateur

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manuel utilisateur

Panasonic

Panasonic CS-E12HKEW Manuel utilisateur

nedis

nedis ACMB1WT7 Manuel utilisateur

Samsung

Samsung AR KV Series Mode d’emploi

Daikin

Daikin FCFV50A Manuel utilisateur

Fujitsu

Fujitsu Inverter ASBA30JFC Manuel utilisateur

Toshiba

Toshiba RAS-M10SMUV-E Manuel utilisateur

Daikin

Daikin FXLQ20MAVE Manuel utilisateur

Hitachi

Hitachi RAS-E24CAK Manuel utilisateur

CIAT

CIAT Magister 2 Series Mode d’emploi

Bestron

Bestron AAC6000 Manuel utilisateur

Hisense

Hisense 7K Manuel technique

Frigidaire

Frigidaire FFRE0533S1E0 Manuel utilisateur

Samsung

Samsung AS09HM3N Manuel utilisateur

Frigidaire

Frigidaire CRA073PU11 Manuel du propriétaire

Soleus Air

Soleus Air GB-PAC-08E4 Manuel utilisateur

McQuay

McQuay MCK020A Manuel utilisateur
