John Lewis Trumpet Manuel utilisateur

John Lewis Partnership

171 Victoria Street

London SW1E 5NN

johnlewis.com

Made in China Please retain these instructions for future reference.

5 year guarantee

If you experience any unresolvable technical issues with the product,

contact your nearest John Lewis & Partners shop or John Lewis & Partner

Technical Support on 03301 230106.

Aftercare and

Troubleshooting

Max. power: 3 x 6W

Voltage: 220–240V, 50Hz

IP rating: 20

Weight: 6.16kg

At John Lewis & Partners we test every light to high quality standards so we are

able to offer you a 5 year guarantee.

Specification

Recycling

Caring for

your product

We recommend cleaning with a soft dry cloth. Do not use abrasive materials as

these will damage the nish.

Glass parts - Remove and wash in warm water or just use a damp cloth. Do not

use abrasive materials as these will damage the nish.

This symbol indicates that this product should not be treated as

normal household waste and it should be recycled. John Lewis & Partners

do not operate instore take back, but as members of the Distributor Take

Back scheme have funded the development and upgrade of recycling

facilities across the UK. Please take it to your nearest collection facility or

for further details contact your local council or visit www.recycle-more.

co.uk.

TRUMPET FLOOR LIGHT

USER GUIDE

28/10/2020

01 02

Parts list

Introduction Thank you for purchasing this Trumpet Floor Light.

Please read the instructions carefully before

use to ensure safe and satisfactory operation

of this product.

Warnings This is a Class II product and must NOT be earthed.

Please read these instructions carefully before commencing any work.

For your safety, always switch off the supply before changing the lightbulbs, cleaning or

removing shades.

Always use the correct type and wattage bulb. Never exceed the wattage stated.

If you are in any doubt, please consult a qualied electrician.

Recommended bulb (not included)

3 x 6W SES LED Energy Efcient Golf Ball

When changing a bulb, always switch off at the mains and allow the bulb to cool

before handling. Dispose of used bulbs carefully. Do not exceed the rated power

stated or use a different shape bulb from that indicated on the tting.

Recommended bulb

Product assembly

Screw top assembly (A) on to tube (B),

Take care not to trap the cable or cross the thread,

rmly tighten the tube by hand.

Check all joints are tight.

Pull any excess cable through from the underside

of the base. Turn the assembly (A+B) anticlockwise

approximately 6 times (Turning the tube anticlockwise

rst, ensures that the cable will straighten when tubes

are fully assembled).

Screw assembly (A+B) in a clockwise direction on to

the base. Take care not to trap the cable or cross the

thread, rmly tighten the tube by hand.

To attach the glass shades remove shade ring (E) from

threaded body (D), place glass shade over threaded

body (D) and replace the shade ring (E), tighten with

light pressure.

Fit the recommended bulb as mentioned overleaf.

Refer to assembly drawing opposite. Carefully unpack

the carton, making sure all the parts are

present before assembly. Gently pull away any

protectors from the ends of the tubes. The tting has

been packaged as three separate parts to prevent

damage during transit; please ensure all packaging has

been removed.

ShadesLight tting

Gently pull the remaining slack cable through from the

underside of the base.

6Your oor lamp is now ready to use. Switch on using

the foot switch.
