John Lewis JLBICH605 Manuel utilisateur

JLBICH605

Ceramic glass hob

Instruction manual

Safety information

It is most important that this instruction book should be retained with

the appliance for future reference. Should the appliance be sold or

transferred to another owner, or should you move house and leave the

appliance, always ensure that the book is supplied with the appliance in

order that the new owner can get to know the functioning of the appliance

and the relevant warnings.

These warnings have been provided in the interest of safety. You MUST

read them carefully before installing or using the appliance. If you are

unsure of the meanings of these warnings contact the John Lewis branch

from which you purchased the appliance.

General safety

Warning! Persons (including

children) with reduced physical

sensory, mental capabilities or lack of

experience and knowledge must not

use the appliance. They must have

supervision or instruction for the

operation of the appliance by a person

responsible for their safety.

Child safety

• Only adults can use this appliance. Children

must get supervision to make sure that they

do not play with the appliance.

• Keep all packaging away from children.

There is a risk of suffocation.

• Keep children away from the appliance

when it is on.

Warning! Start the child safety device

to prevent small children and pets

from an accidental activation of the

appliance.

Safety during operation

• Remove all packaging, stickers and layers

from the appliance before the first use.

• Set the cooking zones to "off" after each

use.

• Risk of burns! Do not put cutlery or

saucepan lids on the cooking surface, as

they can become hot.

Warning! Fire danger!

Overheated fats and oils can ignite

very quickly.

Correct operation

• Always monitor the appliance during

operation.

• Only use the appliance for domestic

cooking tasks!

• Do not use the appliance as a work or a

storage surface.

• Do not put or keep very flammable liquids

and materials, or fusible objects (made of

plastic or aluminium) on or near the

appliance.

• Be careful when you connect the appliance

to the near sockets. Do not let electricity

bonds touch the appliance or hot

cookware. Do not let electricity bonds

tangle.

How to prevent a damage

to the appliance

• If the objects or cookware fall on the glass

ceramic, the surface can be damaged.

• Cookware made of cast iron, cast

aluminium or with damaged bottoms can

scratch the glass ceramic if you move them

on the surface.

• Do not let cookware boil dry to prevent

the damage to cookware and glass

ceramics.

• Do not use the cooking zones with empty

cookware or without cookware.

• Do not cover any part of the appliance with

aluminium foil.

Warning! If there is a crack on

the surface, disconnect power

supply to prevent the electric

shock.

Contents

For the User

Safety information

Description of the appliance

Operating the appliance

On and Off 6

Automatic Switch Off 6

The heat setting 7

The child safety device 7

Helpful hints and tips

Care and cleaning

What to do if...

For the Installer

Installation

Guide to use the

instruction manual

The following symbols will be found in the text

to guide you throughout the instructions:

Safety instructions

Hints and tips

Environmental information

Description of the appliance

Cooking surface layout

210

180

145

1 2

1Single cooking zone 1200 W

2Single cooking zone 1800 W

3Single cooking zone 1200 W

4Control panel

5Single cooking zone 2300 W

Control panel layout

1 2 3

Use the sensor fields to operate the appliance.

sensor field function

starts and stops the hob

heat setting display shows the heat setting or functions which are on

/ increases or decreases the heat settings

Heat setting displays

Displays and sounds tell which functions are started

Display Description

The cooking zone is off

- The cooking zone operates

There is a malfunction

A cooking zone is still hot (residual heat)

Lock/Child safety device is on

The automatic switch off is active

Residual heat indicator

Warning! Risk of burns from

residual heat!

Operating the appliance

On and Off

Touch for 1 second to start or stop the

appliance.

Automatic Switch Off

The function stops the hob automatically if:

• all cooking zones are off .

• you do not set the heat setting after you

start the hob.

• you cover a sensor field with an object (a

pan, a cloth, etc.) for longer than 10

seconds. The sound operates some time

and the hob stops. Remove the object or

clean the control panel.

• you do not stop a cooking zone or change

the heat setting after some time. See the

table. comes on.

Automatic Switch Off times

Heat setting - - -

Stops after 6 hours 5 hours 4 hours 1.5 hours

The heat setting

Touch to increase the heat setting. Touch

to decrease the heat setting. The display

shows the heat setting. Touch and at

the same time to switch off.

The child safety device

This function prevents an accidental operation

of the hob.

Starting the child safety device

•Start the hob with . Do not set the

heat settings .

•Touch of the two front cooking zones at

the same time for 4 seconds. The symbol

comes on. Switch off the appliance.

Switching off the child safety device

•Start the hob with . Do not set the

heat settings .

•Touch of the two front cooking zones at

the same time for 4 seconds. The symbol

comes on. Switch off the appliance.

Overriding the child safety device for one

cooking session

• Start the hob with . The symbol

comes on.

•Touch of the two front cooking zones at

the same time for 4 seconds. The symbol

comes on. Set the heat setting in

less than 10 seconds. You can operate

the hob. When you stop the hob with ,

the child safety device operates again.

Helpful hints and tips

Cookware

• The bottom of the cookware must

be as thick and flat as possible.

• Cookware made of enamelled steel

and with aluminium or copper

bottoms can cause discoloration on

glass ceramic surface.

Energy saving

• If possible, always put the lids on the

cookware.

• Put cookware on a cooking zone

before you start it.

• Stop the cooking zones before the

end of the cooking time to use

residual heat.

• The bottom of pans and cooking

zones must have the same

dimension.

Examples of cooking

applications

The data in the table is for guidance only.

Heat

settin

Use to: Time Hints

1 Keep cooked foods warm as

required

Cover

1-2 Hollandaise sauce, melt: butter,

chocolate, gelatine

5-25 min Mix occasionally

1-2 Solidify: fluffy omelettes, baked eggs 10-40

min

Cook with a lid on

2-3 Simmer rice and milkbased dishes, heating

up ready-cooked meals

25-50

min

Add at least twice as much liquid as

rice, stir milk dishes part way through

3-4 Steam vegetables, fish, meat 20-45

min

Add a few tablespoons of liquid

4-5 Steam potatoes 20-60

min

Use max. ¼ l water for 750 g of

potatoes

4-5 Cook larger quantities of food, stews and

soups

60-150

min

Up to 3 l liquid plus ingredients

6-7 Gentle fry: escalope, veal cordon bleu,

cutlets, rissoles, sausages, liver, roux,

eggs, pancakes, doughnuts

required

Turn halfway through

7-8 Heavy fry, hash browns, loin steaks,

steaks

5-15 min Turn halfway through

9 Boil large quantities of water, cook pasta, sear meat (goulash, pot roast), deep fry chips

Information on

acrylamides

Important! According to the newest

scientific knowledge, if you brown food

(specially the one which contains starch),

acrylamides can pose a health risk. Thus, we

recommend that you cook at the lowest

temperatures and do not brown food too

much.

Care and cleaning

Clean the appliance after each use. Always use cookware with clean bottom.

Warning! Sharp objects and abrasive

cleaning agents will damage the

appliance.

For your safety, do not clean the

appliance with steam blasters or high-

pressure cleaners.

Scratches or dark stains on the glass

ceramic have no effect on how the

appliance operates.

Removing the dirt:

1. – Remove immediately: melting

plastic, plastic foil, and food containing

sugar. Use a special glass ceramic

scraper. Put the scraper on the glass

ceramic surface at an acute angle and

slide the blade on the surface.

–Stop the appliance and let it cool

down before you clean: limescale rings,

water rings, fat stains, shiny metallic

discolorations. Use a special cleaner for

glass ceramic or stainless steel.

2. Clean the appliance with a damp cloth and

some detergent.

3. At the end rub the appliance dry with

a clean cloth.

What to do if...

Problem Possible cause and remedy

You cannot start the appliance or

operate it.

• You touched 2 or more sensor fields at the same time. Only

touch one sensor field.

• There is water or fat stains on the control panel. Clean the

control panel

•The child safety device operates . Stop the function. See the

section “Child safety device”.

• Start the appliance again and set the heat setting in 10 seconds.

The residual heat indicator does

not come on.

The cooking zone is not hot because it operated only for a short

time. If the cooking zone must be hot, speak to the after sales

service.

A sound operates and appliance

starts and stops again. After 5

seconds one more sound

operates.

You covered . Uncover the sensor field.

comes on. • The automatic switch-off operates. Stop the appliance and start

it again.

Overheating protection for the cooking zone operates. Stop the

cooking zone and start it again.

Problem Possible cause and remedy

and a number come on. There is an error in the appliance.

Disconnect the appliance from the electrical supply for some time.

Disconnect the fuse from the electrical system of the house.

Connect again. If comes on again, speak to the after sales service.

If you tried the above solutions and cannot

repair the problem, speak to your dealer or

the Customer Care Department. Give the

data from the rating plate, three-digit-letter

code for the glass ceramic (it is in the corner

of the cooking surface) and an error message

that comes on.

If you operated the appliance incorrectly, the

servicing by a customer service technician or

dealer will not be free of charge, even during

the warranty period. The instructions about

the customer service and conditions of

guarantee are in the guarantee booklet.

Autres manuels pour JLBICH605

Table des matières

Autres manuels John Lewis Plaque

John Lewis

John Lewis JLBIGH603 Manuel utilisateur

John Lewis

John Lewis JLBIGGH 704 Manuel utilisateur

John Lewis

John Lewis JLBIIH 804 Manuel utilisateur

John Lewis

John Lewis JLBICH601 Manuel utilisateur

John Lewis

John Lewis JLBIIH613 Manuel utilisateur

John Lewis

John Lewis JLBIGGH703 Manuel utilisateur

John Lewis

John Lewis U29492 JLBIIH603 Manuel utilisateur

John Lewis

John Lewis JLBIIH804 Manuel utilisateur

John Lewis

John Lewis JLBIGH601 Manuel utilisateur

John Lewis

John Lewis JLBIIH804 Manuel utilisateur

John Lewis

John Lewis JLBIGH753 Manuel utilisateur

John Lewis

John Lewis JLBICH605 Manuel utilisateur

John Lewis

John Lewis JLBIGH702 Manuel utilisateur

John Lewis

John Lewis JLBIGGH606 Manuel utilisateur

John Lewis

John Lewis JLBIGGH605 Manuel utilisateur

John Lewis

John Lewis JLBICH602 Manuel utilisateur

John Lewis

John Lewis JLBIIH614 Manuel utilisateur

John Lewis

John Lewis JLBICH605 Manuel utilisateur

John Lewis

John Lewis JLBIGH754 Manuel utilisateur

John Lewis

John Lewis JLBICH602 Manuel utilisateur

John Lewis

John Lewis JLBIGGH756 Manuel utilisateur

John Lewis

John Lewis JLBIIH615 Manuel utilisateur

John Lewis

John Lewis JLBIIH604 Manuel utilisateur

John Lewis

John Lewis JLBIGH602 Manuel utilisateur

Manuels Plaque populaires d'autres marques

Siemens

Siemens EX875KYV1E Fiche technique

AEG

AEG CERAMIC HOB 6010 K Manuel utilisateur

VALERA

VALERA CT 70A Manuel utilisateur

Zanussi

Zanussi ZGF 6420 Manuel utilisateur

Gaggenau

Gaggenau CI 273 Manuel utilisateur

G3 Ferrari

G3 Ferrari Energy Manuel utilisateur

Pkm

Pkm IN4B Manuel utilisateur

Award

Award H903BG Manuel utilisateur

Zanussi

Zanussi VCH 5005 RZ Manuel utilisateur

Miele

Miele KM 523 Manuel utilisateur

Hotpoint

Hotpoint IS67V8CCXT/E Manuel utilisateur

AEG

AEG HK854870XB Manuel utilisateur

Cookology

Cookology SEP600BK Manuel utilisateur

Bauknecht

Bauknecht Hob Manuel utilisateur

Zanussi

Zanussi ZGM 782 Manuel utilisateur

dipo INDUCTION

dipo INDUCTION DIBK218S Manuel utilisateur

Miele

Miele KM 5987 Manuel utilisateur

Miele

Miele KM 360 G Manuel utilisateur
