JMC Multi2SDI Manuel utilisateur
JMC Systems Engineering AB www.jmc.se +46-8-82 82 70
Multi2SDI
Scaling
User Manual
V1.1
JMC Systems Engineering AB www.jmc.se +46-8-82 82 70
Content
Feature ...................................................................................3
Front Panel...............................................................................4
Rear Panel................................................................................4
Top Panel.................................................................................5
Side Panel ................................................................................5
Button/LED Indicate ....................................................................6
Installation ............................................................................. 11
Package Contents ..................................................................... 11
Specifications.......................................................................... 12
Appendix Table A ..................................................................... 13
JMC Systems Engineering AB www.jmc.se +46-8-82 82 70
Feature
SDI Supports HD formats :
720p50 & 60
1080i50 & 60
1080p24, 25, 30, 50 & 60
SDI Support 525i & 625i SD D1 format
Auto 3G/HD/SD-SDI detection
Can be split one 3G-SDI displays simultaneously.
Frame rate conversion(1.000/1.001)
External Button Configuration
Firmware is upgradable in the field using the integrated USB port
The converter is Plug-and-Play
Support DVI-D, DVI-A, Component, CVBS and S-Video Input
JMC Systems Engineering AB www.jmc.se +46-8-82 82 70
Front Panel
NO
Component
Function
1
SDI Output Port
From your SDI Display Device plug into this ports
2
Mode Buttons
Select Format/Output Port
3
Power Jack
The Power adapter plug into here
Rear Panel
NO
Component
Function
1
Phone Jack
Form you Audio Device plug into this port
2
Component/CVBS/S-Video
Input Port
From your YPbPr/CVBS/S-Video Device plug
into this port
3
DVI-D/DVI-A Input Port
From your DVI-D/DIV-A Device plug into this
port
1
3
1
3
2
2
JMC Systems Engineering AB www.jmc.se +46-8-82 82 70
Top Panel
NO
Component
Function
1
Input Source LED
The LEDs are indicate Input source
2
Power and Lock LED
The LEDs is indicate power and signal locked.
3
Main Format LED
The LEDS are indicate output format
Side Panel
NO
Component
Function
1
USB Port
Upgrade firmware/Control Box From PC
1
1
2
3
JMC Systems Engineering AB www.jmc.se +46-8-82 82 70
Button/LED Indicate
1. Firmware Mode:
Hold on the 1 and 2 button, the display is showed firmware version on display of
left upper.
FIRMWARE VERSION
0.1.0.1
2. Default Mode:
Push all button (1, 2 and 3) at same time, the box auto reset to default.
3. Audio Mode
Push all button 2 to setting audio Mode..
DVI-D
Embadded Audio (Default)
External Audio
Mute
DVI-A
Mute
YPbPr
Composite
External Audio
SVIdeo
JMC Systems Engineering AB www.jmc.se +46-8-82 82 70
4. Output Format Mode:
Push button 1 change to format mode, frame rate and Fraction by button 2 and 3.
Button 1
Button 2
Button 3
720x480
59.94i
720x576
50i
1280x720
60p
59.94p
50p
30p
25p
1920x1080
60i
59.94i
50i
60p
59.94p
50p
30p
29.97p
25p
24p
23.98p
5. Input Source Mode:
Push button 4 change to input source mode. The button 3 and 4 can be switch
output source.
DVI-D/DVI-A
Pb/CVBS
Y/Y
Pr/C
DVI-D
●
○
○
○
DVI-A
●
○
○
○
YPbPr
○
●
●
●
CVBS
○
●
○
○
S-VIDEO
○
○
●
●
1
2
3
JMC Systems Engineering AB www.jmc.se +46-8-82 82 70
1. DVI-D + L/R Audio:
DVI-D + L/R Audio
2. DVI-A+ L/R Audio:
DVI-A + L/R Audio
JMC Systems Engineering AB www.jmc.se +46-8-82 82 70
3. YPbPr + L/R Audio:
YPbPr + L/R Audio
4. Composite (CVBS) + L/R Audio:
Composite(CVBS) + L/R Audio
5. S-VIDEO + L/R Audio
JMC Systems Engineering AB www.jmc.se +46-8-82 82 70
Composite(CVBS) + L/R Audio
3. Pattern Genertor Mode:
input signal is plug out, the Box auto change to Pattern Genertor mode.
It is proivded the 13 of Mode
