TOPAX®DX

Multi-Channel Controller

EN 01 Operation & Maintenance Instructions

Read this operating instructions before start up!

To be retained for future reference.

Dosing

Conveying

Control

Liquids

Gases

Systems

2 | Operation Manual TOPAX DX | BA-40100

List of Contents

1. Safety ................................................................................................... 3

1.1 General ................................................................................................ 3

1.2 Warnings used in this Operation & Maintenance Manual.......................... 3

1.3 Operators qualiﬁcation and training........................................................ 3

1.4 Electrical safety tips .............................................................................. 3

1.5 Hazards due to non-compliance with the safety instructions .................... 3

1.6 Safe operation ...................................................................................... 3

1.7 Safety instructions for the operator......................................................... 3

1.8 Safety instructions for installation, maintenance and inspection................ 3

1.9 Self-made modiﬁcations and spares procurement................................... 4

2. Before placing in operation................................................................. 4

2.1 Compliant use ...................................................................................... 4

2.2. Scope of delivery.................................................................................. 4

2.3 Steps to take for start-up....................................................................... 4

3. Technical data...................................................................................... 5

3.1 Cable recommendation ......................................................................... 6

3.2 Order variants....................................................................................... 6

4. Mounting build-in housing.................................................................. 7

4.1 General notes of instruction ................................................................... 7

4.2 Wall mount ........................................................................................... 7

4.3 Product overview .................................................................................. 8

4.4 Technical components........................................................................... 8

4.5 Power connections.............................................................................. 10

4.6 Terminal clips on the technical components .......................................... 12

4.7 Operation and keyboard layout............................................................. 14

4.8 First set-up and programming guidelines.............................................. 14

4.9 Next steps .......................................................................................... 17

5. Measuring values inputs ................................................................... 18

5.1 Free chlorine measurements input ....................................................... 18

5.2 Measuring input pH value.................................................................... 20

5.3 Measurement output Redox potential .................................................. 21

5.4 Measuring input temperature............................................................... 22

5.5 Measurement input total chlorine and display of bonded chlorine........... 22

5.6 Conductivity measurements input......................................................... 22

6. Explanation of digital inputs ............................................................. 23

6.1 Start-up lag time................................................................................. 23

6.2 Deactivation of the controller function with alarm signaling in the case of lack

of sample water........................................................................................ 23

6.3 Controller function deactivation (ﬁlter cleaning) without alarm ................ 23

6.4 Pre-alarm, alarm and warning "level dosing pump"............................... 23

7. Explanation measuring values outputs ............................................ 24

7.1 Output types....................................................................................... 24

7.2 Output limit switch .............................................................................. 24

7.3 Actuator elements............................................................................... 24

8. Controller explanation ....................................................................... 25

8.1 Proportional controller (P controller)...................................................... 25

8.2 Proportional-integral-derivative controller ((PI, PID controller) ................. 25

8.3 Calculation of setable values................................................................ 25

8.4 Controller parameters.......................................................................... 26

8.5 Controller direction.............................................................................. 26

8.6 Base load metering ............................................................................. 26

8.7 Manual operation................................................................................ 26

9. Alarms................................................................................................ 27

9.1 Measuring values alarms..................................................................... 27

9.2 Emergency stop (Y-alarm).................................................................... 27

10. Analogue power outputs 0/4...20 mA for remote display .............. 27

11. Night operation ................................................................................ 28

12. Economy mode - DIN-contact and ECO-contact ............................ 28

12.1. TOPAX®DX is responsable for economy mode................................... 28

12.2. TOPAX®DX controlled DIN-contact only ............................................. 28

13. Control of the ﬂocking pump .......................................................... 29

14. Log book function............................................................................ 29

15. Auto setup (First system self-setting) ............................................ 30

16 Menu conﬁguration and main settings............................................ 31

16.1 Menu of TOPAX®DX ......................................................................... 31

16.2 conﬁguration example and terminal connection................................... 39

17. Wiring diagrams .............................................................................. 40

17.1 Examples overview............................................................................ 40

18. Software updates............................................................................. 49

18.1 Firmware update............................................................................... 49

18.2 Update for further menu languages.................................................... 49

19. Default settings................................................................................ 49

20. Spare parts and options .................................................................. 50

21. MMC (Multi-Media-Card) memory card.......................................... 50

22. Troubleshooting and diagnostics.................................................... 51

23. terminal connection diagram for own conﬁgurations ................... 52

24. Index................................................................................................. 54

25. Declaration of conformity................................................................ 55

26. Device revision................................................................................. 56

27. Warranty Application....................................................................... 57

BA-40100 | Operation Manual TOPAX DX | 3

Chapter 1: Safety

1. Safety

1.1 General

This manual contains very important information for assembly,

start-up, use and maintenance of the meter. Please have your

staff and any person in charge of the unit read and understand

this manual before starting any work with it. Store this manual

safely in a place where mechanics, installers and other techni-

cal staff as well as operators can rapidly access it in case of

emergency. Pay special warning and provide compliance with all

safety notices in this manual!

1.2 Warnings used in this Operation & Maintenance Manual

This Operation & Maintenance Manual contains vital information

which may endanger people and the unit if they are disregarded.

These statements are identiﬁed by the following symbols:

WARNING!

Refers to a potentially hazardous situation. Non-

compliance can lead to death or extremely serious

injury.

CAUTION!

Refers to a potentially hazardous situation. Non-

compliance can lead to minor injury or property

damage.

IMPORTANT! or NOTICE!

Appears in conjunction with safety instructions

which may endanger the machine and its operation

if disregarded.

IMPORTANT!

Draws attention to supplementary information to

make the work easier and ensure troublefree opera-

tion. Appropriate reference attached directly on the

unit or any of its other parts must absolutely be con-

sidered and held in completely readable condition for

future reference.

1.3 Operators qualiﬁcation and training

Your assembly, operation, maintenance and inspection staff must

be trained and have the appropriate qualiﬁcation for use and op-

eration of the unit. Area of responsibility, tasks and supervision

of the personnel must be provided at all times by the customer.

Unskilled operators must be duly trained and instructed. If neces-

sary, this can also be undertaken by the manufacturer or certi-

ﬁed supplier on behalf of the owner. Operators who are to work

with the meter must read and understand the manual in all of

its parts.

1.4 Electrical safety tips

When installing and using this electrical equipment, basic safety

precautions should always be followed, including the following:

WARNING!

1.) Read and follow all instructions.

2.) To reduce the risk of injury, do not permit children

to use this product unless they are closely super-

vised at all times.

3.) Risk of Electric Shock. Ensure that the device is

secured with a ground fault - circuit breaker (GFCI

= earth-leakage circuit breaker). Contact a qualiﬁed

electrician if you cannot verify that the receptacle is

protected by a GFCI.

4.) Do not bury cord. Locate cord to minimize abuse

from lawn mowers, hedge trimmers, and other

equipment.

5.) To reduce the risk of electric shock, replace dam-

aged cord immediately.

6.) To reduce the risk of electric shock, do not use

extension cord to connect unit to electric supply;

provide a properly located outlet.

7.) Keep this instruction at close for future refer-

ence.

1.5 Hazards due to non-compliance with the safety

instructions

Failure to comply with the safety instructions may endanger not

only people, but also the environment and the unit. Non com-

pliance with the safety information will immediately cancel your

rights of claiming for damages even during the warranty period.

The following hazards in particular may arise: - Failure of system

functions. - Danger to people due to electrical, mechanical and

chemical effects. - Danger to the environment due to leakage of

hazardous substances.

1.6 Safe operation

The safety instructions contained in this Operation & Maintenance

Manual must be observed. The owner is responsible for ensuring

compliance with local safety regulations. Disturbances suscepti-

ble of impairing safety are to be eliminated immediately!

1.7 Safety instructions for the operator

Statutory regulations must be observed. A safe and ecologically

beneﬁcial disposal of process materials as well as replacement

parts must be ensured. Danger due to electric current must be

excluded (for further details, refer to the German VDE1) standards

as well as local rules and regulations as well as chapter 1.4).

1) Association of German Electrotechnical Engineers

1.8 Safety instructions for installation, maintenance and

inspection

The operator has to ensure that all assembly, maintenance and

inspection works are done by authorized and qualiﬁed technical

operators.

4 | Operation Manual TOPAX DX | BA-40100

Chapter 2: Before placing in operation

WARNING!

Assembly and maintenance of the equipment

are to be strictly done after disconnecting the

device from the power supply. It must be se-

cured against reconnection during the works!

Auxiliary assemblies and tools should be dismounted

prior to maintaining. Cables are to be attached like-

wise only in this condition.

Neglecting of these instructions can lead to severe damages of

TOPAX®DX and loss of warranty.

All safety mechanisms and guards must be reﬁtted and reacti-

vated as soon as the work is complete.

NOTICE!

Apart from an incorrect installation also wrong con-

troller settings (default settings, data of the param-

eter and conﬁguration level, and internal changes of

the instrument) can impair or damage the process

normal functions.

There should always be a safety device that is independent of the

controller. Conﬁgurations may only be carried out by technical

personnel! If necessary use password protection! Always comply

with the safety regulations and accident prevention laws of the

country of use.

1.9 Self-made modiﬁcations and spares procurement

TOPAX®DX may be converted or changed only by qualiﬁed tech-

nical personnel.

If the conﬁguration of the TOPAX®DX is wrongly made by as-

sembly or service personnel, errors and dangers in the function

of the machine can result. In this case, the manufacturer declines

any liability.

NOTICE!

Genuine spare parts and sensors authorized by the

manufacturer ensure greater safety. Otherwise the

guarantee expires.

2. Before placing in operation

2.1 Compliant use

Der TOPAX®DX is especially designed and meant for metering

and control applications in swimming pools, SPA and bath wa-

ters, water treatment plants and waste water management. The

operational safety of the delivered unit can only be guaranteed

when it is used in conformity with its intended use.

Other usage and modiﬁcations will determine the immediate can-

cellation of the warranty and any other manufacturer’s liability.

2.2. Scope of delivery

Carefully check the delivery before installation and refer to the

delivery note to ensure the delivery is complete and to check

for any transport damages. Contact the supplier and/or carrier

regarding any questions concerning the delivery and/or transport

damages.

Do not operate any defective devices.

The following belong within the scope of delivery:

• TOPAX®DX casing (as per the model)

• Tool (M4 screw) to open the casing

• MMC memory card

• Mounting material

• Operation & Maintenance Instructions

• Measuring protocol

• Terminal plan for the sensors

• Electrodes (optional)

• Cable connection TOPAX®DX to the electrodes (optional)

The device is delivered either as detached or mounted onto a

measuring water table.

2.3 Steps to take for start-up

The following steps are recommended by the manufacturer in

order to install the TOPAX®DX successfully:

• Reading the operation manual

• Mount the device

• Attach the sensors and actuating element (to the controlling

pumps and switch, etc.)

• Initial conﬁguration of the in- and output (see chapter 4.8)

• Calibrate the sensors to the measuring output (see chapter

5 and 6)

• Set up the set points (see chapter 16, menu 1.1)

• Set up the control (see chapter 16, menu 2.1)

• Conﬁguration of the regulating output (see chapter 7)

BA-40100 | Operation Manual TOPAX DX | 5

Chapter 3: Technical data

3. Technical data

Supply voltage 90...264 VAC, 47...63 Hz

Power consumption Approx 24 W

Housing dimensions 302 x 231 x 108 mm (W x H x D) wall mounted unit

Display Graphic colour display 5.7 inch, 320 x 240 pixels (RGB), with background lighting

Keyboard Glass keyboard with touch keys

Measuring inputs

(potential-free)

- inputs for free chlorine, pH value, REDOX potential, temperature

- 4...20 mA input for the measurement of total chlorine and controlling of bonded chlorine with supply of the electrode (24 VDC)

- 4...20 mA input for conductivity (passive) measurement and control

Regulating characteristic for 4

inputs (free chlorine, pH value,

bonded chlorine, conductivity,

depending of conﬁguration level)

P, PI, PD or PID performances

Fixed value regulation, standard channel selectable with disturbance variable feed forward

2-side controller

Control parameter Xp: 1...500%, Tn: 1...200 min., Tv: 1...1200 sec.

Measuring input for free chlorine open amperimetric electrode with mechanical cleaning (excess chlorine detector with 2 electrodes, CS 120)

Measuring range adjustable between 0-1,00 mg/l, 0-2,00 mg/l, 0-5,00 mg/l or 0-10,00 mg/l. connection via line-up terminals*

Potentiostat (PM)

Measuring range adjustable between 0-1,00 mg/l or 0-2,00 mg/l

Encapsulated electrode 20 mA type, measuring range depending on type of electrode

Measuring input for pH value Measuring range pH 0..14 connection via line-up terminals*

REDOX potential measuring input Measuring range 0..1,000 mV connection via line-up terminals*

Temperature measuring input

- Pt 100

Measuring range -10°C ...

+100°C

two-leader connection by means of line-up terminals*

Total chlorine measuring input Encapsulated electrode 20 mA type, measuring range depending on type of electrode

Conductivity measurement Conductive and inductive with

separate measuring ampliﬁer

20 mA type, measuring range depending on type of measuring ampliﬁer

Disturbance factor input 0/4...20 mA programmable

Disturbance factor: 0.1...10 times ampliﬁcation

Digital inputs - Early warning level input for metering pump 1

- alarm level input for metering pump 1

- Early warning level input for metering pump 2

- Alarm level input for metering pump 2

- Filter cleaning: disconnection of the controller function without alarm

- measuring water shortage disconnection of the regulating function with alarm (external cut off)

- activate night-time economy mode

Automatic controller outputs Electronic output

(optocouplers)

- 48 VDC; 250 mA

(pulse frequency 10... 200 impulses/min)

Relay output - ON/OFF

- pulse frequency 10...100 Impulses/min

- Pulse length 10…120 seconds

- 3-point step output with

- Position feedback

value of the Potentiometer 1...10 kOhm

continuous output - 0/4...20 mA, max. load 500 ohms

Alarm output Relay output as collective alarm for the measuring size of free and bonded chlorine, pH value, redox potential, temperature and

conductivity as potential free changer

Measuring value alarm min. and max. alarm freely adjustable, time delay adjustable: max. 200 min

Safety shut off To prevent over metering (Y-alarm), time delay adjustable: max. 200 minutes

Current outputs to remote trans-

mission of measuring values

- Free and unbonded chlorines

- pH value

- Redox potential

- temperature and conductivity

0/4...20 mA possible spreading; max. load 500 ohms potential free

average spreading >50 % with measuring input free chlorine and 0/4...20mA

>10% during measurement input of pH-value and redox potential

Computer interface (optional) RS 485

Load capacity of the relay 230 V AC, 3A

Protection class IP 65 with locked screw connections

Ambient temperature -5°C ... +45°C

Atmospheric moisture 95 % non-condensing

*) max. 0,5 mm² with cable ends protection sleeve and max. 1,0 mm² without cable end sleeve.

6 | Operation Manual TOPAX DX | BA-40100

Chapter 3: Technical data

3.1 Cable recommendation

Recommended cables for the different connections and applications:

Connections and applications dimensions Types

Mains voltage M20 X 1,5 NYM-I 3 x 1,5 mm ( 9,1 mm)

Relay output (ATE- engine) M20 X 1,5 NYM-I 4 x 1,5 mm ( 9.8 mm)

Relay output (pulse frequency), (pulse length) M16 X 1,5 NYM- O 2x 1,5 mm ( 8,7 mm)

Relay output alarm) M16 X 1,5 NYM- O 3x 1,5 mm ( 9,1 mm)

connection to PC, computer cable Cat 5 M12 X 1,5 Type 2X2XAWG24/1 ( 5,7 mm)

Connection of current outputs (remote communication cable) M12 X 1,5 J-Y (St) Y 4 x2x0,6 mm ( 6,5 mm)

Position feedback ATE- engine (remote communication cable) M12 X 1,5 J-Y (St) Y 2x2x0,6 mm ( 5,0 mm)

Continuous controller output (remote communication cable) M12 X 1,5 J-Y (St) Y 2x2x0,6 mm ( 5,0 mm)

Input chlorine measuring cell M12 X 1,5 LIYY 2x 0,25 mm

Digital inputs (for each input) (remote communication cable) M12 X 1,5 J-Y (St) Y 2x2x0,6 mm ( 5,0 mm)

3.2 Order variants

The TOPAX®DX is available in different product variants upon request. The following ﬁve variants are standard articles:

Order no. 40100001 40100002 40100003 40100004 40100005

Inputs

Component 78403 X X X X X

Component 78404 X X X X

Free chlorine Measuring cell (optional):

Amperometric (Excess chlorine detector with 2 electrodes CS120) X X X

Potentiostatic X X X X

Diaphragm-covered X X X

pH value X X X X X

Redox X X X X X

Temperature X X X X X

Position feedback with 3-point-steps controller 1 2 2 2 2

Measurement of total chlorine by means of an encapsulated electrode with integrated electronic

ampliﬁer (4...20 mA input with electrode electronics supply)

X X

Measurement of conductivity with a separate measurement ampliﬁer (4...20 mA input) X X

Outputs

Component 78399 X X X X X

Controller with 3-point stepping output with potentiometer feedback, pulse length output, Pulse

frequency output, ON/OFF switching output or 0/40...20 mA power output

1 2 2 2 2

Controller with pulse length output, pulse frequency output, control output IN/OUT or current

output 0/4...20 mA

1 1 1 2

BA-40100 | Operation Manual TOPAX DX | 7

Chapter 4: Mounting build-in housing

4. Mounting build-in housing

4.1 General notes of instruction

For installation, the local directions and regulations have to be

adhered to. Any mounting position is possible. The ambient con-

ditions are to be maintained in accordance with the technical

data. Exposure of the unit to direct heat and sunlight must be

avoided.

Diagram TOPAX®DX housing

The front housing ④and the reare housing ①of TOPAX®DX

are securely bolted together with two bolts (see ②and ③in ﬁg.

4.1). The construction is so arranged that the TOPAX®DX can be

opened and accessed on both sides.

③

①

②

④

Fig. 4.1: Front and reare housing

Opening the casing

The bolts (hinge pivots) are purposely tightened so that they can

only be removed using a tool. To unscrew, ﬁrst release the nuts⑤

at the top with the help of a screwdriver at one axis, and this axis

⑥ can be pulled out downwards. The curled thumb M4 screw ⑦

provided serves as a tool for this, which is screwed in the axis

from underneath (see ﬁg 4.2).

When the reassembling, make sure to ﬁt all nuts back in place.

NOTICE!

In order to open the housing remove only one hinge

pivot from the equipment. If both bolts are removed

at the same time, the upper part and the lower part

of the box will fall loose.

⑤

⑦

⑥

Fig. 4.2: Open the casing onto the casing fastener on the wall and/or onto the

cable connection fastener.

NOTICE!

The equipment is to be opened only when plugged

off the power supply.

4.2 Wall mount

For the wall assembly 4 mounting holes are to be found in the

lower part of the housing. The hardware for wall ﬁxation is pro-

vided with the unit by the manufacturer (see ﬁg. 4.3).

8 | Operation Manual TOPAX DX | BA-40100

Chapter 4: Mounting build-in housing

Fig. 4.3: Spacing of hole for monting the device (left) and the device dimensions

4.3 Product overview

The TOPAX®DX device is composed of two parts, a rear and

a front housing (see Abb. 4.1). The rear shell of the housing is

electrically connected with a ﬂat cable with the front one.

reare housing

consists of rear housing with the motherboard, in which the cable

connections are screwed in.

On the motherboard there are the main modules for the function-

ing. Depending upon the model, two input blocks are available

together with an output block. For networking purposes with con-

nection to a PC, an additional interface (RS485) is available. All

blocks are connected by plug connectors to the motherboard and

fastened with several nuts.

front housing

On the front housing there are the display plate and the key-

board. A colour display is available for displaying measurements

and adjustments. The operation takes place with 6 function keys

as well as a control cross with "OK" key. The keys are integrated

in a glass keyboard and react to contact. All displays of the indi-

vidual menus appear as plain text.

Fig. 4.4: Front and reare housing (left) with display and reare housing.

4.4 Technical components

Besides the main board, the following can be ﬁtted in addition

• up to 2 input components

• an output component and

• an Interface module (RS 485)

(see Fig. 4.5) To operate the TOPAX®DX at least one entry com-

ponent has to be built in.

Ausgangsbaugruppe

Hauptplatine

DO4 DO3 DO2 DO1

78404

78403

78402

DO7 DO6 DO5

DO0

78399

Rechnerschnittstelle (verdeckt)

78406

+-+-+-+-+-+-

20 mA Stromausgänge Digitale Eingänge

Netzteil

- -+ +

51A

52A

51B

52B

- -+ +

Eingangsbaugruppe

5-fach

Alarmrelais

Eingangs-

baugruppe

3-fach

Steckverbindung

zur Displayplatine

Fig. 4.5: Arranging the components on the main board

Main board (order no. 78402)

Besides this function, to incorporate the further components, the

main board is made up of the following connections:

• 8 analogue power inputs (0/4...20mA)

• 8 digital inputs

• Alarm relay

• power supply

5-fold Input block (Code 78403):

with 5 measurement inputs for:

• free chlorine (amperometric or membrane covered elec-

trode) (0/4...20 mA)

• pH single-rod measuring cell

• Redox single-rod measuring cell

• Temperature sensor Pt100

• Position feedback of an eventual servo motor with potenti-

ometer

171 mm

267 mm 302 mm

240 mm

171 mm

267 mm 302 mm

240 mm

Reverse side

BA-40100 | Operation Manual TOPAX DX | 9

Chapter 4: Mounting build-in housing

3-fold Input block (Code 78404):

with 3 measurement inputs for:

• free chlorine (potentiostatic electrode)

• Position feedback of an eventual servo motor with potenti-

ometer

• a 0/4...20 mA power entrance for the connection of a

disturbance factor or a conductivity measuring unit with

upstream measuring ampliﬁer

IMPORTANT!

When free chlorine potentiostatic electrode is used

in a 5-fold input block, it is possible to connect also

a total-chlorine electrode. At the same time bonded

chlorine is calculated by PC and displayed.

Output board (order no. 78399)

On the output block there are 5 integrated relay output and 3

electronic outputs (optocouplers).

The following output can be conﬁgured:

• Controller output free chlorine

with different functions

• Controller output pH value

with different functions

• Controller output bonded chlorine

with different functions

• Controller output conductivity

with different functions

• DIN - contact: Free contact if all conditions of the DIN-

Standards are respected.

• Contact for starting of the ﬂocking pump.

The software conﬁguration automatically assigns these outputs

to the respective terminals in a sequential order- depending on

the conﬁguration of the TOPAXTOPAX®DX:

1. Automatic controller free chlorine

2. Automatic controller pH value

3. Automatic controller bound chlorine

4. Automatic controller conductivity

5. DIN - contact

6. Eco - contact

7. Flocking contact

Depending upon output type, TOPAX®DXselects the next free

relay output or optocoupler. The clamps are assigned in a ﬁrm

order: clamps 87/88 to 95/96 for relays, or 81/82 bis 85/86 for

optocouplers.

NOTICE!

For further information on the terminal connection,

refer to Chapter 4.6

Interface board RS 485 (order no. 78406)

The TOPAX®DX has the option of being ﬁtted with a serial inter-

face RS 485. The RS 485 allows you to transfer data to a PC. The

data communication protocol installed is MODBUS.

With the RS 485 interface it is possible to connect more than one

TOPAX®DX to a network. For this an address is to be assigned

to each TOPAX®DX. In addition to this each TOPAX®DX is ﬁtted

with a computer-interface RS 485.

It is possible to have a maximum of 1000 m of data transfer with

the RS 485 interface. Up to 14 TOPAX®DXs can be connected to

a network with a PC.

An example of a network with more than one device is shown in

chapter 17.

NOTICE!

The data line is to be attached direct to the con-

necting terminals of the TOPAX®DX (clip A and B).

Separate clamping or branching boxes should not be

set. The network address 10 is not permitted.

IMPORTANT!

For the realization of a network with the TOPAX®DX

and the structure of a bus system to a PC a computer

cable "KAT.5 type 2X2XAWG24/1 (Lapp cable)" or

better is to be used.

Using other cables can cause data errors and affect the data

communication. The manufacturer is not liable for this.

Most modern computers are equipped with the serial computer

interface R-S 232 and/or with USB - interfaces. For the connec-

tion to a RS 485 network, an additional connector converter (RS

485 to RS 232 or RS 485 to USB) is necessary.

There are interface components in the under casing part of the

main board in the TOPAX®DX. They are partially hidden from

view by the output components (see diagram 4.6).

Fig. 4.6: RS 485 connections on the interface component’s board partially hid-

den from view by the output components

10 | Operation Manual TOPAX DX | BA-40100

Chapter 4: Mounting build-in housing

NOTICE!

The data line must be locked at both sides with a

120 Ohm line resistance and must be supplied a

ﬁrm potential using the two link plugs on the two

jumpers on the circuit board of the display of all la-

test TOPAX DX versions.

Two link plugs/jumpers have to be connected to the TOPAX®DX

(the last one in the network) for the 120 ohm switch, Pull-up and

Pull-down resistances. The resistances are not active in its deliv-

ered state. The resistance of 120 ohms on the PC side is applied

via the connector converter.

The jumper plug-in slots are located in the upper casing on the

display board, above the ﬂat band-connection to the main board

(see diagram 4.7).

resistances are NOT activated

(delivery status)

resistances are activated

(last device in the network)

Jumper position: OFF Jumper position: ON

The resistances are NOT active.

jumpers are set DOWN

The resistances are active.

jumpers are set UP

Fig. 4.7: Position and setting of the jumper to activate the RS 485 resistances

on the last TOPAX®DX in the network.

TopView Software

For the remote indication a visualization program is offered in two

versions. The program TopView mini is free of charge and can be

downloaded from Internet.

4.5 Power connections

The equipment may be installed and attached only by authorized

and qualiﬁed electricians. Connections must be made according

to the enclosed wiring diagrams.

NOTICE!

Only work on electric connections when the device is

disconnected from the power supply.

Insert the cables in the various connections screwed on the bot-

tom side of the housing. After the installation, tighten all cable

connections so that the required protection class is provided (see

ﬁg. 4.8).

Fig. 4.8: Cable connections for protected cable feedthrough on the rear side of

the housing.

For the connection to the power supply and to the actuators,

TOPAX®DX is equipped with special terminal clips (see ﬁg. 4.9).

For a better assembly these clamps are designed plug-ins (see

ﬁg. 4.10), whereby the maximum cross section is 2.5 mm2for

the power cord and 1.5 mm2for all other cable to the terminal

clips.

Fig. 4.9 and 4.10: The principle of the connecting terminal to the technical com-

ponents. Individual connecting terminals, removable for installation, of

the technical components.

NOTICE!

When choosing the line material, for installation and

electrical connection of the device, observe the regu-

lations of VDE 0100 “Provisions for setting up elec-

tric power plants with nominal voltages below 1000

V“ or the individual national rules.

NOTICE!

The equipment is not suitable for the installation in

explosive conditions!
