Jensen VX7024 Manuel utilisateur

6VRMS

RCA Output

VX7024

6.2" Double DIN Multimedia Receiver

AM-FM / DVD / NAV / SiriusXM Ready™ / Pandora /

Bluetooth / iPhone® - iPod®/ Screen Mirroring /

USB / AV In / Rear Camera In / CarPlay

Operation Manual

VX7024

Android is a trademark of Google Inc.

Sirius, XM and all related marks and logos are registered trademarks of Sirius XM

microSD is a trademark or registered trademark of SD-3C, LLC in the United

States, other countries or both.

Pandora® is a registered trademark of Pandora Media, Inc.

“Made for iPod,” and “Made for iPhone” mean that an electronic accessory (This

head unit) has been designed to connect specifically to iPod®/, or iPhone® ,

respectively, and has been certified by the developer to meet Apple performance

standards.

Apple is not responsible for the operation of this device or its compliance with

safety and regulatory standards. Please note that the use of this head unit with

iPod® or iPhone® may affect mobile phone performance.

iPod®/ iPhone® are trademarks of Apple Inc., registered in the U.S. and other

countries. Apple CarPlay is a trademark of Apple Inc.

VX7024

CONTENTS

Features ...�� 5

Controls and Indicators ..........�� 8

Remote Control ..... ��10

External Devices ......�.��13

Quick Start ................�.��14

Audio Equalizer .....................�.��17

System Settings ....�.��19

Disc Operation �.��.....��28

AM-FM Radio ......................�.��.��40

USB / microSD card...............�.��........��45

iPod®/ iPhone® Connectivity�.��.��50

AV In1 / AV In2 .....................�.��54

Bluetooth / Hands Free Calling.��.58

Rear Camera .........................�.��66

Steering Wheel Controls (SWC) ..............................�.��67

Pandora® Radio ..........................��.��.68

SiriusXM® Radio .......................�.��.72

Care and Maintenance .......�.��92

Specifications �.��.....��93

Notes �.��...��95

Common Replacement Parts��..Back Cover

HDMI / MHL Connectivity .....�.��55

Troubleshooting ......................�.��.88

Apple CarPlay Operation.........�.��.85

VX7024

FCC Statement

1. This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that

may cause undesired operation.

2. Changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined

by turning the equipment o and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated with

minimum distance of 20 centimeters between the radiator and your body.

•Connect the equipment into an outet on a different from that to which the

receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

VX7024

Thank you for choosing a Jensen product. We hope you will find the instructions

in this owner’s manual clear and easy to follow. If you take a few minutes to look

through it, you’ll learn how to use all the features of your new Jensen VX7024

Multimedia Receiver for maximum enjoyment. Please save this manual for future

reference.

We recommend having your Jensen VX7024 Multimedia Receiver installed by a

reputable installation shop.

FEATURES

DVD

• Audio Equalizer

• Next Chapter and Previous Chapter

• Play/Pause

• Track Direct Entry

• Disc Menu

• Selection Repeat / Track Repeat

• Disc Audio

• Disc Language

• Picture Adjustment

CD / MP3 / WMA

• CD-Text Compatible

• ID3 Tag Compatible

• MP3 and WMA Files on a DVD+R / RW

• Random, Repeat and Intro

• Play, Pause, Stop, Next Track and Previous Track

iPod®/iPhone®

• iPod®/ iPhone® via USB

• High Speed Direct Connect Interface to Access iPhone® and iPod® Playlists,

Artists, Albums

• Power Management Charges iPhone® / iPod® while Connected

AM-FM Tuner

• Region Support: USA, Asia, Japan, Europe, Europe LW (Long Wave), Oirt

and Brazil

• RBDS w/ Clock Time, Radio Text (RT), Program Service (PS) and Program

Type (PTY)

• 30 Station Presets (18 FM / 12 AM)

• Auto Stereo / Mono

• Local / Distance

• Autostore

VX7024

SiriusXM Ready®

• Satellite Channel Name, Artist, Song, and Categories Displayed on Monitor

(Vehicle Tuner and Subscription required and sold separately)

Chassis

• 2.0 DIN (Import / ISO-DIN Mountable)

• Fixed Front Panel

• 6.2” High Definition TFT LCD

• 800h x 480w x RGB WVGA

General

Rear Camera

• The VX7024 is “camera ready.” Before accessing any camera features, you must.

purchase and install a rear video camera.

Built-In Navigation

• iGo Primo Next Gen Navigation Engine

• USA Map Data (Tele Atlas)

• >10 Million Points of Interest

• 4GB SD Card w/ Navigation Software

• Latest Map Guarantee (Must be redeemed within 30 days of initial activation)

• 13 Natural Voice Languages for Navigation Guidance

• TTS (Text to Speech) Voice Guidance - Street Names Pronounced

• Beep Tone Confirmation (ON-OFF Option)

• Bluetooth Hands-Free operation for safety and convenience and A2DP for

streaming music from your smartphone.

• One Composite Video Output for Additional Screens

• Front Panel Audio/Video Input

• Front Panel USB - Playback Music / Video Files via Portable Hard Drives / USB

flash drives; Rear USB (for charging only)

•10 Band Graphic Equalizer

• 6VRMS Front / Rear / Subwoofer RCA Line Output

• Rear Camera Input

•Touch Screen Calibration Mode

• Rotary Encoder Audio Control

• Screen Mirroring - See and control smartphone apps on the larger TFT screen.

*Some apps may not be supported.

• USB Charging Current - 2.1 Amp Support

VX7024

WARNING! To reduce the risk of a traffic accident (except when using for

rear view video camera) never use the video display function while driving

the vehicle. This is a violation of federal law.

WARNING! Never disassemble or adjust the unit.

WARNING! To prevent injury from shock or fire, never expose this unit to

moisture or water.

WARNING! Never use irregular discs.

WARNING! Using an improper fuse may cause damage to the unit and

result in fire.

CarPlay

Smart interface that uses SIri to enable hands-free control of music, navigation,

phone and messaging apps.

•Make phone calls and check voicemail

•Send, read and reply to text messages

•Access music by artist, song, playlist and more

•Search by address or point of interest, or request turn-by-turn directions

VX7024

CONTROLS AND INDICATORS

OPEN

VX7024 Controls and Indicators

1. Disc Slot:

Accepts DVD/CD/MP3 discs. If the unit is turned on, playback begins when a

disc is inserted.

2. LCD Screen and Touch Screen:

Touch icons on this screen to access menus or control functions.

3. Remote Sensor:

Used to receive command signals from the remote control.

4. 3�5mm AV IN Jack:

This connector accepts a 3.5 mm jack through which signals from various

audio/video devices can be applied to the unit.

5. microSD Card Slot:

Used to insert microSD cards containing navigation software. Do not delete

or modify SD card contents.

Push to Talk:

Press this button to access Siri or Google Voice through the head unit when

connected via BT. You mobile phone must support Siri or Google Voice in

order for this feature to be supported on the head unit.

NOTE:

Samsung "S" Voice and other third-party apps may not be supported.

VX7024

6. USB Slot:

Used to connect an iPhone/iPod®, MP3 player or USB flash drive for playback

of music/video files.

7. Interface Cover:

Covers the 3.5mm AV In, microSD card and USB slot.

8. Reset Button:

Press this button to reset the system settings (except password and parental

lock settings) and to correct a system halt or other illegal operation. Use the

tip of a pen to press the Reset button.

9. Power On/Off ( ) Button / Rotary Volume ( ) Knob / Mute Button

Press to turn the unit ON. Press and hold to turn the unit OFF.

Rotate the knob to adjust the volume.

Press the knob momentarily to mute the audio. Press the knob again to

restore the audio.

10.

11. Eject ( ) Button:

Press this button to eject a DVD/CD/MP3 disc. Disc play is stopped, the disc is

ejected and the unit will change to radio operation. If the disc is not removed

from the unit and the button is pressed again, the disc will be re-loaded. If the

disc is not removed from the disc slot within 10 seconds of being ejected, it

will be automatically reloaded to prevent it from being accidentally damaged.

VX7024

NOTES ON REMOTE CONTROL USAGE

• Aim the remote control at the TFT/screen.

•Remove the battery from the remote control or insert a battery insulator if the

remote control will not be used for a month or longer.

•DO NOT store the remote control in direct sunlight or in a high temperature

environment, or it may not function properly.

•The battery will last for 6 months under normal conditions. If the remote

control does not work, please change the battery.

• Use lithium battery type CR2025 (3V) only.

• DO NOT recharge, disassemble, heat or expose the battery to fire.

• Insert the battery in the proper direction according to the ( + ) and ( - ) polarity

marks.

• Store the battery in a place where children cannot reach it to avoid the risk of

an accident.

Autres manuels pour VX7024

Table des matières

Autres manuels Jensen Récepteur de voiture

Jensen

Jensen AWM975 Manuel utilisateur

Jensen

Jensen CD3610XM Manuel utilisateur

Jensen

Jensen JHD3630BT Manuel utilisateur

Jensen

Jensen JHD3510 - Heavy Duty CD Receiver Manuel utilisateur

Jensen

Jensen CH4001 - 160 Watt AM/FM Stereo Mode d'emploi

Jensen

Jensen VM9022 - DVD Player With LCD Monitor Manuel utilisateur

Jensen

Jensen VM9411 Manuel utilisateur

Jensen

Jensen VM8013HD - Screen MultiMedia Receiver Manuel utilisateur

Jensen

Jensen VX6020 Manuel utilisateur

Jensen

Jensen CD315X Mode d’emploi

Jensen

Jensen VX4014 Manuel utilisateur

Jensen

Jensen VM9512 - Motorized Touch-Screen Multimedia... Manuel utilisateur

Jensen

Jensen AWM960 Manuel utilisateur

Jensen

Jensen JCD2006 Manuel utilisateur

Jensen

Jensen Receiver CD2610 Manuel utilisateur

Jensen

Jensen DV2011 Manuel utilisateur

Jensen

Jensen VM9313 Manuel utilisateur

Jensen

Jensen VM9223 - Touch Screen Double Din MultiMedia... Manuel utilisateur

Jensen

Jensen CM720K Mode d’emploi

Jensen

Jensen VM9126 Manuel utilisateur

Jensen

Jensen VM9311TS - DVD Player With LCD Monitor Manuel utilisateur

Jensen

Jensen VM9312HD - DVD Player With LCD Monitor Manuel utilisateur

Jensen

Jensen Phase Linear CD1213 Manuel utilisateur

Jensen

Jensen VM8022 - DVD Player With LCD Manuel utilisateur

Manuels Récepteur de voiture populaires d'autres marques

Motorola

Motorola VWA63 Manuel utilisateur

Nextar

Nextar D3201 Manuel utilisateur

Alpine

Alpine CDE-163BT Manuel utilisateur

Pioneer

Pioneer DEH-P645R Manuel utilisateur

Axxera

Axxera XDMA7600 Mode d'emploi

XM OnyX Manuel utilisateur

Sound Storm

Sound Storm STM93R Manuel utilisateur

Soundstream

Soundstream VIR-5000 Manuel utilisateur

Avson

Avson MKT Platform Manuel utilisateur

Sony

Sony MEX-1HD - Audio Library System Manuel utilisateur

Pioneer

Pioneer DVH-P500UB Manuel utilisateur

JVC

JVC KD-AHD69 Manuel utilisateur

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manuel utilisateur

Sony

Sony CDX-4160 - Cd Receiver Manuel utilisateur

XFIRE AUDIO

XFIRE AUDIO BMW42S Manuel utilisateur

VDO

VDO CD 2253 Manuel utilisateur

Volvo

Volvo 13 84 580 Manuel utilisateur

ZENEC

ZENEC ZE-160DVD Manuel utilisateur
