1
Compact Excavators
8008 CTS, 8010 CTS
Quick Start Guide
2Please see operator manual for full details.
>
This Quick Reference Guide is to provide quick and simple information to the Operator
and does not include any health and safety aspects. In addition, because of our continual
development of machines, features described in this Quick Reference Guide may differ
from those on your machine. No errors and emissions be entirely ruled out.
>
This Quick Reference Guide DOES NOT replace the Operators Manual. You MUST
read ALL the disclaimers and safety and other instructions in the Operators Manual
before initially operating this product. Accordingly, no legal claims can be entertained on
the basis of the data, illustrations or descriptions in this Quick Reference Guide.
>
This machine should not be operated by any person who isn’t appropriately qualified or
had the appropriate training.
>
Operation of this machine without periodic maintenance could cause it to malfunction.
For more information please contact your JCB Dealer.
Disclaimer
8008 CTS, 8010 CTS 3
Intended Use ......................................................................................................................................4
Dimensions ........................................................................................................................................5
Tie Down Points ................................................................................................................................6
Lifting Points .......................................................................................................................................7
Cab Layout & Controls ................................................................................................................. 8 -11
Start Up Sequence ...........................................................................................................................12
Shut Down Sequence .......................................................................................................................13
Mechanical Hitch Unlock ..................................................................................................................14
Maintenance Position ........................................................................................................................15
Service & Maintenance .....................................................................................................................16
Service & Access Covers...................................................................................................................17
Service / Maintenance Points ............................................................................................................18
Fluids & Lubricants ............................................................................................................................19
Machine Attachments .......................................................................................................................20
Troubleshooting / FAQs ....................................................................................................................21
Your Notes ................................................................................................................................. 22-23
Index
4Please see operator manual for full details.
General
> Machine Type – Compact Excavator
> Self propelled machine with a tracked undercarriage
> 360° revolving upper structure with boom, dipper, bucket and slew mechanism
Intended Use
> Machine intended to be used in normal conditions as detailed in the operators manual
> With bucket fitted, machine work cycle consists of digging, elevating, slewing and discharging
of materials
> Applications include earthmoving, road construction, building and construction, landscaping etc.
> Can be used for object handling
> Not intended for use in mining and quarrying applications, demolition, forestry, any use
underground and any explosive atmospheres.
> Must not be used for forestry, used with attachments of unknown weight, used on surfaces with
unknown stability – list not exhaustive
>
PPE may be required in certain applications/environments e.g. high silica concentration or asbestos
> TThe machine should not be operated by any person without appropriate qualifications, training
or experience of using this type of machine
> Prior to use, the machines suitability should be considered with regards to the intended
applications and any hazards which may be present
Intended Use
8008 CTS, 8010 CTS 5
Dimensions
Machine model 8008 CTS 8010 CTS
Dipper –800mm 950mm
A Overall height (transport position) mm 2310 2295 2295
B Overall length (transport position) mm 2682 2957 3000
CTailswing mm 800 900 900
D Track width - extended mm 865 1000 1000
D Track width - retracted mm 700 700 700
E Superstructure width mm 865 930 930
F Sprocket idle centres mm 1440 1597 1707
Operating weight* kg 950 1110 1110 *
Transport weight kg 875 1028 1028*
* Operating weight to ISO 6016 including cab, rubber tracks, standard dipper, standard dozer, (460 mm) bucket,
full tanks and 75 kg operator. Please see data plate for specific machine weight
Fig 1
6Please see operator manual for full details.
Tie Down Points
Fig 2
REFER TO OPERATORS MANUAL TRANSPORTING MACHINE
1. Machines fitted with mechanical slew lock, engage slew lock. Ensure by operating the slew control
that the slew lock is engaged.
2. Close the bucket. Position the dipper vertically and lower the boom until the bucket rests on a
wooden block on the trailer bed.
3. Position a wire rope A of suitable breaking strain over the bucket and secure to the trailer shackles.
4. Place skids B under each track at front and rear to prevent movement of the machine in the fore
and aft direction.
5. Use nylon straps C of suitable breaking strain around each track at front and rear and secure to the
trailer shackles to prevent lateral movement of the machine.
6. Attach wire ropes D of suitable breaking strain to the kingpost and secure to the trailer shackles to
prevent the superstructure from slewing.
8008 CTS, 8010 CTS 7
REFER TO OPERATORS MANUAL TRANSPORTING MACHINE
Lifting Points
Fig 3
The correct lifting positions are identified on the machine by their labels: Lifting point
position label.
Carry out the following procedure when lifting a machine:
1. Remove all attachments.
2. Remove all loose equipment from machine exterior.
3. Check the unladen weight of the machine.
4. Attach lifting equipment to each end of the dozer blade.
5. Attach lifting equipment to each side of the boom.
6. Take the weight of the machine.
7. Check that the lifting eye is positioned directly above the machine centre of gravity.
Lifting points have been provided on the
machine as follows:
1. On each end of the dozer blade at point A.
2. On each side of the boom at points B.
8Please see operator manual for full details.
Cab & Switch Panel
A Graphic symbol
B Light bar
The rocker switches have two or three positions (as shown)
Fig 5
Fig 4
1 Track controls
2 Hand throttle lever
3 Console switches
4 Starter switch
5 Instrument panel
6 Excavator controls
7 Dozer control
8 Extending undercarriage control
9 Excavator lever lock
Operator Station Layout
Switch Panel
Work Lights
1 Off
2 Work light on
Horn
1 Off
3 On
Fig 6
8008 CTS, 8010 CTS 9
Instrument Panel
A Hourmeter
B Charge (fault) indicator
C Glow plugs (on) indicator
D Low fuel indicator
E Engine oil pressure (low) indicator
F Coolant temperature (high) indicator
Fig 7
Instrument Panel
10 Please see operator manual for full details.
Excavator Controls
A Slew cab left
B Slew cab right
C Raise boom
D Lower boom
E Dipper in
F Dipper out
G Close bucket (to gather a load)
H Open bucket (to dump a load)
WARNING: The swing and auxiliary pedals must be in their folded positions when not in use.
A Swing left
B Swing right
C Swing pedal (fold down into operating position)
Fig 8
Fig 9 Fig 10
Excavator Levers
Swing Pedal
