JBL Harman TUNER2 Manuel utilisateur

WHAT’S IN THE BOX

quick

START

GUIDE

Connections

TUNER2

Radio Tuning

Radio Preset

BUTTONS

30 mins

0 m

IPX7

WATERPROOF

IPX7

Bluetooth

Language setting

Connected

37%

DAB

Some radio stations may have noise interference when listening to radio while charging.

English

Set default language for the first time or after factory reset (press + >10 seconds)

lish

When DAB mode is activated for the first time, a full scan will automatically start.

You can save a maximum of 5 preset radio stations.

Radio Auto Scanning

DAB

>2S

Settings Bluetooth

Bluetooth

DEVICES

JBL Tuner 2

Now Discoverable

Connected

• In FM mode, JBL Tuner 2 will automatically search for and tune to an available radio station.

• In DAB mode, JBL Tuner 2 scans all available DAB radio stations and play the first available radio station.

Radio Preset

Auto ScanTune Down Tune Up

Bluetooth

Power On/Off

DAB/FM Selection

BBC Radio 1

DAB

BBC Radio 1

DAB

P1 Saved

DAB

TECH SPEC

Transducer: 1 x 1.75”

Rated output power: 5 W RMS

Frequency response: 80 Hz - 20 kHz (-6 dB)

Signal-to-noise ratio: > 80 dB

Battery type: Lithium-ion polymer 9.075 Wh

Battery charge time: 3.5 hours (5V / 0.9 A)

Charging Input: 5 V, 1.2 A

Music playing time: up to 12 hours for radio listening

(dependent on volume level and audio

content)

Bluetooth® version: 4.2

Bluetooth® proﬁle: A2DP V1.2, AVRCP V1.5

Bluetooth® transmitter frequency range: 2.402 - 2.480 GHz

Bluetooth® transmitter power: 0 - 9 dBm (EIRP)

Bluetooth® transmitter modulation: GFSK, π/4 DQPSK, 8DPSK

DAB Tuning range: 174.928 MHz - 239.200 MHz (Band-III)

FM Tuning range: 76 MHz - 108 MHz (varies by countries)

Dimensions (W x H x D):

180 x 70 x 72 (mm) / 7.08”x 2.76”x 2.83”

Weight: 0.54 kg (1.20 lbs)

SA_JBL_Tuner 2_QSG_Global_SOP_V10.indd 1 2020/3/3 10:26:48
