Twist the top part of the enclosure in a

clock-wise direction until it disengages

from the bottom part.

Lift o the top section.

Control 85M/88M Mushroom Landscape Speaker

Installation Instructions

Before nal assembly and installation of the Landsape speaker, it is important to prepare the installation site. The speaker is

designed to be able to sit below grade, with the lower half burried in the soil no deeper than the boundary point where the

two parts of the speaker meet. Another installation method is to place the speaker on the surface and use ground cover

materials to“berm up”to the boundary between the two sections, being careful not to cover the ared waveguide in the upper

half of the speaker, or the speaker can be installed on the top surface of wooden decks or cement slabs. There are three

recessed pathways on the bottom of the speaker to allow for entrance and exit when using mutiple speakers on distributed

lines.

Anchoring the speaker for stability and security can be accomplished using after-market stakes placed through one, two or all

three pre-drilled holes located at the base of each of the legs on the bottom section.

The second gland nut can be installed by drilling a 22 mm

(7/8 in, 0.875 in) hole on the side of the bottom half of the

enclosure, in one of three recesses on the underside of the

enclosure, or other locations as needed, while taking care

that the location chosen does not interfere with the

locking parts so both halfs of the enclosure will mate and

close properly.

Attach one of the two included Gland Nuts into the open

hole on the seal plate as shown above.

Install the gland nut into the hole as shown

above in #6 and feed external wire from

outside through the gland nut and up through

the center hole in the lower half of the speaker

as shown above.

Close-up view of tap setting for the Control 85M and

Control 88M. **Adjusting tap setting required before

powering up system.

88M

85M

Continue to extend external wire up through the gland

nut installed on the seal plate and attach to pre-existing

wires from the top section of the speaker with included

gel-lled wire nuts.

** To achieve a watertight

seal with these gland nuts,

use only round jacketed

cable with outside diameter

(O.D.) between 4.0mm (0.16”)

and 9.0 mm (0.36”).

IMPORTANT: WIRE SIZE

When all wires are set into place as shown in #9, tighten

down both gland nuts by rotating the larger side until

the gland material clamps down on the wire creating a

water tight seal.

Line up the upper section pins and lower section

grooves.

Begin to re-assemble speaker by taking care to place wire nut

connectors in top section of speaker and reattach the seal

plate with screws as shown above.

Rotate top section counter-clockwise to lock the

top to the bottom section, being careful to line up

the security screw hole with brass nut on the

bottom half of the speaker.

Using included security screwdriver, and making sure you

have lined up the security screw with brass nut, turn clock-

wise so screw will lock top and bottom section together.

10 11

12 13

Replace cap covering set screw.

JBL Professional

8500 Balboa Blvd

Northridge, CA 91329

USA

IS-C80MLS

REV A 03/2016

** INCLUDED PARTS IN CARTON

(1) Round Seal Plate (green)

(4) Set Screws (for green seal plate)

(2) Gland Nuts

(2) Gel-Filled Wire Nuts

(1) Security Screw (M4 x 0.7 x 14 mm)

(1) Security Screw Cover

(1) Security Screwdriver
