JBL P963 Manuel utilisateur
•The new Power Series®line features
all-new textile-dome tweeters with soft
roll-off at 23kHz. The woofer performance
has been optimized for low-frequency
extension and minimum distortion.
MORE SPL
• In addition to better sound quality,
the new woofer design offers
far higher SPL and better suspension
symmetry than the previous generation.
HIGHER EFFICIENCY
• Like our GTO models, these speakers
feature reduced impedance of 2 ohms for
increased efficiency, while maintaining
full compatibility with 4-ohm amplifier
output stages, as on standard head units.
TWEETER-LEVEL CONTROL
• Most models feature a switch to
reduce the tweeter output level to
match personal listening preference,
or different mounting locations (not
available on the P462).
UNIPIVOT™(patent no. 6,002,780)
ROTATING TWEETER
•5-1/4" and 6-1/2" coaxial models
feature a tweeter that is mounted
on a 15-degree angle and can be
rotated nearly 360 degrees to point
at the listening position for better
high-frequency response.
OUTBOARD CROSSOVER
NETWORKS
•All Power Series speakers come with
external crossovers. The component
system networks feature in-line
polypropylene caps and low-insertion-
loss air-core inductors. The outboard
crossovers are integrated into a harness
connected to each speaker model for
easy installation. Oversized Direct-
Connect terminals ensure perfect
connectivity for bare speaker wires.
PLUS ONE®HONEYCOMB-
LAMINATE (HCL
™)
WOOFER CONES
•This material combines extreme
stiffness with low weight to optimize
efficiency and cone distortion.
THE LATEST JBL®POWER SERIES®
SPEAKER LINE
SPECS
POWER SERIES®
P462 P6462 P562 P662 P662S P8662 P963 P560C P660C P26t
Configuration: 2-Way 2-Way 2-Way 2-Way 2-Way 2-Way 3-Way 2-Way 2-Way 1" Edge-Driven-
Plate Component Component Dome Tweeter
System System
Size: 4" 4" x 6" 5-1/4" 6-1/2" 6-1/2" 5" x 7"/6" x 8" 6" x 9" 5-1/4" 6-1/2" 1"
Power Handling, 50W 50W 55W 75W 55W 75W 110W 75W 90W 60W
RMS:
Power Handling, 150W 150W 165W 225W 165W 225W 330W 225W 270W 180W
Peak:
Nominal 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms
Impedance:
UniPivot™Rotating No No Yes Yes No Yes No No No No
Tweeter:
I-Mount™*N/A N/A N/A N/A N/A N/A N/A Yes Yes Yes
tweeter mounting
system
Tweeter-Level No Yes Yes Yes Yes Yes Yes No No No
Control (0/–3dB):
Tweeter-Level No No No No No No No Yes Yes Yes
Control (0/–6dB):
Tweeter No No No No No Yes Yes Yes Yes Yes
Protection (PTC):
Sensitivity 91dB 91dB 92dB 93dB 93dB 92dB 96dB 92dB 94dB 94dB
(2.83V @ 1m):
Frequency 75Hz – 23kHz 75Hz – 23kHz 55Hz – 23kHz 45Hz – 23kHz 55Hz – 23kHz 40Hz – 23kHz 35Hz – 23kHz 55Hz – 23kHz 45Hz – 23kHz 2.5kHz – 23kHz
Response:
Mounting Depth: 1-7/8" 1-15/16" 2-1/16" 2-1/4" 1-15/16" 2-5/16" 3-1/4" 2-1/16" (woofer) 2-1/4" (woofer) 11/16"
*patent no. 5,859,917
Features, specifications and appearance are subject to change
without notice.
JBL, Power Series and Plus One (patent pending) are registered
trademarks, and UniPivot and I-Mount are trademarks, of
Harman International Industries, Incorporated.
Designed, edited and digitally produced by the
Harman Consumer Group Marketing & Design Center, Woodbury, NY.
© 2008 Harman International Industries, Incorporated.
All rights reserved.
Part No. JBLPSPISHEET 1/08 Printed in USA 1/08
Harman Consumer Group, Inc.
250 Crossways Park Drive
Woodbury, NY 11797
516.255.4JBL (4525) Fax: 516.682.3556
www.jbl.com
