BPX1100.1

2 CHANNEL

POWER AMPLIFIER

SERVICE MANUAL

JBL Consumer Products

250 Crossways Park Dr.

Woodbury, New York 11797 Rev1 2/2004

CONTENTS

Specifications………………………….…………………..……1

Features…………………………………………………………2

Test Conditions And Notes……………………………………2

Controls/connections…………………………………..………3

Mounting…………………………………………….…..………3

Applications………………………………………..……………4

Typical System Configuration…………………………………5

Troubleshooting……………………………………….……..…6

PCB drawings……………………………………..……………7

Electrical Parts List……………………………………………10

Mechanical Parts List……………….………………..………13

Block Diagrams……………………………………….………14

Semiconductor Pinouts………………………………………15

Exploded view…………………………………………………20

Schematics……………………………………………….……21

Packing………………………………….………………………30

SPECIFICATIONS

Power Output, 4 Ohms: n/a

Power Output, 2 Ohms: 575W x 2

Power Output, Bridged, 4 Ohms: 1100W x 1

Power Output, Parallel, 1 Ohm: 1100W x 1

MIN. Speaker Impedance: 1 ohm

Frequency Response: 20Hz~320Hz, -3dB

Input Sensitivity (RCA type): 250mV~6V

THD + Noise (4 Ohms): 0.5%

Signal-to-Noise: 93 dB

Maximum Current Draw: 110A

Fuse Replacement: 30Ax3

External Dimensions:

Length 12 ¼” (312mm)

Width 17” (432mm)

Depth 2 9/16” (66mm)

JBL continually strives to improve its products. New materials, production methods and design refinements are introduced into existing

models without notice as a routine expression of our design philosophy. For this reason, Power Series Multichannel Automotive

Amplifiers may differ in some respects from their published specifications and descriptions, but will always equal or exceed the original

specifications unless otherwise stated.

Power Amplifier

BPX1100.1

Test Conditions and Notes

2-Channel Operation

Advanced MOSFET Oversized Floating Rail Power Supply

Floating Ground Factory - Head - Unit Speaker - Level input

Variable Input Sensitivity (250mV - 6V)

Fully Complementary Output Stage with Class-D Voltage Amplification

Gold-plated Power, Input and Output Connectors

1-Ohm Stable ( 2 ohm parallel )

All tests to be done, unless otherwise specified, from 20Hz to 320Hz at 14.4V DC into 2 ohm loads and adjust

the units gain so that with a .775 volt input signal the unit is at its maximum rated output. All measurements

will be done using an Audio precision system one and the supply voltage.

An A+ line voltage of 14.4V DC shall be applied to the unit under test for all measurements unless otherwise

specified. The voltage applied to the unit shall be measured at the power connection on the Amplifier.

Signal Source

Unless otherwise specified, all tests shall be conducted with the Audio Signal Generator output configured to

be balanced, less than or equal to 50 ohm source impedance, and floating. The signal source "GND" shall be

connected to the Amplifier PWR GND at the Amplifier.

Output Load

Unless otherwise specified, all tests shall be conducted with 2 ohm resistive loads having less than 10%

reactive components at any frequency below 350Hz. Each resistor shall have a value that remains within 1%

while dissipating the rated output of the unit under test.

Power Indicator LED steadily illuminates for normal operation. LED blinks when

protection circuitry is engaged, and during power up.

Features

BPX1100.1

Power Amplifier

Controls and Connections

Mounting the Amplifier

The JBL BP Series amplifiers can be mounted in virtually any location inside the vehicle.

However, make sure to keep the amplifier away from heater vents or ducts.

1. At the chosen site, use the amplifier as a mounting template and mark the locations of the

four mounting holes.

2. Drill a small pilot hole at each marked location.

3. Mount the amplifier and securely tighten the mounting screws.

BPX1100.1

Power Amplifier

Controls and Connections

4. Preamp-Level Input Connector - Connects to

5. Pre amp-Level AUX output Connector

line-level output from the source unit.

3. Speaker Output Connector - Connect speaker

wiring to these connectors. See wiring instruc-

tions on page 4 for more information.

2. Fuse - Three 30 Amp ATC type Fuses.

1. Power Connection for 12V+, GND and REM

connections for power wires. See wiring instruc-

tions on page 4 for more information.

6. Input-Level Control - Adjusts input sensitivity

7. This switch is select X-over slope

for pre-amp level and speaker level inputs.

10. The crossover frequency can be set at any frequency

11. (1) The HP frequency can be set at any frequency

(2) Bass Boost control will provide at frequency

Between 32Hz and 320Hz.

Between 20Hz and 100Hz.

Being set between 20Hz ~ 100Hz

8. This switch is set to 2-channel mode(2CH/BR) to drive

a pair of subwoofers or bridge(mono) mode to drive a

single subwoofer(PARALLEL).

It's allowed to use parallel mode when the nominal

impedance of the speaker system is 2 ohm or greater

1 2 3

4 56

1011

Remotr Volume Control Jack.

APPLICATIONS – BPx MODELS

To the right are several application

diagrams to help plan your subwoofer

system installation. Figures 1 through 3

show how to configure the JBL Power

Series subwoofer amplifiers (models

BPx500.1, BPx1100.1 and BPx2200.1)

for 2-channel, bridged-mono and

parallel-mono operation

“Setting the Output Mode” on page 6).

NOTE: For simplicity, Figures 1 through

3 do not show power, remote and input

connections.

NOTE: If the nominal impedance

of your speaker system is close to

2 ohms, be prepared to try both

bridged and parallel configurations to

determine which performs better.

BPx Amplifier

(partial rear panel)

SEE MANUAL FOR PARALLEL CONNECTION

2 CHANNEL

BRIDGED

PARALLEL

CH 1

CH 2

SPEAKER OUTPUTS

NEON

Subwoofer Subwoofer

Set OUTPUT MODE

to 2CH/BR

(on input panel)

PARALLEL 2CH/BR

OUTPUT MODE

12dB 24dB

32Hz 320Hz

FREQ

SLOPE

X-OVER

BPx Amplifier

(partial rear panel)

SEE MANUAL FOR PARALLEL CONNECTION

2 CHANNEL

BRIDGED

PARALLEL

CH 1

CH 2

SPEAKER OUTPUTS

NEON

Subwoofer (less than 2 ohms)

Set OUTPUT MODE

to PARALLEL

(on input panel)

PARALLEL 2CH/BR

OUTPUT MODE

12dB 24dB

32Hz 320Hz

FREQ

SLOPE

X-OVER

jumper

Figure 1. The JBL Power Series

subwoofer amplifier is set to

2-channel mode to drive a pair

of subwoofers.

Figure 2. The JBL Power Series

subwoofer amplifier is set to

bridged (mono) mode to drive

a single subwoofer. Use this

mode only when the nominal

impedance of the speaker

system is 2 ohms or greater.

Figure 3. The JBL Power Series

subwoofer amplifier is set to

parallel mode to drive a single

subwoofer. Use this mode only

when the nominal impedance

of the speaker system is less

than 2 ohms.

NOTE: A jumper is added

between the + terminals.

BPx Amplifier

(partial rear panel)

SEE MANUAL FOR PARALLEL CONNECTION

2 CHANNEL

BRIDGED

PARALLEL

CH 1

CH 2

SPEAKER OUTPUTS

NEON

Subwoofer (2 ohms or greater)

Set OUTPUT MODE

to 2CH/BR

(on input panel)

PARALLEL 2CH/BR

OUTPUT MODE

12dB 24dB

32Hz 320Hz

FREQ

SLOPE

X-OVER

Power Series Amp OM 5/20/03 10:51 AM Page 3

Power Amplifier

BPX1100.1

Typical System Configuration

Vehicle Battery

Chassis Ground

Ignition

Switch

CD Player or Changer

Cassette/CD Tuner

(Head Unit)

Power Ground

Speakers

60 Amp (Not Included) Main +12V

Amplifier

Power

Connection

Line

Level

Input

Remote On/Off

Remote Antenna

Power Supply

Antenna Motor Ground

Remote On/Off

Black - Power Ground

Red - Main +12V

Black Power

Antenna Input

Power

Antenna

Cassette/Receiver

Power Supply

Wires

Fuse

Power

Antenna

Relay

BPX1100.1

Power Amplifier

TROUBLESHOOTING

SYMPTOM LIKELY CAUSE SOLUTION

No audio No voltage at BATT+ Check voltages at

(POWER LED or REM terminals, amplifier terminals

is off) or bad or no ground with VOM

connection

No audio DC voltage on Amplifier may need

(PROTECT LED amplifier output service; see enclosed

flashes every warranty card for

4 sec.) service information

No audio Amplifier is Make sure amplifier

(PROTECT overheated cooling is not blocked

LED is on) at mounting location;

verify speaker-system

impedance is within

specified limits (see

“Specifications” on the

next page)

No audio Voltage less than 9V on Check vehicle

(PROTECT BATT+ connection charging system for

and POWER defective voltage

LEDs flash) regulator

I-E/OPT LED Amplifier is being Check INPUT

is on all times overdriven LEVEL setting;

(not flashing) see previous page

No audio Voltage more than 16V Check vehicle

(PROTECT or less than 8.5V on charging system for

LED is on) BATT+ connection defective voltage

regulator

Distorted audio Input sensitivity is Check INPUT

not set properly, or LEVEL setting; or

amplifier or source check speaker wires

unit is defective for shorts or grounds

Distorted audio Short circuit in Remove speaker leads

and PROTECT speaker or wire one at a time to locate

LED flashes shorted speaker or

wire, then repair

Music lacks Speakers are not Check speaker

“punch” connected properly connections for

proper polarity

Power Amplifier

BPX1100.1

Printed Circuit Board (Top View)

BPX1100.1

Power Amplifier

Printed Circuit Board (BOTTOM View)

BPX1100.1

Power Amplifier

Printed Circuit Board (SUB TOP View)

BPX1100.1

Power Amplifier

PAS132-01

REV.0

A20K

623PCB4-B

A20K

623PCB4-B

A20K

623PCB4-B

A20K

623PCB4-B 623PCB4-B

A20K

623PCB4-B

A20K

623PCB4-B 623PCB4-B

A20K A20K

623PCB4-B 623PCB4-B

A20K

VR701

R701

MOD02

VR701

R701

MOD02

VR701

R701

MOD02

VR701

R701

MOD02 MOD02

R701

VR701

R701

MOD02

VR701

R701

MOD02 MOD02

R701

VR701

R701

MOD02 MOD02

R701

VR701

Autres manuels pour BPx1100.1

Table des matières

Autres manuels JBL Amplificateur

JBL

JBL Grand Touring Series GTO14001 Manuel utilisateur

JBL

JBL MPC Manuel utilisateur

JBL

JBL CSA-2120 Manuel utilisateur

JBL

JBL CS300.1 Manuel utilisateur

JBL

JBL PX600.2 Manuel utilisateur

JBL

JBL VMA160 Manuel utilisateur

JBL

JBL BPx1100.1 Manuel utilisateur

JBL

JBL PA454 Manuel utilisateur

JBL

JBL Synthesis S800 Manuel utilisateur

JBL

JBL CSA-2120 Manuel utilisateur

JBL

JBL DA850 Manuel utilisateur

JBL

JBL Grand Touring Series GTO504 Manuel utilisateur

JBL

JBL Grand Touring Series GTO3501 Manuel utilisateur

JBL

JBL 6230 Manuel utilisateur

JBL

JBL Club Series Manuel utilisateur

JBL

JBL Grand Touring Series GTO3501 Manuel utilisateur

JBL

JBL GT0-804EZ Manuel utilisateur

JBL

JBL 6230 Manuel utilisateur

JBL

JBL BP300.1 Manuel utilisateur

JBL

JBL GTO Series 601.1 Manuel utilisateur

JBL

JBL 6021 Manuel

JBL

JBL SR6615 Manuel utilisateur

JBL

JBL SA550 Classic Manuel utilisateur

JBL

JBL BP600.1 Manuel utilisateur

Manuels Amplificateur populaires d'autres marques

ASTRO

ASTRO HVO V40 P Manuel utilisateur

Marantz

Marantz SUPERSCOPE BLA-545 Instructions de montage

NAD

NAD CI980 Manuel utilisateur

Technics

Technics SE-CH770 Manuel utilisateur

Harman Kardon

Harman Kardon HK6300 Manuel utilisateur

NAD

NAD T975 Manuel utilisateur

McIntosh

McIntosh MA6850 Manuel utilisateur

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Manuel utilisateur

Viatron

Viatron Autrix Manuel utilisateur

GME

GME GA9800 Manuel utilisateur

Atlas

Atlas CP700 Manuel utilisateur

Roland

Roland KC-1000 Manuel utilisateur

Pyle

Pyle PFMRA350BW Manuel utilisateur

Advantage

Advantage S-250 Manuel utilisateur

IRT Electronics

IRT Electronics DVA-3007 Manuel utilisateur

Dimavery

Dimavery BA-100 Series Manuel utilisateur

Sony

Sony XM-S400D Manuel utilisateur

Schertler

Schertler ROY X Manuel utilisateur
