Jay J3 BACK Manuel utilisateur

STEP 1 Cushion Height

STEP 2 Cushion Width & Depth

STEP 3 PLA (Pelvic Loading Area) Size

STEP 4 PLA Insert

STEP 5 Cover Options

STEP 6 Positioning Cushion

OVERVIEW

1

For a custom-ﬁt J3 Cushion, follow this

6-step guide to determine your

J3 Cushion Smart Part Number.

The part number that is generated over

the next several pages is for illustrative purposes.

Actual part numbers may vary.

J3 Cushion

Part

Numbers

begin with

“J3C”

- - - - -

STEP 1 STEP 2 STEP 3 STEP 4 STEP 5

J3C -

STEP 6

1

STEP 1

Cushion Height

S = Standard

x

3.6"

Note: Measurements above can vary depending upon cover selection.

D = Deep

Un-Loaded Femoral Height Loaded Femoral Height

3.0"

Un-Loaded Femoral Height

4.1" 3.5"

Loaded Femoral Height

2

3

Step 1 determines Cushion Height.

How much immersion and envelopment does

the user require? Standard or Deep height?

J3 Cushion

Part

Numbers

begin with

“J3C”

- - - - -

STEP 1 STEP 2 STEP 3 STEP 4 STEP 5

J3C -

STEP 6

S

2

3

STEP 2

Cushion Width

and Depth

12" 14" 15"16" 17" 18"19" 20"21" 22"23" 24"

12"SS

14"S

15"S

16"S

17"S

18"S

19"S

20"S

21"S

22"S

24"

Size Matrix

A

B

(A available)

C

(A&B available)

Std PLA

Special Order

N/A

Standard Size

Av ailable in Std. Ht Only

S

Width

Depth

Cushion Width

Cushion Depth

4

5

Step 2 determines Cushion Width and

Cushion Depth. Available sizes range

from 12" x 12" to 24" x 24".Write in the actual

inch measurements starting with the width.

J3 Part

Numbers

begin with

“J3”

- - -

STEP 1 STEP 2 STEP 3 STEP 4 STEP 5

J3 PL

J3 Cushion

Part

Numbers

begin with

“J3C”

S - - -

STEP 1 STEP 2 STEP 3 STEP 4 STEP 5

J3C -

STEP 6

1816

4

5

STEP 3

PLA (Pelvic Loading

Area) Size

Based upon human anatomy, PLA size has been

designed to optimize trochanteric loading and

stability. Standard PLA sizes shown below, alternate

sizes available on the order form.

Standard on 12" – 15"

widths

x

B

AC

Standard on 16" – 19"

widths

Standard on 20" – 24"

widths

6

7

Step 3 determines PLA size.

Reference page 6 for size and

width guidelines.

J3 Cushion

Part

Numbers

begin with

“J3C”

S - -

STEP 1 STEP 2 STEP 3 STEP 4 STEP 5

J3C -

STEP 6

1816 B

6

7

STEP 4

PLA Insert

Factory Filled PLA Insert

Field Variable PLA Insert

Three ﬂuid chambers to reduce

ﬂuid migration.

x

FF

FV Adjusts to changing user needs

and skeletal deformities.

Air Single PLA Insert

AS Adjustable immersion with stability.

Air Dual PLA Insert

AD Adjustable immersion with stability

and obliquity solution.

8

9
