CA-1802 and CA-1803 Athos

T2711 - Jablotron - Manual Atho1 1T2711 - Jablotron - Manual Atho1 1 8.4.2009 13:26:388.4.2009 13:26:38

Thank you for purchasing our product. May you always ﬁnd your car where you have parked it.

JABLOTRON ALARMS a.s.

CA-1802 and CA-1803 Athos

Contents

1Car alarm control .................................................................................................................................. 3

2Other services ....................................................................................................................................... 6

3Alarm – car intrusion ............................................................................................................................. 7

4Signalling .............................................................................................................................................. 8

5Car location and immobilization ........................................................................................................... 9

6Remote access and service................................................................................................................. 10

7Telephoning using a handsfree set (HF-03) ........................................................................................ 11

8Other functions .................................................................................................................................... 11

T2711 - Jablotron - Manual Atho2 2T2711 - Jablotron - Manual Atho2 2 8.4.2009 13:27:118.4.2009 13:27:11

1Car alarm control

1) By remote-control

Depending on the installation, the car alarm can either be controlled with an RC-8x car alarm controller,

see paragraph a), or with an original remote control used for locking the car, see paragraph b). Please fol-

low the article which corresponds to the type of installation in your car.

a) By RC-8x car alarm controller

Setting: The car alarm is set by pressing a button on the remote control. If a central

locking system is installed, the car is concurrently locked.

Partial setting: When the remote control button is pressed repeatedly (within 15 seconds

of alarm setting), partial setting takes place (conﬁrmed by an acoustic signal).

The inside of the car is not guarded by wireless internal detectors and so

neither a voltage drop detector nor any supplementary detectors are activated.

Unsetting the car alarm: The car alarm is unset by pressing a remote control button . If the car is

equipped with a central locking system, it is concurrently unlocked.

The buttons on the right side of the controller can also be used (programmed) for different functions – e.g.

the remote control of garage doors, gates, light in the garage or house, etc. More information is available

from the installer or from the manufacturer.

b) By the original car remote control

Setting: When the car is locked with its remote control, the car alarm is set

concurrently.

T2711 - Jablotron - Manual Atho3 3T2711 - Jablotron - Manual Atho3 3 8.4.2009 13:27:118.4.2009 13:27:11

Partial setting: When you dial the car alarm number from an authorized phone (see the next

paragraph), the car alarm switches to partially set mode 3). The inside of the

car is not guarded by wireless internal detectors and so neither a voltage drop

detector, nor any supplementary detectors are activated in this mode.

Unsetting the car alarm: Unlocking the car with its remote control also unsets the car alarm.

2) Remote control via your telephone

With the SMS commands: Set / unset / check vehicle status – car alarm functions can be controlled via

a mobile phone. The car alarm is able to send alarm messages and dial up to

4 telephone numbers (hereinafter “the authorized phone“) when an alarm is

triggered. The authorized phone can be used to send commands by means of

SMS messages to the alarm phone number (see the table on the following page).

By dialling in from authorized phone numbers 3):

If the car alarm is controlled with RC-8x controllers, you just need to dial the

car alarm number (the ignition key must be switched off). The car alarm will

not answer the call (i.e. the call is not charged for) and its status will change

(set – unset – set...). If the car alarm is controlled with an original remote

control, dialling in will activate partial setting only (see paragraph 1b).

The car alarm may conﬁrm the change of status with an SMS message 3).

If you forget the wording of SMS message commands, you can ask the alarm unit for “help” by sending

the HELP command.

T2711 - Jablotron - Manual Atho4 4T2711 - Jablotron - Manual Atho4 4 8.4.2009 13:27:118.4.2009 13:27:11

SMS car alarm commands

SMS command Alarm action

AM Set the alarm (and lock the vehicle if operated according to paragraph 1.a)

AM EXT Partially set the alarm (and lock the vehicle if the RC-80 remote control is used)

DM Unset the alarm (and unlock the vehicle if operated according to paragraph 1.a)

IMO Block (immobilize) the car

UNIMO Unblock (mobilize) the car

STATUS Send an SMS about the current status of the car alarm

GPS Send the last known GPS position

LOCATOR Send an SMS with the approximate position of the car 2) 3)

HELP Send an SMS with help

SIREN Triggers on a siren for 30 seconds

CREDIT Check the amount of credit (when using a pre-paid SIM card) 3)

AUX parametr Control of appliances, see page 12

UC xx...x New PASSWORD (change after installation). The xx..x password can consist

of 4 to 8 characters (A to Z and 0 to 9), the default one is USER

• Only basic ASCII can be used in the SMS command texts.

• Ask the installer to edit the SMS commands for you.

1) only with the CA-1803 2) the service must be supported by your GSM provider 3) the function must be set by an installer

T2711 - Jablotron - Manual Atho5 5T2711 - Jablotron - Manual Atho5 5 8.4.2009 13:27:118.4.2009 13:27:11

3) Controlling from a different phone

The car alarm can also be controlled with SMS command messages from an unauthorized phone. In such

a case you have to add a user code (password) in the command SMS before the command. The text

should be as follows: PASSWORD space COMMAND. The default user code (PASSWORD) is USER.

You can change the password using a command from the table above or ask the installer to do it for you.

An example of setting a car alarm with an SMS message from an unauthorized phone is: USER AM

An example of requesting an SMS with help is: USER HELP

Other services

The car alarm can also be used for securing a garage, cargo space, a caravan, etc.

Wireless detectors: Up to 8 wireless detectors can be enrolled to the car alarm. Depending on their type,

they react to the breaking of windows, motion or smoke. The detectors guard the

inside of the car, possibly even its outside up to a distance of approx. 20 meters.

After setting the car alarm, an exit delay of 20 seconds is provided to all enrolled

detectors (e.g. for leaving the garage). If a detector is triggered while the car alarm

is set (and within reach of the detector), the alarm is triggered either immediately

or after 20 seconds of the entrance delay (depending on the detector settings).

Detectors can be enrolled as internal or external ones.

• Internal detectors are not active when the car alarm is partially set, e.g. when you leave a dog in the car.

• External detectors are always enabled when the system is set.

The detectors (sensors) are powered by batteries with a lifetime exceeding 1 year. When the batteries are low,

the system sends an SMS message. Should you need more information, contact the installer or the manufacturer.

T2711 - Jablotron - Manual Atho6 6T2711 - Jablotron - Manual Atho6 6 8.4.2009 13:27:128.4.2009 13:27:12

Alarm – car intrusion

Alarm: If the car is guarded by the car alarm and one of the sensors is triggered (open-

ing of door, bonnet, detector activation etc.), the siren sounds for 30 seconds 4).

Alarm SMS messages are sent, or optionally, calls to the authorized phones

(up to 4) are made 5).

An alarm can be terminated:

• by pressing a remote control button

• by sending an SMS command to unset the alarm from a mobile phone

Unsetting the alarm will terminate the sending of SMS messages and calling. You will subsequently

receive an SMS conﬁrming proper alarm termination. When the car alarm is controlled with the RC-80

wireless keyfob, alarm termination will only switch off the siren, but the car will remain secured and locked.

It can only be unlocked with repeated pressing of the unset button.

Reduction of the number of alarms:

If an alarm is triggered repeatedly by the same sensor (e.g. a faulty bonnet

sensor) at a time when the alarm is set, then this sensor is bypassed after

3 triggered alarms. It will be re-enrolled when the alarm is set again.

Remote switching of the siren:

The siren can also be triggered remotely from authorized phones using the

“SIREN” SMS command. This command will switch the siren on for 30

seconds. The siren can be triggered off with the “SIREN OFF” command.

4) A siren alarm can be disabled by an installer

If calling in the case of an alarm having been activated and you answer the call, you will hear the sound of a siren. If the car is equipped with

a handsfree set, being able to listen in to the sounds in the car interior will be subsequently triggered.

T2711 - Jablotron - Manual Atho7 7T2711 - Jablotron - Manual Atho7 7 8.4.2009 13:27:128.4.2009 13:27:12

Signalling

1) Acoustic signalling with the alarm siren

The car alarm informs the user about its status by siren

chirps. The chirps for unsetting, setting and setting with

a triggered input (e.g. open door) can be disabled. Other

chirps cannot be disabled due to their importance.

Warning! If the car alarm has no GSM signal at the time

of setting, it chirps six times. The car alarm is thus unable

to transmit SMS messages and make calls.

2) LED indicator in the car

The LED indicator is used to show

the car alarm status. The table below

describes its individual meanings.

Warning! If the LED indicator starts

ﬂashing quickly after the ignition

is switched off, it indicates that there

is no GSM signal and it will not be able

to send any messages or make

a call in the case of an alarm.

Chirps Meaning

1x Setting

2x quickly Partial setting

2x Unsetting

3x Unsetting after an alarm

4x Setting with a triggered input

6x quickly GSM network is not available

LED state Meaning

OFF Unset

Permanently ON A phone call or connecting to a GSM network

Flashes slowly Set

Flashes quickly GSM network is not available or alarm has been

triggered

Interrupted ﬂashing Car blocked (immobilized)

Before switching

the ignition on Flashing indicates wireless detector activation

After switching

the ignition on

Flashing indicates the number of enrolled cont-

rollers

T2711 - Jablotron - Manual Atho8 8T2711 - Jablotron - Manual Atho8 8 8.4.2009 13:27:128.4.2009 13:27:12

Car location and immobilization

1) GPS (CA-1803 only)

When you enter the “GPS” command, the car alarm will respond by sending you the last known GPS loca-

tion. If the current location is unknown (the car is parked in an underground garage etc.), the car alarm will

send the last known position. The car can be tracked temporarily with the “GPS ON” command when the

car alarm sends car position information in 1-minute intervals (only for 15 minutes).

An example of an SMS response with a GPS position:

The car alarm reports: Position: (GMT:3.12.10:35)

50*43.495N;15*11.253E;515;50, Time:3.12.05 11:35

(GMT:3.12.08 10:35) Greenwich Mean Time (prime meridian)

50*43.495N;15*11.253E geographic latitude and longitude

515 approximate elevation

50 current speed

Time:3.12.08 11:35 current local time

2) LOCATOR

If the SIM card used in the car alarm supports the possibility of ﬁnding an approximate position of the car

in a GSM network, the “LOCATOR” command will ﬁnd out where the car is located 2).

2) The service must be supported by the GSM operator

T2711 - Jablotron - Manual Atho9 9T2711 - Jablotron - Manual Atho9 9 8.4.2009 13:27:128.4.2009 13:27:12

An example of an SMS reply with a GSM position:

+44603012345 Region: South East England, District: Greater London, Name: Kingston-upon-

Thames. Distance approx 5.4 km. E14*52‘1“@ N48*50‘24“, + -500m 11:35:01, 03.12.08

3) Remote blocking of the car (IMO)

The car is “immobilized” by blocking the immobilization circuit every time the car alarm is set. However,

if the keys are stolen, the car can also be blocked remotely. If you send the “IMO” command to the car

alarm phone number, you will receive a conﬁrmation SMS. The immobilization circuit will be blocked im-

mediately if the ignition key is off. If the ignition key is on when the car alarm receives the command, the

circuit will be blocked as soon as the ignition is switched off. This will be conﬁrmed to you by an SMS

message. The unblocking of the car alarm will only be possible via the “UNIMO” SMS command.

Ask the installer whether the IMO circuit has been installed in the car and what it blocks.

Remote access and service www.gsmlink.cz

Both the user and the installer can use the www.gsmlink.cz website to register the car alarm and commu-

nicate with it remotely. The access is secure and protected with a password. The website allows inspec-

tion and control of the car alarm and the changing of phone numbers and texts. The CA-1803 version also

allows the display of the current car position on a map. It is also possible to obtain an extract from the event

memory listing including time information, source, event type and car movement history

1).

If you need to change any car alarm settings, you do not usually have to go to your service company.

You just have to make a phone call and the installer can perform remote setting.

More detailed information about the GSMLink application is available at www.jablotron.cz.

1) only with CA-1803

T2711 - Jablotron - Manual Atho10 10T2711 - Jablotron - Manual Atho10 10 8.4.2009 13:27:128.4.2009 13:27:12

Autres manuels pour CA-1802 athos

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels jablotron Alarme de voiture

jablotron

jablotron CA-1803BT Athos Manuel utilisateur

jablotron

jablotron CA-2103 Athos Manuel utilisateur

jablotron

jablotron Accent CA-322 Manuel d'exploitation et d'entretien

jablotron

jablotron CA-340 Manuel utilisateur

jablotron

jablotron Athos CA-1202 Manuel utilisateur

jablotron

jablotron CA-1802 athos Manuel utilisateur

jablotron

jablotron Athos CA-1202 Manuel utilisateur

jablotron

jablotron CA-01 Pulse Mode d’emploi

jablotron

jablotron CA-1802 athos Manuel utilisateur

jablotron

jablotron CA-1802 athos Manuel utilisateur

jablotron

jablotron CL-306 Click Manuel utilisateur

jablotron

jablotron Athos CA-1202 Manuel utilisateur

jablotron

jablotron CA-10 REX Manuel utilisateur

jablotron

jablotron CA-320 Manuel utilisateur

jablotron

jablotron CA-02 Fox Manuel utilisateur

jablotron

jablotron CA-1802 athos Manuel utilisateur

jablotron

jablotron CA-1202 Athos Manuel de service

Manuels Alarme de voiture populaires d'autres marques

Clifford

Clifford 3606X Manuel utilisateur

Ultra Start

Ultra Start 2500M SERIES Manuel utilisateur

Ultra Start

Ultra Start 650 Series Manuel utilisateur

Audiovox

Audiovox Prestige Platinum+ APS-511C Manuel utilisateur

Sparkrite

Sparkrite SRA8 Manuel utilisateur

Viper

Viper 4708V Manuel utilisateur

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manuel

Falcon

Falcon Predator XL3 Guide de l'utilisateur

Audiovox

Audiovox Auto Security XR91 Mode d'emploi

Clifford

Clifford Sabre II Manuel utilisateur

CrimeStopper

CrimeStopper CS-8717 Guide de démarrage rapide

Ultra Start

Ultra Start 450 SERIES Manuel utilisateur

Scytek electronic

Scytek electronic Vectra X3 Manuel utilisateur

Excalibur

Excalibur AL-1860-EDPB Manuel utilisateur

Clifford

Clifford CYBER 2 Manuel utilisateur

Gemini

Gemini 7057 Manuel utilisateur

FlashLogic

FlashLogic FLRSBA PRESTIGE Manuel utilisateur

Magicar

Magicar FAI-440 Manuel utilisateur
