J2 650

Integrated Touchscreen Computer

System Manual

August 2008

650 System Manual (Draft)

Version 0.4 August 20, 2008

Contents

Overview............................................................................................................................ 5

Specification....................................................................................................................... 7

Unique Features................................................................................................................ 9

Intel’s Desktop Processor Socket LGA 775 ................................................................... 9

Hot Swappable RAID/ Dual Hard Drives....................................................................... 9

Green Mode / Fan less Operation ................................................................................... 9

Automatic LCD Brightness Control............................................................................. 10

UPS............................................................................................................................... 10

Printer Power Port......................................................................................................... 10

Cooling System............................................................................................................. 10

Versatility...................................................................................................................... 10

System .............................................................................................................................. 11

Configurations............................................................................................................... 11

Processor Support ......................................................................................................... 11

Processors currently supported on the 650 ................................................................... 12

I/O Ports........................................................................................................................ 13

Off / On Button............................................................................................................. 13

Hard Disks .................................................................................................................... 14

Compact Flash .............................................................................................................. 15

Touch Screen ................................................................................................................ 15

System Board................................................................................................................ 16

LCD Display................................................................................................................. 16

Secondary Display Port................................................................................................. 17

PS/2 Keyboard port....................................................................................................... 17

Serial ports.................................................................................................................... 18

Parallel Port................................................................................................................... 19

USB ports...................................................................................................................... 19

Ethernet Connection...................................................................................................... 20

Kensington Security Slot .............................................................................................. 20

Audio............................................................................................................................. 21

Printer Power Port......................................................................................................... 21

Cash Drawer Ports ........................................................................................................ 22

Power Supply................................................................................................................ 23

Service.............................................................................................................................. 24

Removing the Head from the Base............................................................................... 24

Removing the Power Supply ........................................................................................ 25

Wall Mounting Bracket................................................................................................. 26

VESA Mounting ........................................................................................................... 27

650 System Manual (Draft)

Version 0.4 August 20, 2008

Removing the Back Cover............................................................................................ 28

Changing the System Board.......................................................................................... 29

Adding Memory............................................................................................................ 31

Changing the Processor................................................................................................. 31

Accessing the CF Card.................................................................................................. 32

Accessing the Hard Drives............................................................................................ 33

BIOS Setup...................................................................................................................... 34

Entering the BIOS Setup............................................................................................... 34

Main, System Overview................................................................................................ 34

Advanced Settings ........................................................................................................ 35

SATA Configuration..................................................................................................... 35

Super I/O Configuration ............................................................................................... 37

USB Configuration ....................................................................................................... 38

Green Mode .................................................................................................................. 39

LCD Brightness Control Mode / Manual Mode........................................................... 39

LCD Brightness Control Mode / Auto Mode ............................................................... 40

Restore on AC Power Loss........................................................................................... 41

2nd Display D-SUB15 19V Out................................................................................... 41

Run PXE ROM............................................................................................................. 41

Display OEM Logo....................................................................................................... 42

RTC Configuration ....................................................................................................... 42

Wake On LAN.............................................................................................................. 43

CMOS Clear.................................................................................................................. 43

Boot Settings................................................................................................................. 43

Exit Options.................................................................................................................. 45

Driver Installation / Vista, XP ....................................................................................... 46

Chipset Driver Installation............................................................................................ 46

Graphics Driver Installation.......................................................................................... 46

Audio Driver Installation.............................................................................................. 47

LAN Driver Installation................................................................................................ 48

Touch Screen Driver Installation.................................................................................. 49

OPOS drivers................................................................................................................ 53

J2 Health Monitor........................................................................................................... 54

Overview....................................................................................................................... 54

Hardware Supported ..................................................................................................... 54

Operating System Supported ........................................................................................ 54

Hardware/Software Requirements................................................................................ 54

Installing Health Monitor.............................................................................................. 54

Running Health Monitor............................................................................................... 55

Theory of Operation...................................................................................................... 56

Values Monitored.......................................................................................................... 56

Registry Keys................................................................................................................ 57

Refresh Interval............................................................................................................. 58

650 System Manual (Draft)

Version 0.4 August 20, 2008

Applications.................................................................................................................. 58

RAID ................................................................................................................................ 59

RAID Overview............................................................................................................ 59

AHCI............................................................................................................................. 59

Enabling RAID in the BIOS......................................................................................... 60

RAID Volume Creation................................................................................................ 60

F6 Installation Method.................................................................................................. 60

Installing the Intel Matrix Storage Manager Software ................................................. 61

Hot Swapping RAID 1 drives....................................................................................... 61

Packing List..................................................................................................................... 64

Standard Items .............................................................................................................. 64

650 Optional Peripherals................................................................................................ 65

MSR.................................................................................................................................. 65

Overview....................................................................................................................... 65

Installing the 650 MSR................................................................................................. 66

J2 650 MSR Utility....................................................................................................... 68

MSR Utility, Basic Settings.......................................................................................... 68

Advanced Settings ........................................................................................................ 69

MSR Firmware Update................................................................................................. 71

650 UPS............................................................................................................................ 72

Specifications................................................................................................................ 72

Hardware....................................................................................................................... 72

Software Setup in XP.................................................................................................... 73

STATUS LED............................................................................................................... 75

Customer Display............................................................................................................ 76

Secondary Video Display................................................................................................ 76

Fingerprint Reader / MSR............................................................................................. 76

iButton / MSR.................................................................................................................. 77

RFID / MSR..................................................................................................................... 77

Laser Scanner.................................................................................................................. 77

Contact Information....................................................................................................... 78

650 System Manual (Draft)

Version 0.4 August 20, 2008

Overview

The 650 from J2 is the most high performance integrated Point of Sale computer

available to date. This amazingly versatile unit can be configured as either a low power

fan less thin client terminal; as a midrange thick client terminal; or even as a Dual Core

high speed server with RAID. Product versatility and reliability are the key strengths of

this 650 system.

This ingenious integrated touch screen computer has special “all in the head” design

built-in, which means it can be used as a counter top unit, a wall-mount or a pole-

mounted computer. You will find that both the counter top base and VESA/ wall mount

brackets are supplied as standard equipment with the 650.

There are many processor variants available, the 650 comes standard with an Intel 1.6

GHz Celeron 420 Conroe Core processor. This system board uses the Intel LGA775

socket and it can be upgraded or ordered with a wide range of single or dual core

processors.

The 650 unit also has a very unique feature when using the 420 processor, this is called

the “Green Mode”. This mode is set by a simple BIOS setup item, and when the unit is in

this “Green Mode” the processor speed is reduced to 1GHz and fans are turned off.

This, in effect, turns the 650 into a fan less system for thin-client use and also reduces the

650 power consumption by 25%, thereby reducing the 650 carbon footprint which is

already very small.

Accessibility is key to machine maintenance and upgradeability, the following is a list of

important 650 features:

1. Upgrades to the memory modules can be easily done by simply removing two

screws on the back cover.

2. A complete motherboard upgrade can be carried out in less than 2 minutes.

3. The two quick change hard disk drives are easily accessible, housed on a slide-

in drive bay that allows the drives to be hot swappable.

4. The footprint of the J2 650 is particularly compact making it ideal for the space

conscious retailer.

The 650 offers thick or thin-client or server configurations which support standard

Microsoft operating systems Vista, XP, WePOS, CE.NET and XPe, further

demonstrating its versatility. The 650 is equally proficient with the many flavors of

Linux.

650 System Manual (Draft)

Version 0.4 August 20, 2008

650 System Manual (Draft)

Version 0.4 August 20, 2008

Specification

Main board

CPU Support Intel Desktop Processors LGA775, 1066 MHz FSB, 65W TDP max

Intel 1.6 GHz Celeron 420 Conroe Core, Standard

Chipset Intel Q965 North Bridge, Intel ICH8R South Bridge,

HD Audio VIA1708B, Ethernet Realtek 8111C

System Memory 2 x 240-pin DDR2 DIMM 533/677/800 MHz sockets - up to 4 GB

Graphic memory Share system memory 8MB~256MB

BIOS AMI

LCD Touch Panel

LCD Size 15” TFT LCD

Brightness 250 nits, adjustable in 8 steps to 25nits, auto adjust mode

Resolution 1024 x 768

Touch Screen 650RT Resistive 5 wire, 650ST SAW

Tilt Angle 0゜~ 90゜

Storage

HDD Two 2.5 SATA HDD bay, RAID Support, Quick Change-hot swap

Flash Memory CF adapter Quick Change

Internal Expansion

USB 2.0 Two, one normally used for 802.11n wireless card

I/O Ports

USB Four x in cable well / 1 x on left side

Serial Three, DB9 ( COM 2 /COM 3 pin 9 with 12V by BIOS setting )

Parallel One, DB25 in cable well

LAN (10 /100/ 1000) One, RJ45 in cable well (Realtek 8111C)

2nd Display One, supports standard PC monitor or optional

(J2 provided) secondary customer side display

Cash Drawer 2 x RJ 11 24V with status

DC In 1 Power in, 19VDC 7.1 amps

Audio Jack One headset, one microphone-in, left side (VIA1708B)

Printer Power +24 V 2.5 amps, supports most 24V POS printers,

Power Cable included

Power LED Located under front panel logo - green for on, amber for standby

650 System Manual (Draft)

Version 0.4 August 20, 2008

Power

Power Adapter 19VDC, 135W, 100-240 VAC,50~60Hz, 2.2A

Optional Peripheral

MSR 3 Track ( on PS2 port, wedge type )

iButton Dallas Key iButton ( on PS2 port, wedge type )

2-in-1 MSR MSR 3 track (PS2) / Finger Print (USB)

Second Display optional 8.4”, 10.4” or 12.1” 2nd display, with or without touch

Customer Display Customer Side LCM display with 9mm 2 x20 characters,

Black on White Characters,

Uninterruptable

Power Supply 2 hour DC UPS, mounts in base of unit

Bar Code Scanner 1D and 2D hands-free scanner

Mounting

Standard Counter Top Base, Adjustable Viewing Angle 0-90°

Included Wall Mount / VESA Mount Bracket

Optional Pole Mount, Adjustable angle VESA, Swing-arm Mounts

Environment

EMC & Safety FCC, Class A, CE, LVD

Operating

Temperature 0 ~ 40℃

Storage

Temperature -20 ~ 55℃

Operating Humidity 20% ~ 80% RH non-condensing

Storage Humidity 20% ~ 85% RH non-condensing

Dimensions

(W x D x H) 370 x 250 x3 40mm

Weight 7.45kg

OS Support Microsoft Vista, Windows XP, WEPOS, XP Embedded,

Windows CE 6.0 and Linux

* This specification is subject to change without prior notice.

650 System Manual (Draft)

Version 0.4 August 20, 2008

Unique Features

The 650 truly has some unique features not hitherto seen on an integrated touch screen

computer before. These features allow for a great deal of versatility in how the 650 can

be configured and used. A quick list of unique features is as follows:

Intel’s Desktop Processor Socket LGA 775

By using the new generation of Intel’s green processors and chipsets, a very wide

range of processors can be used in the 650 system. From a Celeron single core

processor running fan less at 1 GHz to a 2.667GHz Core 2 Duo with 1GHz FSB

and 4MB cache, the performance range is truly unique.

Most POS computers use Intel’s Mobile processor and chipset to keep heat and

power down. This is fine but the performance is lower and the cost is higher for

Mobile processor solutions. By taking advantage of J2 company’s and partners’

vast experience with notebook, desktop, and POS computer designs, we are able

to combine features of all three for an optimal POS system design. The result is a

POS system that can utilize a desktop chipset that draws very little power and

generates a low amount of heat, similar to mobile chipsets and processors.

Notebook quality components are used in the processor, chipset, and power

supply circuit, which allow greatly for reduced heat generation and minimal

power usage. Additionally, the 650 takes full advantage of the low power

features built into the Intel processor and chipset to further reduce heat.

Hot Swappable RAID/ Dual Hard Drives

The 650 is the first integrated POS system on the market to offer a hot swappable

RAID feature. The two internal 2.5 inch SATA hard drives can be configured as a

RAID array which gives true fault tolerance to the hard drive subsystem. This has

not been available on an integrated POS device before!

Green Mode / Fan less Operation

By changing one setting in the BIOS, the 650 can be configured to function as a

fan-less POS system. In this mode the standard 1.6GHz processor and chipset run

in a reduced power mode which means that the two fans are off and the 650 is

convection cooled. The system performance in green mode is greater than other

fan-less POS systems on the market, with the 650 benchmarking near the same

performance as a 1.3GHz Celeron M processor based system. This patent pending

feature is unique to J2.

650 System Manual (Draft)

Version 0.4 August 20, 2008

Automatic LCD Brightness Control

Another innovative feature of the 650 is its use of a light sensor to control the

LCD brightness. A light sensor is built into the unit and can detect when a room is

darkened. It will automatically dim the LCD so that it is not too bright. This

patent pending feature is also unique to J2.

UPS Not your ordinary UPS, the J2 650 UPS is a DC, not an AC UPS. The UPS fits

conveniently into the base of the unit. Unlike an AC UPS the J2 UPS makes the

650 work more like a notebook computer. In addition to running the 650 for up to

two hours, the UPS will run all the POS peripherals attached to the 650, including

the printer. Because of the unique design of the J2 UPS and power supply, the

need for special AC power conditioning devices is eliminated.

Printer Power Port

The 24 volt Printer Power Port can power most POS printers on the market,

including the popular Epson line of printers. When used along with the J2 UPS, if

a power outage should occur, the POS terminal can still operate and print receipts

for up to two hours. Also, when the 650 is turned off the printer is turned off also.

This is very useful when the auto power on and off features of the 650 is used.

Cooling System

Great attention was paid to the thermal solution of the 650; it is truly a unique

feature. The 650 can run as a fan less or fan-cooled system. Because of the very

wide range of processors supported, thermal loads can range from 20 watts to as

high as 80 watts. The 650 was designed to handle these thermal loads while still

being super quiet. Two smart fans are used in conjunction with an Embedded

Controller (EC) to ensure that the fans run at the lowest possible speed while still

providing proper cooling. Fan speed changes are controlled to produce the

smallest acoustical signature possible. The 650 also includes a JAM-FAN mode.

If the fan does not spin up when it should, the fan turns on to full power to

dislodge any dust that may be jamming the fan! The 650 fans are the type used in

Blade Servers and have a speed range from 2500~13500rpm at very high torque.

Versatility

The word versatility is very much over used, but it is the correct word to describe

the most unique feature of the 650. The combination of all the 650 unique features

allows for the 650 to fit many roles. The 650 is not just one product, but a full

product range all in one system. From fan less thin client to Core 2 Duo RAID

Server - the 650 does it all.

Table des matières

Autres manuels J2 Ordinateur de bureau

J2 485 Guide de l'utilisateur

Manuels Ordinateur de bureau populaires d'autres marques

HP m9060n - Pavilion - Elite Fiche technique

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

HP Presario SV7000 - Desktop PC Manuel utilisateur

HP ProDesk 400 G5 Manuel

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur
