iZone 225 Guide rapide
Installation, Configuration & User Manual
for
iZone 225 & iZone 325
Section Description Page No.
1. Installation 5
1.1 iZone 225—Wiring layout for base system up to 8 zones 5
1.2 iZone 225—Wiring layout for base system up to 9 to 14 zones 6
1.3 Stand alone A system for a typical 4 zone system 7
1.4 iZone 325—Wiring layout for base system up to 8 zones 8
1.5 iZone 325—Wiring layout for base system up to 9 to 14 zones 9
1.6 Optional equipment for wireless temperature controlled zones 10
1.7 Optional equipment for wired temperature sensors 11
1.8 Optional equipment for iSense temperature and occupancy controlled zones 12
1.9 Optional equipment for colour touch screen temperature controlled zones 13
1.10 Example of different types of temperature sensors and controllers on a single system 14
1.11 Option equipment for wired WiFi control of system 15
1.12 Option equipment for wireless WiFi control of system 16
1.13 iZone 325—Optional equipment for iSave addition (up to 6 zones) 17
1.14 iZone 325—Optional equipment for iSave addition (7 to 12 zones) 18
1.15 iZone 325—Optional equipment for Ethernet Home Automation connection 19
1.16 iZone 325—Wiring connection to AC units 20
1.17 iZone 325—Wiring connection to LG units 21
1.18 iZone 325—Wiring connection to Temperzone units 22
1.19 iZone 325—Wiring connection to Samsung units 23
1.20 General installation instructions 24
Table of contents
Table of contents
Section Description Page No.
2. System initialisation 25
2.1 During initialisation 26
3. System Configuration 27
3.1 Configuration main menu 28
3.2 Zone setup 29-30
3.2.1 Sensor configuration 31
3.2.2 Pairing and configuring iZone RF sensors 32
3.2.3 Sensor calibration 33
3.2.4 iSense controller configuration 34
3.3 AC unit configuration (iZone 325 only) 35
3.3.1 Fan auto configuration 36
3.3.2 Fan auto zone area setup 37
3.4 System options (Display, Taglines, Filter Maintenance, Locks, Non Standard Damper Motors) 38-39
3.5 WiFi bridge configuration 40
3.5.1 Manual IP configuration 41
3.5.2 WiFi connection 42
3.5.3 Smart phone, tablet and PC configuration 43-45
3.6 Home automation integration 46
Table of contents
Section Description Page No.
4. User Manual 47
4.1 iZone 225 home screen 47
4.2 iZone 325 home screen 48
4.3 iZone 325 AC unit control 49
4.4 Zone control 50
4.5 Edit zone names and settings 51
4.6 Adjusting temperature controlled zones 52
4.7 Zone airflow summary 53
4.8 Changing zone airflows 54
4.9 Favourites 55
4.10 Assigning and editing favourites 56
4.11 Schedules 57
4.12 Setting and editing a schedule 58
4.13 Setting the time 59
4.14 Changing the home screen colour 60
4.15 iSense controller 61
4.16 Warranty registration 62
4.17 Airstream product warranty policy 63
4.18 Further assistance 64
1.1 iZone 225 - Wiring layout for base system up to 8 zones
8 Zone system with 1 colour touch screen shown above
A maximum of 14 zones and 12 colour touch screens can be supported by
one iZone system (See Network Extension Module 1.3 for Details)
iZone
1.2 iZone 225 - Wiring layout for base system 9 to 14 zones
iZone
14 Zone system with 1 colour touch
screen shown above
A maximum of 14 zones and 12 colour touch
screens can be supported by one iZone sys-
tem (See Network Extension Module 1.3 for
Details)
1.3 Stand alone A systems - Wiring layout for typical 4 zone
system
4 Zone system shown above. (CVAV4)
A maximum of 14 zones and 14 iSense controllers can be supported by one
iZone system. For CVAV1 to CVAV3 no CNEM is required
1.4 iZone 325 - Wiring layout for base system up to 8 zones
8 Zone system with 1 colour touch
screen shown above
A maximum of 14 zones and 12 colour touch
screens can be supported by one iZone sys-
tem (See Network Extension Module 1.3 for
Details)
1.5 iZone 325 - Wiring layout for base system 9 to 14 zones
14 Zone system with 1 colour
touch screen shown above
A maximum of 14 zones and 12 colour
touch screens can be supported by one
iZone system (See Network Extension
Module 1.3 for Details)
1.6 Optional equipment for wireless temperature controlled zones
