IVT BlueSoleil Manuel utilisateur

IVT BlueSoleil™

User Manual

Version: 1.4

This document describes how to use IVT BlueSoleil™.

IVT BlueSoleil™ User Manual

All specifications are preliminary and subject to change without notice. 2

Contents

1BlueSoleil™ Introduction............................................................................1

1.1 Profiles ....................................................................................................1

1.2 New features in BlueSoleil 1.4 ..................................................................... 2

1.3 Features in BlueSoleil 1.2 ...........................................................................2

2BlueSoleil™ Basic Operations .....................................................................4

2.1 Start BlueSoleil™ ......................................................................................4

2.2 Exit BlueSoleil™ ........................................................................................4

2.3 BlueSoleil™ Main Window ...........................................................................5

2.4 Service Window.........................................................................................8

2.5 What You Need To Do Before Build A Connection ......................................... 10

2.6 Start Or Stop A Bluetooth Service Connection.............................................. 14

3Bluetooth Security....................................................................................16

3.1 Introduction ........................................................................................... 16

3.2 BlueSoleil Security Configuration ............................................................... 17

4Personal Area Networking........................................................................22

4.1 Introduction ........................................................................................... 22

4.2 Communication Between Two Computers.................................................... 23

4.3 Access LAN Through PAN-NAP ................................................................... 29

4.4 Access LAN Through IVT BlueSoleil™.......................................................... 33

4.5 Access Internet through IVT BlueSoleil™..................................................... 35

4.6 PAN Configuration ................................................................................... 36

5Dial-Up Networking.................................................................................. 38

5.1 Introduction ........................................................................................... 38

5.2 Connect to a Dial-up Gateway from a Computer........................................... 38

5.3 Settings for Dial-up Networking Profile (client side) in Windows98/Me............. 41

6Bluetooth Serial Port................................................................................46

6.1 Introduction ........................................................................................... 46

6.2 Connect Two Computers........................................................................... 46

6.3 Use SPP to Print a Document..................................................................... 48

6.4 Use a cellphone to control a computer ........................................................ 48

6.5 SPP Configuration.................................................................................... 50

7Bluetooth File Transfer.............................................................................52

7.1 Introduction ........................................................................................... 52

7.2 Transfer files to/from a Computer .............................................................. 52

7.3 FTP Configuration .................................................................................... 55

8LAN Access...............................................................................................56

8.1 Introduction ........................................................................................... 56

8.2 Access a Local Area Network (LAN) ............................................................ 56

8.3 Access a LAN via a LAN Access Point .......................................................... 60

8.4 Settings for LAN Access Profile (client side) in Windows98/Me........................ 61

8.5 Usage of LAN Access Profile (server side) in Windows98/Me........................... 65

9Object Push.............................................................................................. 70

9.1 Introduction ........................................................................................... 70

9.2 Transfer Objects from a Computer to a Bluetooth Cellular Phone .................... 70

IVT BlueSoleil™ User Manual

All specifications are preliminary and subject to change without notice. 3

9.3 Transfer Objects from a Bluetooth Cellular Phone to a Computer .................... 74

9.4 Transfer Objects between Two Computers................................................... 75

9.5 Configure OPP Service.............................................................................. 76

9.6 Using OPP in Microsoft Outlook .................................................................. 77

10 Synchronization.....................................................................................80

10.1 Introduction......................................................................................... 80

10.2 Exchange PIM Data with a Cellular Phone ................................................. 80

10.3 Set up SYNC Connection between Two Computers ..................................... 81

10.4 Synchronization Configuration ................................................................ 83

10.5 Using Synchronization in Outlook ............................................................ 84

11 Hardcopy Cable Replacement ................................................................ 87

11.1 Introduction......................................................................................... 87

11.2 Print a Document Using a Bluetooth Printer .............................................. 87

12 Human Interface Device........................................................................89

12.1 Introduction......................................................................................... 89

12.2 Connect a Computer to a Bluetooth Mouse ............................................... 89

12.3 Connect a Computer to a Bluetooth Keyboard ........................................... 91

13 FAX........................................................................................................94

13.1 Introduction......................................................................................... 94

13.2 Connect to a FAX Gateway from a Computer ............................................ 94

13.3 Using FAX software on a bluetooth computer ............................................ 94

14 Headset.................................................................................................96

14.1 Introduction......................................................................................... 96

14.2 Create an audio connection between computer and Headset ....................... 96

14.3 Using Headset Profile in BlueSoleil........................................................... 98

15 Advanced Audio Distribution ...............................................................100

15.1 Introduction....................................................................................... 100

15.2 Play music between computer and AV Headphone wirelessly ..................... 100

15.3 Play music between two computers wirelessly......................................... 103

16 Basic Imaging .....................................................................................107

16.1 Introduction....................................................................................... 107

16.2 Push an image from a digital still camera. .............................................. 107

16.3 Control a digital still camera remotely.................................................... 108

17 Connection Shortcut............................................................................ 110

17.1 Introduction....................................................................................... 110

17.2 How to use Connection Shortcut ........................................................... 110

18 Bluetooth Glossary ..............................................................................113

IVT BlueSoleil™ User Manual

All specifications are preliminary and subject to change without notice. 1

1 BlueSoleil™Introduction

BlueSoleil™is a Windows-based Bluetooth Wireless software suite from IVT

Corporation. It is fully compliant to the latest Bluetooth SIG specifications.

BlueSoleil™incorporates Bluetooth and computer technologies to enable users to

wirelessly access computing devices, form networks, and exchange information.

1.1 Profiles

BlueSoleil™V1.4 includes ten Bluetooth profiles. The following table indicates

which of these profiles is available for client and server devices.

Profile Description Client Server

PAN Personal Area Networking √√

SPP Serial Port √√

DUN Dial-Up Networking √

LAP LAN Access √√

FTP File Transfer √√

HID Human Interface Device √

HCRP Hardcopy Cable Replacement √

OPP Object Push √√

SYNC Synchronization √√

AG Audio Gateway √√

AV Audio Source

Audio Sink

√√

BIP Basic Imaging √√

BlueSoleil™supports more than ten Bluetooth chip-sets and HCI interfaces

including USB, UART, PCMCIA and Compact Flash.

IVT BlueSoleil™supports:

♦ Windows 2000/XP

♦ Windows 98SE/Me

This manual describes how to use BlueSoleil™:

♦ How to start and exit BlueSoleil™.

♦ How to navigate the Main Window and Service Window.

♦ How to use the Bluetooth profiles.

IVT BlueSoleil™ User Manual

All specifications are preliminary and subject to change without notice. 2

1.2 New features in BlueSoleil 1.4

BlueSoleil version 1.4 is ready now with even more exciting new features,

multimedia profiles are added into BlueSoleil.

They include:

♦ Headset

With this feature, users can use Bluetooth Headset to listen to music, to record

sound or to chat with others. Headset increases the user’s mobility.

♦ Audio/Video

With this feature, users can listen to stereo music with any media player

wirelessly between Bluetooth enabled computers or Bluetooth enabled

computer and Bluetooth Stereo headphone.

♦ Basic Image

With this feature, users can push an image from a digital still camera to a

computer, or control a digital still camera remotely from a computer.

1.3 Features in BlueSoleil 1.2

BlueSoleil version 1.2.0 is ready with exciting new features, aiming at making

Bluetooth more easy to use for end user. Less steps is required to setup wireless

connections. User can even do not care what is Bluetooth. Anyway, Bluetooth is

just a kind of connecting method. So, please just have fun from all these new

functions.

They include:

♦ Seamless Integration with Windows

This is an important improvement to make it more easy to use Bluetooth.

Generally, users do not care about what is Bluetooth and how can they connect

to a Bluetooth device. From users' point of view, they just want to print a

document, open a serial port, dial-up to Internet and send a FAX etc. To make

this, BlueSoleil automatically setup Bluetooth connections for users. There is no

need to setup connection before using Bluetooth anymore.

♦ Integration with MS Outlook for Object Push and Synchronization

With this feature, contact cards and email messages can be sent or

synchronized from Outlook directly via Bluetooth. Received cards and other

information items will be imported to Outlook automatically.

♦ Shortcut on Windows Desktop

Windows shortcut is introduced here to let user to be able to setup Bluetooth

connection when they want by just double- clicking them. It makes Bluetooth

connection extremely simple.

♦ Security 2

With this feature, users can manage local Bluetooth services in a flexible way.

Authentication, encryption and authorization can be configured based on every

service. Users can set which remote device can access local services and which

not.

♦ FAX

FAX enable users to send a FAX from PC side via Bluetooth cellular phone or

Bluetooth FAX machine wirelessly.

♦ Network Address Translation, Network Access Point, and DHCP server

in PAN

IVT BlueSoleil™ User Manual

All specifications are preliminary and subject to change without notice. 3

With these functions, users can setup ad-hoc Personal Area Network quickly

and share the Internet accessing among computer.

♦ More Bluetooth Serial Ports

More Bluetooth Serial Ports are supported, with 4 Bluetooth Serial Ports for

out-going connections and 2 Bluetooth Serial Ports for incoming connections.

♦ Mobile HID

With this feature, users can make cellular phones like Ericsson T39 or T68 to

work like a mouse and keyboard. Users can remotely control their PC to show

Power Point etc.

IVT BlueSoleil™ User Manual

All specifications are preliminary and subject to change without notice. 4

2 BlueSoleil™ Basic Operations

2.1 Start BlueSoleil™

After installing BlueSoleil™, there are two ways to start the program:

1. A BlueSoleil™ shortcut icon on the Windows desktop.

2. An IVT BlueSoleil™program group entry in the Windows’ Start | Programs menu.

Double-click the BlueSoleil™shortcut icon on the desktop or click the BlueSoleil™

menu item on the Start | Programs | IVT BlueSoleil™menu to start the

BlueSoleil™ software.

The BlueSoleil™ icon will be displayed at the bottom right corner of the

Windows desktop (Figure 2.1).

Figure 2.1: BlueSoleil™ icon

The BlueSoleil™Main Window pops up as shown in Figure 2.2.

2.2 Exit BlueSoleil™

To exit BlueSoleil™, right-click the BlueSoleil™ icon at the bottom right corner of the

Windows task bar and select Exit on the pop-up menu.

Note: Selecting the Close button at the top right corner of the BlueSoleil™ window

only hides the BlueSoleil™ window.

IVT BlueSoleil™ User Manual

All specifications are preliminary and subject to change without notice. 5

2.3 BlueSoleil™ Main Window

The BlueSoleil™ Main Window displays all surrounding Bluetooth devices. From

the BlueSoleil™ Main Window users can search for surrounding Bluetooth devices

and can execute connect/ disconnect functions.

Figure 2.2: BlueSoleil™ Main Window

The main elements in the BlueSoleil™ Main Window are:

♦ My Device Icon

♦ Remote Bluetooth Device Icons

♦ Bluetooth Service Icons

2.3.1 My Device Icon

This icon represents the client computer. It is called the ‘My Device icon’ or ‘center

ball’ in this document.

Functions:

♦ Hover the mouse over the My Device icon to display the client Bluetooth device

name and address.

♦ Double-click to start/ stop searching for surrounding Bluetooth devices.

♦ Drag scrollbar on the right of main window to find other Bluetooth devices if

there are more than seven devices.

♦ Right-click to display the pop-up menu with related operations.

Remote Device

Local Device Icon

Remote Device Serivce Icon

IVT BlueSoleil™ User Manual

All specifications are preliminary and subject to change without notice. 6

2.3.2 Remote Bluetooth Device Icons

The icons in the table below represent the remote Bluetooth devices.

Device Type Icon

Headset

Keyboard

LAN Access Point

Laptop

Mobile

Modem

Mouse

Personal Computer

PDA

Printer

Scanner

Unknown device

The following colors are used to indicate the status of the remote Bluetooth device:

♦ White (Idle)

This is the normal status of the device.

IVT BlueSoleil™ User Manual

All specifications are preliminary and subject to change without notice. 7

♦ Yellow (Selected)

The device has been selected by the user.

♦ Green (Connected)

The device has been connected.

Functions:

♦ Single-click to select.

♦ Double-click to get the services remote Bluetooth device supports.

♦ Right-click to display the pop-up menu with related operations.

2.3.3 Bluetooth Service Icons

The Bluetooth Service Icons represent the Bluetooth services supported by the

remote device.

Bluetooth Service Icon

Personal Area Networking

Dial-up Networking

Serial Port

LAN Access

File Transfer

Information Synchronization

Object Push

Printer

Fax

Human Interface Device

Table des matières

Autres manuels IVT Logiciel

IVT

IVT CBD-120 Manuel utilisateur

IVT

IVT Flybook V2 Mode d’emploi

IVT

IVT GN-BTD02 Manuel utilisateur

Manuels Logiciel populaires d'autres marques

COMPRO

COMPRO COMPROFM Manuel utilisateur

Muratec

Muratec OFFICEBRIDGE ONLINE Manuel utilisateur

Oracle

Oracle Contact Center Anywhere 8.1 Manuel utilisateur

Adobe

Adobe 65007312 - Photoshop Lightroom Manuel

Avaya

Avaya NULL One-X for RIM Blackberry Manuel utilisateur

HP ProLiant BL420c Manuel utilisateur

PS Audio

PS Audio PowerPlay Manuel du propriétaire

Brady

Brady LOCKOUT PRO 3.0 Manuel de service

Avaya

Avaya Interaction Center Manuel utilisateur

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuel

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuel utilisateur

Oracle

Oracle Application 9i Manuel utilisateur

Acer

Acer RDM Manuel utilisateur

Canon

Canon Vixia HF21 Manuel utilisateur

Canon

Canon ZR950 Manuel utilisateur

Samsung

Samsung Auto Backup Manuel utilisateur

Polycom

Polycom Vortex EF2201 Instructions d'installation et d'utilisation

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuel utilisateur
