Ivation IVASNOWPUSH Manuel utilisateur
ROLLING SNOW
PUSHER
USER GUIDE
MODEL #: IVASNOWPUSH
Thank you for purchasing the Ivation® Rolling Snow Pusher. This User Guide is intended to provide you with
guidelines to ensure that operation of this product is safe and does not pose risk to the user. Any use that
does not conform to the guidelines described in this User Guide may void the limited warranty.
Please read all directions before using the product and retain this guide for reference. This product is
intended for domestic use only.
This product is covered by a limited one-year warranty. Coverage is subject to limits and exclusions. See
warranty for details.
TABLE OF CONTENTS
2 SAFETY PRECAUTIONS
2 BOX CONTENTS
3-6 ASSEMBLY
6 CUSTOMER SERVICE
Wheels (x2)
SAFETY PRECAUTIONS
BOX CONTENTS
• The blades inside the snow pusher are very sharp and could cause injury. Do not put hands, feet, or any
other appendages into the snow pusher for any reason.
• If snow or ice becomes lodged in the pusher, do not reach in to try and dislodge it. Use a stick or
similar object.
• This item should only be used by adults who are physically capable of pushing heavy objects. Children
or persons with medical conditions that cannot lift or push heavy items should not use the snow pusher
Blade
Wheels
Handle
2
A
D
Blade (x1)
B
Lower Handle (x1)
C
Upper Handle (x1)
EF
Arms (x2)
Bolts (x4)
K
Bolts (x2)
I
Locknuts (x4)
N
Nuts (x2)
H
Bolts (x2)
Q
O
Screws (x4)
P
Locknuts (x2) Nuts (x4)
L
Washers (x4)
M
Rings (x2)
G
Plates (x2)
A
I
E
I
E
G
G
F
F
K
L
M
M
N
N
L
L
L
K
D
D
ASSEMBLY
Step 1: Blade Assembly
Install the arms (E) in the back of the shovel, silver part facing inward, with R going to R and L going to L .
Secure arms with the plates (G), bolts (F) and locknut (I) as shown in the picture below:
Step 2: Wheels Assembly
Install the wheels (D) on the arms using the bolts (K). The washers (L) are to be placed both sides the of the
wheels. The ring (M) needs to be placed between the arm and the nut (N), as shown in the picture below:
3
Step 3: Handle Assembly
1. Install the lower handle (B) connecting to the inside of the arms of the blade using bolts (H)
and locknuts (Q).
4
B
H
Q
H
2. Attach the upper handle (C) with screws (O) and secure with nuts (P). This part is height adjustable
by mounting in higher or lower holes.
5
O
C
O
O
O
P
P
P
P
Finished Product
6
Distributed by C&A Marketing
114 Tived Lane East, Edison, NJ 08837
info@myivation.com
Europe: C&A Europe
167 Hermitage Road, Crusader Industrial Estate, London N4 1LZ, UK
Made in China
IVATION is a trademark of C&A IP Holdings, LLC in the US, Canada and the EU.
©2019 All rights reserved
QUESTIONS OR PROBLEMS? CONTACT US!
info@myivation.com | 1-866-849-3049
