ITC Entone Manuel utilisateur
Your remote control needs to be programmed to
operate properly. It needs to be told how to run your
television, which 'stream' it should change the
channels for, and which set top box (STB) to control.
1. Does the remote turn on/off the TV and control
volume?
If YES, proceed to next question.
If NO, program remote using this procedure:
a. Manually turn on the TV. (or auxiliary device)
b. Press and release the TV key.
c. Press and hold the SETUP key until the key
blinks twice and then release.
d. The TV key will stay lit. Press the POWER
key once.
e. Aim the remote at the TV and press and
release CHANNEL UP/DOWN. The remote
will auto scan at 10 second intervals. The TV
key will be on, blinking every 10 seconds.
f. If the TV turns off, a working code has been
found. Press OK once to lock in the code.
The TV key will blink twice.
g. If all codes are exhausted, the TV key will
blink fast 7 times and the search will be
terminated.
2. Can you change channels and/or see the
guide?
If YES, your remote is programmed.
If NO, the remote needs to be programmed
to control the correct stream.
a. Be sure that the RF antenna is attached
to the REMOTE ANTENNA port on the back
of the STB.
b. On the STB, press and hold the OK
button until the STB display will read RC
REG.
c. On the remote, press and hold the STB
button for five seconds. The STB button will
light up and stay lit. Release the STB
button.
Programming Your Remote
Best Seat Help Desk
24 hours a day/7 days a week
1-800-455-5958
With amazing high definition picture quality,
widescreen format, and Dolby Digital surround
sound, HDTV makes you feel like you’re at the
movies - no matter what you’re watching! Colors
will be brighter, sounds more intense, and you will
see details that you can’t believe are possible. It’s
TV like you’ve never experienced it before!
There are 72 HD programming channels and two
premium movie HD* channels - making 74
channels! (*You must subscribe to the premium
movie channel and HD to receive these channels)
You will need a HD television and ITC’s Best Seat
Digital TV service for this service to work.
High Definition TV
d. On the remote, press and release the
STB button. Both the STB and the AUX
buttons will illuminate.
e. On the remote, enter number for the
stream:
-0 for infrared Stream 1 (Use “0” if the
remote will always be used in the same
room as the box or if you are using the
Entone Amulet single stream box.)
-1 for UHF Stream 1 (Channel 10)
-2 for UHF Stream 2 (Channel 23)
-3 for UHF Stream 3 (Channel 39)
f. On the remote, the STB button will blink
twice to indicate the registration was
successful. On the STB, the display will
read RC REG Dx to indicate the registration
was successful.
Helpful Hint: When powering up, push the STB
button every time.
Entone Remote
Guide
1-800-417-8667
7/30/12
Functions section by section:
Note: If you push the TV button, you will change television channels—not STB box
channels—with the remote. The INPUT button will let you scroll between your input
(also known as video or aux) channels, your S-Video, and HD inputs. Remember to
push the STB button to regain control of your STB channels.
Your remote controls the set top box, your television set and, optionally, an auxiliary device like a DVD player or VCR.
Press STB, TV or AUX to select the device you wish to operate.
DVR/PVR Instructions:
7. Phone Button - Displays Caller ID log
6. Numeric Keypad - Enter channels or other numeric
information at menu prompts.
MUTE - silences TV volume
Note: Press VOL + to cancel MUTE
5. Navigation
- To move on-screen highlights
OK - To select the highlighted option
Move 12 hours at a time in the program guide:
- Page Left
- Page Right
4. Volume and Channel
VOL +/- - Adjusts volume on TV
CH / - Changes channels or pages up/down in guide
LAST - Return to last channel viewed
3. Program Guide
INFO - Provides information about selected program
MENU - Displays system menu to access features
GUIDE - Displays detailed program listings
EXIT - Returns to program or to previous menu
2. Turn TV On - If the remote is set to STB, the POWER button will turn
the TV and STB on together.
1. INPUT - Will change inputs on TV, only in TV mode.
PLAY, REWIND, FAST FORWARD, PAUSE, & STOP -
Use these buttons to control your PVR (only on your
main TV). You may also use these buttons to control your
VCR, if you have programmed the remote to your VCR.
To record
- To record a show your are watching, press REC.
- To record a future show you see on the guide,
select the show on the guide and press REC or
press MENU, select PVR and schedule event.
To stop recording
- Press the STOP button, or choose MENU, select
PVR and select RECORDINGS, highlight the program,
press OK and STOP RECORDING.
To view everything you have recorded
- Press MENU, select PVR.
- Highlight RECORDINGS and press OK.
- Make sure to scroll down when looking for title, you
may have more than one page of shows stored.
To play a recorded show
- Press MENU, select PVR.
- Highlight RECORDINGS and press OK.
- Select title you want to view, press OK, then press
PLAY RECORDINGS.
To delete a recorded show
- Press MENU, select PVR.
- Highlight RECORDINGS and press OK.
- Select title you want to view, press OK, then press
DELETE RECORDINGS and follow instructions.
Important: Each of your remote battery covers are labeled 1, 2, or 3.
Each remote will correspond with a different TV.
Play
Stop
Record
Pause
Fast Forward
or Rewind
(press again to
go faster)
DVR/PVR Buttons
Whole Home DVR Instructions:
PLAY or RECORD - Using the DVR instructions above, you can play or
record content from any TV in your home with a set-top box. You can still
pause and rewind live TV from your main TV and you can also record and
play HD shows on the TVs with HD programming.
Controlling Your Remote
8. Record-it Button - Displays your DVR recordings
Buttons reserved for future use.
Quick Reference Guide
Your Stream 1 TV should be set to ____ and used with remote #1.
Remote #1 has been programmed to code ____.
Your Stream 2 TV should be set to ____ and used with remote #2.
Remote #2 has been programmed to code ____.
Your Stream 3 TV should be set to ____ and used with remote #3.
Remote #3 has been programmed to code ____. For a complete guide on how your system works, please visit ITC’s website at www.itc-web.com.
Under Digital TV, look for the overview tab.
