Ice maker Clear installation and
first usage
Like all Indel Webasto Marine products the most important thing is:
VENTILATION
Producing ice requires a higher heat removal so ventilation must be more than
adequate. The ice-maker gets fresh air off the front grid and blows it off the back
much hotter. To make the ice-maker work perfectly it’s important that the front grid
is always open and not partially or completely blocked. At the same time on the
back of the installation hole a ventilation grid has to be created to let hot air out.
If ventilation is difficult to achieve Indel Webasto Marine can supply a ventilation kit
which allows to direct the hot air flux to the outside, making the installation more
versatile.
Ventilation kit 230V 50-60Hz spare part number SBE00094AA
Ventilation kit 115V 60Hz spare part number SBE00108AA
The ice-maker gets fresh air off the front grid and blows it out off the back
Connection to boat main water system
On the back of the ice-maker there are all the necessary connections to connect it
on the boat main water system. The ice-maker is supplied with a water inlet hose
(blue) and a water outlet hose (grey).
The package also inlcudes:
• Plastic scoop
• 4 plastic feet
• Instruction manual
Water inlet – connect
included blue hose
Water outlet –
connect included
grey hose
Attention: water falls by gravitu, keep the water outlet hose lower than
the exit. Avoid loops.
It is important also to prime the ice-maker manually before first usage.
Lift up the ice-maker lid and lift up the flappers. Pour 3 liters of potable or mineral
water into the water bin. Indel Weabsto Marine ice-maker is especially built to work
with potable or mineral water only.
Connect the ice-maker to the main power
supply system.
Press the button in front of the ice-maker to turn
it on.
The ice-maker has been correctly installed, it has been correctly connected and has
been manually primed: it’s now ready to produce ice.
Once on the ice-maker takes 30-40 minutes for the first ice cycle. This is because
the ice-maker has to cool all the water inside the water bin as well as all the cooling
system.
After the first cycle the ice-maker takes 10 minutes to make any other ice cycle; this
until the ice bin is full or the ice-maker is manually turned off.
Attention: the time needed for the first ice cycle may vary depending on the
ambient temperature: the higher the temperature the more time it takes, the lower
the temperature the less.
Beneath the vent grid
Ice-bin thermostat. This thermostat regulates the quantity
of ice to be stored in the ice bin before turning the ice-
maker off automatically.
Evaporator thermostat. This thermostat regulates the
temperature of the evaporator and the «thickness» of
the ice.
Timer. The timer regulates the frost and defrost time
span. Attention: the timer turns clockwise only
Thermostats setting
Evaporator thermostat and ice bin thermostat are both set between 4 and 5 on a
scalefrom1to7;It’s important not to alter their setting even when working
with high ambient temperatures.
Ice formation cycle. In this phase the pump is
sprays water onto the evaporator and starts
creating ice cubes.
Defrost cycle. While the timer is in this position the
ice-maker refills automatically and ice falls into the
ice bin. Pump isn’t working
