iSMA-D-PD
User Manual
Industrial LCD Panel
iSMA-D-PD User Manual
www.ismacontrolli.com
DMP222en | 1st Issue rev. 3 | 11/2023
page 2 of 13
Table of Contents
1 Introduction .................................................................................................................................... 3
1.1 Revision History.......................................................................................................................................3
2 Safety Rules..................................................................................................................................... 4
3 Technical Specification ................................................................................................................. 5
4 Standards and Norms ..................................................................................................................7
5 Dimensions ..................................................................................................................................... 8
6 Interfaces......................................................................................................................................... 9
7 Operation Guide..........................................................................................................................10
7.1 Rear Navigation Buttons.................................................................................................................... 10
7.2 OSD Options - Adjustment................................................................................................................ 10
8 Installation.....................................................................................................................................13
8.1 Snap Joint Installation......................................................................................................................... 13
8.2 Wall Mount Installation ...................................................................................................................... 13
iSMA-D-PD User Manual
www.ismacontrolli.com
DMP222en | 1st Issue rev. 3 | 11/2023
page 3 of 13
1 Introduction
The iSMA-D-PD10C-B1 is 10.1'' is an industrial LCD panel, which has been designed to
simplify the use of MAC36 controllers, iSMA-B-MAC36NL and iSMA-B-MAC36PRO.
The LCD panel is equipped with multiple interfaces to accelerate the connection with the
master controller. The applied RJ45 interface provides transmitting touch commands
(RJ45-USB).
The 16:9 aspect ration with 1366x768 resolution allows for displaying graphics clearly.
The panel is VESA compliant and can be wall-mounted. It has an extensive menu in 7
languages.
Available with EU, UK, and US power supply.
Figure 1. iSMA-D-PD10C-B1 panel connected to the iSMA-B-MAC36NL controller
1.1 Revision History
Rev. Date Description
1.3 10 Nov 2023 iSMA-B-MAC36PRO references
1.2 25 May 2022 Rebranded
1.1 31 Mar 2020 Company data update
1.0 28 Aug 2015 First edition
Table 1. Revision history
iSMA-D-PD User Manual
www.ismacontrolli.com
DMP222en | 1st Issue rev. 3 | 11/2023
page 4 of 13
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
2 Safety Rules
Improper wiring of the product can damage it and lead to other hazards. Make sure
that the product has been correctly wired before turning the power on.
Before wiring or removing/mounting the product, make sure to turn the power off.
Failure to do so might cause an electric shock.
Do not touch electrically charged parts such as power terminals. Doing so might cause
an electric shock.
Do not disassemble the product. Doing so might cause an electric shock or faulty
operation.
Use the product only within the operating ranges recommended in the specification
(temperature, humidity, voltage, shock, mounting direction, atmosphere, etc.). Failure
to do so might cause a fire or faulty operation.
Firmly tighten the wires to the terminal. Failure to do so might cause a fire.
Avoid installing the product in close proximity to high-power electrical devices and
cables, inductive loads, and switching devices. Proximity of such objects may cause an
uncontrolled interference, resulting in an instable operation of the product.
Proper arrangement of the power and signal cabling affects the operation of the entire
control system. Avoid laying the power and signal wiring in parallel cable trays. It can
cause interferences in monitored and control signals.
It is recommended to power controllers/modules with AC/DC power suppliers. They
provide better and more stable insulation for devices compared to AC/AC transformer
systems, which transmit disturbances and transient phenomena like surges and bursts
to devices. They also isolate products from inductive phenomena from other
transformers and loads.
Power supply systems for the product should be protected by external devices limiting
overvoltage and effects of lightning discharges.
Avoid powering the product and its controlled/monitored devices, especially high
power and inductive loads, from a single power source. Powering devices from a single
power source causes a risk of introducing disturbances from the loads to the control
devices.
If an AC/AC transformer is used to supply control devices, it is strongly recommended
to use a maximum 100 VA Class 2 transformer to avoid unwanted inductive effects,
which are dangerous for devices.
Long monitoring and control lines may cause loops in connection with the shared
power supply, causing disturbances in the operation of devices, including external
communication. It is recommended to use galvanic separators.
To protect signal and communication lines against external electromagnetic
interferences, use properly grounded shielded cables and ferrite beads.
Switching the digital output relays of large (exceeding specification) inductive loads can
cause interference pulses to the electronics installed inside the product. Therefore, it
is recommended to use external relays/contactors, etc. to switch such loads. The use
of controllers with triac outputs also limits similar overvoltage phenomena.
Many cases of disturbances and overvoltage in control systems are generated by
switched, inductive loads supplied by alternating mains voltage (AC 120/230 V). If they
do not have appropriate built-in noise reduction circuits, it is recommended to use
external circuits such as snubbers, varistors, or protection diodes to limit these effects.
iSMA-D-PD User Manual
www.ismacontrolli.com
DMP222en | 1st Issue rev. 3 | 11/2023
page 5 of 13
3 Technical Specification
Panel Type HD industrial TFT LCD
Screen Type LED; backlight lifetime ≥50000 h,
Size 10.1’’
Aspect Ratio 16:9
Luminance 300 nit, up to 800 nit
Contrast 800:1
Active Area 222.7x125.2 mm
Display Color 16.7 M
Point Distance 0.264 mm
View Angle 75/75/75/75
Response Time ≤5 ms
Installation Compatible with VESA, for embedding, wall mount
Menu Languages English, French, German, Spanish, Chinese, Italian, Russian
Touch Type 10-point capacitive touch screen
Material Metal/aluminum alloy
Signal Port VGA, HDMI, DVI
Power Port 12 V- 24 VDC
Audio Port Audio I/O
Touch Port RJ45 (customized USB)
Anti-interference Anti-interference electromagnetic compatibility; electromagnetic interference
Anti-Vibration 5-19 HZ/1.0 mm amplitude; 19-200 HZ/1.0 g accelerated speed
Temperature Operating temperature: -10°C to 60°C
(14°F to 140°F)
Storage temperature: -10°C to 60°C (14°F
to 140°F)
iSMA-D-PD User Manual
www.ismacontrolli.com
DMP222en | 1st Issue rev. 3 | 11/2023
page 6 of 13
Humidity Operation humidity: 10% to 80% Storage humidity: 10% to 90%
Anti-static 4 KV-8 KV; (customized MAX 16 KV)
Rated Voltage 100 V AC～240 V to 12 V-24 VDC
Rated Frequency 50 Hz/60 Hz
Power Supply 110-240 V AC, 50/60 Hz
Power Power consumption ≤ 30 W Power standby ≤ 1.5 W
Dimension 293.6x193.6x48.5 mm (11.560x7.622x1.909 in)
IP IP65 – for front panel
Table 2. Technical specification
iSMA-D-PD User Manual
www.ismacontrolli.com
DMP222en | 1st Issue rev. 3 | 11/2023
page 7 of 13
4 Standards and Norms
EN 55032:2015
Electromagnetic compatibility of multimedia equipment. Emission Requirements.
EN 61000-3-2:2014
Electromagnetic compatibility (EMC). Limits for harmonic current emissions for
equipment input current ≤ 16 A per phase).
EN 61000-3-3:2013
Electromagnetic compatibility (EMC). Limits for voltage changes, voltage fluctuations and
flicker in public low-voltage supply systems, for equipment with rated current ≤ 16 A per
phase.
EN 55024:2010 + A1:2015
Information technology equipment. Immunity characteristics. Limits and methods of
measurement.
EN 60950-1:2006 + A11:2002 + A1:2010 + A12:2011 + A2:2013
Information technology equipment. Safety General requirements specifies requirements
intended to reduce risks of fire, electric shock or injury for the OPERATOR and layman
who may come into contact with the equipment and, where specifically stated, for a
SERVICE PERSON.
iSMA-D-PD User Manual
www.ismacontrolli.com
DMP222en | 1st Issue rev. 3 | 11/2023
page 8 of 13
5 Dimensions
Figure 2. Dimensions of iSMA-D-PD10C-B1
iSMA-D-PD User Manual
www.ismacontrolli.com
DMP222en | 1st Issue rev. 3 | 11/2023
page 9 of 13
6 Interfaces
The monitor recognizes and selects the signal automatically.
Figure 3. Interface details
iSMA-D-PD User Manual
www.ismacontrolli.com
DMP222en | 1st Issue rev. 3 | 11/2023
page 10 of 13
•
•
•
•
•
7 Operation Guide
7.1 Rear Navigation Buttons
The rear navigation buttons are used to turn the device on and off. Brightness +/- buttons
are prepared for future development:
Figure 4. Rear navigation buttons
Symbol Name Instruction
Left Choose + Choosing different submenus, the function of this button
is the change of data quantity.
Right Choose -
ON/OFF On / off button Start-up/Shut down the monitor.
Return Back button Return to the up level menu.
Menu Main menu First time this button is pressed, OSD will pop-up.
Table 3. Operating of rear navigation buttons
7.2 OSD Options - Adjustment
OSD menu's basic functions:
Screen display effect adjustment;
Brightness adjustment;
Contrast ratio adjustment;
Color adjustment;
etc.
If order to enter the OSD menu interface, go into trial testing of below parameters by
clicking main MENU options.
