iFP-700 Series

www.iRiver.com

Hardware Instruction Manual

Thank you for your purchase.

Please read this manual carefully

before using your new player.

www.iRiver.com

Digital Audio player/

Recorder/FM Tuner

Model iFP-700 Series

GETTING STARTED

LOCATING THE CONTROLS

PC SOFTWARE INSTALLATION

BASIC OPERATION

CONVENIENT FUNCTIONS

ADDITIONAL INFORMATION

ontents

THIS MANUAL COVERS THE INSTALLATION AND USE OF

THE PLAYER HARDWARE. FOR DETAILS REGARDING THE

SOFTWARE OPERATION INCLUDING TRANSFERRING MUSIC

TO THE PLAYER, PLEASE SEE THE SOFTWARE

INSTRUCTION MANUAL.

NOTE

THIS D VIC COMPLI S WITH PART 15 OF TH FCC RUL S. OP RATION IS SUBJ CT

TO TH FOLLOWING TWO CONDITIONS:

(1) THIS D VIC MAY NOT CAUS HARMFUL INT RF R NC , AND

(2) THIS D VIC MUST ACC PT ANY INT RF R NC , R C IV D, INCLUDING

INT RF R NC THAT MAY CAUS UND SIR D OP RATION.

N te : This equipment has been tested and found to comply with the limits for

a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a residential

installation.

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of the

following measures :

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

NOTE: TH MANUFACTUR R IS NOT R SPONSIBL FOR ANY RADIO OR

TV INT RF R NC CAUS D BY UNAUTHORIZ D MODIFICATIONS TO THIS

QUIPM NT. SUCH MODIFICATIONS COULD VOID TH US R'S AUTHORITY TO

OP RAT TH QUIPM NT.

F ertification

GETTING STARTED

ONTENTS

INTERNET

FEATURES

ABOUT POWER SUPPLY

1-1

1-2

1-3

Getting started...

THIS MANUAL COVERS THE INSTALLATION AND USE OF

THE PLAYER HARDWARE. FOR DETAILS REGARDING THE

SOFTWARE OPERATION INCLUDING TRANSFERRING MUSIC

TO THE PLAYER, PLEASE SEE THE SOFTWARE

INSTRUCTION MANUAL.

NOTE

Getting started...

1-2

Getting started...

1-1

URL : www.iRiver.com

Find information on our company, products, and customer and technical

support.

Update your player with firmware downloads. Firmware upgrades offer

support for new COD CS and deliver new product features.

Consult the product FAQ.

provide support as efficiently as possible.

All contents contained in this manual subject to change without notice to

improve ability of this player or according to changing of specification.

iRiver Limited does not assume any responsibility for errors or omissions in

this document or make any commitment to update the information contained

herein.

iRiver is a registered trademark of iRiver Limited in the Republic of Korea and

/or other countries and is used under license. Microsoft Windows Media and the

Windows Logo are trademarks or registered trademarks of Microsoft

Corporation in the United States and /or other countries.

All other brand and product names are trademarks of their respective

companies or organization. All other product names may be trademarks of the

companies with which they are associated.

INTERNET

Multi-C dec Player

Supports MP3, WMA, OGG and ASF formats.

Firmware Upgrade

Provides the latest updated features via firmware upgrade.

Graphic LCD supp rting Multiple Languages

iFP-700 Series comes with graphic LCD which can support multiple languages (40

languages).

FM Functi n

You can easily listen to FM stations and set your favorite stations by using Auto Preset and

Frequency Memory functions.

6 Preset EQ : Normal, Rock, Jazz, Classic, U Bass, Metal

Xtreme EQ and Xtreme 3D

Customize your own Q with Xtreme Q and enhance bass and surround sound with

Xtreme 3D.

GUI (Graphic User Interface) Menu System

Simple Navigati n

Simple navigation makes it easy to find any song.

Supp rts 8 levels f subf lders, 500 f lders t tal and up t 1500 files at ne time.

Create y ur wn playlists.

Direct Enc ding

11.025KHz ~44.1KHz, 8Kbps ~ 320Kbps

Rec rd FM Radi , V ice, r line-in fr m an ther device

Voice record level is automatically controlled by AGC function.

C nvenient neck strap.

Supp rts USB 2.0 (iFP-780 Supports USB 1.1 only)

FEATURES

Open the battery c ver.

Cl se the battery c ver.

Insert the battery. (AA

1.5V type x 1ea)

Be sure to match the + and -

ends of the battery with the

diagram inside the battery

compartment.

ABOUT POWER SUPPLY

Inserting a battery

Getting started...

1-3

If the battery is worn out, “Low

Battery” is displayed on the LCD.

Insert a fresh battery.

To avoid corrosion, remove the

battery if the player is not to be used

for a long time.

Remove dead battery immediately to

avoid damage from corrosion.

When corrosion occurs, wipe the

battery compartment immediately with

a dry cloth and insert a new battery.

NOTE

Locating the ontrols

ontents

Fr nt View

Side View

LCD Screen

2-1

2-2

2-3

THIS MANUAL COVERS THE INSTALLATION AND USE OF

THE PLAYER HARDWARE. FOR DETAILS REGARDING THE

SOFTWARE OPERATION INCLUDING TRANSFERRING MUSIC

TO THE PLAYER, PLEASE SEE THE SOFTWARE

INSTRUCTION MANUAL.

NOTE

Locating the ontrols

2-2

Locating the ontrols

2-1

Locating the ontrols

Side View

Locating the ontrols

Front View

MIC LCD Screen Volume +

Volume -

(Previous Track/Fast Reverse)

(Next Track/Fast Forward)

NAVI/M NU

ST R O

Power ON/OFF

/(Play/Stop) M MORY/ Q

A-B (Interval repeat)

MOD /R C

USB

Connection

Port

HOLD

LIN IN

Battery

arphones

ASF WMA

OGG MP3

FIL FORMAT

2-3

SONG

NUMB R

BIT RAT

PLAY

TIM PLAYBACK MOD

BATT RY INDICATOR

VOLUM

QUALIZ R

VISUALIZATION

FOLD R NAM

SAMPL RAT

PROGRAM ARTIST/TITL NAM

HOLD

Locating the ontrols

L D Screen

IRM (iRiver Rights Management)

iRiver Rights Management is a digital music format.

Please visit our web site for details about this music format.

IRM

Locating the ontrols

PC s ftware installati n

Attach the player

Detach the player

3-1

3-4

3-7

P software installation

ontents

THIS MANUAL COVERS THE INSTALLATION AND USE OF

THE PLAYER HARDWARE. FOR DETAILS REGARDING THE

SOFTWARE OPERATION INCLUDING TRANSFERRING MUSIC

TO THE PLAYER, PLEASE SEE THE SOFTWARE

INSTRUCTION MANUAL.

NOTE

THIS SECTION COVERS THE INSTALLATION FOR WINDOWS

OPERATING SYSTEMS ONLY. FOR INSTALLATION

INSTRUCTIONS FOR MAC OS, PLEASE SEE THE SOFTWARE

INSTRUCTION MANUAL.

NOTE

P software installation

3-2

P software installation

3-1

P software installation

Software installation

System Requirements (Windows)

Pentium133MHzorfaster

USB port

Window 98S / M / 2000 / XP CD-ROM drive

10MB free hard disk space

Note

The player can store MP3 files or files of any type.

You can upload files, other than music (MP3, WMA, OGG, ASF), to the PC using the iRiver

Music Manager Program.

Download latest versions of drivers and iRiver Music Manager at www.iRiver.com

Insert the Installati n CD int the CD-ROM drive.

The f ll wing screen appears after inserting the CD.

If the installation doesn't automatically begin,

execute the "setup.exe" file in the installation

CD. The installation program will begin.

The installation CD contains the following

contents :

- Device Driver

- iRiver Music Manager

- Manager Program for Mac

Please be sure your login has Administrator privileges if using Windows 2000 or Windows XP.

Please c mplete the steps in this secti n BEFORE ATTACHING YOUR

PLAYER TO YOUR PC.

IMPORTANT

P software installation

Software installation

Click “Next” to Install iRiver Music

Manager. Select the folder to Install.

Click “Next”.

Please n te that the installati n screens may differ slightly fr m th se appearing

here, as s ftware may be f a m re recent versi n. If y ur screens differ, please

visit www.iRiver.c m/s ftware f r an updated user guide.

Note

Insert the Installation CD into the CD-ROM

drive. Installation starts automatically.

Click “Next” after selecting the language to

install.

3-4

3-3

P software installation

Software installation

Click “Install” to begin the installation.

Click “Next” after confirming the

installation folder.

Installation is in progressing.

Click “Finish” after the installation is completed.

Attach the player

onnecting to the P

Connect the USB cable (provided) to the USB port of your computer.

Type “A”

Type “B”

USBportonthePC USB port on the player

USB cable

Type “A”

Type “B”

Turn on the player by pressing the button

marked ST R O. Lift the protective cover

over the USB port and connect the USB

cable to the player.

“USB CONN CT D” will appear on the

LCD screen of the player.

Connect the USB cable to the PC after playback stops to avoid errors.

iFP-780 supports USB 1.1 (Full speed) and iFP-790/ 795/ 799 supports USB 2.0

(High speed) version.

Note

3-6

3-5

P software installation

Attach the player

Installation of New Hardware

Select “Install the software automatically

(Recommended)” and click “Next”. If a "Hardware Installation" warning

message appears, click "Continue

Anyway". (Windows XP)

The iRiver software driver will not cause

any damage to your computer.

After installing iRiver Music Manager from

the CD and connecting the player to your

PC, "Found New Hardware" screen is

displayed.

The computer will automatically search to

find your new hardware.

Attach the player

Installation of New Hardware

Information screen is displayed on the PC. New hardware is installed successfully

and ready to use.

The installation will continue. Click “Finish”

Completed the installation of “New

hardware”.



Windows 98S , Windows M , Windows 2000 O.S do not need any other device

driver installation.



Install New Hardware after installing iRiver Music Manager program.

Note

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels IRiver Lecteur MP3

IRiver

IRiver T20 1GB Manuel utilisateur

IRiver

IRiver Astell & Kern AK380 Manuel utilisateur

IRiver

IRiver T30 512MB Manuel utilisateur

IRiver

IRiver T5 2GB Manuel utilisateur

IRiver

IRiver iFP-300 Series Manuel utilisateur

IRiver

IRiver Simple S7 Manuel utilisateur

IRiver

IRiver N10 Manuel utilisateur

IRiver

IRiver iFP-500 Series Manuel utilisateur

IRiver

IRiver H10 5GB Manuel utilisateur

IRiver

IRiver H10 Manuel utilisateur

IRiver

IRiver astell & kern AK100 Manuel utilisateur

IRiver

IRiver T10 1GB Manuel utilisateur

IRiver

IRiver N10 512MB Manuel utilisateur

IRiver

IRiver astell & kern AK120 Manuel utilisateur

IRiver

IRiver T9 Manuel utilisateur

IRiver

IRiver iFP-799 Manuel utilisateur

IRiver

IRiver S100 Soft Silhouette Manuel utilisateur

IRiver

IRiver H10 Manuel utilisateur

IRiver

IRiver X20 2GB Manuel utilisateur

IRiver

IRiver iHP-140 Manuel utilisateur

IRiver

IRiver T10 Manuel utilisateur

IRiver

IRiver T8 Manuel utilisateur

IRiver

IRiver T10 1GB Manuel utilisateur

IRiver

IRiver H320 Manuel utilisateur

Manuels Lecteur MP3 populaires d'autres marques

Blaupunkt

Blaupunkt Compact Drive MP3 Manuel utilisateur

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manuel utilisateur

Meizu Electronic Technology

Meizu Electronic Technology E5 Manuel utilisateur

Naxa

Naxa NMV-173NX Manuel utilisateur

Philips

Philips PSA250 Manuel utilisateur

Zipy

Zipy go! Waving Manuel utilisateur

Sylvania

Sylvania SMPK4068 Manuel utilisateur

Sony

Sony NW-MS7 - Memory Stick Walkman Manuel utilisateur

Irradio

Irradio RF-42UC Manuel utilisateur

NABAIJI

NABAIJI SWIM MUSIC 100 Manuel utilisateur

Laser

Laser MP3-A9-4GB Manuel utilisateur

Samsung

Samsung YP-T7F Manuel utilisateur

Savant

Savant SMS-1001-00 Guide de référence rapide

Trevi

Trevi XP 71 BT Manuel utilisateur

AGPtek

AGPtek C2 Manuel utilisateur

MobiBlu

MobiBlu DAH-1500i Manuel utilisateur

Denver

Denver MPS-201 Manuel utilisateur

Steren

Steren MP3-002 Manuel utilisateur

IRiver iFP-790 Instructions de montage

Manuels Lecteur MP3 populaires d'autres marques
