IRiver E300 Manuel utilisateur

USER GUIDE

DESIGN BY IRIVER

E300

CONTENTS

Getting Started

Components

Locating the Controls

Power Management

Connecting the Product

Using iriver plus 4

01 03

Using E300

Home Screen

MUSIC

VIDEO


FM RADIO

RECORDING

TEXT

BROWSER

SETTING

FITNESS

Other Information

Important Safety Information

Troubleshooting

Copyrights

Certification

Registered Trademark

Exemption

Components

Getting Started

Components may be changed without prior notice for improvement

of product performance or quality.

The exterior and the contents printed or engraved may differ by model

or according to the name of each part.

E300

USB Cable

Locating

the Controls

Quick Start Guide &

Product warranty

Earphones

Earphones: You can connect this to the product to output sound.

USB Cable: You can connect this to the computer and use it to

recharge the power.

Quick Start Guide: This is the manual explaining how to use our device.

Product Warranty: Please keep this in a safe place for use during any

warranty repairs.

Power

Necklace Connection Loop Line-In Jack Earphones Jack

Micro SD Card Slot

RESET KeyUSB Port

Down

Sub Menu

Upper Menu/Previous

Select MIC

LCD Volume -Volume + Speaker

Necklace Connection Loop: Connects with the necklace.

Power: Turn off the power by pressing and holding. Switch to standby

mode by pressing briefly.

You can switch to the standby mode by pressing it briefly.

Line-In Jack: Connects external device when Line-in recording.

Earphone Jack: Connect earphone here.

USB Port: Connect to computer or recharge the battery using this port.

RESET: Resets the product.

Micro SD Card Slot: Inserts the Micro SD card to

view and replay the files on the card.

LCD: Screen displays.

Volume: Controls the sound volume.

Speaker: Produces sounds.

MIC: Records voice.

Direction Key: Moves menu/list.

Access Key: Executes file/menu.

Getting Started

Power

Management

1. Press and hold the [ ] until power comes on.

2. If you press and hold the [ ] when the product is turned on,

then the power will be turned off.

Power on/off

This model supports an automatic power-saving feature to minimize battery

consumption. Depending on [SETTING – Timer Settings - Auto Power off], the

product will be automatically turned off when keys are not operated for a specified

time. (Refer to page 25)

Even if you use reset function, current time and memory data will be preserved.

Do not use reset function while the product is playing. It may cause severe damage

to its memory.

1. If you press the [ ] button while using the device, it will be locked.

2. Unlock the device by pressing the [ ] button again.

Using the Hold Function

1. If buttons will not work while the device is being used, open the

cover of Micro SD card slot to release the cap and then press [RESET].

Using the Reset Function

To avoid malfunctions, only use the USB cable provided.

Verify that the product is connected to a high-power USB 2.0 port. Some low-power

USB ports built into certain peripheral devices, such as some types of keyboards

and USB hubs without internal power may not provide enough power to charge.

While the PC is switched to standby mode, the product may not be charged.

1. Turn on your computer.

2. Connect the product to your computer. The internal battery will

charge automatically.

Charging the Battery

Getting Started

Connecting

the Product 1. Connect the earphones to the earphone jack.

Connecting Earphones

1. Turn on the power of the device and computer.

2. If you connect the device to your computer, you will see the screen

where you can select connection mode.

- Power & Data: The connection between the product and the

computer is established and you can start transferring data.

- Power & Play: The product is currently being charged and a file is

being played.

- Power Only: The product is currently being charged.

Connecting to Your Computer

Do not use cables other than the USB cable provided. It may cause malfunction.

For successful computer/USB connection, disable all functions.

Check that the product is connected to a high-power USB 2.0 port. Connecting to a

keyboard or a USB hub without a power supply of its own may result in malfunction.

File system does not support other than FAT32. Format this device into FAT32.

Turn the product off when charging. Leaving the device turned on during recharge

may prevent “Charge Complete” from being displayed.

The battery will be fully charged within about 4 hours 30 minutes. (Based on fully

discharged, power Off).

Charging times may vary if device is used during recharge.

Charge and store the product only at room temperature. Do not expose the device to

extremes in temperature while recharging. The rechargeable battery is a consumable

and the available usage time of charged battery becomes shorter over time.

Getting Started

1. Safely disconnect the product from your computer by clicking the

icon on the taskbar of the computer screen.

2. Confirm the device disconnection by clicking [Confirm].

Disconnecting from your computer

1. After selecting files/folders to copy from your computer, drag and

drop the selected file/folder to the added drive.

2. Files (or folders) will be transferred to folders below according to

their content type.

- Music : Music - Pictures : Pictures

- Video : Video - Text : Text

Copying Files (Folders) to the Product

Depending on the operating system for example Windows XP, the icon may be

hidden from the taskbar. Hidden icons can be displayed by clicking indicator.

Safe disconnection may not be performed if application programs such as Windows

Explorer or Windows Media Player are being used.

Make sure that the product is safely disconnected after all the active application

programs are closed. If safe disconnection fails, try again later. Failure to safely

disconnect result in data loss.

Please connect the USB cable properly.

If the power of the computer or product is turned off or the USB cable is

disconnected while copying or moving files/folders, serious damage to the memory

may result.

Transfer rate may differ depending on the computer or OS environment available for

your region.

It is recommended to save music, video, text and document files using iriver plus 4.

When saving through a removable disk, rebuild Database in [SETTING – Advance

Settings - Rebuild Library]. (Refer to page 25)

Getting Started

1. Select the files/folders to be deleted, right-click on them and select

[Delete].

2. Click [Yes] when the [Confirm File/Folder Deletion] window pops up,

and the selected files/folders will be deleted.

Deleting Files (Folders) from the Product

1. Turn the power off, place the SD card (see the figure below) in the

SD card slot, and press gently.

2. Press it in once more and the card can be removed.

Inserting/removing the Micro SD card

Brand: SanDisk, Transcend

Recommended SD cards

Getting Started

Insert/remove the Micro SD card while the power is off.

Do not force the Micro SD card. It may cause malfunction and damage to the Micro

SD card.

Do not remove the Micro SD card when in use. It may delete data, cause

malfunction, or damage the Micro SD card.

Please do not repeatedly insert/remove the Micro SD card.

If the Micro SD card is not positioned properly, the product may malfunction or the

card may become stuck.

Use only the recommended Micro SD cards. The use of other Micro SD cards may

cause malfunction.

The transfer rate of the Micro SD card may differ according to the computer status.

When formatting a Micro SD card, all the data are deleted. Make sure that the data

is backed up before formatting.

Format the a Micro SD card to FAT 32 system.

If a Micro SD card is not recognized or malfunctions, reformat and retry.

Micro SD cards can be purchased separately.

It is recommended that you use a Micro SD card up to 32GB.

Please download the iriver plus 4 software program from the iriver website

(www.iriver.com).

Minimum computer specifications are:

Windows® XP

- Intel® Pentium® 233MHz or above

- Memory: 64MB or above

- 30MB or more free space

- 16bit Sound Card and Speaker

- Microsoft Internet Explorer V 6.0 or above

- SVGA or high-resolution monitor (min 1024x768 resolution)

Using

iriver plus 4 iriver plus 4 is integrated software that manages a variety of multimedia

files. Using iriver plus 4, you can transfer files on the computer to the

product and do automatic firmware upgrade.

1. After installing the iriver plus 4 software program, you will see the

installation guide screen appearing.

2. Follow the step-by-step instructions on the screen to complete

the installation process.

Installation

Getting Started

Windows® Vista Specifications

(For Windows® Vista, note that only the 32-bit version will be supported.)

- Intel® Pentium® 800MHz or above

- Memory: 512MB or above

- 20MB or more free space

- 16 bit Sound Card and Speaker

- Microsoft Internet Explorer V 6.0 or above

- SVGA or high-resolution monitor (min. 1024x768 resolution)

Windows® 7 Specifications (For Windows® 7, note that only 32-bit version will be

supported.)

- 1GHz or above, 32-bit processor

- Memory: 1GB or above

- 16GB or more free space

- DirectX 9 Graphic Device with WDDM 1.0 higher Drive

- SVGA or high-resolution monitor (min. 1024x768 resolution)

- Maximum file size for transfer: 4GB.

1. When iriver plus 4 is first run, the Add Media Wizard will be executed.

2. According to the screen instructions, you can add to the library

media files such as music, and e-books stored in the computer.

Adding Media to the Library

1. Insert a music CD into the CD drive and execute iriver plus 4.

2. Select the music checkboxes you want to extract from [CD] tab in

iriver plus 4 and click [CD Ripping] at the bottom left.

3. When the music extraction is complete and [All Music] is selected,

you will see the extracted music files added to the library.

Extracting Media from a CD

1. Connect the product to your computer’s USB port and then

execute iriver plus 4.

Transferring Media to the Product

Getting Started

Table des matières

Autres manuels IRiver Lecteur MP3

IRiver

IRiver T8 Manuel utilisateur

IRiver

IRiver E200 Manuel utilisateur

IRiver

IRiver iFP-790 Instructions de montage

IRiver

IRiver iFP-1090 Instructions de montage

IRiver

IRiver T30 512MB Manuel utilisateur

IRiver

IRiver X20 2GB Manuel utilisateur

IRiver

IRiver N10 512MB Manuel utilisateur

IRiver

IRiver H10 20GB Manuel utilisateur

IRiver

IRiver iFP Series Manuel utilisateur

IRiver

IRiver Spinn 4GB Manuel utilisateur

IRiver

IRiver S10 1GB Manuel utilisateur

IRiver

IRiver MP3 Player T30 Manuel utilisateur

IRiver

IRiver N10 Manuel utilisateur

IRiver

IRiver X20 8GB Manuel utilisateur

IRiver

IRiver iFP-590 Manuel utilisateur

IRiver

IRiver Astell & Kern AK100 II Manuel utilisateur

IRiver

IRiver B30 Manuel utilisateur

IRiver

IRiver S100 Soft Silhouette Manuel utilisateur

IRiver

IRiver S100 Soft Silhouette Manuel utilisateur

IRiver

IRiver iFP-380T Manuel utilisateur

IRiver

IRiver Data Play IDP-100 Manuel utilisateur

IRiver

IRiver E100 4GB Manuel utilisateur

IRiver

IRiver H10 Manuel utilisateur

IRiver

IRiver iFP-195T Comment utiliser

Manuels Lecteur MP3 populaires d'autres marques

Blaupunkt

Blaupunkt Compact Drive MP3 Manuel utilisateur

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manuel utilisateur

Meizu Electronic Technology

Meizu Electronic Technology E5 Manuel utilisateur

Naxa

Naxa NMV-173NX Manuel utilisateur

Philips

Philips PSA250 Manuel utilisateur

Zipy

Zipy go! Waving Manuel utilisateur

Sylvania

Sylvania SMPK4068 Manuel utilisateur

Sony

Sony NW-MS7 - Memory Stick Walkman Manuel utilisateur

Irradio

Irradio RF-42UC Manuel utilisateur

NABAIJI

NABAIJI SWIM MUSIC 100 Manuel utilisateur

Laser

Laser MP3-A9-4GB Manuel utilisateur

Samsung

Samsung YP-T7F Manuel utilisateur

Savant

Savant SMS-1001-00 Guide de référence rapide

Trevi

Trevi XP 71 BT Manuel utilisateur

AGPtek

AGPtek C2 Manuel utilisateur

MobiBlu

MobiBlu DAH-1500i Manuel utilisateur

Denver

Denver MPS-201 Manuel utilisateur

Steren

Steren MP3-002 Manuel utilisateur
