Installation
To install the IRIS106 you will need the following tools:
• Drill Bit for Pilot Holes (2mm)
• 3mm Hex Key (Supplied)
• Drilling Template (Supplied)
• Hand tools for connecting cables (unless pre-made cables are being
used), including wire cutters, wire stripper, and cross headed screw
driver.
• Appropriate tool for terminating BNC connector (unless pre-made
cables are being used), such as knife to remove coax cable outer
sheath and dielectric, BNC Crimp Tool, Cable Insulation Stripper.
• Marine Sealant
Before you begin the installation, please take time to consider the
following important points:
• Always wear safety goggles, dust mask and ear protection when
drilling, cutting or sanding. Where suitable gloves when handling fibre
glass and GRP.
• Before drilling or cutting always ensure there are no obstructions,
cables or equipment on the opposite side of the surface you're working
on. Also ensure there is sufficient space behind the surface to
accommodate the body of the camera, and cabling and ensure you can
get the necessary cables to the camera position.
• Observe safe working procedures when working with electricity. Do not
connect the equipment to live power sources until correct, safe
termination through an appropriately rated fuse or breaker is made. Do
not attempt to install this product unless you are a certified electrical
installer. Failure to do so could result in injury or death.
• It is advised that before the equipment is fixed down, check that
desired viewing angles can be achieved in the intended installation
position, and that the equipment will not obstruct other equipment or
