User Manual
IR IP Camera

2/42
WARINGS
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MISTURE.
DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS.
CAUTION
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
COPYRIGHT
THE TRADEMARKS MENTIONED IN THE MANUAL ARE LEGALLY REGISTERED
TO THEIR RESPECTIVE COMPANIES.

3/42
Content
I.
PREFACE....................................................................................................................................... 4
II.
PRODUCT SPECIFICATIONS ....................................................................................................... 4
III.
PRODUCT INSTALLATION ........................................................................................................... 7
A.
M
ONITOR
S
ETTING
..................................................................................................................................... 7
B.
H
ARDWARE
I
NSTALLATION AND
I/O
P
IN
A
SSIGNMENT
............................................................................... 8
C.
IP
A
SSIGNMENT
....................................................................................................................................... 11
D.
I
NSTALL
A
CTIVE
X
CONTROL
:................................................................................................................... 13
IV.
LIVE VIDEO.................................................................................................................................. 15
V.
SYSTEM CONFIGURATION........................................................................................................ 18
A.
S
YSTEM
.................................................................................................................................................... 19
B.
N
ETWORK
................................................................................................................................................ 22
C.
A/V
S
ETTING
........................................................................................................................................... 29
D.
E
VENT
L
IST
.............................................................................................................................................. 36
VI.
NETWORK CONFIGURATION .................................................................................................... 40
VII.
FACTORY DEFAULT.................................................................................................................... 42
VIII.
PACKAGE CONTENTS ............................................................................................................... 42
APPENDIX I .......................................................................................................................................... 42
V1.1_110905

4/42
I. Preface
IR IP CAMERA is a professional CCD IP camera. It has built-in web server which
enables user to view real-time video via IE browser. It also supports
simultaneously H.264, MPEG-4&JPEG video compression and dual streaming
which provides smooth and high video quality. The video can be stored in the SD
card, and can be playback remotely.
IR IP CAMERA is an easy-to-use IP Camera which is designed for security
application.
II.Product Specifications
Video Out
High Definition Resolution at 30FPS support(720P)
IP66
External Vari-focal lens adjustment
True Day/Night Function
Mechanism IR Cut Filter Available
Fan Built-in
IR Distance: 40/30 Meter
H.264/ JPEG/ MPEG4 compression
Support Cell Phone/PDA/3GPP
Triple streaming
SDK for Software Integration
Free Bundle 36 ch recording software
Specifications
Hardware
CPU ARM 9 ,32 bit RISC
Memory 256MB
Flash 16MB
Sensor 1/3” CMOS(2M-Pixel)
Sensitivity 0 Lux(IR on)

5/42
Lens 30M/40M: Vari-Focal Auto Iris 3.6~16mm
Fan Always On
ICR Yes
LED
56 Unit 5φ850nM infrared LED, 10000hrs
(40M)
42 Unit 5φ850nM infrared LED, 10000hrs
(30M)
IR DISTANCE 40M/30M
I/O 1 in/ 1out(Relay Out)
Video Out 1
Power Consumption DC 12V
Water Resistance IP66
Dimensions 114mm(ψ) x 260mm(D) (With Shield)
99.4mm(ψ) x 225mm(D) (Without Shield)
Network
Ethernet 10/ 100 Base-T
Network Protocol HTTP, UDP,TCP/ IP, SMTP, FTP, PPPoE,
DHCP, DDNS, NTP
Wireless (Optional)
Wireless 802.11b/g
Security WEP,WPA-PSK,WPA2-PSK
System
Video Resolution 1600x1200, 1280x1024, 1280x960,1280x720,
800x600,640x480, 320x240, 176x144
Video adjust Brightness, Contrast, Sharpness,BLC,Night
Mode
Triple Streaming Yes
Image snapshot Yes
Full screen monitoring Yes
Privacy Mask Yes
Compression format H.264/JPEG/MPEG4(3GPP only)
Video bitrate adjust CBR, VBR
Motion Detection Yes, 3 different areas
Triggered action Mail, FTP, Relay
Pre/ Post alarm Yes, configurable
Security Password protection

6/42
Firmware upgrade HTTP mode, can be upgraded remotely
Simultaneous connection
Up to 10
Web browsing requirement
OS Windows 2000, XP, 2003, Microsoft IE 6.0 or
above
Hardware
Suggested
Intel Dual Core 1.66G,RAM: 1024MB, Graphic
card: 128MB
Minimum Intel-C 1.6G, RAM: 256MB, Graphic card: 32MB
*SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.

7/42
III. Product Installation
A. Monitor Setting
i. Right-Click on the desktop. Select “ Properties”
ii. Change color quality to highest (32bit).

8/42
B. Hardware Installation and I/O Pin
Assignment
i. Connect a power adapter and IP Camera to PC or local network
ii. I/O Control Instruction
I/O terminal connector – used in application, for e.g., motion detection, event
triggering, alarm notifications. It provides the interface to:
1 Digital Input (GND+Alarm) – An alarm input for connecting devices that can
toggle between an open and closed circuit, for example: PIRs, door/window
contacts, glass break detectors, etc. When a signal is received the state changes
and the input becomes active.
Relay output (COM +N.O.) / (COM+N.C.) – An output to Relay switch, for
example: LEDs, Sirens, etc
iii. Digital Input
Alarm Input
1. GND (Ground) : Initial state is LOW
2. Alarm : Max. 50mA, DC 3.3V
Relay Output
1. N.C. (Normally Close): Max. 1A, 24VDC or 0.5A, 125VAC
2. COM: (Common)
3.5mm Phone Jack (Audio Input, Red)
3.5mm Phone Jack (Audio
Out
put,
Green
)

9/42
3. N.O. (Normally Open): Max. 1A, 24VDC or 0.5A, 125VAC
Relay
1. Digital Input connection
GND
ALARM
N.C.
COM
N.O.
Door/Window
Contacts
ALARM IN
RELAY OUT

10/42
2. Relay Output Connection
Or
GND
ALARM
N.C.
COM
N.O.
GND
ALARM
N.C.
COM
N.O.
