Thank you for purchasing our welding machine. Before using the product,
please read and follow the instructions and safety instructions carefully.
These instructions apply to IPOTOOLS brand products purchased in Europe.
INSTRUCTION MANUAL
MIG-160ER
1
TABLE OF CONTENT
MAIN FUNCTIONS .................................................................................................................................. 2
SAFETY MEASURES ............................................................................................................................. 3
TECHNICAL INFORMATION .................................................................................................................. 5
OPERATING CONDITIONS & WORKING ENVIRONMENT .................................................................. 6
BEFORE STARTING WORK .................................................................................................................. 6
CONTROL PANEL .................................................................................................................................. 7
WELDING WIRE INSTALATION ............................................................................................................. 8
CONNECTION & SETTINGS .................................................................................................................. 9
MIG/MAG welding with/without gas: ..................................................................................................... 9
MMA Welding ..................................................................................................................................... 10
WELDING TIPS ..................................................................................................................................... 11
MIG MAG WELDING – WHICH WELDING WIRE? .............................................................................. 12
TROUBLESHOOTING .......................................................................................................................... 12
PROPER DISPOSAL ............................................................................................................................ 14
MANUFACTURER WARRANTY ........................................................................................................... 14
MIG-160ER
2
Dear customer!
Thank you for choosing to purchase our welding machine. Please read the instructions carefully for safe
use and trouble-free operation of the device. Follow the instructions strictly for safe work!
The IPOTOOLS welding devices are suitable for private users in the hobby sector.
MAIN FUNCTIONS
MIG MAG WELDING
Direct current (DC) gas protection welding with inert gas “MIG welding” (e.g. – argon)
or with active gas “MAG welding” (a mixture of carbon dioxide CO2 and argon)
WELDING WITH FLUX CORED WIRE
Welding with FLUX cored wire (welding without protective gas)
MMA
Welding with stick electrodes
DIGITAL DISPLAY
Digital control of the individual welding parameters
INVERTER
Modern IGBT technology, which provides high power and long duty cycle
MIG-160ER
3
SAFETY MEASURES
Caution: Improper use of any welding machine can result in injury or death.
CONNECT THE WELDING APPLIANCE ONLY TO THE APPROPRIATE ENERGY SOURCE. This
information is given on the rating plate on the welding machine. When welding outdoors, use only an
extension cord designed for such use.
WORK WITH THE APPLIANCE ONLY ON A DRY AREA AND ON A SOLID GROUND. Make sure the
work area is clean and tidy.
MAKE SURE THERE ARE NO FLAMMABLE SUBSTANCES IN THE WORKING AREA.
KEEP CLEAN CLOTHES WITHOUT TRACE OF GREASE OR OIL AT WORK.
MAKE SURE THE CABLES DO NOT COME INTO CONTACT WITH GREASE OR OIL and never
wrap them around your shoulders.
SAFE WORK WITH CLAMPS or in other means, do not overdo it.
NEVER ESTABLISH AN ARCH ON A PRESSURE GAS TANK.
THE UNINSULATED PART OF THE ELECTRODE HOLDER SHOULD NEVER TOUCH THE
GROUND WHILE THE CURRENT IS FLOWING!
IT IS NECESSARY TO TURN OFF AND DISCONNECT THE CABLES WHEN REPAIRING OR
ADJUSTING THE APPLIANCE. Check the device before each use. Use only original spare parts.
FOLLOW ALL MANUFACTURER'S RULES regarding modification, and adjustment of the device.
APPROPRIATE PROTECTIVE NON-FLAMMABLE CLOTHING AND FOOTWEAR AGAINST HEAT
AND FLAMMES MUST BE CARRIED AT WORK. The welder should be dressed in a work suit made
of non-combustible fibbers during welding. The dress should be dry, clean, not too loose and without
cut-outs or pockets. Shoes should be closed, high. The use of non-flammable gloves, a hat, a
protective mask, and a leather apron is mandatory. Low shoes, self-made fibber dresses and short
gloves are not suitable for welding.
ALWAYS WARE A WELDING MASK WITH APPROPRIATE EYE PROTECTION WHEN WELDING.
Sparks can cause blindness during welding, so always wear protection under the welding mask.
BE CAREFUL OF HOT METAL PARTS, ESPECIALLY WHEN WELDING OVER YOUR HEAD.
Always wear head, arm, leg, and body protection.
MAKE SURE YOU HAVE A FIRE EXTINGUISHER ALWAYS AT YOUR HAND.
DO NOT SKIP THE MACHINE OPERATING CYCLE. The estimated cycle of the welding machine is a
percentage of ten minutes, with this in mind the machine can operate safely in terms of output power.
PREVENT CHILDREN, ANIMALS AND THIRD PARTIES FROM ACCESSING THE WORK AREA.
When storing equipment, make sure it is out of the reach of children.
PROTECT YOURSELF AGAINST ELECTRIC SHOCK. Do not work when you are tired or under the
influence of drugs, alcohol, or other illicit substances. Do not allow the body to come into contact with
grounded surfaces.
SPECIAL WARNINGS:
Welding is not allowed in rooms with flammable and explosive materials,
it is not allowed to weld in / on containers where there were gases, oils, paints…,
more demanding welds should be welded only by certified welders,
persons with a pacemaker should consult a doctor before welding.
MIG-160ER
4
Before welding, always make sure that all regulations and instructions for safe work are met.
When welding by MIG / MAG process, the noise can be higher than 85db (A), so the worker must
wear non-flammable earmuffs during welding.
Welding produces strong UV rays that can burn uncovered parts of the body.
The protective glass on the mask should be numbered 9-15 according to DIN 4647.
Do not look into the electric arc during welding, as there is a risk of instantaneous glare.
Only weld when there is another person nearby who can give you first aid in case of injury.
PEOPLE IN THE VICINITY MUST FOLLOW THE INSTRUCTIONS ABOVE!
In the rooms where we weld, it must be sufficiently airy, suction is desirable. Ventilation device to
protect against particles must be available during welding. Toxic gases are formed especially when we
weld material that is galvanically coated with other metals or materials with detergent residues. Do not
weld closed containers containing flammable liquids (petrol, oil, varnishes…) as there is a high risk of
explosion!
FIRE HAZARD
Follow these instructions:
Remove combustible materials within 5m of the welding site
Cover openings, cracks, and other objects that can trap sparks
Keep fire extinguishers nearby
After welding, inspect the welding area again
Do not weld on containers with flammable liquids
Shielding gas cylinders must be protected against mechanical damage and excessive heat (max. 50 C).
cylinders must also be protected from frost.
DANGERS OF ELECTRIC CURRENT
The device can only be connected to the mains with a shielded connection cable. The fuse must be of
the same power as specified in the technical data of the device. The fuse design must be slow.
Replace damaged torch parts, cable ground, or damaged mains connector immediately. Replacement
of parts on the network, replacement of the connecting cable can only be performed by an authorized
person. Never hold the burner under your arm or otherwise wrapped around your body. In the event of
prolonged work interruptions, switch off the appliance and close the shielding gas supply.
In the event of an accident, immediately pull out the plug of the connecting cable!
MIG-160ER
5
PURPOSE AND USE
The IPOTOOLS MIG160ER is a welding machine with two welding functions. You can use it for MMA
and MIG / MAG welding. Any other use may endanger the safety of the welder or cause the device to
malfunction! Use of the device in violation of these operating instructions is not permitted! Damage to
the device resulting from improper use is not covered by the warranty statement. The machine can be
used to weld several materials, such as steel and stainless steel. The welding current is stable and
stepless adjustable. The appliance provides a beautiful weld, and the welding itself takes place quietly
and without spattering. The device is small in size, light and thus easy to transport.
TECHNICAL INFORMATION
Type MIG MAG Inverter Welding Machine MIG-160ER
Welding procedures MMA & MIG/MAG, LIFT TIG
Connection voltage 230V 1-Phase / Frequency: 50/60Hz
Housing protection IP21S
Overload display Yes
Cooling Fan
Magnetic valve Yes
MIG Duty Cycle 160A – 60% / 125A – 100%
MMA Duty Cycle 160A – 60% / 125A – 100%
Welding current MIG 40-160A / MMA: 40-160A
No-load Voltage 60 – 65 V
Welding Wire Ø MIG 100mm / Wire Ø MIG: 0,8/1,0mm
Wire feed 2 Wheels (1 with drive)
Max. welding wire diameter Ø 0,6mm / 0,8mm / 0,9mm / 1,0mm
MMA electrode diameter 1-4mm
Dimensions 360x150x350mm
Weight 8 kg
Note: The above parameters may change with future machine improvements!
MIG-160ER
6
OPERATING CONDITIONS & WORKING ENVIRONMENT
1. Operating conditions:
Voltage, voltage source: AC 220 V/230V/240V,
Frequency: 50/60Hz,
Reliable grounding.
2. Work environment
Relative humidity: not more than 90%,
Ambient temperature: -10 ℃ ~ 40 ℃,
The welding site must not contain any harmful gas, chemicals, mold and flammable
substances, explosive and corrosive media. The welder must not be subjected to any vibration
or other disturbances,
Avoid rain and water, work in such circumstances is prohibited.
BEFORE STARTING WORK
Before welding, it is necessary to read and understand the instructions of use,
Check the machine for any defects or damage,
To ensure the safety of persons and equipment, it is necessary to properly install the earthing with a 4
mm2 conductor, depending on the requirements of the power supply system,
Welding must take place in a dry and well-ventilated area. Objects in the vicinity must be at least 0,5 m
away from the appliance,
Check that all cables are tightly fastened / connected,
The appliance must not be moved while the appliance is switched on and welding is in progress.
The appliance must be maintained, used, and operated by a qualified person,
Distribution board current: less than 40A.
MIG-160ER
7
CONTROL PANEL
Description of the control panel and the front and back of the appliance:
1. Digital display: Amps
2. Overload display
3. Choice: FLUX / MIX / Co2 / LIFT TIG / MMA
4. Control knob: Wire / ampere feed
5. Control knob: Voltage (deviation +/- 10V)
You can see more on our website!
MIG-160ER
8
6. Control panel
7. Connection "+"
8. Connection "-"
9. On / off switch
10. Connection cable
11. Shielding gas supply
12. "+" Pol
13. "-" Pol
14. Star grip (tension lever)*
15. Welding wire reel holder
* Be careful not to overtighten the tensioner lever when mounting the wire!
WELDING WIRE INSTALATION
- Open the door on the side of the device, move the star knob towards you and lift the lid of the clamping
system.
- Make sure that, depending on the welding wire diameter, the appropriate wire feed roller (e.g. 0.8mm,
1,0mm, etc.) is in the wire feed system (the wire feed roller side with the correct mm specification must
point towards the wire feed).
- Unscrew the screw of the wire locating pin, place the corresponding welding wire on the wire locating
pin and retighten the screw (The welding wire must be positioned so that it enters the wire feeder from
its lower part.)
MIG-160ER
9
- Guide the welding wire into the right opening of the wire feeder, over the wire feed roller into the left
opening of the wire feeder.
- Close the cover of the clamping system and move the star grip away from you so that the cover is
locked. Adjust the tensioner with the star grip (e.g., with 0,9 mm wire to 3.5). Do not turn the tensioner
past value 5!
- The next step is to turn on the unit, make sure the torch cord is straight and remove the nozzle and
nozzle assembly from the gun.
- You can then pull the wire to the torch nozzle either with the button on the torch or with the “Fast Wire
Drive” button. After the wire comes out of the gun, reattach the nozzle and nozzle assembly to the gun.
CONNECTION & SETTINGS
MIG/MAG welding with/without gas:
Connect the torch and the earth cable correctly, depending on whether you want to weld with or
without gas (filler wire).
Filled wire welding (without gas)
Set the appliance to "FLUX" by pressing the button (3)
