1.0 SAFETY WARNINGS
Please read and observe all warnings contained in this operations manual before any attempt to
operate the equipment.
Misuse of Equipment
Misuse of the Equipment can cause serious injury. Use the equipment only for its intended purpose.
Care should be taken to prevent over pressurization of the pump or accessories connected to it. Use
only proper parts in good condition. Use the pump only with compatible fluids. Improper use or
misuse of this equipment could result in fluid being splashed on the skin or in the eyes, serious bodily
injury, property damage, fire or explosion.
Make daily check on the equipment and repair damaged or worn parts immediately.
Do not alter this equipment, doing so could cause it to function incorrectly and could cause serious
injury.
Material & Fluid compatibility
Always ensure the chemical compatibility of the fluids and solvents with the wetted parts in the pump
and any components. Check the fluid manufacturer’s data sheets and specifications before using the
fluids or solvents in this pump.
Pressurized Hoses
Because the hoses are pressurized, they present a danger should the fluid escape at high pressure.
This escaping fluid pressure can spray out and cause serious bodily injury or property damage.
Ensure that the hoses do not leak or rupture due to wear, misuse or damage.
The hoses should be handled properly - do not pull on the hoses to move the equipment around. Use
the hoses only for fluids in which they are compatible both for the inner liner of the hose and the outer
covering. Use care not to exceed the temperature rating of the hose.
Before each use, ensure that the fluid couplings are tight and that the entire length of hose is not
worn or damaged. Check the entire hose for leaks, bulging cover, damage, abrasion or cuts. These
conditions may cause the hose to fail that could result in splashing of pressurized fluid on the skin, or
in the eyes and cause serious bodily injury or property damage.
Pressure Specification
The maximum working fluid pressure of this equipment is 180 psi (12.5bar) at the maximum incoming
air pressure of 180 psi (12.5bar). Ensure all equipment and accessories used with this pump are
rated to withstand the maximum working pressure of this pump. Never exceed the maximum working
pressure of the pump or any device attached to the pump.
Procedure for Pressure Relief
In order to avoid the risk of serious bodily injury such as splashing fluid on the skin or in the eyes, or
risk of injury from moving parts, the following procedure should be used. This procedure should be
used when shutting down the pump, when servicing or repairing the pump or any part of the system,
when replacing or cleaning components, or when pumping of fluid is stopped.
1. Close the air valve to the pump.
