switching point with release position
programmed parameters: SP.1: 100.0°C
rP.1: 40.0°C
An increasing temperature up to SP.1 (e.g. 100°C), switches the output according to the
adjusted switching function (no or nc). This state remains also for higher temperatures.
For decreasing temperatures the switching state changes with the temperature value at
rP.1 (e.g. 40°C). If SP.1 will be changed, rP.1 remains the same.
The minimum range between SP1 and rSP.1 is 1% of the maximum temperature.
switching point with hysteresis
programmed parameters: SP.1: 50.0°C
HYS.1: 30.0°C
An increasing temperature up to SP.1 (e.g. 50°C) switches the output according to the ad-
justed switching function (no or nc). This state remains also for higher temperatures.
For decreasing temperatures the switching state changes after passing the hysteresis (e.g.
30°C). If SP.1 will be changed, the hysteresis HYS1 remains the same, that means the re-
lease position is (SP.1 – 20°C).
temperature [°C]
switching pointrelease position
switching point
temperature [°C]
switching pointswitching point
hysteresis HYS1
100
