Adjustment and programming
On delay:1. Connect the sensor with the M12-socket of the time module and switch on the operating voltage.
The connection can be made by a 4-wire cable socket, e.g. VK200321.
2. Connect the teach input A (PIN 2, white) to +UB(PIN 1, brown).
3. Activate the sensor. The time the sensor is activated corresponds to the delay at a later time.
4. Release the teach-input from +UB.
Off delay:1. Connect the sensor with the M12-socket of the time module and switch on the operating voltage.
The connection can be made by a 4-wire cable socket, e.g. VK200321.
2. Activate the sensor.
3. Connect the teach input A (PIN 2, white) with +UB(PIN 1, brown).
4. Disconnect the sensor. The time the sensor is not activated corresponds to the delay at a later
time. If you wish an off delay of 4s, disconnect the sensor for 4s and activate it again.
5. Disconnect the teach-input from +UB.
Reset to factory settings:Connect the teach input A (PIN 2, white) for at least 10s to +UB(PIN 1, brown). During this time
the sensors’s state must not be changed! The device operates now with an off delay
of 100ms.
SAFETY WARNINGS:
Before initial operation, please make sure to follow all safety instructions that may be provided in the product infor-
mation!
Never use these articles in applications where the safety of a person depends on their functionality.
