IP Camera IP Vandal Dome Manuel utilisateur

1/39

User Manual

IP Vandal Dome

2/39

WARINGS

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

PRODUCT TO RAIN OR MOISTURE.

DO NOT INSERT ANY METALLIC & ELETRIC CONDUCTIVE OBJECT THROUGH

VENTILATION GRILLS.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION：TO REDUCE THE RISK OF ELECTRIC SHOCK.

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

THE TRADEMARKS MENTIONED IN THE MANUAL ARE LEGALLY REGISTERED

TO THEIR RESPECTIVE COMPANIES.

3/39

Content

I. PREFACE.....................................................................................................................................................4

II. PRODUCT SPECIFICATIONS.................................................................................................................4

III. PRODUCT INSTALLATION................................................................................................................6

A. MONITOR SETTING.....................................................................................................................................6

B. HARDWARE INSTALLATION ........................................................................................................................7

C. IPASSIGNMENT .......................................................................................................................................10

D. INSTALLACTIVEXCONTROL:...................................................................................................................13

IV. LIVE VIDEO.........................................................................................................................................15

V. IPVANDALDOME CONFIGURATION................................................................................................17

A. SYSTEM ...................................................................................................................................................18

B. NETWORK................................................................................................................................................22

C. A/V SETTING ...........................................................................................................................................26

D. EVENT LIST..............................................................................................................................................34

VI. NETWORK CONFIGURATION........................................................................................................37

VII. FACTORY DEFAULT..........................................................................................................................39

VIII. PACKAGE CONTENTS......................................................................................................................39

APPENDIX I......................................................................................................................................................396

V1.00

2008/08/13

4/39

I. Preface

IP Vandal Dome is a professional CCD IP Vandal Dome. It has built-in web server

which enables user to view real-time video via IE browser. It also supports

simultaneously MPEG-4&JPEG video compression and dual streaming which

provides smooth and high video quality. The video can be stored in the SD card,

and can be playback remotely.

IP Vandal Dome is an easy-to-use IP Camera which is designed for security

application.

II.Product Specifications

zSupport PoE (Power Over Ethernet) - Optional

zSupport IP66 (Weatherproof)

zSupport Dual streaming

zHigh Resolution (540 TV Lines)

zTrue Day/Night function, removable IR Cut Filter, ICR (Optional)

zVandal Proof (Polycarbonate shell withstand impact up to 400 pounds)

zMPEG4/ JPEG compression

zSupports SD card for local recording

z2-way audio

zSupport Cell Phone/PDA

zSupport 3GPP

zOnline firmware upgrade

zCompatible with Microsoft Windows Media Player

Specifications

Hardware

Model CDV-3V930MU CDV-3V930HU

Picture Elements H×V NTSC：510×492, PAL：500×582 NTSC：768×494, PAL：752×582

Horizontal Resolution More than 420 TV Lines More than 540 TV Lines

Image sensor 1/3” CCD

Lens Changeable 3.7~12mm vari-focal lens,F1.6

IR LED IR LED Built-in (optional)

CPU ARM 9 ,32 bit RISC

5/39

SDRAM 64MB

Flash 8MB

Video Out 1 Vp-p, 75 Ohms

I/O 1 in/out Relay out (COM. & N.O.)

Audio in 1

Audio Out 1

Power Consumption DC 12V, 490mA

Dimensions (W×H×D) 126 x 126 x 100 mm

Weatherproof IP66

Vandal Proof Polycarbonate shell can withstand impact up to 10 pounds

Network

Ethernet 10/ 100 Base-T

Network Protocol HTTP, TCP/ IP, UDP, SMTP, FTP, PPPoE, DHCP, DDNS, NTP,

3GPP, UPnP

System

Video Resolution NTSC：720x480, 704x480,352x240, 176x120

PAL：720x576, 704x576, 352x288, 176x144

Video adjust Brightness, Contrast, Saturation, Hue

Power Over Ethernet(PoE) Optinal

Dual Streaming Yes

CCD setting BLC

Image snapshot Yes

Full screen monitoring Yes

Compression format MPEG-4/ JPEG

Video bitrate adjust CBR, VBR

Motion Detection Yes, 3 different areas

Triggered action Mail, FTP, Save to SD card

Pre/ Post alarm Yes, configurable

Security Password protection

Firmware upgrade HTTP mode, can be upgraded remotely

Simultaneous connection Up to 10

Audio Yes, 2-way

SD card management

Recording trigger Motion Detection, IP check, Network break down (wire only)

Video format AVI, JPEG

Video playback Yes

6/39

Delete files Yes

Web browsing requirement

OS Windows 2000, XP, 2003, Microsoft IE 6.0 or above

Hardware Suggested Intel-C 2.0G, RAM：512MB, Graphic card：64MB

Minimum

Intel-C 1.6G, RAM：256MB, Graphic card：32MB

III. Product Installation

A. Monitor Setting

i. Right-Click on the desktop. Select “ Properties”.

ii. Change color quality to highest (32bit).

7/39

B. Hardware Installation

i. Connect power adaptor

ii. Connect Ethernet cable to IP Camera

iii. Connect IP Camera to a computer or Local network.

Ｂ-1 I/O Control Instruction

I/O terminal connector – used in application, for e.g., motion detection, event

triggering, alarm notifications. It provides the interface to:

1 Digital Input (GND+Alarm) – An alarm input for connecting devices that can toggle

between an open and closed circuit, for example: PIRs, door/window contacts, glass

break detectors, etc. When a signal is received the state changes and the input becomes

active.

1 Relay output (COM +N.O.) – An output to Relay switch, for example: LEDs, Sirens,

etc

Digital Input

Alarm Input

1. GND (Ground) : Initial state is LOW

2. Alarm : Max. 50mA, 12VDC

Relay Output

1. COM: (Common)

2. N.O. (Normally Open): Max. 1A, 24VDC or 0.5A, 125VAC

8/39

B-2 Relay Connection:

Digital Input connection

Relay Output Connection

GND

ALARM

COM

N.O.

ALARM IN

Relay Out

GND

ALARM

COM

GND

ALARM

COM

Door/Window

Contacts

9/39

B-3 PoE ( Power Over Ethernet)(Optional) 802.3af, 15.4W PoE Switch is recommended

Power over Ethernet (PoE) is a technology that integrates power into a

standard LAN infrastructure. It enables power to be provided to the network

device, such as an IP phone or a network camera, using the same cable as that

used for network connection. It eliminates the need for power outlets at the

camera locations and enables easier application of uninterruptible power

supplies (UPS) to ensure 24 hours a day, 7 days a week operation.

Ethernet

PoE Switch

PoE IP Camera

Ethernet Cable

10/39

C. IP Assignment

i. Use the software, “IP Installer” to assign the IP address of IP Camera.

The software is in the attached software CD.

ii. There are two languages for the IP installer

a. IPInstallerCht.exe：Chinese version

b. IPInstallerEng.exe：English version

iii. There are 3 kinds of IP configuration.

a. Fixed IP (Public IP or Virtual IP)

b. DHCP (Dynamic IP)

c. Dial-up (PPPoE)

iv. Please execute IP Installer

v. For Windows XP SP2 user, the following message box may appear.

Please click “Unblock”.

vi. IP Installer configuration:
