ION Patio mate Manuel utilisateur

Patio Mate

Quickstart Guide English ( 3 – 9 )

Guía de inicio rápido Español ( 10 – 14 )

Guide d'utilisation rapide Français ( 15 – 19 )

Guida rapida Italiano ( 20 – 24 )

Schnellstart-Anleitung Deutsch ( 25 – 29 )

Snelstartgids Nederlands ( 30 – 34 )

Quickstart Guide (English)

Introduction

Box Contents

Patio Mate

Micro-USB Cable

Hanging Strap

Quickstart Guide

Support

For the latest information about this product (system requirements, compatibility

information, etc.) and product registration, visit ionaudio.com.

For safety/warranty information, visit ionaudio.com/warranty.

Trademarks and Licenses

ION Audio is a trademark of ION Audio, LLC, registered in the U.S. and other

countries.

The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any

use of such marks by ION Audio is under license.

All other product or company names are trademarks or registered trademarks of their

respective owners.

Safety Instructions: Read and follow these instructions, heed all warnings, and keep this

document in a safe place for future reference. Clean only with dry cloth. Refer all servicing to

qualified service personnel. Servicing is required when the apparatus has been damaged in any

way, such as power cord or plug is damaged, liquid has been spilled or objects have fallen into the

apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has

been dropped. Connect this product to a power supply only of the type described in these

operating instructions, or as marked on the unit. Keep this product away from direct contact with

liquids. The apparatus shall not be exposed to dripping or splashing and no objects filled with

liquids, such as vases, shall be placed on the apparatus.

Caution: To reduce the risk of electric shock, do not remove any cover. No user-serviceable parts

inside. Refer servicing to qualified service personnel only.

Notice Concerning FCC Regulations: You are cautioned that changes or modifications not

expressly approved by the part responsible for compliance could void the user's authority to

operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures: (a) reorient or relocate the receiving antenna; (b) move this unit; (c) increase the

separation between the equipment and receiver; (d) connect the equipment into an outlet on a

circuit different from that to which the receiver is connected; (e) be sure that all cables are properly

shielded, using a choke or ferrite where appropriate; (f) consult the dealer or an experienced

radio/television technician for help.

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT

CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY

INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE

UNDESIRED OPERATION.

FCC RF Radiation Exposure Statement: This equipment complies with FCC radiation exposure

limits set forth for an uncontrolled environment. End users must follow the specific operating

instructions for satisfying RF exposure compliance. This transmitter must not be co-located or

operating in conjunction with any other antenna or transmitter.

RSS Statement for Canadian models: This device complies with Industry Canada licence-exempt

RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause

interference, and (2) this device must accept any interference, including interference that may

cause undesired operation of the device

ESD / EFT Warning: This unit may contain a microcomputer for signal processing and

control functions. In very rare situations, severe interference, noise from an external

source, or static electricity may cause it to lock up. In the unlikely event that this should

happen, turn off the unit, wait at least five seconds, and then turn it back on again.

Correct Disposal of This Product: This marking indicates that this product should not

be disposed with other household wastes throughout the EU. To prevent possible harm

to the environment or human health from uncontrolled waste disposal, recycle it

responsibly to promote the sustainable reuse of material resources. To return your used

device, please use the return and collection systems or contact the retailer where the

product was purchased. They can take this product for environmentally safe recycling.

his device complies with Industry Canada's licence-exempt RSSs.

IC déclaration:

Cet appareil est conforme aux CNR exemptes de licence d'Industrie Canada . Son fonctionnement est soumis

aux deux conditions suivantes :

( 1 ) Ce dispositif ne peut causer d'interférences ; et

( 2 ) Ce dispositif doit accepter toute interférence , y compris les interférences qui peuvent causer un mauvais

fonctionnement de l'appareil.

Quick Setup

Press the Open button on Patio Mate and fit the base to a pole style umbrella. The

clamp fits 1.0”–1.6” (25–41 mm) diameter umbrella poles. Use the included strap

with a cantilever style umbrella. Pass the strap through the mounts and fold the flap

over the Velcro strips to hang from a cantilever umbrella.

Pole style umbrella

Cantilever style

umbrella

Han

strap

Features

Front Panel

1. Power/Charging LED: The

LED will be solid green

when powered on, flash

red when the battery is

low, and is solid red when

charging. If the unit is

powered on while charging, the LED will turn green when battery charging is

completed. If the unit is powered off while charging, the LED will turn off when

charging is completed.

2. Pairing LED: The LED will blink blue when pairing. The LED is solid blue when

pairing is established.

3. Power: Hold this button for 2 seconds to power on or off. If the unit is on, with

LEDs turned off, and no audio playing, the unit will power off after 5 minutes.

4. Bluetooth: Press and release to disconnect a currently paired Bluetooth device

and start pairing to another device. Patio Mate will pair to the nearest

previously connected Bluetooth device when powered on.

5. Light Control: Press this button to adjust the brightness settings for the

lights: LED high, LED low, and off.

6. –: Press this button to adjust the volume down.

7. +: Press this button to adjust the volume up.

8. Charge/Aux: Open this rubber door that covers the 2 input ports. The micro

USB port charges the unit and the 1/8” (3.5mm) Aux input connects to line-

level devices such as media players, tablets, or CD players.

CHARGE/AUX

345678

Top Panel

1. Clamp: Attach this to an umbrella pole between

1.0”–1.6” (25–41 mm) in diameter.

2. Lights: Provides different levels of brightness set

by the Light Control button.

3. Speakers: Outputs the audio from a paired

Bluetooth device.

4. Open Latch: Press this to open the latch and fit

the clamp on an umbrella pole. To close, press

the latch while inserting it into the locking

mechanism.

5. Strap Mounts: Pass the included strap through

these mounts and secure Patio Mate to a cantilever style umbrella.

Pairing a Bluetooth Device

1. Turn on your Bluetooth device.

2. Power on Patio Mate and it will automatically go into pairing mode to search

for Bluetooth devices.

Note: Voice notifications will be heard when operating Patio Mate (e.g., “Power

On”, “Bluetooth Pairing”, “Bluetooth Connected”). If you wish to disable these,

hold the Light Control button for 4 seconds. To enable voice notifications

again, hold the Light Control button for 4 seconds.

3. Navigate to your Bluetooth device’s setup screen, find “Patio Mate” and

connect.

Note: If your Bluetooth device prompts for a pairing code, enter 0000.

4. Press and release the Bluetooth button to disconnect a paired Bluetooth

device.

5. Repeat step 3 to pair to another Bluetooth device.

Technical Specifications

Output Power 6W Peak (2 x 3W Peak)

Frequency Response 120 Hz – 18 kHz

Bluetooth Profile A2DP

Bluetooth Range * 100 feet (30 m)

Battery Type Built-in rechargeable lithium-ion battery

Battery Battery life (when fully charged):

Up to 9 hours with just the lights on **

Up to 48 hours with only music playing. **

Up to 8 hours with lights and music. **

Recharge time: 6 hours

LCD Brightness 80 lumens (High Setting); 40 lumens (Low Setting)

Power Micro USB port for charging (power adapter sold separately). You may use your

tablet's/smartphone's 5V DC, 500mA USB power adapter.

Water Resistance IPX4

Dimensions

(width x depth x height)

7.87" x 7.87" x 1.57"

20 cm x 20 cm x 40 cm

Weight 1.10 lbs.

0.50 kg

Specifications are subject to change without notice.

* Bluetooth range is affected by walls, obstructions, and movement. For optimal performance, place the product in the

center of the room so it is unobstructed by walls, furniture, etc.

** Battery life may vary based on temperature, age, and volume usage of product.

Audio Output Power

Audio Frequency Response

Power Supply

ionaudio.com

Manual Version 1.1

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

Changes or modifications not expressly approved by the party responsible for compliance could

void the user's authority to operate the equipment

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates, uses

instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one or more of

the following measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and receiver.

-- Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

-- Consult the dealer or an experienced radio/TV technician for help.
