ION Party Rocker Plus Manuel utilisateur

Quickstart Guide English ( 3 – 6 )

Appendix English ( 7 )

Quickstart Guide (English)

Introduction

Box Contents

Party Rocker Plus

Microphone with Cable

1/8” Stereo Aux Cable

Power Cable

Quickstart Guide

Safety & Warranty Manual

Support

For the latest information about this product (system requirements, compatibility information,

etc.) and product registration, visit ionaudio.com.

Rechargeable Batteries

Rechargeable lead-acid batteries are the same type used in automobiles. As with your car

battery, how you use this battery has a significant impact on its lifespan. With proper use and

treatment, a lead-acid battery can last for years. Here are some recommendations for getting

the longest life from the internal battery.

General Usage

Fully charge the battery before using it.

Charge the battery completely after each use.

Storage For best product longevity, do not store at exceedingly hot (greater than

90°F / 32°C) or exceedingly cold (less than 32°F / 0°C) temperatures.

It is acceptable to leave your sound system plugged in. This will not

overcharge the battery.

If you leave the battery level low and do not charge it for 6 months, it may

permanently lose capacity.

Repair If the battery fails to charge, check your fuse near the power cable input. If

your fuse is intact and it still will not charge, contact ION Audio at

ionaudio.com.

Disposal Bring the unit to a recycling center or dispose of in accordance with local

ordinances.

Quick Setup

1. Make sure all items listed under Introduction > Box Contents at the beginning of this

guide are included in the box.

2. Read safety instruction booklet before using the product.

3. For optimal performance, place Party Rocker Plus in the center of the room so it is

unobstructed by walls, furniture, etc.

4. Turn down the Master Volume on the Party Rocker Plus.

5. Turn on Party Rocker Plus.

6. Connect your music player with an audio cable or Bluetooth. (see Connecting with a

Bluetooth Device for more details on this)

7. Adjust the volume on your music player and on Party Rocker Plus as needed.

8. Adjust the Light Mode button on Party Rocker Plus as needed.

9. Turn off Party Rocker Plus when not in use.

Connection Diagram

Items not listed under Introduction > Box Contents are sold separately.

Smartphone,

tablet, etc.

Power

Microphone

Features

Front Panel

1. Auxiliary input: This stereo 1/8” input

can be used to connect a smartphone,

MP3 player, or other audio source.

2. Microphone Inputs with Volume

Control (1/4”): These mono inputs

accept 1/4” inputs such as a microphone,

guitar, or other musical instrument.

3. Power/Charge LED: The LED will be solid green when powered on and solid red when

the unit is charging. If the unit is powered on while charging, the LED will turn green when

battery charging is completed. If the unit is powered off while charging, the LED will turn

off when charging is completed.

4. Bluetooth LED/Disconnect Button: The LED will be lit when a device is paired to Party

Rocker Plus. This LED will not be lit when Party Rocker Plus is first powered on (unless it

was previously paired with a device). Press the button to disconnect a paired Bluetooth

device.

5. All Lights On/Off: Press this button to turn all lights on or off.

6. Light Mode: There are four modes to select from for how the dome lights react to the

music:

•Beat Sync: The dome lights spin and change color to the beat of the music playing.

•Auto: The dome lights spin and change color with a predetermined pattern regardless

of the beat of the music playing.

•Fade: Each color fades in and out for about one second before changing to the next

color.

•Freeze: All colors remain on and unmoving until a new mode is selected.

•Off: The dome lights turn off.

7. Light Buttons: Use these buttons to turn each color in the Dome on or off–Red, Green,

Blue, White, Pink, and Orange.

8. Echo: Use this knob to add or remove an echo effect when using a microphone.

9. Master Volume Control: This adjusts the speaker’s main mix volume, which includes

Microphone Inputs, Auxiliary Input, and the audio of a paired Bluetooth device.

Rear Panel

1. Power On/Off Switch: Turns Party

Rocker Plus on or off.

2. Power Cable Input (IEC): Insert the

included power cable here to power the

unit.

3. Dome: The dome light can spin and react

to the music playing (depending on the

Light Mode that is selected).

Warning: Do not look directly into the dome light. Do not sit, stand, or apply pressure on

the dome light.

Connecting with a Bluetooth Device

1. Turn on your Bluetooth device.

2. Power on Party Rocker Plus and it will automatically go into pairing mode to search for

Bluetooth devices. You will know you are in pairing mode when the Bluetooth LED is off.

3. If your Bluetooth device is not able to pair to Party Rocker Plus, press the Bluetooth

Disconnect button on the unit to break previous Bluetooth connections and reset the

Bluetooth module.

4. Navigate to your Bluetooth device’s setup screen, find Party Rocker Plus and connect.

Note: If your Bluetooth device prompts for a pairing code, enter 0000.

5. Bluetooth LED will light up solid when it is “paired.”

Note: If you experience trouble pairing or playing music, update your device's OS.

6. To disconnect pairing, press the Bluetooth Disconnect button on Party Rocker Plus.

7. To connect to another Bluetooth device, repeat steps 3-4.

Note: Maximum range will be achieved when using devices with Bluetooth 4.0.

Troubleshooting

If the sound is distorted: Try lowering the volume control of your sound source or musical

instrument. Also, try to reduce the overall volume of Party Rocker Plus.

If there is too much bass: Try adjusting the tone or EQ control on your sound source to lower

the bass level. This will allow you to play the music louder before clipping (distortion) occurs.

If there is a high-pitched whistling noise when using microphones: This is probably

feedback. Point the microphone away from the speaker.

If you can’t hear the microphone over the music volume: Turn down the music volume

from your source.

Appendix (English)

Technical Specifications

Output Power 50 W (peak)

Drivers

6” woofer

1” tweeter

Lights 6 3 W LEDs (1 per color–Red, Green, Blue, White, Pink, and

Orange)

Supported Bluetooth Profile A2DP

Bluetooth Range Up to 100 feet / 30.5 meters *

Microphone Type Dynamic microphone recommended (included)

Battery 12 V, 5 Ah SLA

Battery Life

Up to 50 hours **

Recharge time: 10 hours

Power Input voltage: 100-240 V AC, 50/60 Hz

Dimensions

(width x depth x height)

12.25" x 9.4" x 15.1"

311 mm x 239 mm x 384 mm

Specifications are subject to change without notice.

* Bluetooth range is affected by walls, obstructions, and movement. For optimal performance,

place the product in the center of the room so it is unobstructed by walls, furniture, etc.

** Battery life may vary based on temperature, age, and volume usage of product.

Trademarks & Licenses

ION Audio is a trademark of ION Audio, LLC, registered in the U.S. and other countries.

The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such

marks by ION Audio is under license.

All other product or company names are trademarks or registered trademarks of their

respective owners.

ionaudio.com

Compliance Manual Version 1.0
