IOGear GUH284R Manuel utilisateur
Quick Start Guide (GUH284R)
USB 2.0 Hub & Card Reader
6-Port Hub & 12-in-4 Memory Card Reader/Writer
®
Welcome
Thank you for purchasing IOGEAR®’s USB 2.0 Hub and Card Reader/Writer™
model number GUH248R, one of the fastest Hi-Speed USB 2.0 hub and card
reader/writer on the market. IOGEAR® only manufactures high quality connectiv-
ity devices so we are sure you will be satisfied with your purchase.
©2004 IOGEAR. All Rights Reserved. PKG-30115
IOGEAR, the IOGEAR logo, are trademarks or registered trademarks of IOGEAR, Inc.
Microsoft and Windows are registered trademarks of Microsoft Corporation. IBM is a registered
trademark of International Business Machines, Inc. Macintosh, G3/G4 and iMac are registered
trademarks of Apple Computer, Inc. All other brand and product names are trademarks or
registered trademarks of their respective holders. IOGEAR makes no warranty of any kind
with regards to the information presented in this document. All information furnished here is for
informational purposes only and is subject to change without notice. IOGEAR, Inc. assumes no
responsibility for any inaccuracies or errors that may appear in this document.
Package Contents......................................………………………………………...........
Overview ................................. ............................................……………………..........
Features ...............................................................................………………….............
Requirements .............................................................................................................
Introductions ...............................................................................................................
Software Installation....................................................................................................
Hardware Installtation .................................................................................................
Additional Considerations...........................................................................................
Specifications .............................................................................................................
Radio & TV interferences Statement ..........................................................................
Limited Warranty ........................................................................................................
Table of Contents
2
3
4
5
6
7
8
10
11
12
13
Package Contents
2
The complete Universal USB 2.0 Hub Reader/Writer™ package consists of:
1 Universal USB 2.0 Hub Reader/Writer™ model GUH248R
1 Power Adapter
1 USB Cable (Type A - miniB) 6 feet
1 Quick Start Guide
1 Warranty/ Registration Card
If any of the items are missing or damaged please contact your dealer immediately.
3
Overview
The USB 2.0 Hub & Card Reader bridges the gap between your computer and devices
like digital cameras, digital camcorders, portable MP3 players, as well as peripherals
such as scanners, external hard drives and more. Combining six high-speed USB 2,0
ports with a 15-in-1 card reader, this elegant system delivers lightening-fast connectivity
as well as file transfer capabilities. Just insert your memory card and transfer data at
480 Mbps.
Plus, you can insert up to four different cards and transfer data between them! Move
digital photos from a Compact Flash card to a Memory Stick that you can insert into
your TV. Copy snapshots from one camera to another. The uses are endless!
4
Features
·Six (6) USB ports available for you to add USB devices
·USB 2.0 interface, USB 1.1 compliant
·Supports the following Memory Cards:
o CompactFlash I / II
o CompactFlash USB
o CompactFlash Ultra
o Micro Drives
o Memory Stick
o Memory Stick Switch
o Memory Stick Pro
o Magic Gate Memory Stick
o Magic Gate Memory Stick Duo (Requires Duo Adapter)
o Multimedia Card (MMC)
o SecureDigital (SD)
o Smart Media
·LED power indicator/data indicator light
·Remarkable high-speed digital image and data transfer to computer.
·Plug & Play and hot-swappable
5
Requirements
For MAC Users
• Mac OS 8.6 to 9.x *
• Mac OS X
• Available Hi-Speed USB 2.0 Port
For PC Users
• PC Compatible, 200MHz or Greater
• Windows® 98SE, 2000, ME, XP
• Minimum 64MB RAM
• Available Hi-Speed USB 2.0 Port**
*Operates as USB 1.1 device
**Will operate at 1.1 speeds when used with USB 1.1 port
6
Pictorial Introduction
1. 1xCompactFlash
2. 1xSmart Media
3. 1xMemory Stick
4. 1xSecure Digital/MultiMediaCard
If the USB 2.0 Hub and Card Reader/
Writer™ is laid down horizontally, all the
cards should face up (with the logo on
top)except the SD card. The SD card is
the only one that should face down
(with the logo on the bottom).
Important: This software installation is not required for Mac OS 10.x, Windows ME,
Windows 2000 or Windows XP Operating Systems. If you have one of these Operating
Systems, please skip the software installation and go to Hardware Installation in page 8.
Step 1
Download the software from the internet
at http://www.iogear.com then click on
“Support”, on the drop-down menu. Then
click on “Drivers/Manuals”; it will give you a
new page for “Drivers/Manuals”. Within the
new drop-down driver list menu click on
“select a driver”, and then select our
product GUH248R. Select your Operating
System and save the files to your hard
drive.
Step 2
Double click on the file “Setup.exe”, follow
the instruction on the screen.
Step 3
You will get a message that the driver has
been installed successfully. Close all of the
open windows, and then shutdown your
computer.
7
Software Installation
Hardware installation of Universal USB 2.0 Hub Reader/Writer
(PC and Mac Users)
78
Hardware Installation
Note: Before you begin, please make sure
that your computer has been turned off.
Step1.
Connect the power adapter to the power
supply and the other end to the USB 2.0
Hub Reader/Writer™
Step2.
Plug the Hi-Speed USB 2.0 Cable (Type
mini-B connector) into the USB 2.0 Hub
Reader/Writer™.
Step3.
Plug the Hi-Speed USB 2.0 Cable (Type A
connector) into your computer’s USB 2.0 or
USB 1.1 port.
Step4
Turn on your computer.
