User Manual
327 Installation Guide Video
327 Product Video
Product Video InformationProduct Video Information
Product StoryProduct Story
Serious airow. Serious value
The iconic 3-Series maintains its
high-quality stature and modern aesthetic design.
The InWin team presents the 327, a condensed bit of
craftsmanship to meet the needs of mATX builds.
Model 327
Model Number IW-CS-327BLK-3AL120
Color Black
Case Type Mini Tower
Materials Tempered Glass, SECC
M/B Compatibility Micro-ATX, Mini-ITX
Expansion Slots 4 x PCI-E
Maximum Compatibility GPU Length: 290 - 310 mm
CPU Heatsink Height: 160 mm
I/O Ports
1 x USB 3.2 Gen 2x2 Type-C
2 x USB 3.2 Gen 1
HD Audio
Internal Drive Bays 1 x 3.5" / 2.5"
2 x 2.5"
Thermal Solution
Compatibility
Air Cooling Fans:
Front: 2 x 120 mm
Rear: 1 x 120 mm
Bottom: 2 x 120 mm
(3 InWin Luna AL120 Fans Included)
Water Cooling Radiator:
Front: 1 x 240 mm
Rear: 1 x 120 mm
Power Supply Compatibility PSII: ATX12V
- Length up to 160 mm
Product Dimensions
(L x W x H)
391.5 x 188 x 381 mm
15.4 x 7.4 x 15"
Package Dimension
(L x W x H)
458 x 272 x 450 mm
18 x 10.7 x 17.7"
Net Weight 7.0 kg / 15.43 lbs
Gross Weight 7.9 kg / 17.42 lbs
* InWin's products comply with RoHS regulations.
* Specications may vary based on dierent regions.
SpecicationsSpecications
InWin 327 Chassis
Model Luna AL120
Quantity Included Single Pack Triple Pack
Model Number IW-FN-AL120-1PK IW-FN-AL120-3PK
Colors Black
Fan Size 120 x 120 x 25 mm
Materials PC, PBT
Rated Voltage DC 12V
Rated Power 3.96W
Rated Current 0.33A
ADD RGB Rated Voltage DC 5V
ADD RGB Rated Power 1.5W
ADD RGB Rated Current 0.3A
Speed Mode PWM 600-1800 +/-10% RPM
Air Flow 82.96 CFM
Air Pressure 2.31 mm / H2O
LED Addressable RGB
Connector (Fan to Fan) Non-Modular Cables
Connector to M/B 4-Pin (PWM, 12V), 3-Pin (ARGB, 5V)
Noise Level 25 dB(A) (Normal)
Bearing Type Long Lifespan Sleeve Bearing
Net Weight 133 g 399 g
Gross Weight 169 g 484 g
Package Dimensions
(L x W x H)
185 x125x30 mm
7.3 x 4.9 x 1.2”
185 x 125 x 82 mm
7.3 x 4.9 x 3.2”
Warranty 2 Years
* InWin's products comply with RoHS regulations.
* Specications may vary based on dierent regions.
InWin Luna AL120 Fans
Hexagon Head Screws x 15 Cable Ties x 5
2.5” SSD Screws x 12
Water-cooling System Washer x 8
Motherboard Stand-os x 4 Graphics Card Holder x 1
Motherboard Stand-o Socket x 1
QR Code Card x 1
Package ContentsPackage Contents
Accessories Bag
Case StructureCase Structure
1
2
3
4
5
1Power Button
2USB 3.2 Gen 1
3Speaker
4Microphone
5USB 3.2 Gen 2x2 Type-C
Case StructureCase Structure
63.5" / 2.5" Drive Bays
72.5" Drive Bays
8Front Fans / Radiator Mounting Area
(2 InWin Luna AL120 Fans Pre-Installed)
9Bottom Fans Mounting Area
10 Rear Fan / Radiator Mounting Area
(1 InWin Luna AL120 Fans Pre-Installed)
11 Motherboard Mounting Area
12 CPU Cooler Installation Cut-Out Hole
13 PCI-E Expansion Slot
14 Graphic Cards Holder Mounting Area
15 Power Supply Mounting Area
16 Shock-Proof Stands
17 Anti-Dust Filters
18 Punch-Out Cable Routing Holes
7
8
9
10
11
12
15
16
17
18
13 14
6
Cable ConnectionCable Connection
I/O Wire
HD Audio Header
USB 3.2 Gen 1
USB 3.2 Gen 2x2 Type-C
1
2
3
4
5
6
7
8
9
10
19
18
17
16
15
14
13
12
11
PORT2_L
PORT2_R
PORT1_R
PORT1_L
BLUE
PURPLE
YELLOW
10
8
6
4
2
KEY
WHITE
BLACK
9
7
5
3
1
POWER SW
■ Notices
1. Please follow the user manual for installation guidelines.
2. When installing computer components, please use the antistatic precautions
to prevent ESD (electrostatic discharge) damage. This can cause injury to the
installer and/or damage to the machine. Incorrect installation may burn your
motherboard and other system components.
3. To avoid any damages, please do not use this product for any other purpose
than its intended use.
4. Any modications may damage the product.
5. Please remove all internal devices before shipping or moving.
(Including power supply, hard drives, CD-ROM, motherboard and CPU, etc)
6. When storing the case, please keep this product away from high temperatures.
Keep away from machines such as heaters that might cause high
temperatures.
7. For more technical support, please visit the InWin Forum
at https://forum.in-win.com/
■ Warranty
1. For more detailed warranty information, please visit the InWin retail website
at www.in-win.com
2. The actual product is subject to change without prior notice.
In Win Development Inc. reserves the right to make any nal modications.
Notices and WarrantyNotices and Warranty
