InWin S-Frame Manuel utilisateur
OPEN-AIR CHASSIS
InstallationInstallation
GuideGuide
Case Structure
Power Button
Reset Button
USB 3.0 Port
Audio Ports (Earphone and Microphone)
HDD LED Indicator
PCI-E Expansion Slot
Motherboard Mounting Area
120mm Bottom Fan Mounting Area
Limited Edition Number
Adjustable Stand
3.5”/2.5” Drive Bay
Power Supply Mounting Area
Tempered Glass Side Panel
Thumb Screw
1
2
3
4
5
6
7
8
9
10
11
12
13
14
11 12
6
7
8
9
11 12
68
9
10
10
13 14
1
2
3
4
5
OPEN-AIR CHASSIS
InstallationInstallation
GuideGuide
Installation Guide
Opening the Chassis
Loosen the thumb screws, and dismantle the tempered glass side panel
Motherboard Installation Add-on Card PCI-E Installation
3.5” or 2.5” Drive Bays Installation
a. Loosen the thumb screws, and remove 3.5”/2.5”
HDD bracket
b. Install the 3.5” or 2.5” HDD in proper location
and secure it with screws
Remove the fan bracket and install the fans
Bottom Fan Installation
* Please follow the related chapters to assemble
* Please use original accessories to avoid damage the product.
Parts Required
Hexagon head screws
Parts Required
2.5” HDD Screws
3.5” HDD Screws
Parts Required
Hexagon head screws
Motherboard standoffs
Motherboard standoff socket
a. Loosen the thumb screws, and remove power supply bracket
Power Supply Installation
OPEN-AIR CHASSIS
InstallationInstallation
GuideGuide
Installation Guide
Cable Installation
a.USB 3.0 to USB 2.0 cable
Connect to the USB 3.0 cable
Connect to the motherboard
b.8Pin to 4+4pin power supply
extension cable
Connect to the motherboard
Connect to the HDD
Connect to the HDD Connect to the power supply
Connect to the power supply Connect to the motherboard
c.SATA connector d.SATA power supply extension cable
Adjustable Stand Completing Installation
Parts Required:
Thumb Screw
b. Install the power supply in proper location and secure it with screws
Parts Required:
Cable clamp
Cable tie
Hexagon head screws
c. Power cord raceway
